User Guide

HIGH-SPEED MULTISERVICE TEST MODULE

Power Blazer

88000 Series

Table of Contents

Advertisement

Chapters

Table of Contents

Need help?

Need help?

Do you have a question about the Power Blazer 88000 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for EXFO Power Blazer 88000 Series

Page 1 User Guide HIGH-SPEED MULTISERVICE TEST MODULE Power Blazer 88000 Series...
Page 2 EXFO Inc. (EXFO). Information provided by EXFO is believed to be accurate and reliable. However, no responsibility is assumed by EXFO for its use nor for any infringements of patents or other rights of third parties that may result from its use.
Page 3: Table Of Contents
Contents Certification Information ......................x 1 Introducing the High-Speed Multiservice Test Module ......1 Features ..........................1 Technical Specifications ......................2 Conventions ..........................3 2 Safety Information ..................5 Additional Laser Safety Information ..................7 Installation Instruction Warnings ....................8 3 Getting Started ..................11 Inserting and Removing Test Modules .................11 Inserting and Removing Transceiver Adaptors (TA) ..............12 Turning On the Unit ......................14...
Page 4 6 Test Setup - Test Applications ..............41 iOptics ..........................42 iSAM .............................43 Multi-Channel OTN .......................44 OTN BERT ..........................45 OTN-SONET/SDH BERT ......................47 SONET/SDH BERT ........................50 DSn/PDH BERT ........................53 SONET/SDH - DSn/PDH BERT ....................55 NI/CSU Emulation ........................58 EtherSAM (Y.1564) ........................59 RFC 2544 ..........................61 RFC 6349 ..........................63 EtherBERT ..........................64 Traffic Gen &...
Page 5 8 Test Setup - Test Configurator, Timer, and System ........95 Test Configurator Overview ....................100 Modify Structure Button ....................108 Signal Auto-Detect ......................131 1588 PTP ..........................132 BERT and Unframed BERT ....................139 Cable Test ..........................145 CFP4/CFP8/QSFP/SFP/SFP+/SFP28 ..................147 Clock ..........................148 EtherBERT, FC BERT, BERT (CPRI/OBSAI), and Unframed BERT ..........155 EtherSAM - Burst .......................163 EtherSAM - Global ......................165 EtherSAM - Ramp ......................169...
Page 6 System ..........................325 TA-SFP28 ..........................326 TCP Throughput .........................327 Test Sequence (iOptics) ......................329 Timer ..........................330 Traces (OTN) ........................332 Traces (SONET/SDH) ......................336 Wander ..........................338 9 Test Results ....................341 Alarms/Errors Overview .......................344 Analysis - MTIE/TDEV ......................417 Analysis - Time Error / Time Interval Error ................419 FTFL/PT and PT ........................421 GFP-F/GFP-T ........................423 Graph (RFC 2544) ......................426...
Page 7 Summary (Link OAM) ......................497 Summary (Multi-Channel OTN) ..................499 Summary (NI/CSU Emulation) ....................501 Summary (RFC 2544) ......................502 Summary (RFC 6349) ......................505 Summary (S-OAM and MPLS-TP OAM) ................508 Summary (SyncE) .......................513 Summary (TCP Throughput) ....................516 Summary (Traffic Gen & Mon) ...................519 Summary (Wander) ......................521 Traces - OTN ........................525 Traces - SONET/SDH ......................527 Traffic - Ethernet ........................528...
Page 8 14 Troubleshooting ..................667 Solving Common Problems ....................667 Contacting the Technical Support Group ................668 Transportation ........................668 15 Warranty ....................669 General Information ......................669 Liability ..........................670 Exclusions ...........................671 Certification ........................671 Service and Repairs ......................672 EXFO Service Centers Worldwide ..................673 A Specifications ....................675 viii 88000 Series...
Page 9 B Glossary ....................677 Acronym List ........................677 10G Ethernet Client ......................694 1588 PTP ..........................697 CPRI ...........................703 Ethernet Cables .........................708 G.709 Optical Transport Network (OTN) ................710 Generic Framing Procedure (GFP) ..................727 MPLS Labels ........................739 OBSAI ..........................740 SONET/DSn/SDH/PDH ......................745 SyncE ..........................755 Unicast/Multicast Addresses for Ethernet OAM ..............757 VLAN ID and Priority ......................758 C Remote ToolBox ..................
