Summary of Contents for WolfVision Visualizer VZ-8
- Page 1 INSTRUCTIONS VZ-8 English...
- Page 2 Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Manufacturer: WolfVision GmbH, Vlbg. Wirtschaftspark, A-6840 Götzis, Austria Tel. ++43-(0)5523-52250-0, Fax ++43-(0)5523-52249 E-Mail: wolfvision@wolfvision.com, Internet Homepage: www.wolfvision.com...
- Page 3 ENGLISH 1 Camera head 2 Light 3 Connectors (on the back as shown below) 4 Working surface 5 Power on/off key 6 Light key (Also works as White Balance key if pressed for 3 seconds - see page 7) 7 Close up lens for camera 8 Pull ring 9 Auto focus on/off key (a light above this key shows...
-
Page 4: Infrared Remote Control
Infrared remote control One of the unique features of WolfVision's portable Visualizers is that there are only 5 buttons on the unit. Therefore anyone can use it without instructions. For more experienced users there are some additional functions on the remote control:... -
Page 5: Pal/Ntsc Video Outputs
Choosing the right output mode (SXGA/XGA/SVGA at 75 or 60Hz) The RGBHV- and DVI-output (#13 and #12) can output signals in the following formats: - SXGA (1280x1024 pixel) at 60Hz - XGA (1024x768 pixel) at 75Hz (default setting when resetting the resolution) - XGA (1024x768 pixel) at 60Hz (default setting if auto resolution does not work) - SVGA (800x600 pixel) at 75Hz - SVGA (800x600 pixel) at 60Hz... -
Page 6: Digital Zoom
Please note that objects with a very low contrast (like a blank sheet of WolfVision lightboxes (optional) paper) are difficult to focus. If the Connect the power cord to the light box autofocus does not work just move connector (#19) on the back side of the the object slightly. -
Page 7: White Balance
White balance: Correct white balance adjustment is important for true colors! The default white balance setting when the VZ-8 is shipped is "Auto Tracking". This means that the white balance is continuously adjusted. If the colors appear to be wrong try to move any object in the picture. - Page 8 Just connect the USB port (#16) of the Visualizer and the USB port of your computer, using the supplied USB cable. A dedicated WolfVision USB-software can be found on the CD-ROM. Please check our Internet homepage at: www.wolfvision.com/wolf/techinfo.html if an update of this software is available as a free-download.
- Page 9 The following chapters are for experienced users only: ON-SCREEN MENU / ON-SCREEN HELP For standard use of the WolfVision Visualizer it is not necessary to go into the Visualizer's menu and change settings. Inexperienced users should not make any adjustments there.
-
Page 10: Auto Power Off
The firmware (software) of your Visualizer can be upgraded to the latest version. This can be done by connecting a computer or a modem to the RS232 port of your Visualizer. Please consult your WolfVision dealer or check the WolfVision homepage at: www.wolfvision.com/wolf/techinfo.html. -
Page 11: Technical Data
Technical data: Camera 1/3" 1-CCD Progressive Scan Output signals SXGA / XGA / SVGA, PAL / NTSC, DVI, USB Pictures per second (as pi cked up by the camera) Horizontal resolution 640 lines (center) Vertical resolution 490 lines (center) - 640 lines in Image Turn Mode Image Turn mode 40% increased resoluti on of full pages Effective Pixel (=pixels which are act ually used for the... -
Page 12: Remote Control
Remote Control: ZOOM PRESETS IMAGE TURN CODES: FOCUS IRIS Storing Presets: Press one of the PRESET keys (#21) for 2 sec. TEXT EXT / INT MENU Storing Images: Press one of the MEMORY keys (#29) for 2 sec. 25 26 27 28 Activating the on-screen menu: MEMORY Press the MENU-key (#28) for 1 sec.
