  • Page 3 DEAR CUSTOMER THANK YOU FOR CHOOSING A GLOBUS PRODUCT. WE REMAIN AT YOUR DISPOSAL FOR ANY ASSISTANCE OR ADVICE YOU MAY NEED Devices for radio frequency “RF Beauty 6000” are produced and distributed by: Domino S.r.l. Via Vittorio Veneto, 52 31013 Codognè...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS TECHNICAL FEATURES ........................6 Device ............................... 6 Supplied accessories ......................... 6 Disposal ............................10 Warranty conditions ........................10 INTENDED USE ..........................12 LABELLING AND SYMBOLS ......................13 Device ............................. 14 Panel and keyboard ........................15 Display and Interface........................15 Accessories .............................
  • Page 5 AESTHETIC PROGRAM LIST ......................37 Benefits in the aesthetic field ......................51 Mechanism of energy transfer ......................58 How to apply the handpiece ......................59 MAINTENANCE AND CLEANING ....................70 Device and accessories ........................70 Transportation ..........................71 FAQ ..............................72...

  • Page 6: Technical Features

    TECHNICAL FEATURES Device Frequency: 400, 470, 700, 1000 KHz + 10% Case: in ABS Food grade Protection level: IP 20 Size: 170x220x60 mm Weight: 1100 g Power: 200 W +/-10% Power supply BRAND XP POWER model: AHM150PS48C2-8 PRI: 100-240Vac 50/60Hz 1.8A SEC: 48Vdc 3.13A Weight 600 g Supplied accessories Neutral electrode or plate...
  • Page 7 Monopolar capacitive handpiece Ergonomic handpiece for capacitive treatments. The handpiece is designed for a plug-in connection which facilitates the resistive electrode insertion. Size 110 x 70 mm, weight 230 g Electrodes The electrodes are made of steel and consist of a brass pin to make the connection with the handpiece.
  • Page 8 Cream for diathermy Conductive cream Globus, 250 ml Self-treatment kit The self-treatment kit is composed of a series of accessories useful to carry out the treatments in automatic mode. All the accessories can also be purchased separately.  Resistive neutral Cable "A"...
  • Page 9 for the connection between the electrode and the cable.  Reusable silicone flexible round electrode, with carbon area. Dimensions of Ø 75 mm and female connection (Ø 2 mm).  Bag with preformed gel discs for round electrode (Ø 85 mm). ...

  • Page 10: Disposal

    Conditions of use Temperature: from 0°C to 35°C Max. relative humidity: from 30% to 75% Atmospheric pressure: from 700 hPa to 1060 hPa Storage and shipping temperature (for the original packaging) Temperature: from -10°C to 45°C Max. relative humidity: 75% Atmospheric pressure: from 700 hPa to 1060 hPa If the accessories are not stored in the original package, please refer to the storage conditions of individual products.
  • Page 11 (receipt or sales invoice), that attests the purchase date of the product. 3. The repair work shall have no effect on the original warranty expiry date and shall neither renew nor extend it. 4. If no defect is found when it comes to carrying out the repair work the costs related to the time to check will in any case be charged.

  • Page 12: Intended Use

    INTENDED USE Rf Beauty 6000, including its variants, is a device for cosmetology purpose and is not intended for domestic purposes. The device is suitable for use in all environments other than domestic ones and those directly connected to the public low-voltage power supply network that supplies buildings used for domestic purposes.

  • Page 13: Labelling And Symbols

    LABELLING AND SYMBOLS Warning It indicates that the device complies with the current requirements directives WEEE symbol (Waste of Electrical and Electronic Equipment). Recycling symbol. The WEEE symbol used for this product indicates that the device can’t be treated as a household waste. Proper disposal of the product will contribute to protecting the environment.

  • Page 14: Device

    It indicates the humidity of the environment where the device and its accessories are stored and transported Device Input PWR: AHM150PS48C2-8 PRI: 100-240Vac 50/60Hz 1,8A SEC: 48Vdc 3.13A PIN 1,2: + V Output: 48Vd.c.; 2.2A 105VA PIN 3,4: GND Frequency Output: 400, 470, 700, 1000KHz Max.

  • Page 15: Panel And Keyboard

    Panel and keyboard Power regulation control handle Back to the previous menu (3”) Pause Button Power Increase- Switch On/Off button Decrease Buttons Display and Interface user short-circuited alert off transfer mode sound alert off program Cellulite Default user lifespan Total 20.00 emission percentage 100%...

