USER GUIDE
Extending SafeGate - Hardware Mount
Inside Opening
Outside Opening
Height
Min 25.6" (65 cm)
Min 22.4" (57 cm)
29.9" (76 cm)
Max 40.9" (104 cm)
Max 37.8" (96 cm)
IMPORTANT:
Qdos wants to keep your children safe
and for that we need you to do your part by carefully
reading and following the instructions below. Please read
through the instructions before starting the installation.
For installation videos and FAQ go to: QdosSafety.com
Advertisement
Table of Contents
Related Manuals for Qdos Extending SafeGate
Summary of Contents for Qdos Extending SafeGate
- Page 1 Max 40.9" (104 cm) Max 37.8" (96 cm) IMPORTANT: Qdos wants to keep your children safe and for that we need you to do your part by carefully reading and following the instructions below. Please read through the instructions before starting the installation.
-
Page 2: Maintenance And Cleaning
• ALWAYS install and use gates as directed using all required parts. Qdos will either repair, or at its option replace, free of • Intended for use with children from 6 months up charge, any parts necessary to correct any defect in to 24 months of age. -
Page 3: Installation
OPENING SIZE ANGLE MOUNTING The Extending SafeGate will fit inside openings from Besides the normal perpendicular 25.6″-40.9″ (65-104 cm). The size of the gate is adjustable mounting, the Extending SafeGate can by how you clamp the two gate sections together as also be mounted at any angle within shown below. -
Page 4: Parts List
PARTS LIST: 1x Gate Section with 1x Gate Section with 2x Hinge Brackets 2x Top Covers 2x One-Way Stop Two Locking Spindles Two Hinge Spindles for Hinges 2x Clamping 2x Top Covers for 2x Bottom Covers 1x Double Sided 1x Installation Installation Level Brackets Clamping Bracket... - Page 5 Determine Installation Position Your gate can be installed in two different ways. Bottom IMPORTANT: REGARDING THE INCLUDED MOUNTING SCREWS! Inside an opening in Before marking where to attach the gate, make sure you between two surfaces In front of an opening have chosen a solid surface for mounting the gate to.
- Page 6 Step 2 If using at the top of stairs install gate a minimum of 1" (2.5 cm) from the top step! Before marking the holes for the hinges, using the Hinge side of the Installation Template(Side B), decide which way is the best direction for the gate to swing.
- Page 7 If not, remove to adjust the length of one must use one or two Qdos Baseboard Kits to create a of the spindles and test until horizontal. smooth vertical surface to mount the gate to. Do not mount the gate over baseboards.
-
Page 8: Gate Operation
Step 12 With the gate in the locked position and adjusted properly, hand tighten all four Locking Nuts and finally secure them firmly using the Installation Wrench. The gate is now installed and ready to be used. GATE OPERATION To open the gate with one hand, push down on the release latch on the Top Lock with your thumb, while simultaneously lifting the gate. - Page 9 Distributed by Regal Lager, Inc. Kennesaw, GA 30144 USA 1-800-593-5522 • www.QdosSafety.com support@qdos.zendesk.com ©2019 Qdos All rights reserved. Qdos is a trademark of Regal Lager, Inc. Made in China 06/19...
