- Page 1 AFOKAR-08A-RK39 MODEL: AFOKAR-08A-RK39 8” In-Vehicle Android Panel PC with P-CAP Touchscreen, Rockchip RK3399 on-board SoC, OBD-II, GPS, HDMI, microSD, USB 2.0/3.0, RS-232, Wi-Fi, Bluetooth, Camera, Digital I/O, RoHS Compliant, IP 54 Front Panel User Manual Page I Rev. 1.00 – October 8, 2018...
- Page 2 AFOKAR-08A-RK39 Revision Date Version Changes October 8, 2018 1.00 Initial release Page II...
- Page 3 AFOKAR-08A-RK39 Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
- Page 4 AFOKAR-08A-RK39 Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product.
-
Page 5: Table Of Contents
AFOKAR-08A-RK39 Table of Contents 1 INTRODUCTION ......................1 1.1 O ........................2 VERVIEW 1.2 F ........................2 EATURES 1.3 F ......................3 RONT ANEL 1.3.1 LED Indicators ....................4 1.4 R ....................... 5 ANEL 1.5 T & B ....................6... - Page 6 AFOKAR-08A-RK39 4 ANDROID OS ......................30 4.1 H ......................31 CREEN 4.1.1 Adding a Home Screen ..................31 4.1.2 Switching between Home Screens ..............32 4.1.3 Favorites Tray ....................32 4.1.4 Adding Shortcuts ....................33 4.1.5 Arranging the Home Screen ................35 4.2 N...
- Page 7 AFOKAR-08A-RK39 List of Figures Figure 1-1: AFOKAR-08A-RK39 Panel PC ..................2 Figure 1-2: Front View ........................3 Figure 1-3: LED Indicators ......................4 Figure 1-4: Rear Panel ........................5 Figure 1-5: Top and Bottom Panels ....................6 Figure 1-6: Side Panel ........................6 Figure 1-7: Dimensions (unit: mm) ....................
- Page 8 AFOKAR-08A-RK39 List of Tables Table 1-1: LED Indicators ......................4 Table 1-2: Technical Specifications ....................9 Table 2-1: Packing List ......................... 12 Table 2-2: Optional Items ......................13 Table 3-1: IO 1 Connector Pinouts ....................20 Table 3-2: IO 2 Connector Pinouts ....................22 Table 3-3: HDMI Connector Pinouts ...................
-
Page 9: Introduction
AFOKAR-08A-RK39 Chapter Introduction Page 1... -
Page 10: Overview
AFOKAR-08A-RK39 1.1 Overview Figure 1-1: AFOKAR-08A-RK39 Panel PC The AFOKAR-08A-RK39 is an 8" Android panel PC designed for in-car use. At the heart of the system is the Rockchip RK3399 on-board SoC, offering low power in a powerful package. The system also offers a multimedia experience with a built-in 5-megapixel camera, HDMI port and speaker. -
Page 11: Front Panel
Android 7.1 OS pre-installed RoHS compliance 1.3 Front Panel The front of the AFOKAR-08A-RK39 is a flat panel screen with a plastic frame. The components on the front panel are listed below: 5-megapixel camera Ambient light sensor ... -
Page 12: Led Indicators
AFOKAR-08A-RK39 1.3.1 LED Indicators The LED indicators on the front panel show the status of power, Bluetooth, Wi-Fi and WWAN connection. Figure 1-3: LED Indicators The system is turned off. Power LED Blue The system is turned on. Bluetooth is disabled. -
Page 13: Rear Panel
AFOKAR-08A-RK39 1.4 Rear Panel The rear panel has VESA mounting screw holes and an access panel for microSD card and SIM card. The following I/O connectors can also be found on the rear panel. 1 x 9 V~ 30 V DC input connector ... -
Page 14: Top & Bottom Panel
AFOKAR-08A-RK39 1.5 Top & Bottom Panel The top panel has a power button. Press the power button for 4~6 seconds to power on the system. The bottom panel has a 2 W speaker. Figure 1-5: Top and Bottom Panels 1.6 Side Panel The right side panel has one USB 3.0 port. -
Page 15: Dimensions
AFOKAR-08A-RK39 1.7 Dimensions The dimensions are shown below. Figure 1-7: Dimensions (unit: mm) Page 7... -
Page 16: System Specifications
AFOKAR-08A-RK39 1.8 System Specifications The technical specifications for the AFOKAR-08A-RK39 systems are listed in Table 1-2. System Rockchip RK3399 on-board SoC (dual-core Cortex-A72 + quad-core Cortex-A53, 64-bit) Memory 2 GB 1866 MHz LPDDR3L on-board memory Storage One microSD card slot... -
