Icare EXPORT TS03 Instruction Manual For Patients

Patient app
Hide thumbs
Table of Contents

Advertisement

Quick Links

Icare CLINIC
Icare EXPORT
Icare PATIENT app
INSTRUCTION MANUAL
F O R
P A T I E N T S
ENGLISH

Advertisement

Table of Contents
loading

Related Manuals for Icare EXPORT TS03

Summary of Contents for Icare EXPORT TS03

  • Page 1 Icare CLINIC Icare EXPORT Icare PATIENT app INSTRUCTION MANUAL F O R P A T I E N T S ENGLISH...
  • Page 2 Icare CLINIC, EXPORT and PATIENT Instruction Manual for Patients | ENGLISH Icare CLINIC (Type: TS02), Icare EXPORT (Type: TS03) and Icare PATIENT app (Type: TS04) - Instruction Manual for Patients TS02-014-EN-1.4 The information in this document is subject to change without prior notice.

  • Page 3: Table Of Contents

    4.4.2 Managing IOP results and creating reports ..............15 4.5 Using Icare EXPORT to upload IOP results from the Icare HOME tonometer ....... 19 4.6 Using the Icare PATIENT app to upload IOP results from the Icare HOME tonometer ..21 5 MAINTENANCE AND UPDATES ...................... 21 6 DECOMMISSIONING ........................

  • Page 4: Safety Instructions

    Icare CLINIC service. Icare EXPORT can also be used for viewing the IOP results stored in an Icare HOME tonometer and storing the IOP results in a local file. Refer to chapter 4.5 for the use of the Icare EXPORT.

  • Page 5: Intended Use

    You need to use either Icare EXPORT on a computer or the Icare PATIENT app on a smartphone or a tablet to upload IOP data to the Icare CLINIC database. Icare EXPORT installer file can be downloaded from the Help menu of Icare CLINIC.
  • Page 6 To install Icare EXPORT on the PC, follow the instructions in the steps below: 1. Double-click the Icare EXPORT Setup.exe file. A setup wizard window appears. The PC will notify if Microsoft’s .NET framework has not been installed. (Follow the instructions displayed by the PC to install the .NET framework).
  • Page 7 3. A window for selecting the installation folder appears. Select a folder to install the application. Select Everyone to allow Icare EXPORT to be visible to all users of the computer; select Just me to restrict use of the application to the user installing the application.
  • Page 8 Icare CLINIC, EXPORT and PATIENT Instruction Manual for Patients | ENGLISH 4. Choose to install Icare EXPORT in cloud mode or local mode. In cloud mode Icare EXPORT sends the measurement results to your healthcare provider using the Icare CLINIC service.

  • Page 9: System Requirements And Installation Of The Icare Patient App

    6. A window indicating completed installation appears. Click Close to finish installation process. You are now ready to start using the Icare EXPORT application. Start the application by clicking the Icare EXPORT icon on the desktop of the PC. 4.1.3 System requirements and installation of the Icare PATIENT app...

  • Page 10: Start-Up And Shutdown

    Google Play) or another application providing equivalent functionality. To install the Icare PATIENT app on your smartphone or tablet, search for the Icare PATIENT app in the Google Play application store and then follow the installation instructions displayed on the smartphone or tablet screen.

  • Page 11: Using The Icare Home Tonometer, Icare Clinic, Icare Export And The Icare Patient App Together

    Icare CLINIC, EXPORT and PATIENT Instruction Manual for Patients | ENGLISH To start Icare EXPORT, click the icon on the PC desktop. The icon is created during the installation of Icare EXPORT. To shut-down Icare EXPORT, click the close symbol (x) in the upper right-hand corner of the application window.
  • Page 12 Note that to download measurement results from your Icare HOME tonometer, you can always choose to use your PC with Icare EXPORT or your smartphone or tablet with the Icare PATIENT app – whichever is the most convenient.

  • Page 13: Using Icare Clinic

    Icare CLINIC, EXPORT and PATIENT Instruction Manual for Patients | ENGLISH 4.4 Using Icare CLINIC 4.4.1 Introduction to the user interface of Icare CLINIC Patient profile shows your personal information. This information includes your personal forehead and cheek support settings. You should check that these settings are the same as documented in the patient profile before self-measuring.
  • Page 14 Measurement list shows your measurements, either your self-measured readings (indicated by the device type Icare HOME) or those measured by your healthcare provider. By default, the IOP measurements from the most recent HOME use period are shown. OD means the right eye. OS means the left eye.

  • Page 15: Managing Iop Results And Creating Reports

    Icare CLINIC, EXPORT and PATIENT Instruction Manual for Patients | ENGLISH 4.4.2 Managing IOP results and creating reports IOP measurements are listed under the Measurements tab. OD means the right eye. OS means the left eye. The listed measurements can be filtered either by entering From and To dates or by selecting a HOME use period from the Select period drop down list.
  • Page 16 Icare CLINIC, EXPORT and PATIENT Instruction Manual for Patients | ENGLISH An IOP report is created from the rows of IOP measurement data listed. The user can exclude a measurement by ticking the Exclude box on the measurement row. To create a report, click on the REPORT button.
  • Page 17 Icare CLINIC, EXPORT and PATIENT Instruction Manual for Patients | ENGLISH Chart type Scatter The chart type Scatter displays the data points without connecting them with lines. www.icarefinland.com...
  • Page 18 Icare CLINIC, EXPORT and PATIENT Instruction Manual for Patients | ENGLISH Chart type Diurnal The chart type Diurnal positions all the IOP data points to a 24-hour x-axis. Thus, all data points measured at the same time of the day will show at the same point on the x-axis. The IOP data points of each day are connected with direct lines.

  • Page 19: Using Icare Export To Upload Iop Results From The Icare Home Tonometer

    Once you have made some measurements, perform the following steps: 1. Connect the Icare HOME tonometer to the PC using a USB cable. Icare EXPORT starts up when the tonometer is connected. 2. Successful uploading is confirmed by Icare EXPORT with Measurements saved!
  • Page 20 Results are not uploaded to the Icare CLINIC database if the Icare HOME that you are using does not belong to the device fleet of any healthcare provider or Local mode is set in Icare EXPORT. In these cases, the results in the memory of the connected Icare HOME tonometer can be removed by clicking the Clear all measurements button and by confirming the removal.

  • Page 21: Using The Icare Patient App To Upload Iop Results From The Icare Home Tonometer

    Icare CLINIC database. The results are removed from the memory of the Icare HOME tonometer Click the “LOG IN →” text at the bottom of the display to log into Icare CLINIC to view uploaded results.

  • Page 22: Decommissioning

    Icare PATIENT app. You have uploaded the IOP measurement result to Icare CLINIC, but they do not show up under your patient record. The possible reasons are the following: a) Your health care provider has not registered the Icare HOME device for your use.

  • Page 23: Symbols

    Icare HOME tonometers are always displayed as integers of mmHg. For the proper use of the Icare EXPORT on a PC, the user’s network environment must allow Icare EXPORT to access the internet using TCP port 443. Failure to access the internet through the defined port prevents the sending of data from a device connected to Icare EXPORT to the database in the Icare CLINIC service.
