Bit 0: Host/Local (R/W)
0 = Local
1 = Host
Bit 1: Run/Stop (R/W)
0 = Stop
1 = Run
Bit 2: Load/Unload (R/W)
0 = Unload
1 = Load
Bit 3: Unused
Bit 4: Unused
Bit 5: Stopped in Auto Restart (R)
0 = Not Stopped in Auto Restart
1 = Stopped in Auto Restart
FIGURE 4-41 INTELLISYS SIERRA SINGLE STAGE BOOSTER 125-200HP CONTROLLER
REGISTER 01-STATUS/CONTROL
Register 096: Language
0 = English
1 = Spanish
2 = French
3 = Portuguese
Register 099: Starter Type
0 = Full Voltage
1 = Star-Delta
2 = No Starter
FIGURE 4-42 INTELLISYS SIERRA SINGLE STAGE BOOSTER 50-100HP CONTROLLER
REGISTER CODES
Bit 0: Run/Stop (R)
0 = Stop
1 = Run
Bit 1: On/Off Line Mode (R)
0 = Not in On/Off Line Mode
1 = On/Off Line Mode
Bit 2: Unused
Bit 3: Load/Unload (R)
0 = Unload
1 = Load
FIGURE 4-43 INTELLISYS SIERRA SINGLE STAGE BOOSTER125-200HP CONTROLLER
STATUS ALARM HISTORY
Bit 6: Alarm (R)
0 = No Alarms
1 = Alarms
Bit 7: Warning (R)
0 = No Warnings
1 = Warnings
Bit 8: On/Off Line Mode (R)
0 = Not in On/Off Line Mode
1 = On/Off Line Mode
Bit 9:Unused
Bits 10-12: Unused
Bits 13-15: Unit Type (R)
100 = Sierra controller
Register 097: Units of Measure
0 = °C and Bar
1 = °C and PSI
2 = °C and kPa
3 = °F and PSI
4 = °C and kg/cm 2
Bit 4: Stopped Auto Restart (R)
0 = Not Stopped in Auto Restart
1 = Stopped in Auto Restart
Bit 5: Unused
Bit 6: Unused
Bit 7: Unused
