VA 150 A, VA 150 P
WINDOW EXTRACT FAN
Installation and Wiring Instructions
VA150 P
STOCK Ref: 152110B
VA150 A
STOCK Ref: 153110B
220-240V/1/50Hz
READ INSTRUCTIONS IN CONJUNCTION WITH ILLUSTRATIONS
PLEASE SAVE THESE INSTRUCTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VA 150 A and is the answer not in the manual?

Questions and answers

Summary of Contents for Vent-Axia VA 150 A

  • Page 1 VA 150 A, VA 150 P WINDOW EXTRACT FAN Installation and Wiring Instructions VA150 P STOCK Ref: 152110B VA150 A STOCK Ref: 153110B 220-240V/1/50Hz READ INSTRUCTIONS IN CONJUNCTION WITH ILLUSTRATIONS PLEASE SAVE THESE INSTRUCTIONS...
  • Page 3: Safety And Guidance Notes

    C. Ensure that the mains supply (Voltage, Frequency, and Phase) complies with the rating label. D. The Fan should only be used in conjunction with the appropriate Vent-Axia products. E. It is recommended that the connection to the fan connecter terminals is made with flexible cable.
  • Page 4: Fan Dimensions

    When fixing thickness exceeds 32mm, the unit should be secured with Extended Fixing Rods, available as an accessory item (56 81 04). If the unit is to be installed in a location exposed to severe wind turbulence thicker glass will be required – consult with Vent-Axia Technical Support for advice. Suggested Minimum...
  • Page 5 PREPARATION FOR INSTALLATION (Dismantling) Place the fan unit, external grille downwards, on a flat surface. Unscrew grille securing screw located at the top of the grille. Remove internal grille. Slacken the two safety catch screws on the face of the housing. Depress the side catches. Lift off the housing.
  • Page 6 FITTING For Dimensions see Bi Measure the glass thickness and determine the length of fixing screw required (C1). Glass thickness 4 to 17mm – Break/ cut off ends of screws supplied. Glass thickness 16 to 32mm – Use screw as supplied. Glass thickness 32mm and greater –...
  • Page 7 RE-ASSEMBLE (WINDOW/ WALL) Replace the housing with the top cover slot uppermost. Feed the pullcord (VA150P) through the slot in the bottom of the housing. Ensure the arm protruding from the actuator housing is in its lower position, i.e. shutter closed. With the two side catches fully engaged, tighten the catch safety screws.
  • Page 8: Servicing And Maintenance

    WIRING. WARNING: THE FAN AND ANY ANCILLARY CONTROL EQUIPMENT MUST BE ISOLATED FROM THE POWER SUPPLY DURING THE INSTALLATION / OR MAINTENANCE. Take the top cover. Make a suitable hole in the grommet. Pass the cable through the hole and slide the top cover into the base housing.
  • Page 9: Product Fiche

    PRODUCT FICHE For Residential Ventilation Units (Complying Commission Delegated Regulation (EU) No 1254/2014) Name:   Vent‐Axia  Vent‐Axia  Model ID (Stock Ref.) :  VA 150 P ‐ 152110  VA 150 A ‐ 153110  SEC Class  F  F  SEC Value ('Average')  13.97  13.97  SEC Value ('Warm')  6.32  6.32  SEC Value ('Cold')  27.32  27.32  Label Required? (Yes/No=Out of scope)  No  No  Declared as: RVU or NRVU/UVU or BVU  RVU‐UVU  RVU‐UVU  Speed Drive  Multi‐Speed  Multi‐Speed  Type HRS (Recuperative, Regenerative, None) ...
  • Page 12 Kingdom contact your local supplier. Vent-Axia guarantees this product for two years from the date of purchase against faulty material or workmanship. In the event of any part being found to be defective, the product will be repaired, or at the Company’s discretion the product will be replaced without charge, provided that the product: Has been installed and used in accordance with the instruction given with each unit.
