USER GUIDE
Extending SafeGate - Hardware Mount
Height 30" (76 cm)
Minimum Opening 25" (63 cm)
Maximum Opening 41" (104 cm)
IMPORTANT:
Qdos wants to keep your children safe
and for that we need you to do your part by carefully
reading and following the instructions below. Please read
through the instructions before starting the installation.
For installation videos and FAQ go to: QdosSafety.com
