Summary of Contents for Xiaomi Mi Electric Scooter

  • Page 1 Mi Electric Scooter User Manual This version is for private use only and should not be distributed.

  • Page 2: Table Of Contents

    Thank you for purchasing Thank you for purchasing Mi Electric Scooter. It is a sports and recreational vehicle with style. Contents 1. Package Contents ............................02 2. Product Overview ............................03 3. Assembly and Set-Up ..........................04 4. Charge Your Scooter............................05 5. How To Ride ..............................05 6.

  • Page 3: Package Contents

    1 Package Contents Assembled Electric Scooter User Manual Legal Statement Quick Start Guide Warranty Card Mi Electric Scooter User Manual Legal Statement Tips Warranty Card Accessories Extended Nozzle Adapter Screw × 4 Hexagon Wrench tire × 2 Charging Adapter Carefully check package contents, if anything is missing or damaged, please contact local customer service for support.

  • Page 4: Product Overview

    2 Product Overview Accelerator Control Panel Headlight Scooter Bell Brake Lever Buckle Folding Mechanism Brake Light Disc Brake Kickstand Wheel Motor Ba ery Charging Port Compartment Control Panel Ba ery level The power level is indicated by four power lights on the control display panel.

  • Page 5: Assembly And Set-Up

    3 Assembly and Set-Up 2. A ach the handlebar to the stem 1. Fasten the handlebar stem on the headset, and put the kickstand down 3. Tighten the screws onto both sides of 4. A er the assembly, press the power the stem with the hexagon wrench bu on to check if it's working properly This version is for private use only and should not be distributed.

  • Page 6: Charge Your Scooter

    4 Charge Your Scooter Li up the Plug the power When charging rubber flap is completed, adapter into the put back charging port the rubber flap 5 How To Ride Wear helmets and knee pads in case 1. Turn on the scooter, and of falls and injuries when you learn check the power indicator to ride the scooter...
  • Page 7 2. Step on the deck with one foot, 3. When the scooter starts to coast, and slowly kicks off the other on put both feet on the deck and press the ground the accelerator (the accelerator initiates once the coasting speed exceeds 5km/h) 4.

  • Page 8: Safety Instructions

    6 Safety Instructions Watch out for safety risks Do not ride in the rain Keep your speed between 5-10km/h when you ride through speed bumps, elevator door sills, bumpy roads or other uneven surfaces. Slightly bend your knee to be er adjust mentioned surfaces Look out for doors, elevators Do not accelerate when you go downhill and other overhead obstacles...
  • Page 9 Do not press the accelerator when Always steer clear of obstacles you're walking alongside the scooter Do not hang bags or other heavy Keep both feet on the deck all time. stuff on the handlebar This version is for private use only and should not be distributed.
  • Page 10 Do not try following dangerous actions Do not ride in traffic lanes Do not turn the handlebar or residential areas where violently during high-speed riding vehicles and pedestrians are both allowed Do not ride in a ponding that Do not ride with anyone else, is higher than 2cm including children This version is for private use only and should not be distributed.
  • Page 11 Keep your feet off the rear Do not touch the disc brake mudguard Always keep your hands on Do not try riding up or down stairs, the handlebar and jumping over obstacles This version is for private use only and should not be distributed.
  • Page 12 When you ride from across pedestrians, Keep to the right at a low speed. Closely follow the safety instructions in the manual especially in China and countries that lack relevant laws and regulations regarding electric scooters. Xiaomi Communication Co., Ltd. shall not be liable for any financial losses, physical injuries, accidents, legal disputes and other interest conflicts resulted from actions that violate user instructions.
  • Page 13 7 Folding and Carrying Fold Open Open Make sure that the scooter's turned off. To fold, unlock the folding mechanism, and bend the handlebar stem to hook the buckle on the rear mudguard. To open, press the bell trigger to remove from the buckle, erect the handlebar and lock the folding structure. Carry Hold the handlebar stem with either one hand or both hands to carry.

  • Page 14: Daily Care And Maintenance

    8 Daily Care and Maintenance Cleaning and storage If you see stains on the scooter's body, wipe them off with a damp cloth. If the stains won't scrub off, put on some toothpaste, and brush them with a toothbrush, then wipe them off with a damp cloth.
  • Page 15 For detailed information, please refer to Mi Home App. Note: fully charged Mi Electric Scooter will last for 120-180 days. The built-in intelligent chip will keep a log of its charging and discharging records. The damage caused by prolonged no charge is irreversible and is beyond limited warranty.
  • Page 16 How to use the extended nozzle adapter If your tires are flat, remove the screw-on cap from the valve, and connect the extended nozzle adapter to the valve for pumping up. Remove the outer and inner tires Note: Crowbars not included, and should be purchased separately. 1.
  • Page 17 Install the inner and outer tires 1. Fill a small amount of air into the deflated inner tire till the inner tire is just bulged to look round. 2. Put the hub on the top of a desk. Pay a ention to the direction when installing the outer tire.

  • Page 18: Specifications

    9 Specifications Performance index Items Specifications L × W × H [1] (cm) 108×43×114 Dimensions A er folding: L × W × H (cm) 108×43×49 Weight Item weight (kg) Approx. 12.2 Load range (kg) 25–100 Riding 16–50 requirements Body length (cm) 120–200 Max.
  • Page 19 10 Trademark and Legal statement is a registered trademark owned by Xiaomi Inc (hereina er referred to as Xiaomi). Xiaomi reserves all rights to the trademark . Ninebot is a registered trademark of Ninebot(Tianjin) Technology Co., Ltd., all other trademarks and trade names are those of their respective owners.

  • Page 20: Certifications

    11 Certifications Federal Communications Commission (FCC) Compliance Statement for USA This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 21 European Union Compliance Statement Ba ery recycling information for the European Union Ba eries or packaging for ba eries are labeled in accordance with European Directive 2006/66/EC concerning ba eries and accumulators and waste ba eries and accumulators. The Directive determines the framework for the return and recycling of used ba eries and accumulators as applicable throughout the European Union.

  • Page 22: Quick Setup

    12 Quick Setup Control your Mi Electric Scooter and interacts it with other smart home devices in Mi Home App. 1. Download Mi Home App Scan the QR code below or go to App Store to download Mi Home App 2.
  • Page 23 Actual functions may vary due to technical upgrades and firmware updates. For latest functions and safety instructions, please go to Mi Community to exchange with other users. Online support: www.mi.com/service www. mi. com V1.0 This version is for private use only and should not be distributed.
