26. Encryption libraries

The new Encryption Libraries are designed to add to the Waspmote sensor platform the capabilities necessary to
protect the information gathered by the sensors. To do so two cryptography layers are defined:
Link Layer: In the first one all the nodes of the network share a common preshared key which is used to
•
encrypt the information using AES 128. This process is carried out by specific hardware integrated in the same
802.15.4/ZigBee radio, allowing the maximum efficiency of the sensor nodes energy consumption. This first
security layer ensures no third party devices will be able to even connect to the network (access control).
Secure Web Server Connection: The second security technique is carried out in Meshlium -the Gateway-
•
where HTTPS and SSH connections are used to send the information to the Cloud server located on the
Internet.
A third optional encryption layer allows each node to encrypt the information using the Public key of the Cloud
server. Thus, the information will be kept confidentially all the way from the sensor device to the web or data base
server on the Internet.
Transmission of sensor data
Information is encrypted in the application layer via software with AES 256 using the key shared exclusively
between the origin and the destination. Then the packet is encrypted again in the link layer via hardware with AES
128 so that only trusted packets be forwarded, ensuring access control and improving the usage of resources of
the network.
Figure: Communication diagram
Related API libraries:
WaspAES.h, WaspAES.cpp
•
WaspRSA.h, WaspRSA.cpp
•
WaspHash.h, WaspHash.cpp
•
All information about their programming and operation can be found in the
All the documentation is located in the Development section in the Libelium website.
-106-
Encryption libraries
Encryption Programming Guide.
