TOOL BAR

FILE

NEW – Clears any data from the screen.

OPEN – Opens a previously saved test.

SAVE – Saves the test displayed on the screen.

PRINT – Prints either the Table or Graph or both.

EXIT – Exits the program.
TOOLS

EXPORT TO EXCEL – Allows test data to be saved to Excel. See Figure C – Sample
Excel Output Format.

ENTER AUTHORIZATION CODE – Each Shear Tester must be authorized to work with
the EZ Shear Software. The software allows for the user to use the software as a trial for
5 tests prior to authorization. Enter the authorization code and click OK or hit the Enter
key.

READ CURRENT SYSTEM TEMPERATURE – ONLY IF OPTIONAL
THERMOCOUPLE IS PURCHASED. Displays the current temperature measured by
the thermocouple (the thermocouple must be connected to the Shear Tester).

READ BATTERY VOLTAGE – Displays the current voltage level of the battery backup.

CALIBRATE THERMOCOUPLE – ONLY IF OPTIONAL THERMOCOUPLE IS
PURCHASED. Calibrates the thermocouple (thermocouple must be connected to the
Shear Tester). Enter the password and click OK or hit the Enter key.

CALIBRATE TOUCHSCREEN – Calibrates the touchscreen display on the SS-RT-10,
SS-HT-8, SS-HT-30, or SS-OSI-8. After the calibration is complete, the display will go
blank and the power to the touch screen will need to be recycled.

DISCONNECT SHEAR STAND – Shutdown the communication between the shear
equipment and the EZ Shear program.

RESET SHEAR STAND CONNECTION – This will attempt to re-connect the connection
to the SS-RT-10, SS-HT-8, SS-HT-30, or SS-OSI-8.
ADMIN

COMPANY NAME – The reports for the Data Table and Graph printouts display a name
in the upper left corner. The name is set to default as ChemInstruments. Type in the
desired name and click OK or hit the Enter key.
