Engine Specifications - MULTIQUIP MC12PH Operation And Parts Manual

Guaranteed ISO 11201:2010 Based
Sound Pressure Level at Operator Station in dB(A)
NOTES:
1. Sound Pressure and Power Levels are "A" weighted Measures per ISO 226:2003 (ANSI S1.4-1981). They are measured with the operating
condition of the machine which generates the most repeatable but highest values of the sound levels. Under normal circumstances, the sound
level will vary depending on the condition of the material being worked upon..
MC12PH CONCRETE MIXER • OPERATION AND PARTS MANUAL — REV. #1 (09/02/15) — PAGE 13
Table 2. MC12PH Noise
Model
Table 3. Engine Specifications/Dimensions
Model
Air cooled 4-stroke OHV petrol engine, 25° inclined
Type
Bore X Stroke
Displacement
Max. Output
Continuous Rated Power
Max. Net Torque
Ignition System
Fuel Tank Capacity
Fuel
Lube Oil Capacity
Oil Type
Speed Control Method
Cooling System
Starting Method
Spark Plug Type
Spark Plug Gap
Dimension (L x W x H)
Dry Net Weight

ENGINE SPECIFICATIONS

GX340UT2QA2/GX340UT2QAP2
cylinder, horizontal shaft, cast iron sleeve
3.2 in. X 2.5 in. (88 mm x 64 mm)
389 cm
3
10.7 H.P. (7.9 kW) @ 3600 RPM
5.6 kW (7.5 HP)/3,000 rpm
6.3 kW (8.4 HP)/3,600 rpm
26.4 Nm/2.69 kgfm/2,500 rpm
Digital CDI with variable ignition timing
1.61 U.S. Gallons (Approx. 6.1 Liters)
Unleaded Gasoline
1.06 qt. (1.1 liters)
4-Stroke API, SF or SG
SAE 10W-30 General Use
Centrifugal Flyweight Type
Forced Air
Recoil Start
BPR6ES NGK
0.028-0.031 in. (0.70 - 0.80 mm)
16.0 x 18.1 X 17.6 in.
(406 X 460 X 448 mm)
69.9 lbs (31.7 Kg.)
MC12PH
TBD
