3.4 Swipe Down menu

When the Display Unit is powered on, you can "swipe" your finger from the top of the screen
towards the bottom, to display a Swipe-Down menu (Figure 3-3) with the following items:
Date and Time: The current date and time (12 hour clock). The time needs to be changed in
areas that observe daylight-savings-time.
Battery: The battery icon displays the amount of power remaining in the battery.
GPS: Shows the status of the GPS receiver
Wi-Fi Network: Indicates if the system is connected to a wireless network and, if so, the name
of the network. See
Description
Saves a screenshot of data.
Used for adding Flags during data acquisition
Figure 3-3: Swipe Down Menu
Section 4.1.6 for details on connecting the system to a wireless network.
9
Getting Started