  • Page 16: Accessories

    Accessories Cream labelling for Globus diathermy PAO symbol, it identifies the useful lifetime of a product after its package has been opened. Dispose of responsibly ALARMS The operator should place the device so that the distribution signals are always audible and visible.
  • Page 17 the correct contact between the electrode and the subject has been lost. If it often happens during the same treatment we recommend that you calibrate the electrode. the handpieces are not suitable for the treatment. For example a capacitive electrode is used to perform a resistive program. It appears if the two electrodes are in contact.
  • Page 18 Protections against device overheating The power limitation thresholds are:  Internal temperature of 55°C, indicated by a fixed yellow icon. The power is limited to 75% in respect to the set point in normal conditions  Internal temperature of 60°C, indicated by a fixed orange icon. The power is limited to 65% in respect to the set point in normal conditions.

  • Page 19: Warnings And Contraindications

    Read the tables at the end of the present manual for a correct use of Rf Beauty 6000. If it is necessary to use the device near or together with other devices, pay attention to how it is working.

  • Page 20: Warnings During The Use

    Before starting the treatment, make sure that the subject's skin is clean and dry. Warnings during the use While using the Rf Beauty 6000 make sure that: - the subject is awake and collaborative in order to communicate immediately the excessive heat sensation that can cause burns;...

  • Page 21: Side Effects

    - Redness - Skin irritation Contraindications Do not use Rf Beauty 6000 on subjects with pacemakers or other electronic devices. Do not treat cephalic area, abdomen, gonads and sexual organs. Do not treat the eyes zone. Do not use the device on pregnant subjects.

  • Page 22: Equipment

    - particularly obese subjects; - acute inflammatory diseases. EQUIPMENT A- RF Beauty 6000 device B- Power supply C- Conductive cream D- Monopolar capacitive handpiece E- Cable for plate connection F- Counter electrode or plate G- Resistive-capacitive electrodes H- Monopolar resistive handpiece...

  • Page 23: Connections

    CONNECTIONS Device This device operates connected to the mains. To connect the power supply to the connector, plug it as shown below. First connect the connector to the device and then to the mains. WARNING: insert the connector with the rectangular part downwards Accessories Counter electrode connection (plate) Connect the counter electrode to the black cable through the plug with the red...

  • Page 24: Device Use

    Switching on/off the device Turn the device on by pressing the OK key for some seconds. The display will visualize the logo Globus and the firmware version. The starting is confirmed by a tone. The main menu will then appear in the display.

  • Page 25: Main Menu

    Free program: shortcut to start a treatment in a very quick manner. My programs: user-created programs are stored. Contextual menu : to access the settings of Rf Beauty 6000. User menu The user menu allows you to individually manage the device even when it is shared among several co-workers.
  • Page 26 From the user menu, it is possible to choose: : it activates a user and load his/her settings and programs. select : it creates a new user : it deletes a user. delete Select Press the arrows to select the name and then press OK to confirm. The selected user will appear in the upper right corner.

  • Page 27: Program Menu

    Delete It is possible to delete a user after selecting it. WARNING: all the programs associated to the user will be permanently deleted. Program menu The program menu includes the stored program list. The user name that the programs refer to will be displayed on the upper right corner.

  • Page 28: Calibration

    Athermy: the program has a modulation that allows to biostimulate the tissues without generating heat. This treatment is useful in all cases where there is the need to carry out a treatment without causing the temperature increase in the tissues. Pulsed: three programs with modulated emission.
  • Page 29 To calibrate, once you have chosen the program and confirmed with the OK button, you will see a screen like this: Default user Head choice 30 mm 50 mm 70 mm Start Bipo 30 mm Bipo 50 mm Start Calib. To start the calibration you need to choose the plate that you are going to use, among the three available sizes, then press the calibration icon and follow the instructions.

  • Page 30: New Program Menu

    The device will calibrate in contact and at the end you will see a warning screen: Calibration Calibration completed! Cancel Confirm Confirm to complete the calibration and go to the work screen. Cancel and return to the calibration screen in case you made a mistake (for example, the head choice) and you want to repeat the process.
  • Page 31 The software will guide the user step by step through the creation of the program. At the beginning you will be asked to choose the number of phases of the program. The choice can be made by choosing a maximum of 3 phases. Phase treatment type Capacitive Resistive...

