- Page 1 HIGH SPEED RELEASE TESTER MODEL HSR-2000 OPERATING INSTRUCTIONS CHEMINSTRUMENTS 510 COMMERCIAL DRIVE FAIRFIELD, OHIO 45014 (513) 860-1598 www.cheminstruments.com Revision 1.1 February 13, 2017...
-
Page 2: Table Of Contents
MACHINE SETUP ....................13 RUNNING A TEST ..................... 19 EZ DATA SOFTWARE SYSTEM .................. 21 MAINTENANCE ......................24 TROUBLESHOOTING ..................24 MAINTENANCE PROCEDURES ............... 25 CLEANING THE TOUCH SCREEN ..............25 P a g e High Speed Release Tester Operating Instructions (HSR-2000) -
Page 3: Product Description
PRODUCT DESCRIPTION Congratulations on the purchase of your new ChemInstruments HSR-2000 High Speed Release Tester. This versatile, user-friendly, carefully designed instrument allows you to determine release values of adhesive laminates at various high speeds. WARNING: This equipment can cause injury if not used properly. It is the operator’s responsibility to observe all safety rules and warnings. -
Page 4: Unpacking
UNPACKING ChemInstruments has made every effort to ensure that the HSR-2000 arrives at your location without damage. Carefully unpack the instrument and check for any damage that may have occurred during shipment. If any damage did occur during transit, notify the carrier immediately. -
Page 5: Assembly
As with any precision piece of laboratory equipment, it is preferable to locate the HSR-2000 in an area where temperature and humidity are controlled to standard conditions of 72 ± 2 degrees Fahrenheit and 50 ± 5% relative humidity. -
Page 6: Connecting The Power Cord
Switch Power Figure 2 WARNING: Before proceeding with using the HSR-2000, it is advisable to become familiar with the Key Components. These Key Components and a brief description of their function follow in the next section. P a g e... -
Page 7: Key Components
• PINCH ROLLER pinches the test specimen against the Drive Wheel in order to separate the test specimen. Drive Wheel Grip Pinch Roller Calibration Load Cell Bracket & Wire Assembly P a g e High Speed Release Tester Operating Instructions (HSR-2000) - Page 8 • TOUCH SCREEN DISPLAY is the control center for the HSR-2000. P a g e High Speed Release Tester Operating Instructions (HSR-2000)
-
Page 9: Operation
The HSR-2000 is designed to regulate the speed of the load cell’s sampling in accordance with the speed of the test. The rate of data sampling will be adjusted to provide 400 data samples regardless of the test speed. -
Page 10: Grip Operation
Grip to come in contact with the wall of the load cell housing will damage the load cell. There must be a physical gap maintained between the Grip and the load cell housing for the load cell to function correctly. 10 | P a g e High Speed Release Tester Operating Instructions (HSR-2000) -
Page 11: Touch Screen Format
• Test Data Delay – is used to add a delay to the acquisition of test data. • Qualify Operation – is used to troubleshoot hardware problems with the HSR- 2000. 11 | P a g e High Speed Release Tester Operating Instructions (HSR-2000) - Page 12 The graph screen will display the graph, minimum, maximum, and average values of the last test. Touch anywhere on the screen to exit the graph screen and return to the main screen. 12 | P a g e High Speed Release Tester Operating Instructions (HSR-2000)
-
Page 13: Machine Setup
It is important to calibrate the load cell to ensure that reliable data will be gathered. A calibration procedure is built into the software of the HSR-2000. This procedure should be followed upon first use of the HSR-2000 and whenever necessary thereafter. The following is the step-by-step procedure for calibrating the load cell. - Page 14 11. Verify the calibration by hanging a different calibration weight on the calibration wire. 12. Repeat the calibration procedure if necessary. 13. Move the calibration bracket/pulley into the test position when finished with the calibration procedure. 14 | P a g e High Speed Release Tester Operating Instructions (HSR-2000)
- Page 15 3. Select the desired units. Select OK to confirm the entered units. MODE The HSR-2000 can be operated in a constant speed mode or a ramp speed mode. The following is a step-by-step procedure for setting the mode. 1. Select SETUP from the main screen.
- Page 16 1. Select SETUP from the main screen. 2. Select SPEED from the setup screen. 3. Select the box next to the desired ramp speed. Select OK to confirm the ramp speed. 16 | P a g e High Speed Release Tester Operating Instructions (HSR-2000)
- Page 17 OK to confirm the entered value. QUALIFY OPERATION Some of the hardware functions of the HSR-2000 can be verified with the qualify operation screen. • Current Load – displays the force currently measured by the load cell. It will be displayed in the selected units.
- Page 18 • Start/Stop Motor – will start or stop the motor so that the speed can be verified with a hand tach. • Pinch On/Off – will engage and disengage the pinch roller for hardware verification. 18 | P a g e High Speed Release Tester Operating Instructions (HSR-2000)
-
Page 19: Running A Test
High-speed release tests are preformed according to the FINAT Test Method number 4. The HSR-2000 will accommodate test samples with dimensions of 2” wide and at least 32 inches in length. The sample is prepared for either a release pull or adhesive pull at 180 degrees. - Page 20 • The TEST DATA DELAY parameter will allow for delaying the acquisition of data the defined number of milliseconds. 20 | P a g e High Speed Release Tester Operating Instructions (HSR-2000)
-
Page 21: Ez Data Software System
EZ DATA SOFTWARE SYSTEM EZ Data is a ChemInstruments program that runs on your computer and will allow you to interface to your ChemInstruments machine in order to save test data files, save raw test data to excel, graph and crop test data, tabulate test data files, and overlay test data files. - Page 22 The following picture is the main screen of EZ Data with a HSR-2000 connected. This screen will show the current load as a value and a real time graph as data is collected from the load cell. It shows the test setup parameters. It will also allow you to change the test parameters.
- Page 23 The following picture shows the HSR-2000 parameter setup in ramp speed mode. The graph displayed for tests run in ramp speed mode will also display the speed measured during the test. 23 | P a g e High Speed Release Tester Operating Instructions (HSR-2000)
-
Page 24: Maintenance
Control board is bad. Replace control board. ChemInstruments logo. Pinch, drive rolls do Solenoid not working. Replace solenoid. not engage Control board is bad. Replace control board. 24 | P a g e High Speed Release Tester Operating Instructions (HSR-2000) -
Page 25: Maintenance Procedures
Note: Most products contain 1-3% Isopropyl Alcohol by volume, which is within acceptable limits for Resistive Touch Panel cleaning use. Caution: Many products contain Ammonia, Phosphates, and/or Ethylene Glycol, which are NOT ACCEPTABLE; check product content label carefully. 25 | P a g e High Speed Release Tester Operating Instructions (HSR-2000)