Page 10 Electronic test and measurement equipment is exempt from FCC part 15, subpart B compliance in the United States of America and from ICES-003 compliance in Canada. However, EXFO Inc. makes reasonable efforts to ensure compliance to the applicable standards. The limits set by these standards are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Page 11 The full text of the EU declaration of conformity is available at the following Internet address: www.exfo.com/library. Laser Your instrument is a Class 1 laser product in compliance with standards IEC 60825-1: 2007/2014 and 21 CFR 1040.10, except for deviations pursuant to Laser Notice...
Page 13: Introducing The High-Speed Multiservice Test Module
Introducing the High-Speed Multiservice Test Module Turnkey field-test solution for deploying, validating, and troubleshooting networks up to 400G. Features Model Features 88200NGE 88260 88400NGE 8870/8880 Intelligent Apps. iOptics iSAM Transport Multi-Channel OTN OTN BERT SONET/SDH BERT OTN-SONET/SDH BERT DSn/PDH BERT SONET/SDH - DSn/PDH BERT NI/CSU Ethernet...
Page 14: Technical Specifications
Introducing the High-Speed Multiservice Test Module Technical Specifications Model Features 88200NGE 88260 88400NGE 8870/8880 Packet Sync 1588 PTP SyncE Wander 8880 Fibre Channel FC BERT Wireless CPRI/OBSAI BERT Technical Specifications To obtain this product’s technical specifications, visit the EXFO Web site at www.exfo.com. 88000 Series...
Page 15: Conventions
Introducing the High-Speed Multiservice Test Module Conventions Conventions Before using the product described in this guide, you should understand the following conventions: ARNING Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury. Do not proceed unless you understand and meet the required conditions.
Page 17: Safety Information
ARNING Use only accessories designed for your unit and approved by EXFO. For a complete list of accessories available for your unit, refer to its technical specifications or contact EXFO.
Page 18 Safety Information MPORTANT When you see the following symbol on your unit , make sure that you refer to the instructions provided in your user documentation. Ensure that you understand and meet the required conditions before using your product. MPORTANT When you see the following symbol on your unit , it indicates that the unit is equipped with a laser source, or that it can be used...
Page 19: Additional Laser Safety Information
Safety Information Additional Laser Safety Information Additional Laser Safety Information This product employs Class 1 Laser transceivers. ARNING When the LASER LED is on or flashing, the module is transmitting an optical signal on the transceiver ports. Note: Refer to the platform’s user guide for additional test equipment safety information and ratings.
Page 20: Installation Instruction Warnings
All wiring and installation must be in accordance with local building and electrical codes acceptable to the authorities in the countries where the equipment is installed and used. ARNING Use only accessories designed for your unit and approved by EXFO. 88000 Series...
Page 21 Safety Information Installation Instruction Warnings AUTION Electrostatic Discharge (ESD) Sensitive Equipment: Plug-in modules can be damaged by static electrical discharge. To minimize the risk of damage, dissipate static electricity by touching a grounded unpainted metal object before removing, inserting, or handling the module. ...
Page 23: Getting Started
Getting Started If the module has been purchased at the same time as the platform, the module is pre-installed with the appropriate software version. Number of Dedicated Modules per Platform The following table lists the maximum number of dedicated modules that can run simultaneously on each platform.
Page 24: Inserting And Removing Transceiver Adaptors (Ta)
Getting Started Inserting and Removing Transceiver Adaptors (TA) Inserting and Removing Transceiver Adaptors (TA) AUTION There is no need to turn off your unit before inserting or removing TA modules. However, inserting/removing TA modules without following the instructions provided in this user documentation could result in the following consequences, depending on the operation underway when the modules are inserted/removed: unexpected behavior of the test applications,...
Page 25 Getting Started Inserting and Removing Transceiver Adaptors (TA) 3. Remove the TA module from its packaging: 3a. Turn the retaining screw counterclockwise until it is Screw loose. Handle 3b. Hold the TA module by the handle and/or the retaining screw (NOT by the connectors) and pull it out.
Page 26: Turning On The Unit
