3. TECHNICAL CHARACTERISTICS

Model
AC TIM 07C P6
Capacity (cooling) BTU
7000 (2,05)
(kW)
Capacity (heating) BTU
(kW)
Rated power consumption
785
(cooling) W
Power supply, V/Hz 220-240~/50
Rated power current
2,61
(cooling/heating)
Air circulation m3/h 330
Water tank volume, L
Capacity of draining (L/d) 35
Noise level, dB(A) 53/48/45
Refregerant R410A
Energy effeciency
(cooling/heating)
Electrical protection class I class
Degree of moisture
IPX0
protection
Filling of Freon, g 360
Operating temperature
18~35
range: cooling, °C
Net weight, kg 24
Gross weiht, kg 28
Net dimensions (mm) 270x480x695
Packing dimensions (mm) 335x540x865
4
www.timberk.com • Electric air conditioner
AC TIM 09C P6 AC TIM 12C P6
9000 (2,63) 12000 (3,52)
- - -
950 1250
220-240~/50 220-240/~50
2,63 2,64
330 330
3 3 3
45 56
53/48/45 53/49/46
R410A R410A
A A A
I class I class
IPX0 IPX0
420 560
18~35 18~35
24,7 28
28,7 32
270x480x695 270x480x695
335x540x865 335x540x865
NOTICE:
The manufacturer reserves the right to make
changes in the design, scope of delivery, product
manufacturing technology, as well as change its
technical characteristics to improve its consumer
and technical properties without prior notice.

4. DEVICE DESCRIPTION

5
17
Fig. 3.
19
1. Air outlet grille
2. Control panel
3. Castors
4. Intake grille
5. Remote control receiver
6. Filter
7. Handles
8. Air exhaust hose housing
9. Condensate drain
10. Power cable
11. Flange Cap*
12. Air exhaust hose
13. Hose outlet
14. Hose inlet
15. Castor locks*
16. Suckers*
17. Window bracket
18. Drain pan*
19. Drain hose*
*the accessary is optional (not in the set)
