Gv-Pad Mini - GeoVision GV-IP Decoder Box Series Quick Start Manual

Note:
1. You can only connect GV-IP Decoder Box Series to one display device through
either HDMI or VGA connector.
2. The default video output is set to HD 720P resolution. If you use a VGA monitor, be sure
to change the output resolution to VGA 1024 x 768. If you want to configure your GV-IP
Decoder Box Ultra to 4K resolution, make sure your monitor is 4K-capable and change
the resolution to 3840 x 2160. To change the output resolution, see 4.1 System in GV-IP
Decoder Box and GV-Pad Mini User's Manual.

3.2 GV-Pad Mini

Follow the steps below to connect GV-Pad Mini.
1. Connect the device to the LAN port using an Ethernet cable.
2. Connect to power using the supplied power adapter.
3. Connect a speaker / headphone to the line out port if needed.
4. Connect a mouse and / or GV-Joystick V2 to the USB ports.
1
2
13
4
3