  • Page 32: Free Program Menu

    Frequency choice Rf Beauty 6000 offers four different emission frequencies. In addition to traditional 470 KHz there are other available emissions: 400 kHz, 700 kHz and 1000 kHz. A higher frequency acts primarily on surface tissues while lower frequencies can penetrate better.

  • Page 33: My Programs Menu

    My programs menu In this section, the personal programs created by each user are stored (up to 99 for each). To delete a program from the list, press the contextual menu and delete it. Working screen Cellulite Total 20.00 100% time Head 50 mm...
  • Page 34 The right and left buttons increase and decrease the power by 10 percentage points while the Up and Down buttons increase and decrease by one point at a time. To pause the treatment, press the specific key on the keypad (pause button). Treatment in pause mode Resume Home...

  • Page 35: Contextual Menu

    Volume Adjustment: you can adjust the volume of alarms by choosing among the four proposed levels. Recharge: this section refers only to the Rf Beauty 6000 RE device (rechargeable). : it can turn the sound signals on or off. Alarms...
  • Page 36 Disable Alarm short-circuited handpiece Disable alarm? Cancel Confirm If you confirm your choice the software will automatically return to the working screen, and you will notice the disabled alarm symbol on the upper right corner: Cellulite Total 20.00 100% time Head 50 mm total...

  • Page 37: Aesthetic Program List

    AESTHETIC PROGRAM LIST Face Area FACE WRINKLES HIGH INTENSITY HANDPIECE DURATION PROTOCOL Bipolar 12' for each side 2 sessions with an interval of of the face 24 hours between them. Repeat after 21 days Apply a sufficient amount of conductive cream on the face and on the handpiece and make the treatment before on one half of the face and then on the other half.
  • Page 38 ACNE SCARS MEDIUM-HIGH HANDPIECE DURATION PROTOCOL INTENSITY 12' for each 2-3 times a week for 3 Bipolar side of the weeks face Apply a sufficient amount of conductive cream on the face and on the handpiece. Massage acne scars in a linear or circular motion.
  • Page 39 COUPEROSIS LOW INTENSITY HANDPIECE DURATION PROTOCOL Bipolar 12' for each side of 2-3 times a week for 3 the face weeks Apply a sufficient amount of conductive cream on the face and on the handpiece. Massage the skin affected by couperosis in a circular motion.
  • Page 40 ANTI-AGING MEDIUM-HIGH HANDPIECE DURATION PROTOCOL INTENSITY 8' for each 2 sessions after 24 hours Bipolar side of the and again after 21 days face Apply a sufficient amount of conductive cream on the face and on the handpiece. Massage the skin in a continuous motion which starts from the inside of the face and goes outward.
  • Page 41 Skin Area ACNE MEDIUM-HIGH HANDPIECE DURATION PROTOCOL INTENSITY Monopolar 6' for each area 2-3 times a week for 3-4 Medium weeks capacitive The program is indicated in cases of acne that affect areas of the body other than the face, for example the back. Place the plate near the area to be treated;...
  • Page 42 CLEAVAGE LIFTING HANDPIECE HIGH INTENSITY DURATION PROTOCOL Medium 2 sessions with an interval monopolar of 24 hours between resistive them. Repeat after 21 days The cleavage with the aging process gradually tends to become wrinkled and lose elasticity. This program helps to stretch the skin and give it a more toned appearance.
  • Page 43 SKIN ELASTICITY HIGH INTENSITY HANDPIECE DURATION PROTOCOL Medium 10' for each area 2 sessions with an monopolar interval of 24 hours capacitive between them. Repeat after 21 days The skin elasticity program is oriented to fight against body skin aging process. Place the plate near the area to be treated.
  • Page 44 SCARS LOW INTENSITY HANDPIECE DURATION PROTOCOL Medium 10' for each area 2-3 times a week for 3-4 monopolar weeks capacitive Hypertrophic scars (both from acne and wounds) can be considerably improved in their appearance through some radio frequency treatments. Place the plate near the area to be treated and use the capacitive handpiece...
  • Page 45 LIPOLYSIS HANDPIECE INTENSITY DURATION PROTOCOL Big monopolar 12' for each area 2-3 times a week for capacitive 6-8 weeks Big monopolar 10' for each area resistive The lipolysis program is indicated as an adjuvant during the weight loss period. Besides stimulating the lipoclasic process, it helps to keep the skin toned and prevent the formation of stretch marks after the weight loss.
  • Page 46 LOCALIZED ADIPOSITY HANDPIECE MEDIUM INTENSITY DURATION PROTOCOL Big monopolar 12' for each area 2-3 times a week for capacitive 6-8 weeks Big monopolar 10' for each area resistive The program is indicated in cases of localized adiposity, for example in the hips, inside of the knee, arms etc.
  • Page 47 EDEMATOUS CELLULITE MEDIUM INTENSITY HANDPIECE DURATION PROTOCOL Big monopolar 12' for each area 2-3 times a week for capacitive 6-8 weeks Big monopolar 10' for each area resistive The edematous cellulite is the first stage of cellulite, the skin looks pasty and, if pinched, the orange peel effect appears on the surface.
  • Page 48 CULOTTE DE CHEVAL LOW-MEDIUM HANDPIECE DURATION PROTOCOL INTENSITY Big monopolar 17' for each 2-3 times a week for 6-8 capacitive area weeks Big monopolar 8' for each area resistive They are fat pads that are located between the thighs and gluteal fold. Place the plate on the anterior part of the thigh.
  • Page 49 ORANGE PEEL SKIN MEDIUM-LOW HANDPIECE DURATION PROTOCOL INTENSITY 12' for each 2-3 times a week for 6-8 Big monopolar area weeks capacitive 5' for each area Big monopolar capacitive The program is indicated to treat the parts of the body that present the orange peel skin, such as legs/gluteal muscles, arms, abdomen.
  • Page 50 PRINCIPLE OF OPERATION Radio frequency spread rapidly and it is now one of the most important therapies used in rehabilitation and for the treatment of the main beauty flaws whose effectiveness has been proved by many studies. The strong point of the radio frequency is that it has extraordinary effects on the most widespread beauty flaws with no need to resort to aesthetic surgery or invasive methodologies.

