- Page 1 UG85 LoRaWAN Gateway Quick Start Guide Ursalink Technology Co., Ltd.
-
Page 2: Related Documents
Thank you for choosing Ursalink UG85 LoRaWAN Gateway. This guide teaches you how to install the UG85 and how to log in the web GUI to configure the device. Once you complete the installation, refer to the Ursalink UG85 User Guide for instructions on how to perform configurations on the device. -
Page 3: Package Contents
Ursalink UG85 Quick Start Guide 1. Packing List Before you begin to install the UG85 LoRaWAN Gateway, please check the package contents to verify that you have received the items below. 1.1 Package Contents 1 × Stubby LoRa 1 × UG85 1 ×... -
Page 4: Hardware Introduction
Ursalink UG85 Quick Start Guide 2. Hardware Introduction 2.1 Overview Front Panel UG85 Front Panel WIFI/LTE Antenna GPS Antenna LoRa Antenna LED Indicator Area POWER: Power Indicator SYSTEM: Status Indicator LORA：LoRa Indicator WIFI: WIFI Indicator LTE: Cellular Status Indicator LAN: Ethernet Port Status Indicator Serial Port &... -
Page 5: Led Indicators
Ursalink UG85 Quick Start Guide 2.3 Pinouts RS232 Description Digital Output Digital Input Ground Common Ground Receive Data Transmit Data Description Positive Negative 2.4 LED Indicators Indication Status Description The power is switched on POWER Power Status The power is switched off... -
Page 6: Reset Button
Ursalink UG85 Quick Start Guide 2.5 Reset Button Description Function SYSTEM LED Action Blinking Press and hold the reset button for about 5-15 seconds. Reboot Static Green Release the button and wait for system to reboot. Blinking Press and hold the reset button for more than 15 seconds. -
Page 7: Hardware Installation
Ursalink UG85 Quick Start Guide 3. Hardware Installation Environmental Requirements - Power Input: 9-48 VDC - Power Consumption: Typical 3.3W (Max 6.4 W) - Operating Temperature: -40°C to 70°C (-40°F -158°F) - Relative Humidity: 0% to 95% (non-condensing) at 25°C/77°F 3.1 SIM Card Installation... -
Page 8: Mount The Gateway
Ursalink UG85 Quick Start Guide 3.3 Connect the UG85 to a Computer 3.4 Mount the gateway The gateway can be placed on a desktop or mounted to a wall or a DIN rail. 3.4.1 Wall Mounting (Measured in mm) Use 4 pcs of M3 × 6 flat head Phillips screws to fix the gateway on the wall. -
Page 9: Power Supply Installation
Ursalink UG85 Quick Start Guide 3.5 Power Supply Installation A. Take out the terminal from the gateway and unscrew the bolt on terminal. B. Screw down the bolt after inserting power cable into the terminal. Connecting the Power Cable Color... -
Page 10: Getting Started
4. PC Configuration for UG85 Web GUI Please connect PC to GE port of UG85 directly. PC can obtain an IP address, or you can configure a static IP address manually. The following steps are based on Windows 10 operating system for your reference. - Page 11 Ursalink UG85 Quick Start Guide Method 2: click “Use the Double Click “Internet Method 1: click “Obtain an IP ⑤ ⑥ following IP address” to assign a Protocol Version 4 address automatically”; static IP manually within the (TCP/IPv4)” to configure IP same subnet of the gateway.
-
Page 12: Log In The Gateway
5. Access to UG85 Web GUI for Cellular Connection This chapter explains how to log in UG85 Web GUI, and connect the gateway to cellular network. Ursalink UG85 provides web-based configuration interface for management. If this is the first time you configure the gateway, please use the default settings below: IP Address: 192.168.1.1... -
Page 13: Configure The Cellular Connection
Ursalink UG85 Quick Start Guide D. After you log in the Web GUI, you can view system information and perform configuration of the gateway. 5.2 Configure the Cellular Connection Take inserting SIM card into SIM1 slot as an example; please refer to the following detailed operations. - Page 14 If you select “3G First”, “3G Only”, “2G First” or “2G Only”, you should manually configure APN, Username, Password, and Access Number. UG85 have two cellular interfaces, named SIM1 & SIM2. Only one cellular interface is active at one time. If both cellular interfaces are enabled, SIM1 interface takes precedence by default.
- Page 15 5.4 Check if Network Works Properly by Browser on PC Open your preferred browser on PC, then type any available web address into address bar and see if it is able to visit Internet via UG85. www.ursalink.com...
-
Page 16: Node Parameters
Ursalink UG85 Quick Start Guide 6. Packet Forwarder Testing 6.1 Node Parameters Channel Plan AS923 Frequency 923.4MHZ, 923.2MHZ Join Type OTAA Device EUI 60C5A8FFFE0003F9 Application EUI 70B3D57ED0007AC2 App Key 328F2A3F5BA8D0B236459CF06D0512B5 6.2 Configure The Things Network A. Gateway Configuration Gateway EUI... -
Page 17: Packet Forwarder Configuration
Ursalink UG85 Quick Start Guide 6.3 Packet Forwarder Configuration A. Click “LoRaWAN” → “Packet Forwarder” → “General” to configure the general setting. B. Click “Radios” to configure the center frequency and channels. www.ursalink.com... - Page 18 Ursalink UG85 Quick Start Guide C. Click “Traffic” to view the data communication of UG85. 6.4 Check Data Transmission on The Things Network A. Click “Gateways”, you can check the Gateways status. B. Click “Applications”and select the Applications, then go to “Data”, you can find the data from the Node.
- Page 19 Ursalink UG85 Quick Start Guide www.ursalink.com...
-
Page 20: Network Server Configuration
Ursalink UG85 Quick Start Guide 7. Network Server Testing Note that only gateway with activated built-in Network Server version supports this function. 7.1 Node Parameters Channel Plan AS923 Frequency 923.4MHZ, 923.2MHZ Join Type OTAA Device EUI 60C5A8FFFE0003F9 Application EUI 70B3D57ED0007AC2... - Page 21 Ursalink UG85 Quick Start Guide C. Add a new Profiles for the device. www.ursalink.com...
- Page 22 Ursalink UG85 Quick Start Guide D. Add device 7.3 Package Forwarder Configuration Click “LoRaWAN” → “Packet Forwarder” → “Radios” to configure the center frequency and channels Note that node frequency needs to be included in the channels frequency. www.ursalink.com...
- Page 23 Ursalink UG85 Quick Start Guide 7.4 Check the Packets Click “LoRaWAN” → “Network Server” → “Packets” to check the packets from the node on network server. [END] www.ursalink.com...