Getting Started Turning On the Unit To remove a TA module from the FTBx-88260 module: 1. Position the FTB-x-88260 module so that its faceplate is facing you. 2. Turn the retaining screw Screw counterclockwise until it is loose. 3. Hold the TA module by the handle Handle and/or the retaining screw (NOT by the connectors) and pull it out.
Page 27: Starting The Module Application
Getting Started Starting the Module Application Starting the Module Application The module can be configured and controlled by starting the application(s) as described in the following table. Module Application Comment Power Blazer 88200NGE 88260 88400NGE 8880 Power Blazer Only one application can run at once. 8870 OpticalRF BBU-Emulation...
Page 29: Physical Interfaces And Leds
Physical Interfaces and LEDs This section describes all connectors (ports) and LEDs available on the 88000 Series. AUTION To prevent exceeding the maximum input/output power level, please refer to this product’s technical specifications at www.exfo.com. FTBx-88200NGE SFP+ CFP4 QSFP REF OUT EXT LCK 1.
Page 30 Physical Interfaces and LEDs FTBx-88400NGE EXT CLK REF OUT CFP8 SFP56 SFP28 QSFP28 1. Laser radiation emitted from this port when LASER LED is on. 88000 Series...
Page 31 Physical Interfaces and LEDs FTBx-8870/8880 LINK/ACT LASER EXT CLK DUPLEX LINK/RX RJ45 SFP+ SFP+ RJ48C BANTAM TX/RX2 1. Laser radiation emitted from this port when LASER LED is on. Power Blazer...
Page 32: Port Availability On The 88000 Series
Physical Interfaces and LEDs Port Availability on the 88000 Series Port Availability on the 88000 Series 88200NGE The following table shows the list of available ports as well as a description and the signals supported on the module. Port Description Supported Signal(s) Labelled SFP+...
Page 33 Physical Interfaces and LEDs Port Availability on the 88000 Series 88260 The following table shows the list of Transceiver Adapter (TA) supported on each port of the FTBx-88260 module. Port Description Supported Transceiver Adapter (TA) Labelled TA left port TA-SFP28 TA right port TA-SFP28 The following table shows the list of port as well as a description and the...
Page 34 Physical Interfaces and LEDs Port Availability on the 88000 Series 88400NGE The following table shows the list of available ports as well as a description and the signals supported on the module. Port Description Supported Signal(s) Labelled SFP28 Optical IN/OUT port SFP28 Ethernet 100/1000 Mbit/s, 10 Gbit/s, 25 Gbit/s optical transceiver SFP56...
Page 35 Physical Interfaces and LEDs Port Availability on the 88000 Series 8870/8880 The following table shows the list of available ports as well as a description and the signals supported for each module. Module Connector Labelled Description and supported signal(s) 8870 8880 Bantam BANTAM...
Page 36: Transceivers
Before inserting an optical module into the interface receptacle, inspect the receptacle to make sure nothing is inside. ARNING Use only EXFO supported transceivers. Refer to www.exfo.com for the list of supported transceivers. Using non-supported transceivers can affect the performance and accuracy of the test.
Page 37: Leds
Physical Interfaces and LEDs Connector type is BNC for coaxial 75-ohm cable connection. An adapter cable (BNC to Bantam) is required for Bantam external clock connection (not supplied). The connector type is SMB for coaxial 75-ohm cable connection. An adapter cable (SMB to Bantam) is required for Bantam connection (not supplied).
Page 39: Graphical User Interface Overview
Graphical User Interface Overview This chapter describes the Power Blazer Series graphical user interface. Main Application Window The following main application window is displayed when the Power Blazer application is started. Title Bar Global Indicator Test Control Main Window Test Menu Application Buttons Status Bar...
Page 40: Navigation Buttons
Graphical User Interface Overview Navigation Buttons Navigation Buttons Navigation buttons appear when there is not enough room on one page to display all available test applications. The left and right arrow buttons allow respectively accessing the previous or next window. The buttons in between the left and right arrow buttons allow directly selecting the window for the type of test application listed.
Page 41 Pattern Analysis (Live) check box is selected. Connection established between two testing units in Dual Test Set Ethernet (DTS), EXFO|Worx Interop, or in Loop Up mode. Connection not established between two testing units in Dual Test Set Ethernet (DTS), EXFO|Worx Interop, or in Loop Up mode.
Page 42 Status Bar Icon Description Test Application and/or text Remote unit is busy (locked) in EXFO|Worx Interop operation mode. Ethernet Loopback Tool enabled on the port unused by the main test Ethernet application. Clock synchronization signal clock. The clock icon is followed by the...
Page 43: Title Bar
