- Page 1 Silent Fan Installation and Wiring Instructions Stock Ref. N° 44 66 58 - VASF100B 44 66 59 - VASF100T 220-240V~50Hz IPX4 PLEASE READ INSTRUCTIONS IN CONJUNCTION WITH ILLUSTRATIONS. PLEASE SAVE THESE INSTRUCTIONS.
-
Page 2: Safety And Guidance Notes
C. Ensure that the mains supply (Voltage, Frequency, and Phase) complies with the rating label. D. The fan should only be used in conjunction with the appropriate Vent-Axia products. E. The fan should only be used in conjunction with fixed wiring. - Page 3 Stock Reference WINDOW FITTING KIT White Brown For use in single or sealed double Wall Fitting Kit 100mm 254102 254100 glazing and most materials up to Window Fitting Kit 100mm 442947 - 40mm thick. A. INSTALLATION IMPORTANT: The fan should only be used in conjunction with fixed wiring. For positioning of fan refer to Fig.1.
-
Page 4: Speed Setting
The fans are factory set to low-speed, but have two speed settings for different installation requirements; you can select either high or low speed as below: SILENT FAN – VASF100B (IMPORTANT- LEAVE MOTOR WIRE IN TERMINAL 3) 1) Low speed: Ensure the motor wire is connected to terminal number 1. -
Page 5: Servicing And Maintenance
1. At intervals appropriate to the installation, the fan should be inspected and cleaned to ensure there is no build up of dirt or other deposits. 2. Wipe the inlets and front face with a damp cloth until clean. Fig.1. Fig.2 – Basic VASF100B 1 PHASE SUPPLY FUSE (220-240V 50Hz). - Page 6 Vent-Axia guarantees its products for two years from date of purchase against faulty material or workmanship. In the event of any part being found to be defective, the product will be repaired, or at the Company’s option replaced, without charge, provided that the product:- •...
