Stair
Mounting Kit
Installation Guide
Installing safety gates in modern homes can be very
challenging, especially for stairs.
The Stair Mounting Kit will allow you to mount gates to
most square and round banisters, as well as between
wood or wrought iron spindles in stairs or railings,
without the need to screw into them. It will create an
even and secure surface to help you mount the gate
properly.
If you have banisters on both sides you will need one
Stair Mounting Kit on each side.
Important:
Qdos wants to keep your children safe and for that
we need you to do your part by carefully reading and
following the instructions below.
Please read through the
instructions before starting the installation.
For installation videos and FAQs go to: QdosSafety.com
https://youtu.be/i5wehUSLj_E
Advertisement
Related Manuals for Qdos Stair Mounting Kit
Summary of Contents for Qdos Stair Mounting Kit
- Page 1 Installing safety gates in modern homes can be very challenging, especially for stairs. The Stair Mounting Kit will allow you to mount gates to most square and round banisters, as well as between wood or wrought iron spindles in stairs or railings, without the need to screw into them.
- Page 2 Double Check Opening Size Brackets 2.8″-4.5″ (71-115 mm) Measure the opening and confirm that your gate will fit Use Long Mounting in the opening, including the Stair Mounting Kit that will Brackets add 1.5″ (3.8 cm) to each side where it is used.
- Page 3 Installation on SQUARE Post/Banister Step 4 Thread the Mounting Strap through For Posts 2.4″-4.2″ (62 - 107 mm) the Long Mounting Bracket with the smooth side of the Mounting Strap Step 1 towards the nut holding the Long Carefully loosen the screws on the Mounting Bracket together.
- Page 4 Mounting Kit. Repeat for Bottom Mouting Bracket. Step 9 Hand tighten the Tightening Nut Install gate on the Stair Mounting Kit, following the gate as much as possible, then use the instructions. Tightening Tool to tighten the strap around the post.
- Page 5 Installation on ROUND Post/Banister Step 4 Thread the Mounting Strap through the Mounting Bracket with the smooth side of the Mounting Strap covering the Step 1 nut that holds the Depending on the thickness of Mounting Bracket the round post/banister carefully together.
- Page 6 IMPORTANT: The Silicone Friction Tape is absolutely After cutting, use the Tightening Tool necessary to hold the Stair Mounting Kit securely in place to loosen Tightening Nuts until the on round banisters. cut end of the straps are protected inside the Tightening Nut.
- Page 7 Installation In Between Two Spindles Step 4 Thread the Mounting Strap Step 1 through the Long Carefully loosen Mounting Bracket the screws on the with smooth side of two Long Mounting the Mounting Strap Brackets by using a towards the nut Phillips screwdriver that holds the Long until it allows...
- Page 8 Mounting Kit. the strap. Step 9 Install gate on the Stair Mounting Kit, following the gate instructions. Hand tighten both Tightening Nuts as much as possible, then use the Tightening Tool to tighten the straps around the spindles.
- Page 9 Distributed by Regal Lager, Inc. Kennesaw, GA 30144 USA 1-800-593-5522 • www.QdosSafety.com support@qdos.zendesk.com ©2020 Qdos All rights reserved. Qdos is a trademark of Regal Lager, Inc. Made in China 06/2020...
