Preventing ESD Damage

In order to preserve the integrity of the components, follow the recommendations listed below:
Use an ESD wrist or ankle strap and ensure that it makes skin contact. Connect the equipment
•
end of the strap to an unpainted metal surface on the chassis.
Avoid touching the adapter against your clothing. The wrist strap protects components from
•
ESD on the body only.
Handle the adapter by its bracket or edges only. Avoid touching the printed circuit board or the
•
connectors.
Put the adapter down only on an antistatic surface such as the bag supplied in your kit.
•
If you are returning the adapter to Xilinx Product Support, place it back in its antistatic bag
•
immediately.
CAUTION! ESD can damage electronic components when they are improperly handled and can
result in total or intermittent failures. Always follow ESD-prevention procedures when removing and
replacing components.

Board Component Descriptions

Debug Header for Main Board Interconnection
The programming module is populated with a 2x15-pin debug connector (Callout 1 in
connects to the Alveo card via a ribbon cable.
2x15 Connector Details:
Manufacturer: SAMTEC
•
Part Number: FTSH-115-01-F-D-RA-K
•
Description: CONN HEADER R/A 30POS 1.27MM
•
Connector debug header pin definitions are given in
Micro USB Connectors
The programming module has two micro-USB connectors (Callouts 2 and 3 in
FT4232 USB to multi-protocol converter. Connect the external micro-USB cable from the host to the
Micro-USB Connector 1 (Callout 2 in
in Figure 1).
Pin description of the micro-USB connector is provided in Table 2.
Alveo Programming Cable User Guide
UG1377 (v2019.1) September 17, 2019
Table 2.
Figure 1). Micro-USB Connector 2 should be left unused (Callout 3
Figure 1) which
Figure 1), one for each
