small screwdriver, taking care not to damage the trimmer.
FADER
A linear fader controls the overall level of each output. Unity
gain is at the top of the travel.

MASTER SECTION

D.C. POWER SOCKET
The cable from the power supply connects to the console via
this 5- pin SRC connector. To the right of the power connec-
tor is the master switch for +48V Phantom Power to all inputs.
WEDGE OUTPUT
The WEDGE output normally drives the engineer's monitor
speaker via a power amplifier, and when no PFL switches are
pressed this is fed by the submix signal. The WEDGE output
automatically switches to the PFL signal when any PFL switch
is active.
The WEDGE output always listens to the same source signal
as the headphones, but is also affected by DIM status and any
external connections to the Insert socket.
WEDGE INSERT
This is similar to the Input Channel Inserts and allow external
processing equipment to be 'inserted' into the output signal
1
path. The " 3 pole 'A' gauge jacks are by-passed except
4
when a plug is inserted.
PHONES
1
A standard " 3 pole'A' gauge jack for monitoring head-
4
phones. See the diagram on Page 8 for connection details.
This output is suitable for headphones with an impedance of
400 or greater.
TALKBACK M ICRO PHONE SOCKET
A standard female XLR-3 connector is provided for a low im-
pedance dynamic talkback microphone on a gooseneck mount
Page 18
