Pressing NEXT will rotate through the various menus. It rotates through the System Items, the 32 Wireless Inputs, the 4
Wired Pulse Inputs, and the 4 Wired Pulse Outputs. Press NEXT once to get to Wireless Input #1. Once there, press
CHANGE to setup Wireless Input #1.
The first sub-menu item allows you to tell NoWire to display Wireless Input #1 on the display. Press CHANGE
repeatedly to toggle between Yes and No. Once Yes is selected, press BACK to save the selection.
Pressing the NEXT key will rotate through Wireless Input #1's sub-menu items. Press NEXT once to modify the
Description. Press CHANGE to begin Description changes.
The CHANGE and NEXT buttons are used to modify the characters of a text
or numeric entry field. CHANGE increments the character. NEXT moves to
the next character position. Press and hold a button for rapid entry. Use
the CHANGE and NEXT buttons to enter "WI 1" for the description. When
done press BACK.
Tip: Press and hold the
Tip: Press and hold the
backwards one character. This is helpful if you rapidly scroll past the character you intended.
Press the NEXT button to rotate
through the various settings until you
get to the Assign Xmitr setting, then
press CHANGE to have NoWire wait
for the EN1501 reset signal.
NoWire Model 2100
NoWire Model 2100 Installation and Operation Manual
NEXT
CHANGE
NEXT
CHANGE button to rapidly move through characters to select.
BACK button and, while still holding it, press the
NEXT,
NEXT...
Submeter Solutions, Inc., 888-64METER
CHANGE
CHANGE
CHANGE
CHANGE &
NEXT
CHANGE button. This moves
CHANGE
BACK
BACK
