ProLiant 6000R/7000R Interlock Kit Installation Information
EK-7000R-IN. A01
June 1999
Introduction
The 2T-QINTL-70 interlock kit contains the components for installing the slide assemblies, the interlock system,
and the shipping bracket on the rackmounted ProLiant 6000 and ProLiant 7000. The interlock system helps prevent
cabinet instability by allowing only one system at a time to be pulled out of the cabinet. The shipping bracket is used
to secure the ProLiant 6000 and ProLiant 7000 in the cabinet during shipment or when moving the cabinet to a new
location.
The interlock system consists of a vertical rod, on which are mounted actuator latches for each product installed in
the cabinet. These actuator latches engage the interlock actuator on the rear of rackmount systems. When a
rackmount system is pulled out of the cabinet, the actuator latches rotate to prevent any other rackmount system that
has an interlock actuator from being pulled out of the cabinet.
Table 1 lists the parts that are shipped with the 2T-QINTL-70 interlock kit. The callouts in column 1 refer to the part
location in Figure 1.
Table 1 2T-QINTL-70 Interlock Kit Parts List
Figure 1
Description
Callout
™
Slide bracket, right front and left rear
š
Slide bracket, right rear and left front
›
8-32 pan-head screw
œ
Flat washer, .190ID x .051THK
Split washer, .171ID
ž
8-32 hex nut
Ÿ
M6 nut bar
Interlock actuator
¡
6-32 truss-head screw
¢
Stabilizer bracket
Actuator latch
10-32 threaded nut bar
‘
10-32 truss-head screw
’
Flat washer, .286ID x .066THK
“
Split washer, .263ID
”
Shipping bracket
•
Flat washer, .221ID x .051THK
–
10-32 Kep nut
HI-Strength thread-locking sealant
ProLiant 6000R/7000R Interlock Kit
Installation Information
© Compaq Computer Corporation. 1999. All Rights Reserved.
®
Compaq, ProLiant, and the Compaq logo are registered in the United States Patent and Trademark Office.
Part Number
Qty.
74-53996-01
2
74-53996-02
2
90-06038-01
8
90-06660-00
8
90-06690-00
8
90-06561-00
8
74-53977-02
4
74-53978-01
1
90-00063-10
4
74-48996-01
1
74-48997-02
1
74-48998-01
1
90-00063-39
4
90-06676-00
2
90-07797-00
2
74-53981-01
1
90-06664-00
2
90-06565-00
2
49-01340-00
1
EK-7000R-IN
1
