- Page 1 Installation Instructions Use and Care Information Instructions d'installation Utilisez et d'entretien Instrucciones de instalación Información de uso y cuidado ZOOMIL16SS400 OCEANA-SH VANILLA-SH...
- Page 2 READ AND SAVE THESE INSTRUCTIONS BEFORE YOU START INSTALLING THIS RANGEHOOD WARNING: - TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE: a) Never leave surface units unattended at high settings. Boilovers cause smoking and greasy spillovers that may ignite. Heat oils slowly on low or medium setting. b) A lways turn hood ON when cooking at high heat or when flambeing food (i.e. Crepes Suzette, Cherries Jubilee, Peppercorn Beef Flambé).
- Page 3 When cutting or drilling into wall or ceiling, do not damage electrical wiring and other hidden utilities. Ducted fans must always be vented to the outdoors. ALL WALL AND FLOOR OPENINGS WHERE THE RANGEHOOD IS INSTALLED MUST BE SEALED. This rangehood requires at least 24" of clearance between the bottom of the rangehood and the electric cooking surface or countertop and at least 30"...
-
Page 4: Electrical Requirements
ELECTRICAL REQUIREMENTS A 120 volt, 60 Hz AC-only electrical supply is required on a separate 15 amp fused circuit. A time-delay fuse or circuit breaker is recommended. The fuse must be sized per local codes in accordance with the electrical rating of this unit as specified on the serial/rating plate located inside the unit near the field wiring compartment. -
Page 5: Available Accessories
MAIN PARTS ZOOMIL16SS400 Components Ref. Qty. Product Components Hood Body, complete with: Controls, Light, Filters, Motor. Ceiling Plate Available Plate Cover Accessories Cable bracket Cable raceway Activated Charcoal Lamp holder Filter sku #; Pawl FILTER1 Knobs Remote Control Long Lasting... - Page 6 RANGEHOOD DIMENSIONS ZOOMIL16SS400 15/16" 1/8" Max. 51 5/8" 15/16" Max. 51 5/8" 3/16" 3/16" 3/16" Ø5 7/8" 3/16" 3/16" 3/16" 3/16" Ø5 7/8" 3/16" Min. 24" - Min. 30"...
- Page 7 MAIN PARTS MAIN PARTS CEILING LIGHTING DIFFUSER OCEANA-SH Components Ref. Qty. Product Components Stainless plates ceiling lighting diffuser Ref. Qty. Installation Components Chrome plated ceiling lighting diffuser fixing Pin / Screws...
- Page 8 RANGEHOOD DIMENSIONS MAIN PARTS CEILING LIGHTING DIFFUSER OCEANA-SH 1/4" 15/16" Max. 51 5/8" 3/16" 3/16" 3/16" Ø5 7/8" 3/16"...
- Page 9 MAIN PARTS MAIN PARTS CEILING LIGHTING DIFFUSER VANILLA-SH Components Ref. Qty. Product Components Glass 3 Glass fixing plates Ref. Qty. Installation Components Screws Screws Rubber washers...
- Page 10 RANGEHOOD DIMENSIONS MAIN PARTS CEILING LIGHTING DIFFUSER VANILLA-SH 1/8" 3/8" 15/16" 15/16" Max. 51 9/16" Max. 51 5/8" 3/16" 3/16" 3/16" Ø5 7/8" 3/16"...
-
Page 11: Non-Ducted Installation
NON-DUCTED INSTALLATION This hood is designed to be mounted on the ceiling, and in Recirculation mode only. This hood is to be installed within the limits listed below: • Range Hood(Up&Down): minimum 24” on electric cooking surface and 30” on gas cooking surface. •... - Page 12 Sequence of operations - Installation Preparing for installation: • Preparation of the ceiling plate • Drilling the ceiling to fix the ceiling plate • Fixing the ceiling plate • Connecting hood-plate cables • Fitting the hood body • Levelling the hood •...
- Page 13 DRILLING THE CEILING TO FIX THE CEILING PLATE Use a plumb-line and mark the centrer of the cooking surface on the Support Ceiling. • Rest the ceiling plate against the ceiling, taking care to keep the limit pawl that has just been fitted in a position facing the installer and the cooking surface (the limit pawl must not be confused with the other 4 used to fix the steel cables that move the Hood).
- Page 14 FIXING THE CEILING PLATE • Lift up the fixing plate, taking care to ensure that the limit pawl is positioned frontally. • Fit the slots onto the two screws previously in- serted in the ceiling, and turn until they are at the centrer of the adjustment slot.
- Page 15 3/16" 3/16" 3/16" Use only screws and small parts in support of the hood. Warning: Failure to install the screws or fixing device in accordance with these instructions may result in electrical hazards. Minimum distances must be kept between the hood and cooking surface.
- Page 16 CONNECTING HOOD-PLATE CABLES N.B. Before continuing with installation it is necessary to move the hood to a height of at least 24" from the electric cooking surface and 30" from the gas cooking surface, using a support or the assistance of another person. This is essential, as the hood cables must necessarily be connected to the plate fitted to the ceiling without the weight of the hood...
- Page 17 FITTING THE HOOD BODY • Insert the cables into the safety knobs (c) with the thread at the top (Fig.12). • Insert the cables into the cable clamp screws (b) (Fig.12). • Pass the cables through the slots in the threaded pawls (a) and screw the cable locking screws (b) to the pawls themselves (Fig.13).
- Page 18 LEVELLING THE HOOD • The hood mobile unit must be lev- elled to allow the movement to op- 13/16" erate properly. • The hood is levelled by adjusting the safety pawls. • Rest a spirit level on the hood. • When safety knobs pressed upwards, movement of the...
-
Page 19: Electrical Connections
ELECTRICAL CONNECTIONS Attention! There is a separate switch needed for the lights on/off operation. This additional electric connection must be a separate from the hood and must operate independently. CONNECTING THE HOOD POWER SUPPLY CABLE • Take the power supply cable from hood and connect the end with exposed wires into the bracket. - Page 20 FITTING THE SHADE OCEANA-SH • Take the G9 LED Lights and insert them in the lamp holders. • They do not have to be screwed in, but simply inserted all the way. • Fix the metal shade 5 to the plate using the fixing knobs 12d.
-
Page 21: Control Panel
CONTROL PANEL For Best Results Start the rangehood several minutes before cooking to develop proper airflow. Allow the rangehood to oper- ate for several minutes after cooking is complete to clear all smoke and odors from the kitchen. Button Function Display Turns the lights On/Off. -
Page 22: Remote Control
REMOTE CONTROL The remote control is powered by a CR2032 type 3 V battery (not included). • Do not place the remote control near heat sources. • Do not discard the batteries with normal waste, they must be put into the specific containers. -
Page 23: Maintenance
MAINTENANCE GREASE FILTER The filter must be cleaned every 2 months of operation, or more frequently for particularly heavy usage, and can be washed in a dishwasher. CLEANING METAL SELF-SUPPORTING GREASE FILTER • Open the lighting unit by pulling on the notch. •... -
Page 24: Wiring Diagram
Wiring Diagram... - Page 25 To obtain warranty service, contact the dealer from whom you purchased the range hood, or the local Faber distributor. If you cannot identify a local Faber distributor, contact us at (508) 358-5353 for the name of a distributor in your area.
