Fluke Biomedical IMPULSE 6000D Demo Instructions page 2

Demo Instructions
3. Future upgradeable: firmware, software and new waveforms
4. Global support network
Pacemaker
input (50 to
1500 ohms)
t
Device
selection
Warning: defibrillators/external pacemakers are capable of emitting lethal
high voltages/energies and should be operated only by trained professionals.
LCD
1) Plug-in defib. paddle contact plates.
(Removable to expose 4mm safety jacks)
2) Main 50-ohm testload input for both external defibrillator
& pacemaker.
2
Low level ECG
Power switch
Navigator
Function
Backlight