Graphical User Interface Overview Title Bar Title Bar The Title Bar displays the module’s slot number in brackets, the software application name and the minimize, maximize, and close buttons. Global Indicator The global indicator area displays the global pass/fail verdict, global alarm, and the test duration.
Page 44 Graphical User Interface Overview Global Indicator Global Verdict Reports the global test verdict status when supported by the test application and enabled (when applicable). Verdict Description PASS is displayed with a green background when all result values meet the configured threshold PASS criteria.
Page 45: Test Control
Graphical User Interface Overview Test Control Test Timer The test timer without the timer icon indicates the time elapsed since the beginning of the test. No timer action is active. The test timer format is “day hour:minute:second”. Timer The timer icon with Armed indicates that a start time is active. The timer icon with the Test Timer indicates that a duration and/or a stop time is active.
Page 46: Application Buttons
Graphical User Interface Overview Application Buttons Application Buttons Help (?) displays the help information related to the content of the  active main window. It is also possible to navigate through the remainder of the help information. Exit (x) closes the application. ...
Page 47 Traffic Scan LINK-OAM Link OAM TST-OAM Test Over Service OAM DUAL-PORT Dual Port Test DP_40-100GE Dual Port at 40/100GE RFC6349 RFC 6349 test application (up to 10GE) RFC6349_40-100GE RFC 6349 test application (40/100GE) RFC6349-EXFOWorx EXFO|Worx Interop Operation Mode Power Blazer...
Page 48 Graphical User Interface Overview Application Buttons Software Option Description DTS-NAT NAT traversal for DTS applications ADV-FILTERS Advanced filtering MPLS MPLS Encapsulation (up to 10GE) MPLS_40-100GE MPLS Encapsulation (40/100GE) Ethernet over Ethernet Encapsulation (up to 10GE) EoE_40-100GE Ethernet over Ethernet Encapsulation (40/100GE) PBBTE Provider Backbone Bridge Encapsulation (up to 10GE) PBBTE_40-100GE...
Page 49: Zoomed-In/Zoomed-Out Views
Graphical User Interface Overview Zoomed-In/Zoomed-Out Views Software Option Description DS3-G747 ITU-T Recommendation G.747 Plesiochronous Digital Hierarchy NI-CSU NI/CSU Emulation Zoomed-In/Zoomed-Out Views Some configuration and result blocks give access to zoomed views allowing more detailed configurations/results. The block title contains the magnifier (+) icon when a zoomed view is available.
Page 50: Keyboard Usage
Graphical User Interface Overview Keyboard Usage Keyboard Usage The GUI pops up different keyboards to modify data. Following are the usual keyboard keys: Left arrow moves the cursor one position to the left.  Right arrow moves the cursor one position to the right. ...
Page 51 Graphical User Interface Overview Keyboard Usage For multiplexing keyboard, tap on all mapped signals that have to be added/removed to/from the test path. A mapped signal with an orange background color is part of the test path. A mapped signal with a gray background color is not part of the test path.
Page 52 Graphical User Interface Overview Keyboard Usage The Trace message keyboard allows entering alphanumerical characters (ITU T.50) required for J0/J1/J2/TTI Trace fields. Tap the Control Characters button to access these characters. ITU T.50 Characters b7 to b1 Character Description b7 to b1 Character Description 000 0000 Null...
Page 53: Test Setup - Test Applications
Test Setup - Test Applications The Power Blazer offers the following test applications. Available on Type Application Page 88200NGE 88260 88400NGE 8870 / 8880 Intelligent iOptics Apps iSAM Transport OTN BERT Multi-Channel OTN SONET/SDH BERT OTN-SONET/SDH BERT DSn/PDH BERT SONET/SDH - DSn/PDH BERT NI/CSU Emulation Ethernet EtherSAM (Y.1564)
Page 54: Ioptics
Typical iOptics test application:  EXFO Module Supported Interfaces/Rates: 40G/100G/OTU3/OTU3e1/OTU3e2/OTU4  parallel interfaces and all serial interfaces up to 10G/OTU2f (refer to Rate on page 245 for more information).
Page 55: Isam
The Dual Test Set test allows bi-directional testing between two compatible modules providing independent results for each test direction. The results from local-to-remote and remote-to-local are available on the local testing unit. Typical iSAM test applications:  EXFO Module EXFO Module Manual or Network Remote under test...
Page 56: Multi-Channel Otn
The Multi-Channel OTN test application validates individual channel connectivity with a device under test by allowing concurrent generation and monitoring of all channels of a single or mixed ODUmux test structure. Typical Multi-Channel OTN test applications:  EXFO Module Network under test Testing Unit DUT Loopback...
Page 57: Otn Bert