  • Page 51: Benefits In The Aesthetic Field

    electrode, the negative ions to the positive ones. Reversing the voltage there will obviously be a change of direction of the ions that are attracted in the opposite direction. The biological effect of these continuous inversions will be an increase of heat in biological tissues due to the impact of the electrical charges of extremely quick motion with other molecules.
  • Page 52 Connective tissue and wrinkles The connective tissue is composed of two basic proteins, collagen and elastin. Both of these proteins are fundamental to maintain a sound and efficient structure of our connective tissue and they are, in different percentage, part of the main structural tissues of the human body: cornerstone of tendons, cartilage, bone, blood vessels, membranes.
  • Page 53 The increase in temperature also results in a very interesting phenomenon: the stimulation of Heat Shock Proteins. These special proteins operate when a rather high temperature or high stress may damage the cell. Their biological function is to protect and to guarantee the production of new protein bonds restoring the three- dimensional structure of proteins that following the heat shock were damaged.
  • Page 54 Stretch marks: they are one of the most common aesthetic problems and difficult to solve. At this point we have to make a distinction: there are newly formed stretch marks (reddish-purple, not depressed on palpation) and long standing stretch marks appearing whitish, of hard and depressed texture. The best results are obtained with the first ones.
  • Page 55 causes fat accumulation, in order to find space they are forced to expand upward, giving to the skin the first hollows (see picture) From an anatomical point of view, in male individuals the fibrous septa are arranged in a completely different way compared to those of the woman. While the former are arranged in a crisscrossed way, those of the woman are perpendicular to the skin.
  • Page 56 permeability, with a dilation of the capillaries, liquid retention and edema formation. The edema causes some metabolic changes that result in hyperplasia and hypertrophy of the capillary network that in the long run lead to the formation of deposits in the interstitial spaces between the fat molecules and the capillaries themselves.
  • Page 57 structures, combined with the force of gravity, causes changes in the skin and there is an aspect of laxity. In the absence of flaccidity, if you stretch the skin upwards you do not notice any difference on the skin surface. On the contrary, in the presence of flaccid skin, if you stretch the skin in the same way you will notice a reduction or even a total disappearance of the orange peel effect.

  • Page 58: Mechanism Of Energy Transfer

    Resistive mode The resistive mode of the RF Beauty 6000 can be carried out in two ways: with the monopolar handpiece; with the bipolar handpiece.