Page 17: Table 1-2: Technical Specifications
AFOKAR-08A-RK39 4-pin (2x2) Molex power connector (with ACC ignition) Power Consumption 12 V @ 2 A Physical Character Construction Material ABS + PC plastic Mounting VESA 75 mm x 75 mm Dimensions (W x H x D) 210 mm x 154 mm x 33.9 mm Operation Temperature -10°C ~ 50°C with air flow... -
Page 18: Unpacking
AFOKAR-08A-RK39 Chapter Unpacking Page 10... -
Page 19: Packing List
If any of the components listed in the checklist below are missing, do not proceed with the installation. Contact the IEI reseller or vendor the AFOKAR-08A-RK39 was purchased from or contact an IEI sales representative directly by sending an email to sales@ieiworld.com. -
Page 20: Optional Items
AFOKAR-08A-RK39 Quantity Item Image AFOKAR-08A-RK39 in-vehicle panel PC Table 2-1: Packing List 2.2 Optional Items The following are optional components which may be separately purchased: Item Image Power adapter with transfer cable (P/N: IVIPOWER-4PIN-R10) ACC power cable (P/N: 32002-001900-100-RS) Cigarette lighter power cable... -
Page 21: Table 2-2: Optional Items
AFOKAR-08A-RK39 Item Image GPS/LTE antenna (P/N: 32506-000400-100-RS) I/O connector 1 cable (20-pin) (P/N: 32024-003800-100-RS) I/O connector 2 cable (24-pin) (P/N: 32124-004400-100-RS) VESA mount stand (138 mm) (P/N: IVI-MK03-R10) Table 2-2: Optional Items If any of these items are missing or damaged, contact the distributor or sales representative immediately. -
Page 22: Installation
AFOKAR-08A-RK39 Chapter Installation Page 14... -
Page 23: Anti-Static Precautions
AFOKAR-08A-RK39 and severe injury to the user. Electrostatic discharge (ESD) can cause serious damage to electronic components, including the AFOKAR-08A-RK39. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the AFOKAR-08A-RK39 is accessed internally, or any other electrical component is handled, the following anti-static precautions are strictly adhered to. -
Page 24: Microsd Card Installation
AFOKAR-08A-RK39 Anti-static Discharge: If a user open the rear panel of the flat panel PC, to configure the jumpers or plug in added peripheral devices, ground themselves first and wear an anti-static wristband. 3.3 microSD Card Installation To install the microSD card, follow the instructions below. -
Page 25: Sim Card Installation (Optional)
3.4 SIM Card Installation (Optional) To install the SIM card, follow the instructions below. WARNING: The AFOKAR-08A-RK39 is not compatible with a micro-SIM (3FF) adapter or a nano-SIM (4FF) adapter. Please install a mini-SIM (2FF or Standard SIM) card for proper network connection. -
Page 26: Figure 3-4: Sim Card Installation
AFOKAR-08A-RK39 Step 2: Locate the push-push SIM card slot (Figure 3-4). Insert a SIM card into the slot to install it. To remove the SIM card, push the SIM card to release it. Figure 3-4: SIM Card Installation Step 3: Replace and secure the SIM card slot access panel with the previously removed retention screw. -
Page 27: Mounting The System
75 mm interface pad. The AFOKAR-08A-RK39 VESA mount retention screw holes for fastening four M4*6 screws are shown in Figure 3-5. Refer to the installation guide that came with the mounting device to mount the AFOKAR-08A-RK39. -
Page 28: External I/O Connectors
AFOKAR-08A-RK39 3.6 External I/O Connectors This section provides an overview of the external I/O connectors of the AFOKAR-08A-RK39. 3.6.1 I/O Connector 1 (20-pin) The 20-pin I/O connector (IO 1) supports the following external peripheral devices: 1 x OBD-II/J1939 ... -
Page 29: Figure 3-7: Obd-Ii Cable
AFOKAR-08A-RK39 User can purchase the optional OBD-II cable (Figure 3-7) to connect the AFOKAR-08A-RK39 with the vehicle. Figure 3-7: OBD-II Cable The pinout locations of OBD-II cable connector are shown below. Figure 3-8: OBD-II Connector Pinouts Page 21... -
Page 30: I/O Connector 2 (24-Pin)
