Register Variable
(40XXX)
128 Remote Start/Stop On/Off
129 Sequence Control On/Off
130 Power Out Restart Option (PORO)On/Off
131 PORO Time (seconds)
132 Air Filter Pressure Drop On/Off
133 Air Filter Pressure Drop Value (10th of psi)
134 Closed Loop Water System
144 High 1st Stage Discharge Temperature
145 High 2nd Stage Discharge Temperature
146 High 3rd Stage Discharge Temperature
147 High Oil Temperature
148 Low Water In Temperature
149 High Water In Temperature
150 High 2nd Stage In Temperature
151 High 3rd Stage In Temperature
152 High Package Discharge Temperature
153 High 1st Stage Discharge Pressure
154 High 2nd Stage Discharge Pressure
155 Low Suction Pressure
156 High Suction Pressure
157 Low Oil Pressure
158 Low Water In Pressure
159 High Water In Pressure
160 Low Water Pressure Drop
252 Software Part Number – Most Significant
253 Software Part Number – Least Significant
254 Software Version Number
255 Warning Code
256-270 Alarm Code History
272-286 Oil Pressure Alarm History
288-302 Water In Pressure Alarm History
304-318 Water Out Pressure Alarm History
320-334 Package Discharge Press Alarm History
336-350 1st Stage Discharge Press Alarm History
352-366 2nd Stage Discharge Press Alarm History
368-382 Suction Pressure Alarm History
384-398 Inlet Vacuum Alarm History
400-414 Oil Temperature Alarm History
416-430 Water In Temperature Alarm History
432-446 2nd Stage In Temperature Alarm History
448-462 3rd Stage In Temperature Alarm History
464-478 Package Discharge Temp Alarm History
480-494 1st Stage Discharge Temp Alarm History
496-510 2nd Stage Discharge Temp Alarm History
512-526 3rd Stage Discharge Temp Alarm History
528-542 Run Hours Alarm History
544-558 10000 Run Hours Alarm History
560-574 100% Loaded Hours Alarm History
576-590 10000 100% Loaded Hours Alarm History
592-606 50% Loaded Hours Alarm History
608-622 10000 50% Loaded Hours Alarm History
624-638 Status Alarm History
640-654 Real Time Clock Alarm History – Hours
656-670 Real Time Clock Alarm History – Minutes
672-686 Real Time Clock Alarm History – Month
Read/ Range
Write
R 0 or 1
R 0 or 1
R 0 or 1
R 10 - 120
R 0 or 1
R .2 – 1.0
R 0 or 1
R/W 150 – 500
R/W 150 – 500
R/W 150 – 500
R/W 120 – 210
R/W 30 – 50
R/W 50 – 150
R/W 80 – 160
R/W 80 – 160
R/W 80 – 500
R/W 100 – 400
R/W 100 – 400
R/W 30 – 400
R/W 35 – 405
R/W 8 – 60
R/W 25 – 45
R/W 50 – 76
R/W 0 – 40
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
Notes
0=Off, 1=On
0=Off, 1=On
0=Off, 1=On
0=Off, 1=On
0=Off, 1=On
High Digits
Low Digits
FIGURE 4-49
See
FIGURE 4-49
See
Less Than 10000 Hours
Multiply by 10000
Less Than 10000 Hours
Multiply by 10000
Less Than 10000 Hours
Multiply by 10000
FIGURE 4-48
See
