  • Page 1 INSTRUCTIONS VZ-7 / VZ-5N / VZ-5b English...
  • Page 2 Manufacturer / Hersteller: WolfVision GmbH & Co KG, Vlbg. Wirtschaftspark, A-6840 Götzis, Austria Tel. ++43 / (0)5523 / 52 250-0, Fax ++43 / (0)5523 / 52249 E-Mail: wolfvision@wolfvision.com, Internet Homepage: www.wolfvision.com...
  • Page 3 ENGLISH Portable Visualizer models: VZ-7 Visualizer with remote control and serial control input RS232 VZ-5b Visualizer without remote control and serial input RS232 VZ-5N Japanese Version (with remote control and serial input RS232) 1 Video camera head 2 Light 3 Connectors (on the back...
  • Page 4 Setting up 1. Pull the arm upwards using the special pull ring (8) 2. Turn the video camera head (1) and point it at the working surface 3. Connect the power adaptor to the DC-input (14). 4. Connect a TV-monitor, a video projector or a video recorder to the video output (12) or the Y/C-output (13) Please note: The picture quality is much better if you use the Y/C...

  • Page 5: Infrared Remote Control

    Infrared remote control (not included with VZ-5b) One of the unique features of WolfVision's portable Visualizers is that there are only 5 buttons on the unit. Therefore anyone can use it without any instructions. For more experienced users there are some additional functions on the remote...

  • Page 6: Switching To Playback Of A Video Recorder

    Switching to playback of a video recorder WolfVision Visualizers do not have an input switch because the following method of connecting a video recorder is much easier and requires no switching at all: Connect the video output (12) or the Y/C (S-VHS) output (13) of the Visualizer to the according input of the video recorder.

  • Page 7: Technical Data

    100V or 110-120 V or 220-240 V AC / 12 V DC, 1.5 A Carrying case (leather imitation): 450x350x130mm (17.7"x13.8"x5.1"), black, side and inside pockets Y/C (S-VHS) cable, instructions,IR-remote control (not on VZ-5b) Other supplied accessories: Specifications and availability subject to change.

This manual is also suitable for:

Vz-7Vz-5n
