5. Hook the test weight onto the Shear Test Clip. The TEST BANK POSITION will
become green and the TIME DISPLAY for that bank will start counting.

Once a test weight falls onto the trip plate, the TEST BANK POSITION becomes red.
The TIME DISPLAY will remain at the time that the trip occurred even if the test weight is
removed.

To clear the TIME DISPLAY, double click the bank's TIME DISPLAY.
