LCD Projector

MC-WU5505/MC-WU5501/MC-WX5505
MC-WX5501/MC-X5555/MC-X5551
User's Manual (detailed)
Operating Guide – Technical
Supported signals for COMPUTER IN
Resolution (H x V)
720 x 400
640 x 480
800 x 600
832 x 624
1024 x 768
1152 x 864
1280 x 768
1280 x 800
1280 x 1024
*1) 1366 x 768
1440 x 900
1600 x 900
*2) 1400 x 1050
*3) 1680 x 1050
1600 x 1200
1920 x 1080
*4) 1920 x 1200
*1) Supported except for [WUXGA Model]
*3) Only for [WXGA Model], [WUXGA Model]
(continued on next page)
Signal mode
TEXT
VGA (60Hz)
VGA (72Hz)
VGA (75Hz)
VGA (85Hz)
SVGA (56Hz)
SVGA (60Hz)
SVGA (72Hz)
SVGA (75Hz)
SVGA (85Hz)
Mac 16" mode
XGA (60Hz)
XGA (70Hz)
XGA (75Hz)
XGA (85Hz)
1152 x 864 (75Hz)
W-XGA (60Hz)
1280 x 800 (60Hz)
SXGA (60Hz)
SXGA (75Hz)
SXGA (85Hz)
WXGA (60Hz)
WXGA+ (60Hz)
WXGA++ (60Hz)
SXGA+ (60Hz)
WSXGA+ (60Hz)
UXGA (60Hz)
Full HD (60Hz)
W-UXGA (60Hz)
Reduced Blanking
H. frequency
V. frequency
(kHz)
37.9
31.5
37.9
37.5
43.3
35.2
37.9
48.1
46.9
53.7
49.7
48.4
56.5
60
68.7
67.5
47.7
49.7
64
80
91.1
47.7
55.9
60
65.2
65.3
75
67.5
74
*2) Only for [XGA Model]
*4) Only for [WUXGA Model]
1
Rating
(Hz)
85
VESA
59.9
VESA
72.8
VESA
75
VESA
85
VESA
56.3
VESA
60.3
VESA
72.2
VESA
75
VESA
85.1
VESA
74.5
60
VESA
70.1
VESA
75
VESA
85
VESA
75
VESA
60
VESA
60
VESA
60
VESA
75
VESA
85
VESA
59.8
VESA
59.9
VESA
60
VESA
60
VESA
60
VESA
60
VESA
60
VESA
60
VESA
QM00112-1