AFOKAR-08A-RK39 3.6.2 I/O Connector 2 (24-pin) The 24-pin I/O connector (IO 2) supports the following external peripheral devices: 1 x Audio out 1 x RS-232 1 x RS-485 2-bit digital input with isolation 2-bit digital output with isolation The pinouts for the IO 2 connector are listed in the figure and table below. -
Page 31: Hdmi Connector
AFOKAR-08A-RK39 3.6.3 HDMI Connector The AFOKAR-08A-RK39 has one HDMI output connector on the rear panel. The pinouts for the HDMI connector are listed in the figure and table below. Figure 3-10: HDMI Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION HDMI_DATA2... -
Page 32: Power Input Connection
Table 3-4: Power Input Connector Pinouts [Optional Choice] The AFOKAR-08A-RK39 can use either ACC power or DC power from the vehicle. To use ACC power, connect the AFOKAR-08A-RK39 to the vehicle through the optional ACC power cable. See Figure 3-12. -
Page 33: Usb Connector
Figure 3-13: Optional Cigarette Lighter Cable 3.6.5 USB Connector The AFOKAR-08A-RK39 has one USB 3.0 port on the right side panel. The USB port has a screw on the side for securing the USB devices, such as barcode scanners and smart card readers. -
Page 34: Power-On Procedure
To power-on the AFOKAR-08A-RK39, connect the AFOKAR-08A-RK39 to the vehicle through a power cable, or connect the system to a power source through the optional power adapter. -
Page 35: Available Drivers
AFOKAR-08A-RK39 3.8 Available Drivers All the drivers for the AFOKAR-08A-RK39 are available on IEI Resource Download Center (https://download.ieiworld.com). Type AFOKAR-08A-RK39 and press Enter to find all the relevant software, utilities, and documentation. Figure 3-15: IEI Resource Download Center 3.8.1 Driver Download To download drivers from IEI Resource Download Center, follow the steps below. - Page 36 AFOKAR-08A-RK39 Step 6: Click the driver file name on the page and you will be prompted with the following window. You can download the entire ISO file ( ), or click the small arrow to find an individual driver and click the file name to download (...
-
Page 37: System Maintenance
AFOKAR-08A-RK39 3.9 System Maintenance If the components of the AFOKAR-08A-RK39 fail, they must be replaced. Please contact the system reseller or vendor to purchase the replacement parts. NOTE: A user cannot replace a motherboard. If the motherboard fails it must be shipped back to IEI to be replaced. -
Page 38: Android Os
AFOKAR-08A-RK39 Chapter Android OS Page 30... -
Page 39: Home Screen
AFOKAR-08A-RK39 The AFOKAR-08A-RK39 comes with Android OS pre-installed. This chapter introduces the user interface and basic functions of Android OS installed in the AFOKAR-08A-RK39. 4.1 Home Screen Android OS supports multiple home screens allowing users to customize the screen with widgets, apps and shortcuts. -
Page 40: Switching Between Home Screens
AFOKAR-08A-RK39 4.1.2 Switching between Home Screens Swipe right or left to switch between home screens. Figure 4-2: Multiple Home Screens 4.1.3 Favorites Tray The Favorites tray at the bottom of each home screen allows users to keep the most important or frequently used shortcuts. -
Page 41: Adding Shortcuts
AFOKAR-08A-RK39 4.1.4 Adding Shortcuts To add app or widget shortcuts on the home screen, follow the steps below. Step 1: To add an app shortcut, tap the up arrow on the home screen to access the All Apps page. To add a widget shortcut, touch and hold the background of a home screen, then tap WIDGETS. -
Page 42: Figure 4-4: All Apps/Widgets Page
AFOKAR-08A-RK39 Step 2: Touch and hold an app icon or a widget, and drag it to the home screen. Figure 4-4: All Apps/WIDGETS Page Page 34... -
Page 43: Arranging The Home Screen
AFOKAR-08A-RK39 4.1.5 Arranging the Home Screen The items on the home screen can be moved and deleted. Touch and hold an item on the home screen and drag it where you want. To trash the item on the screen, drag it to the Remove icon. -
Page 44: Navigation Buttons
