10. Pulse Output jumpers. Allows for output connections to power and ground for making powered
outputs (voiding optical isolation). Output point jumpers to the right: Pulse Output is optically
isolated and non-powered. Output point jumpers to the left: Pulse Output is connected to
NoWire power and ground for creating a non-isolated 5V powered output.
11. LCD contrast adjustment (VR1).
12. FW update jumpers J1 and J5.
13. COM1, 9 pin female D connector for FW update.
14. LCD menu navigation push buttons. Press and hold for repeat key operation.
15. Connector for external EN4000 wireless receiver. Only utilized with NoWire 1100-2 models
without the internal wireless EN4000 receiver.
16. S1 and S2 Red status LEDs. Special status indication. S1 blinking: EN4000 wireless receiver
communications, S2 blinking: COM2 communications.

5 Installation Checklist

NoWire installation requires the following items:

5.1 Required items included

NoWire 1100 with internal receiver.
Power supply: 12VDC, 500mA Class II.
Small flat head screw driver for NoWire terminal blocks and transmitter terminal block
connections.

5.2 Items sold separately

EN1501 pulse transmitters or EN1210 universal transmitters for wireless points.
Outdoor enclosures to house the transmitters.
Meters with digital pulsers.

5.3 Hardware you must provide

Low voltage wiring (telephone, cat5 or thermostat wire) for connection from your meters to the
transmitters, from the meters to the wired pulse inputs of NoWire, and from the pulse outputs
to your input equipment.
RS485/RS232 compatible cabling for connection to Com2 Modbus serial port or terminal block
connection.
Mounting screws for attaching NoWire enclosure to a flat surface.
½" conduit and conduit fittings connecting into NoWire.
Any additional tools required for the installation.

6 Installation Instructions

6.1 Mount the NoWire enclosure

Here are some items to consider when deciding where to permanently locate the NoWire
enclosure.
o Place where it will be easy to view the NoWire LCD display.
o NoWire is outdoor rated if proper watertight conduit connections are used.
o Locate out of direct sunlight to avoid exceeding the maximum temperature rating.
NoWire Model 2100
NoWire Model 2100 Installation and Operation Manual
Submeter Solutions, Inc., 888-64METER
Page 9
