Bit 0: Host/Local (R/W)
0 = Local
1 = Host
Bit 1: Run/Stop (R/W)
0 = Stop
1 = Run
Bit 2: Load/Unload (R/W)
0 = Unload
1 = Load
Bit 3: Unused
Bit 4: Unused
Bit 5: Stopped in Auto Restart (R)
0 = Not Stopped in Auto Restart
1 = Stopped in Auto Restart
FIGURE 4-51 INTELLISYS SIERRA 125-200HP SG CONTROLLER REGISTER 01-
STATUS/CONTROL
Register 096: Language
0 = English
1 = Spanish
2 = Portuguese
3 = French
4 = Italian
5 = Dutch
Register 099: Starter Type
0 = Full Voltage
1 = Star-Delta
2 = Remote Star-Delta
3 = Remote Full Voltage
4 = Soft Starter
FIGURE 4-52 INTELLISYS SIERRA 125-200HP SG CONTROLLER REGISTER CODES
Bit 0: Run/Stop (R)
0 = Stop
1 = Run
Bit 1: On/Off Line Mode (R)
0 = Not in On/Off Line Mode
1 = On/Off Line Mode
Bit 2: Unused
Bit 3: Load/Unload (R)
0 = Unload
1 = Load
FIGURE 4-53 INTELLISYS SIERRA 125-200HP SG CONTROLLER STATUS ALARM
HISTORY
Register 097: Units of Measure
6 = German
7 = Danish
8 = Norwegian
9 = Swedish
10 = Finnish
11 = Turkish
Register 145: Integral Seq. Lead Change – Day
0 = Sunday
1 = Monday
2 = Tuesday
3 = Wednesday
Bit 6: Alarm (R)
0 = No Alarms
1 = Alarms
Bit 7: Warning (R)
0 = No Warnings
1 = Warnings
Bit 8: On/Off Line Mode (R)
0 = Not in On/Off Line Mode
1 = On/Off Line Mode
Bit 9:Unused
Bits 10-12: Unused
Bits 13-15: Unit Type (R)
100 = Sierra controller
0 = °F and PSI
1 = °C and PSI
2 = °C and Bar
3 = °C and kPa
4 = °C and kg/cm 2
4 = Thursday
5 = Friday
6 = Saturday
Bit 4: Stopped Auto Restart (R)
0 = Not Stopped in Auto Restart
1 = Stopped in Auto Restart
Bit 5: Unused
Bit 6: Unused
Bit 7: Unused
7 = Daily
8 = Weekdays
9 = Weekends