AFOKAR-08A-RK39 4.2 Navigation Buttons The navigation buttons shown in Figure 4-8 can always be found at the bottom of every screen. Figure 4-6: Navigation Buttons Buttons Description Tap to turn the volume down. Tap to return to the previous screen. -
Page 45: Status Bar
AFOKAR-08A-RK39 4.3 Status Bar The status bar on the top of the screen (Figure 4-9) displays system status, such as battery level or signal strength. Figure 4-7: Status Bar Swipe down from the status bar to view notification and status details (Figure 4-10). -
Page 46: Figure 4-8: Notification List And System Status
AFOKAR-08A-RK39 Figure 4-8: Notification List and System Status Page 38... -
Page 47: A Regulatory Compliance
AFOKAR-08A-RK39 Appendix Regulatory Compliance Page 39... - Page 48 AFOKAR-08A-RK39 DECLARATION OF CONFORMITY This equipment is in conformity with the following EU directives: EMC Directive (2004/108/EC, 2014/30/EU) Low-Voltage Directive (2006/95/EC, 2014/35/EU) RoHS II Directive (2011/65/EU, 2015/863/EU) If the user modifies and/or install other devices in the equipment, the CE conformity declaration may no longer apply.
- Page 49 AFOKAR-08A-RK39 Español [Spanish] IEI Integration Corp declara que el equipo cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 2014/53/EU. Ελληνική [Greek] IEI Integration Corp ΔΗΛΩΝΕΙ ΟΤΙ ΕΞΟΠΛΙΣΜΟΣ ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ...
- Page 50 AFOKAR-08A-RK39 Româna [Romanian] IEI Integration Corp declară că acest echipament este in conformitate cu cerinţele esenţiale şi cu celelalte prevederi relevante ale Directivei 2014/53/EU. Slovensko [Slovenian] IEI Integration Corp izjavlja, da je ta opreme v skladu z bistvenimi zahtevami in ostalimi relevantnimi določili direktive 2014/53/EU.
- Page 51 AFOKAR-08A-RK39 FCC WARNING This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation.
-
Page 52: B Safety Precautions
AFOKAR-08A-RK39 Appendix Safety Precautions Page 44... -
Page 53: Safety Precautions
Electric shocks can occur if the AFOKAR-08A-RK39 chassis is opened when it is running. To avoid risk of electric shock, this device must only be connected to a supply mains with protective earth. -
Page 54: Anti-Static Precautions
AFOKAR-08A-RK39 and severe injury to the user. Electrostatic discharge (ESD) can cause serious damage to electronic components, including the AFOKAR-08A-RK39. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the AFOKAR-08A-RK39 is opened and any of the electrical components are handled, the following anti-static precautions are strictly adhered to. -
Page 55: Product Disposal
AFOKAR-08A-RK39 B.1.3 Product Disposal CAUTION: Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery. Dispose of used batteries according to instructions and local regulations. Outside the European Union–If you wish to dispose of used electrical and electronic products outside the European Union, please contact your local authority so as to comply with the correct disposal method. -
Page 56: Maintenance And Cleaning Precautions
Some components in the AFOKAR-08A-RK39 may only be cleaned using a product specifically designed for the purpose. In such case, the product will be explicitly mentioned in the cleaning tips. Below is a list of items to use when cleaning the AFOKAR-08A-RK39. ... - Page 57 AFOKAR-08A-RK39 cloth is recommended when cleaning the device. Water or rubbing alcohol–A cloth moistened with water or rubbing alcohol can be used to clean the device. Using solvents–The use of solvents is not recommended when cleaning the device as they may damage the plastic parts.
-
Page 58: C Hazardous Materials Disclosure
AFOKAR-08A-RK39 Appendix Hazardous Materials Disclosure Page 50... - Page 59 AFOKAR-08A-RK39 The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
- Page 60 AFOKAR-08A-RK39 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯 醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T 11363-2006 (现由 GB/T 26572-2011 取代) 标准规定的限量要求以下。...
