3 Technical Data
Machine type ........................................................................DELTA - MINI
Power of motor.....................................................................2.2 Kw three-phase head motor
Electrical connection ............................................................230 V./50 Hz.
Network connection .............................................................CEE 2P+T 16 A./6h.
Control connection ...............................................................48 V./50 Hz.
Current..................................................................................16 A.
Type of spiral pump(sleeve).................................................(according to client preference)
Capacity................................................................................5 to 20 l/min. (*)
Pumping pressure .................................................................max.15 bares max. (*)
Pumping distance .................................................................up to 15 mts. (*)
Air compressor .....................................................................170 l/min. approx.
Maximum air pressure..........................................................3.5 bars
Required water pressure .......................................................3 bars
Water coupling .....................................................................Geka
Loading height......................................................................1050 mm.
Width....................................................................................590 mm.
Length...................................................................................1280 mm.
Total height ..........................................................................1410 mm.
Weight ..................................................................................Approx.155 Kg.
(*) Depending on the type of material, consistency and length of conveying hose.
3.1

Standard model

- 1 Membrane compressor, approx. 170 l/min.
- 1 230 V wet-rotor pump
- 1 Tool box
- 1 25mm straight projecting lance with spout.
- 1 Standard mixer
- 1 Stator (shirt) of choice
- 1 Rotor
- 1 Set cleaning tools (scraper and restorer)
- 1 Nozzle cleaning tool
- Wrenches (2 flat wrenches, 1 ring wrench, 1 pressure regulator /socket wrench,
wrench for switch board)
- 2 Rubber cleaning balls
- 10-metre material conveying pipe, 25 mm diameter with coupling.
- 10-metre air pipe 3/8" with coupling.
- 5-metre water pipe 3/4" with absorption valve.
- 25 metres of electric piping 5x2'5 mm
- 1 CEE Conformity Certificate.
- 1 6-month guarantee.
- 1 User manual and list of machine parts.
Optional:
- 1 pressure checker with gauge
- Additional piece for hopper to increase capacity.
- Full insufflation hood and bore.
35 mm.
2
with base.