  • Page 59: How To Apply The Handpiece

    counter electrode. Thus, it is possible to reach particularly small or difficultly reachable areas. With the bipolar handpiece, the power output does not pass through the body but remains tangential to the treated area. Tissue heating mainly occurs in the structures that have a lower impedance and are more rich in water (epidermis and dermis) and only later in the structures with higher impedance such as the hypodermis.
  • Page 60 The parameters In order to make it more specific and effective the treatments of radio frequency you can intervene on the following parameters: frequency; modulation; intensity-temperature; lifespan; objective. Frequency Our device is capable of delivering a four-level frequency alternating electrical current (400 kHz, 470 kHz, 700 kHz and 1 MHz).
  • Page 61 The depth of action is not only dictated by the frequency used, but also by the positioning of the electrodes. If the plate and the movable electrode are positioned in a transversal mode the depth of action (permitted by the type of electrode and the frequency used) will be greater than to position the plate and the electrode in the longitudinal mode.
  • Page 62 This phenomenon is amplified as the t off increases. Pulsed Rf Beauty 6000 has the following pulsed preset programs: Pulsed 90= t on 900 ms - t off 100 ms Rev.01.17 - 11.01.2017...
  • Page 63 Pulsed 70= t on 700 ms - t off 300 ms Pulsed 50= t on 500 ms - t off 500 ms Pulsed 50 is the program with a greater duty cycle, so the power output being equal it will transfer a lower average power. The choice between using one program or the other can be made depending on the experience and common sense of the operator, because here we cannot give more specific guidelines.
  • Page 64 Intensity The intensity is the amount of current supplied by the machine. The more we increase the intensity the higher the thermal response of the biological tissues. It is therefore of fundamental importance to dose intensity in relation to the objective to be achieved and, above all, according to the function to preserve tissues avoiding overheating.
  • Page 65 NO HEAT SENSATION BARELY PERCEIVED HEAT LIGHT HEAT LUKEWARM VERY LUKEWARM VERY HOT TOO MUCH HEAT EXTREMELY HOT SEARING Rev.01.17 - 11.01.2017...
  • Page 66 Low intensity is defined as the perception of a temperature of light warmth, therefore between the values 2 and 3 of the temperature scale. Medium intensity is defined as the perception of a pleasant heat, therefore between the values 4 and 6 of the temperature scale. High intensity is defined as the perception of a temperature of very intense warmth, therefore between the values 7 and 8 of the temperature scale.
  • Page 67 Lifespan The aesthetic programs duration of the session is a fundamental parameter to consider during the treatments with radio frequency. As a matter of fact, the restructuring of the collagen fibers requires a certain temperature and a period of time in which this temperature is maintained. Broadly speaking, the higher the temperature the shortest time of application will be necessary.
  • Page 68 Big monopolar electrode (70 mm Ø) 21 cm 14 cm Rev.01.17 - 11.01.2017...
  • Page 69 Medium monopolar electrode (50 mm Ø) 10 cm 15 cm Small monopolar and bipolar electrode (30 mm Ø) 6 cm 9 cm Rev.01.17 - 11.01.2017...

  • Page 70: Maintenance And Cleaning

    Taking into account what provides the scientific literature in this respect we can draft a summary plan of how the parameters are modulated as a function of the purpose. Appearance of the skin, wrinkles, superficial beauty flaws: high power, high temperature, short duration of the treatment.

  • Page 71: Transportation

    It is recommended that you clean/disinfect the electrodes after every use. Clean the parts of the device which may come in contact with the subject after every use or at least once per week. It is recommended that you perform the maintenance of the device and its parts every 12 months.

  • Page 72: Faq

    Can the electrodes and the plate be cleaned with any cleaner? For cleaning and disinfection of the electrodes and the plate we recommend that you use a soft cloth soaked in disinfectant or quaternary ammonium. We recommend that you dry the heads and the plate before storing them in the supplied case.
  • Page 73 treatment can create excessive impedance such as to prevent the proper transfer of energy and in some cases cause superficial burns. It is possible, however, to combine the conductive cream with a percentage of other cream, taking care to mix the two parts. What are the recommended power levels? The perception of heat must never be excessive.
  • Page 74 No. It is absolutely not recommended to put the handpiece in contact with the reference plate. Can the thickness of the epidermis affect the perception of heat? Of course. If your skin has a reduced thickness you will have a greater perception of heat.
  • Page 75 Rev.01.17 - 11.01.2017...
  • Page 76 Rev.01.17 - 11.01.2017...
