- Page 1 Installation Instructions Modernist Warming Drawer DWR30M977WIP, DWR30M977WIM, DWR30M977WIS Part No. 115021 Rev A...
-
Page 2: Table Of Contents
Contents Before You Begin Important Customer-Service Information If You Need Help Important Safety Instructions Related Equipment Safety & Important information about safety instructions Installation Requirements Checklist Necessary tools Verifying package contents Installation planning Warming drawer dimensions Installation Instructions Install support platform in cabinet Electrical connection Remove and reinsert drawer Installing the custom front panel... -
Page 3: Before You Begin
• Keep this manual for reference and the electrical inspector’s use. Customer-Service Information If You Need Help For answers to general questions or installation issues, call your Dacor® dealer or Dacor Customer Assurance. For repairs to Dacor appliances, call Dacor Customer Assurance. Before calling, have available the warming drawer's model and serial numbers, which are on the Product Data Label (drawer front, interior side). -
Page 4: Important Safety Instructions
• The Important Safety Instructions and warnings in this manual do not account for all potential issues. Use common sense and caution when installing, maintaining, and operating this appliance. • Always contact the Dacor Customer Assurance about problems and conditions that you do not understand. 4 English... - Page 5 Important Safety Instructions WARNING To reduce risk of property damage, fire, electric shock, serious injury, or death when using your appliance, follow basic precautions, including: • Clean the unit thoroughly before operating it for the first time. • Do not use harsh scrubbers, cleaners, or detergents, which may permanently mar the unit's finish.
-
Page 6: Installation Requirements
Drill Verifying Package Contents These items are provided with the warming drawer. If any of these items are absent, contact your Dacor Service Center or Dacor Customer Assurance (pg. 4). Product Literature (Installation and User Guides, 7 mounting Screws (PN83569) -
Page 7: Installation Planning
Installation planning • A qualified technician must install the unit. The owner shall verify proper installation. • Carefully review the unit's installation site. Access should be convenient. Verify that electrical power can be provided. Install the warming drawer in wood cabinets only. •... - Page 8 Installation Requirements Drawer and Chassis dimensions Drawer for WIP Model without Front Panel Attached Drawer for WIP Model with Front Panel Attached Drawer for WIM and WIS Models 8 English...
- Page 9 (D1) Min. Vertical Gap Betw. 1 1/4” (3.2 cm) Warming Drawer Cutouts (D2) Min. Vertical Gap Betw. 1 1/2” (3.8 cm) Dacor Wall Oven (E1) Flush to Drawer Front 1 5/64” (2.7 cm) (see page 16) (E2) Flush to Cab’t Frame / Drawer with Panel Flush to 1 53/64”...
-
Page 10: Installation Instructions
Installation Instructions Install support platform in cabinet Provide a platform (100 lb. load capacity) within the cabinet to support the unit. The platform must be level, straight, and flush with the crossbrace at the front of the cutout. (See the graphic.) The unit cannot be leveled after installation. 3/4” (1.9 cm) thick plywood is recommended. -
Page 11: Electrical Connection
Electrical Connection WARNING Electrical Shock Hazard IMPORTANT: The unit has a 3-prong grounding plug to prevent possible electric shock. If a dedicated, grounded, 3-prong outlet is unavailable, the owner must have one installed. To avoid an electric shock hazard, DO NOT: •... -
Page 12: Remove And Reinsert Drawer
Installation Instructions Nominal Electrical-Supply Requirements 120 Vac, 60 Hz, 15 Amp., dedicated circuit The unit comes with a 40” (101.6 cm) power cord with a 3-prong grounded plug. Total Connected Load: 0.5 kW (4 Amp.) • The owner shall ensure that a qualified electrician performs the installation, which must comply with the latest revision of the National Electric Code ANSI/NFPA 70, and local codes and ordinances. - Page 13 Installation Instructions Remove the drawer from the appliance 1. Open the drawer fully, and remove the clamp screw. 2. Extract the clamp, and detach the connector. Connector 3. Remove the screw from the Drawer (both sides), near the front. 4. Remove the drawer from the chassis. English 13...
- Page 14 Re-installing the drawer 1. Extend both rails, and pull out the cable (right side) so the connector hangs outside the frame. Put the drawer on both rails, and slide it in until it engages under the rails' rear clips. Clip on slide Slide 2.
-
Page 15: Installing The Custom Front Panel
Installation Instructions Installing the Custom Front Panel This section instructs you how to attach the custom front panel to the warming-drawer face. The panel must be at least 1/2" thick to accommodate the length of the provided screws. 1. On the back of the custom panel, locate the vertical centerline. - Page 16 Installation Instructions Installing the Custom Front Panel, cont. 7. Verify that the screw holes in the brackets and the drawer face align properly. 8. Carefully center the panel side to side if needed. (Some leeway is designed into the product to allow for minor side-to side adjustment.) 9.
- Page 17 Installation Instructions English 17...
- Page 18 Installation Instructions 18 English...
-
Page 19: Verify Warming Drawer Operation
• If the unit still does not work, contact an authorized Dacor servicer: (800) 793-0093. • Do not try to repair the unit yourself. Dacor is not responsible for service required to correct a faulty installation. - Page 20 Dacor ∙ 14425 Clark Avenue, City of Industry, CA 91745 ∙ Phone: (800) 793-0093 ∙ Fax: (626) 403-3130 ∙ www.dacor.com...
