Summary of Contents for WolfVision Visualizer VZ-15
- Page 1 INSTRUCTIONS VZ-15 ENGLISH...
-
Page 2: Precautions
PRECAUTIONS Make sure that sufficient air circulation for cooling the unit is possible (ventilation slots on the left and right side of the unit) If the Visualizer is not used for a long time turn off the main power switch (#34)! If there is any abnormality (abnormal noise, smell, smoke etc.) turn the power off immediately and contact your Visualizer dealer! USE THIS MACHINE ONLY WITH THE CORRECT VOLTAGE AS... -
Page 3: Table Of Contents
Copyright: Wolf Vision GmbH & Co KG, Vlbg. Wirtschaftspark, A-6840 Götzis, Austria, Tel. ++43/5523/52250-0, Fax. ++43/5523/52249 The Wolfvision Visualizer VZ-15 E/U/UE/N was developed and designed by WOLFVISION in Austria. It is "MADE IN AUSTRIA" Patents (examples): US 5027219, FRG 3833908, CH 678576... -
Page 4: Description Of The Wolfvision Visualizer
#1 Arm with pneumatic damper #2 Mirror system #3 Control panel #4 Connections (on the back) #5 Working plate (black/white) #6 Air extraction #7 Ventilation #8 Lamp changer (see page 10) #9 Lamp exchange cover #10 Reflector head #11 Release button for the arm #13 Sensor for infrared remote control #14 Infrared remote control CONTROL PANEL... -
Page 5: How The Visualizer Works
HOW THE VISUALIZER WORKS A light projector (b) inside the Wolfvision Visualizer projects the light via a mirror inside the unit and a mirror on the reflector head onto the working surface. The video camera (a) inside the unit scans the picture where the light falls. -
Page 6: Working With The Wolfvision Visualizer
For showing 3-dimensional objects with the Wolfvision-Visualizer, just place them on the working surface and adjust ZOOM and FOCUS (as mentioned). Due to a special Wolfvision lens the object can be up to 9.7" (25 cm) in height. If the object is to big for the working surface or if you want to show it from the side just place it behind or in front of the unit and tilt the reflector head. -
Page 7: Lighting
PRESET PRESET FUNCTION The Wolfvision Visualizer VZ-15 offers the possibility of programming two presets for the functions Zoom, Focus, Iris, Light and Image. They can be recalled with the PRESET 1 (#25) and PRESET 2 (#26) key. This function is very useful for example if a user requires one preset for papers on the working surface and one preset for an object placed in front of the unit. -
Page 8: Switchable Outputs
Grabber Card. CONNECTING A NUMBER OF MONITORS Connect a control monitor to the Preview video output (#31) of the Wolfvision Visualizer. Connect additional monitors to the Composite video output (#32) or the Y/C output (#37) of the Visualizer by looping them through the inputs and outputs of each monitor (as shown above). -
Page 9: Using A Video Printer
Connect a control monitor to the output of the video recorder SWITCHING TO PLAYBACK OF A VIDEO RECORDER If you want to mix your presentation with the Wolfvision Visualizer with playback of a video tape, connect the Visualizer, the video recorder and the monitor (or video projector) as follows: Connect the Composite video output (#32) or the Y/C output (#37) of the Visualizer to the according input of the video recorder. -
Page 10: Scanning Slides
Visualizer LAMP CHANGER The Wolfvision Visualizer is fitted with a lamp changer. If one lamp fails, there is no need to replace it immediately. Just turn the switch of the lamp changer (#8) on the front side of the machine to the locked position. -
Page 11: Thermostat
Change the fuse for a new one and switch the unit on again. If the fuse fails again contact your Visualizer dealer! INFRARED REMOTE CONTROL For controlling the Wolfvision Visualizer with the infrared remote control aim the remote control at the Visualizer and press the required key. -
Page 12: Changing The Frequency Of The Ir-Control
Changing the frequency of the IR-control: If a user works with two Wolfvision Visualizers and wants to control them both individually with their infrared remote controls, he has the possibility of changing the frequency on one of the units. For switching one Visualizer and its remote control to the second frequency just use the red switch besides the battery of the remote control and simultaneously press the Save key on the camera control panel (#12) and IMAGE on key (#22) on the main control panel of the Visualizer. -
Page 13: Specifications
SPECIFICATIONS PICK-UP ELEMENT: System: 1/2" interline transfer CCD Effective pixels: 752 x 582 = PAL (VZ-15E), 768 x 494 = NTSC (VZ-15U/VZ-15UE/VZ-15N) Horizontal resolution: > 460 TV lines Depth of focus: Tele: 2.7" (70mm), Wide: 9.7" (250mm) White balance: automatic Iris: automatic / manual Gain control:... -
Page 14: Troubleshooting
CONNECTORS Serial port Y/C cable cable (7-pin to 4-pin): (9-pin D-Sub) Function: ASCII-Code : Image on Iris open Focus plus (connectors viewd from front side) Zoom wide 1. Y-signal 3. Y-signal Image off 2. Y-ground 1. Y-ground Iris close Focus minus 5. - Page 15 - If you are sure that the lightfield is still much larger than the recorded area and it is not due to a wrong adjustment of your monitor of video projector, consult your Wolfvision dealer. The size of the lightfield can be adjusted electronically using a special Wolfvision service software.
- Page 16 Storing Presets: Preset Speicherung: Image on Image on Preset 1 Preset 2 oder ZOOM FOCUS Sync in Serial IRIS Mains Parallel IMAGE LIGHT Fuse PRESET Preview Composite POWER Printed in Austria - September 1996...
