1. DisplayPort Connectors
2. LED Indicators
3. Power over Ethernet (PoE) LED Indicators
4. Gigabit Ethernet Ports with PoE
5. 44-pin Digital I/O Connector
6. Isolated Power Input Connector
7. Chassis Grounding Screw
8. Reset Button (not pictured)
9. Power Button

Connector Pinouts

The IC-3173 provides the following connectors.
DisplayPort
Use the DisplayPort connectors to connect one or more monitors to implement a local HMI for
your controller. You can develop a single real-time VI to use for both your user interface and
system logic. For more information, refer to the Using the Embedded UI to Access RT Target
Figure 1. IC-3173 Front Panel
17
16
15
10/100/
1000
14
ACT/
LINK
13
12
11
IC-3173
Industrial Controller
10
9
8
1
3
2
POWER
PoE1
STATUS
DP
PoE2
USER1
USER FPGA1
PoE3
DP
PoE4
DIO
SYS PWR IN
9-30 V
150 W MAX
ISO PWR IN
5-24 V
7
10. System Power Connector
11. User-Accessible Battery Compartment (not
pictured)
12. RS-232/RS-485 Serial Port
13. USB 3.0 Ports
14. Primary Gigabit Ethernet Port
15. Retention Mounts for USB 3.0 Ports
16. Retention Mounts for USB 2.0 Ports
17. USB 2.0 Ports
