LCD Projector
MC-AW3506/MC-AW3006
MC-AX3506/MC-AX3006
User's Manual (detailed)
Operating Guide – Technical
Supported signals for COMPUTER IN
Resolution (H x V)
720 x 400
640 x 480
800 x 600
832 x 624
1024 x 768
1152 x 864
1280 x 768
1280 x 800
1280 x 1024
1366 x 768
1440 x 900
1600 x 900
1680 x 1050
1600 x 1200
1920 x 1080
Signal mode
TEXT
VGA (60Hz)
VGA (72Hz)
VGA (75Hz)
VGA (85Hz)
SVGA (56Hz)
SVGA (60Hz)
SVGA (72Hz)
SVGA (75Hz)
SVGA (85Hz)
Mac 16" mode
XGA (60Hz)
XGA (70Hz)
XGA (75Hz)
XGA (85Hz)
1152 x 864 (75Hz)
W-XGA (60Hz)
1280 x 800 (60Hz)
SXGA (60Hz)
SXGA (75Hz)
SXGA (85Hz)
WXGA (60Hz)
WXGA+ (60Hz)
WXGA++ (60Hz)
WSXGA+ (60Hz)
UXGA (60Hz)
Full HD (60Hz)
H. frequency
V. frequency
(kHz)
37.9
31.5
37.9
37.5
43.3
35.2
37.9
48.1
46.9
53.7
49.7
48.4
56.5
60
68.7
67.5
47.7
49.7
64
80
91.1
47.7
55.9
60
65.3
75
67.5
1
Rating
(Hz)
85
VESA
59.9
VESA
72.8
VESA
75
VESA
85
VESA
56.3
VESA
60.3
VESA
72.2
VESA
75
VESA
85.1
VESA
74.5
60
VESA
70.1
VESA
75
VESA
85
VESA
75
VESA
60
VESA
60
VESA
60
VESA
75
VESA
85
VESA
59.8
VESA
59.9
VESA
60
VESA
60
VESA
60
VESA
60
VESA
QM00132-1
