- Page 1 INSTRUCTIONS VZ-5B English...
- Page 2 To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. Manufacturer / Hersteller: Wolfvision GmbH & Co KG, Vlbg. Wirtschaftspark, A-6840 Götzis, Austria Tel. ++43 / (0)5523 / 52 250-0, Fax ++43 / (0)5523 / 52249 Made in EC (Austria)
-
Page 3: Camera Controls
ENGLISH VZ-5b: 1 Video camera head 2 Light 3 Camera controls (as shown below) 4 Working surface 5 Power on/off switch 6 Light switch 7 Close up lens for camera 8 Knurled wheel 9 Connectors (on back, Connectors (9): Camera controls (3): VIDEO S-VHS POWER... - Page 4 Setting up 1. Loosen the knurled wheel (8) and pull the arm upwards (Do not pull up on the light unit or camera!) 2. Turn the video camera head (1) and point it at the working surface 3. Connect the power adaptor to the DC-input (14) and plug it in 4.
-
Page 5: Technical Data
Technical data: VZ-5b Pick-up element / video Built-in camera system 1 CCD unit - 1/3" interline transfer Effective pixels: 752 x 582 = PAL (VZ-5b E), 768 x 494 = NTSC (VZ-5b U/UE/N) Horizontal resolution: > 450 TV lines White balance / Iris / Gain control: automatic Autofocus: continuously working with high speed, on/off switch...
