Data Aire dap4 Supplement Manual page 14

Enter the Activation Code. The following will be displayed on the screen.
Select "Yes" to enable Zone Master. Press the ESC key to exit. Menu M: Set Zone Master will be
available in the menu loop (if not displayed scroll through the menus until Menu M is hi-lighted).
Press the ENTER key to program the Zone Master.
Note: Every units within a zone needs to be activated to the Zone Master in order to use the Zone
Master Logic.
For all slave units (units 2, 3, ....16), after they have been enabled and connected via pLAN with
unit 1 (master), they will act as a member of the zone unless the user chooses otherwise. To dis-
able a unit from the Zone Master go to Menu J: Factory Settings of slave unit.
The following screen will be displayed:
At the "Zone Master Control" input, select YES for the unit to be in the zone. Select NO to not be in
the zone.
14
Zone Master Control
Enable Zone Master: Yes/No
Insert Zone Master
Access password: 0000
Press Esc to exit
System Settings
Model:
Screen Flip Display: 3s
Temp Units: Fahrenheit
Zone Master Control: Yes/No
Fan Mode: Continuous
Fan Type: Plug Fan
