12 Chapter 2 - Technical Data
TV ANALOG
Television standards
Color standards
Sound demodulator
Sound carrier measurement
NICAM-DECODER
Sound carrier
S/N MEASURING
Sources
Measuring range
DVB-C AND EURO-DOCSIS
QAM demodulator
Symbol rates
Modulation scheme
Measuring parameters
Scan function
106 V3.2
B/G, D/K, L, I, M/N
PAL, NTSC, SECAM
Sound carrier 1 and 2
Decoding of MONO, STEREO and dual sound
broadcasts
Sound carrier 1 and 2 relative to the
video carrier, in dB
Resolution 0.1 dB
Measuring accuracy ± 1.5 dB
(per ETS 300163)
5.85 MHz (B/G, D/K, L) and 6.552 MHz (I)
respectively
Decoding of MONO, STEREO and dual sound
broadcasts
On analog video signals
evaluated measurement according to CCIR 569
TV analog
40 – 55 dB
Noise Margin, NM up to 10 dB
Resolution 0.1 dB
Measuring accuracy ± 1.5 dB
(per ETS 300163)
1.0 – 7.2 MSym/s
16, 32, 64,128 und 256 QAM
(per ETR 290)
BER
1.00 • 10
MER up to 40 dB
Noise Margin, NM up to 10 dB
Resolution 0.1 dB
Measuring accuracy ± 1.5 dB
PE (Packet Errors)
up to 4 • 10
counts packet errors since the start of measurement
-9
9
