Contents SAFETY PRECAUTIONS ....................4 IMPORTANT NOTE TO THE OWNER IMPORTANT NOTE TO THE SERVICER........4 TRANSPORTATION DAMAGE .............4 UNPACKING THE UNIT..............4 OPERATING INSTRUCTIONS ............4 INSTALLATION INSTRUCTIONS ..........5 WIRING ..................8 AIR CONDITIONER FEATURES............9 AUXILIARY CONTROLS-DIP SWITCHES........12 AIR CONDITIONER FEATURES..........13 ADDITIONAL THINGS YOU SHOULD KNOW......17 WARRANTY..................18 This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction...
Page 3
EXPLANATION OF SYMBOLS Indicates a hazardous situation that, if not avoided, will DANGER result in death or serious injury. Indicates a hazardous situation that, if not avoided, could WARNING result in death or serious injury. Indicates a hazardous situation that, if not avoided, may CAUTION result in minor or moderate injury.
To prevent injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring of instructions may cause harm or damage. The seriousness is classified by the following indications. WARNING This symbol indicates the possibility of death or serious injury. CAUTION This symbol indicates the possibility of injury or damage to property.
Page 5
CAUTION When the air filter is to be Do not clean the air conditioner Ventilate the room well when used metal with water. together with a stove, etc. parts of the unit. j n i Water may enter the unit and degrade the insulation.
Page 6
NOTICE Operation of Current Device Please contact Customer Service. with a new cord - please contact Customer Service.
IMPORTANT NOTE TO THE OWNER OPERATING INSTRUCTIONS This equipment is to be serviced by professionally trained Check the data specification plate and ensure the proper personnel only. If this equipment is improperly installed, voltage and current rating for the type of power plug on the adjusted or altered by an unqualified person, a safety unit is available.
CHASSIS INSTALLATION WARNING 1. Remove front grille. See Figure A. To prevent electrical shock, property damage, personal injury, or death, do not remove grounding prong from plug. Follow Lift up on all operating instructions. Filter Handle INSTALLATION INSTRUCTIONS To ensure that the unit operates safely and efficiently, it must be installed, operated, and maintained according to these installation and operating instructions and all local codes and ordinances, or, in their absence, with the latest...
Page 9
Locking Plate MOUNTING SCREW GROUND WIRE Figure 3 3. Remove shipping pads inside air conditioner next to Figure C compressor. (See Figure B.) 6. If outlet is on the left side of the unit. route power cord as shown in Figure D. Remove Power shipping...
Page 10
To replace front grille: Grille EXHAUST AIR VENT Figure 4 AIR DIRECTION: Horizontal louvers on the front grille let you control the Hook the tabs on the front grille even with the tabs on air direction up and down. the case and snap into place. Replace the screws and filter.
Remove the front grille to adjust the vertical louvers WIRING side-to-side to direct the air left or right. Before wiring the unit, please review the following warnings and cautions. WARNING To avoid the risk of electrical shock, personal injury or death, do not service this unit without first opening all disconnects and/or removing the unit cord set plug from the wall outlet.
AIR CONDITIONER Before you begin, thoroughly familiarize yourself with the control panel and remote as FEATURES shown below and all its functions. Then follow the symbol for the functions you desire. The unit can be controlled by the touch pad alone or with the remote. LOWERS TEMPERATURE DISPLAYS...
Page 13
AIR CONDITIONER FEA TURES Notice: • When power is connected (stand by condition), you can + / - button operate the air conditioner through the remote control. • Pressing “+” or “-” button once will increase or decrease • When unit is on, each time you press the button on the set temperature by 1°F(°C).
Page 14
Note: AUXILIARY CONTROLS-DIP SWITCHES • Range of time setting is: 0.5~24h. The auxiliary dip switch controls are lacated behind the room cabinet-as shown in the following figure. • The interval between two motions can’t exceed 5 sec- onds, otherwise the remote control will exit setting sta- The owner is responsible for checking switches and ensuring tus.
AUXILIARY CONTROLS-DIP SWITCHES The auxiliary dip switch controls are located behind the room cabinet-as shown in this figure. The owner is responsible for checking switches and ensuring they are in the desired position. For models: 26TTW09AC230V1A-T 26TTW09HC230V1A-T 26TTW12AC230V1A-T 26TTW12HC230V1A-T Filter Reminder Function 26TTW09HP230V1A-T 26TTW12HP230V1A-T Temperature Limitation 26TTW09AC115V1A-T 26TTW12AC115V1A-T...
AIR CONDITIONER FEATURES (continued) Auto Auto High High Heat Heat Cool Cool Fan Only Fan Only PRESS ON/OFF Mode Temp/Timer Temp/Timer Mode Temp/Timer Temp/Timer Speed Speed BUTTON Reset Reset Timer Timer Filter Filter TO CHANGE TEMPERATURE SETTING: Auto Auto High High Heat Heat...
Page 17
(continued) AIR CONDITIONER FEATURES TO OPERATE ON FAN ONLY: Auto Auto High High Heat Heat Cool Cool Fan Only Fan Only PRESS MODE BUTTON Mode Temp/Timer Temp/Timer Mode Temp/Timer Temp/Timer Speed Speed CHOOSE Reset Reset Timer Timer Filter Filter FAN ONLY Note: Use this function only when cooling is not desired, such as for room air circulation.
Page 18
AIR CONDITIONER FEATURES (continued) COOL models) Auto Auto High High Heat Heat Cool Cool Fan Only Fan Only PRESS Mode Temp/Timer Temp/Timer Mode Temp/Timer Temp/Timer Speed Speed MODE BUTTON SELECT COOL Reset Reset Timer Timer Filter Filter Note: This feature can be used with any combination of FAN Speeds, Timer. When in the “Cool”...
Page 19
AIR CONDITIONER FEATURES (continued) Auto Auto High High Heat Heat Cool Cool Fan Only Fan Only Mode Temp/Timer Temp/Timer Mode Temp/Timer Temp/Timer Speed Speed Reset Reset Timer Timer Filter Filter If the display reads “F1” the Ambient If the display reads “F2”the Inner temperature sensor has failed tube temperature sensor has failed Auto...
ADDITIONAL THINGS YOU SHOULD KNOW Now that you have mastered the operating procedure, here are more features in your control that you should know. The Remote Control will operate all the control panel features, follow the same instructions. The control will maintain any set temperature between 61℉ and 86℉. The control is capable of displaying temperature in degrees Fahrenheit or degrees Celsius.
This warranty does not apply to repairs or replacements necessitated by any cause beyond the control of Gree Electric Appliances including, but not limited to, any malfunction, defect or failure caused by or resulting...
Page 24
For more Information: www. GreeComfort.com Gree Electric Appliances, Inc. 2019 All rights reserved. Cat No. GREE_ 26TTW_INSTALL_082019 66129931033...
