Streetwize SWBLUE5 Quick Start Manual

SWBLUE5 Manual AW-6pp #26.qxp_Layout 1 05/04/2019 09:14 Page 1
Product specification:
FM frequency range: 87.8-102.8MHz
Transmit effective distance: 10M
SNR: 60dB
Distortion: <0.1%
Frequency response: 20Hz-15Khz
Left and right channel dB: >60dB
® ®
Bluetooth version: Bluetooth V2.1+EDR
Support Bluetooth profiles: HFP/HSP/A2DP/AVRCP
Working voltage: DC 9-26V
Power consumption: <1W
Working temperature: -10-70
Degree Working humidity: 0-95%
Product size: 112mm(L) x 26mm(W) x 17(D)mm
Product Net weight: 42g
Attentions
1. The product contains dual USB outputs. It can charge two
devices at the same time with the maximum output of
5V/2.1A.
2. Once powered, the product will connect automatically with
®
the phone via Bluetooth . If the line cable is inserted after
®
Bluetooth connection, 'Wire mode' will prevail.
3. Never have the volume too loud (generally at 28 or below)
when the FM is working so as to avoid sound distortion.
Please adjust the sound volume through the car audio.
4. To get the best results from the Bluetooth
always tune the transmitter to an FM frequency with
NO station transmitting.
5. The method to operate the Bluetooth
the difference of the phones applied.
6. Some phones may not support automatic connection if
they are powered on after a power failure. If so, please
connect them by hand.
7. This product is compatible with more than 95% phones
on the market, but some are still incompatible. Please
pay attention to it when purchasing our product.
8. The volume should be medium during the call to avoid
affecting the other party.
9. Do not use this product in an environment with high
temperature, dust or moisture.
10. The Bluetooth
play. If the phone has a cue tone or call, when playing
music with 'line' function, it will be automatically
switched to the Bluetooth
function after ending the cue tone or call.
®
transmitter,
®
may differ due to
Streetwize Accessories:
Unit 1, Royce Trading Estate, Ashburton Road West,
Trafford Park, Manchester M17 1RY
Sales enquiries: sales@streetwizeaccessories.com
Technical enquiries: support@streetwizeaccessories.com
www.streetwizeaccessories.com
®
of this product supports background
®
mode. It will return to 'line'
M17 1RY
Car Bluetooth
12/24V
FM Transmitter
Play music or make a phone call from an
Android/iOS phone through your FM radio.
Transmit music from your phone to your vehicle sound system
wirelessly. Plus answer calls through the hands-free mode via the
®
Bluetooth transmitter, as long as the mobile phone features a
®
Bluetooth function. When the call is finished, it will automatically
switch back to play music.
Please read and understand this manual before any use of this
product, and retain for future reference.
®
