RM Storage System Interlock Kit Installation Information
EK-CDSTG-IN. A01
May 1999
Introduction
The 2T-QINTL-CD interlock kit contains the components for installing the slide assemblies, the interlock system,
and the shipping bracket on the rackmounted CD storage system. The interlock system helps prevent cabinet
instability by allowing only one system at a time to be pulled out of the cabinet. The shipping bracket is used to
secure the rackmounted CD storage system in the cabinet during shipment or when moving the cabinet to a new
location.
The interlock system consists of a vertical rod, on which are mounted actuator latches for each product installed in
the cabinet. These actuator latches engage the interlock actuator on the rear of rackmount systems. When a
rackmount system is pulled out of the cabinet, the actuator latches rotate to prevent any other rackmount system that
has an interlock actuator from being pulled out of the cabinet.
Table 1 lists the parts that are shipped with the 2T-QINTL-CD interlock kit. The callouts in column 1 refer to the
part location in Figure 1.
Table 1 2T-QINTL-CD Interlock Kit Parts List
Figure 1
Description
Callout
™
Slide bracket, front and rear
š
8-32 pan-head screw
›
Flat washer, .190ID x .051THK
œ
Split washer, .171ID
8-32 hex nut
ž
10-32 nut bar
Ÿ
10-32 truss-head screw
Interlock actuator
¡
6-32 truss-head screw
¢
Actuator latch
Stabilizer bracket
10-32 threaded nut bar
‘
Cable carrier mounting bracket
’
Flat washer, .286ID x .066THK
“
Split washer, .263ID
”
Shipping bracket
•
Flat washer, .221ID x .051THK
–
10-32 Kep nut
RM Storage System Interlock Kit Installation
Information
© Compaq Computer Corporation. 1999. All Rights Reserved.
®
Compaq and the Compaq logo are registered in the United States Patent and Trademark Office.
Part Number
Qty.
74-53882-01
4
90-06038-01
8
90-06660-00
8
90-06690-00
8
90-06561-00
8
74-53977-01
4
90-00063-39
12
74-53883-01
1
90-00063-10
6
74-48997-02
1
74-48996-01
1
74-48998-01
1
74-53975-01
1
90-06676-00
2
90-07797-00
2
74-53884-01
1
90-06664-00
2
90-06565-00
2
EK-CDSTG-IN
1
