Summary of Contents for Russell Hobbs Vario Max RHBCV2502
- Page 1 Vario Max Bagged Cylinder Vacuum Cleaner Model Number: RHBCV2502 220-240V~, 50/60Hz, 700W For Customer Services & Spare Parts please call 0345 209 7461 Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm Or visit us at www.productcare.co.uk PLEASE RETAIN FOR FUTURE REFERENCE...
-
Page 2: Table Of Contents
Spare parts Connection to the mains supply Disposal information Thank you for purchasing your Russell Hobbs Vario Max Bagged Cylinder Vacuum Cleaner. To get the best from your new cleaner, take a few moments to read these instructions and keep them in a safe place for future reference. -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING: • It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to electrical parts. - Page 4 SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE • Do not direct at people, animals, electrical outlets, or equipment containing electrical components. • Unplug from outlet when not in use. Do not leave the cleaner unattended while plugged in. •...
- Page 5 SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING: • Do not let the cord hang over the edge of the worktop, or touch hot surfaces. • Do not use this vacuum to pick up water or any other liquids, combustible substances or hot/burning objects.
- Page 6 SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE • Important: This cleaner has a thermal safety device which automatically cuts off the power supply in case of over heating. If the safety device has switched the cleaner off, unplug from the mains, allow the cleaner to cool down and check for any blockages.
-
Page 7: Energy Performance Label
ENERGY PERFORMANCE LABEL The purpose of the energy label is to help you understand a vacuum cleaner’s energy efficiency performance. 1. Energy rating – based primarily on energy consumption and pick-up. 2. Annual energy usage – the amount of energy used over a year. -
Page 8: Technical Data
TECHNICAL DATA (PRODUCT FISCHE) Trade mark Russell Hobbs Model RHBCV2502 Energy efficiency class Annual energy consumption (kWh/year) Carpet cleaning performance class Hard floor cleaning performance class Dust re-emission class Sound power level 78db Rated input power... -
Page 9: Vacuum Feature Diagram
VACUUM FEATURE DIAGRAM (Not Shown) Hose suction control Floor head Carry handle Hose connector Hose entry point Top cover release latch Extension lock Bag full indicator HEPA Filter Cover Extension tube Power button 2 in 1 Crevice/brush Hose Variable power dial Floor surface selector Cord rewind button For Customer Services &... -
Page 10: Vacuum Cleaner Assembly
VACUUM CLEANER ASSEMBLY Before using your vacuum cleaner Remove all packaging and lay out the separate components. Check the unit after unpacking for any visual damage such as: • Misaligned or damaged parts • Damage to the main body and separate components •... - Page 11 VACUUM CLEANER ASSEMBLY Ensure the unit is unplugged before assembling. 1. Ensure there is a dust bag correctly inserted in the vacuum cleaner. With the vacuum cleaner stood upright, release the top cover by pulling the latch towards you. The cardboard collar of the dust bag should slide into the dust bag holder with the arrow facing upwards.
-
Page 12: Using Your Vacuum Cleaner
USING YOUR VACUUM CLEANER Once assembled: 1. The cord is stored inside the unit. Pull the power cord out of the machine to as long as you require and stop when you see the yellow tab. Do not over-extend. If the red tab is visible, then wind the cord back until only the yellow tab is visible. - Page 13 USING YOUR VACUUM CLEANER 5. You can adjust the extension tube length to a comfortable cleaning height. To alter the length of the telescopic handle, a) Push and hold the extension lock in the direction indicated. b) Slide the tube, up or down, to the correct length. 6.
- Page 14 USING YOUR VACUUM CLEANER 8. When using the floor head you can adapt the brush depending on floor type. Please refer to the diagram below: Hard Floors Carpets Tool Selection This vacuum cleaner is supplied with a 2 in 1 crevice and brush tool designed for different cleaning tasks: The tool attaches to either the extension tube or the hose in the same manner as the floor head.
- Page 15 USING YOUR VACUUM CLEANER Changing the dust bag To maintain peak performance, we recommend replacing the dust bag when it reaches no more than ¾ full. There is a “bag full indicator” which will turn red when the dust bag is full: 1.
-
Page 16: Cleaning And Care
CLEANING AND CARE: CLEANING THE EXHAUST FILTER Before you clean the appliance, disconnect the mains plug from the wall socket. 1. Remove the filter cover on the back of the unit. 2. Pull out the HEPA filter and tap over a bin to remove any excess dust. - Page 17 CLEANING AND CARE: CLEANING THE INTERNAL FILTER Before you clean the appliance, disconnect the mains plug from the wall socket. 1. With the vacuum cleaner stood upright, release the top cover by pulling the latch towards you. The The internal filter will be easier to access if you remove the dust bag.
- Page 18 CLEANING AND CARE Before you clean the appliance, disconnect the mains plug from the wall socket. Disassembly 1. Press the cord rewind button to automatically bring the cord back inside the unit for storage. 2. To remove the extension tube, pull it away from the hose. 3.
-
Page 19: Problem Solving
PROBLEM SOLVING PROBLEM POSSIBLE PROBLEM POSSIBLE SOLUTION Power cord/plug damage Check the power cord and plug for signs of damage. The vacuum cleaner is plugged in but does not work Fuse is damaged Check and replace the fuse in the plug. Suction may decrease if the dust bag is more than ¾... -
Page 20: Guarantee And Customer Services
GUARANTEE AND CUSTOMER SERVICES At Russell Hobbs, we take all our customer feedback seriously. Feel free to contact our Product Care Team, on 0345 209 7461 Monday – Friday: 8am-8pm & Saturday: 9am – 1pm, who will be more than happy to assist you. -
Page 21: Spare Parts
SPARE PARTS To check the availability of the following spare parts, simply contact our friendly Customer Services team using the details provided at the bottom of this page. Dust Bags (Model No. VACBAGS5) HEPA Exhaust Filter Hose Floor Head Extension Tube 2 in 1 Crevice / Brush Tool For Customer Services &... -
Page 22: Connection To The Mains Supply
CONNECTION TO THE MAINS SUPPLY This appliance is designed to operate from a mains supply of 220-240V~ 50/60Hz. Check that the voltage marked on the product corresponds with your supply voltage. How to change the fuse 1. Slot the end of a screwdriver into the recess in the fuse holder of the plug. - Page 23 NOTES...
- Page 24 For Customer Services & Spare Parts please call 0345 209 7461 Opening times: Monday - Friday 8am – 8pm & Saturday 9am –1pm Or visit us at www.productcare.co.uk Revision 1.2 Model: RHBCV2502 Produced for G2S Ltd, Wigan, WN2 4AY This symbol is known as the 'Crossed-out wheelie bin Symbol'. When this symbol is marked on a product/batteries, it means that the product/batteries should not be disposed of with your general household waste.