OTN BERT OTN BERT Allows OTN (framed and unframed), OTN multiplexing, and EoOTN traffic generation with specific test pattern for Bit Error Rate analysis. Typical OTN BERT test applications:  EXFO Module Network under test Testing Unit DUT Loopback EXFO Module...
Page 58 Test Setup - Test Applications OTN BERT 88000 Series...
Page 59: Otn-Sonet/Sdh Bert
Allows the validation of the SONET/SDH embedded in OTN transport protocol by performing a BERT test to check the traffic or payload stability over a network facility. Typical OTN-SONET/SDH BERT test applications:  EXFO Module Network under test Testing Unit DUT Loopback...
Page 60 Test Setup - Test Applications OTN-SONET/SDH BERT Path/Mapping  The OTN-SONET/SDH BERT test application offers the following path/mapping structures depending on the inserted transceiver and enabled options. For OTN-SONET BERT: up to OTU4 for 88200NGE and up to OTU2 for 8870/8880.
Page 61 Test Setup - Test Applications OTN-SONET/SDH BERT For OTN-SDH BERT: up to OTU4 for 88200NGE and up to OTU2 for 8870/8880. Power Blazer...
Page 62: Sonet/Sdh Bert
Allows the validation of the SONET or SDH transport protocol by performing a BERT test to check the traffic or payload stability over a network facility. Typical SONET/SDH BERT test applications:  EXFO Module Network under test Testing Unit DUT Loopback...
Page 63 Test Setup - Test Applications SONET/SDH BERT Path/Mapping  The SONET/SDH BERT test application offers the following path/mapping structures depending on the inserted transceiver, and enabled options. For SONET BERT Power Blazer...
Page 64 Test Setup - Test Applications SONET/SDH BERT For SDH BERT 88000 Series...
Page 65: Dsn/Pdh Bert
Allows validation of the DSn or PDH transport protocol by performing a BERT test to check the traffic or payload stability over a network facility. Typical DSn/PDH BERT test applications:  EXFO Module Network under test Testing Unit DUT Loopback...
Page 66 Test Setup - Test Applications DSn/PDH BERT Path/Mapping  The DSn/PDH BERT test application offers the following path/mapping structures depending on model and enabled options. For DSn: Note: It is possible to enable DS0/E0 from Signal - Signal Configuration (DSn/PDH) on page 294.
Page 67: Sonet/Sdh - Dsn/Pdh Bert
Allows validation of the DSn or PDH embedded in SONET or SDH transport protocol by performing a BERT test to check the traffic or payload stability over a network facility. Typical SONET/SDH - DSn/PDH BERT test applications:  EXFO Module Network under test Testing Unit DUT Loopback...
Page 68 Test Setup - Test Applications SONET/SDH - DSn/PDH BERT Path/Mapping  The SONET/SDH - DSn/PDH BERT test application offers the following path/mapping structures depending on the model and enabled options. For SONET: 88000 Series...
Page 69 Test Setup - Test Applications SONET/SDH - DSn/PDH BERT For SDH: Power Blazer...
Page 70: Dsn/Pdh Bert
Test Setup - Test Applications NI/CSU Emulation NI/CSU Emulation Allows DS1 testing in NI/CSU (Network Interface/Customer Service Unit) emulation mode. Typical NI/CSU Emulation test applications: EXFO Module Network under test Test Head NI/CSU Emulation EXFO Module EXFO Module DSn/PDH BERT...
Page 71: Ethersam (Y.1564)
Test Setup - Test Applications EtherSAM (Y.1564) EtherSAM (Y.1564) EtherSAM can simulate all types of services that will run on the network and simultaneously qualify all key SLA parameters for each of these services. Moreover, it validates the QoS mechanisms provisioned in the network to prioritize the different service types, resulting in more accurate validation and much faster deployment and troubleshooting.
Page 72 Test Setup - Test Applications EtherSAM (Y.1564) Typical EtherSAM (Y.1564) test applications:  EXFO Module EXFO Module Network under test Testing Unit Loopback Unit EXFO Module EXFO Module Network under test Testing Unit Remote Unit EXFO Module Network under test Testing Unit Supported Interfaces/Rates: 10M to 100G.
Page 73: Rfc 2544
Test Setup - Test Applications RFC 2544 RFC 2544 RFC 2544 allows Ethernet Throughput, Back-to-Back, Frame Loss, and Latency performance testing in accordance with RFC 2544 specifications. The RFC 2544 test, in single port configuration, has to be executed in conjunction with a remote module.
Page 74 Test Setup - Test Applications RFC 2544 Typical RFC 2544 test applications:  EXFO Module EXFO Module Network under test Testing Unit Loopback Unit EXFO Module EXFO Module Network under test Testing Unit Remote Unit EXFO Module Network under test Testing Unit Supported Interfaces/Rates: 10M to 100G.
Page 75: Rfc 6349
RFC 6349 is used to confirm that the Ethernet service is able to properly carry TCP traffic. The RFC 6349 test has to be executed in conjunction with a remote compatible module in RFC 6349 Dual Test Set or EXFO Worx Interop operation mode allowing bidirectional testing. The test provides independent results for each test direction.
Page 76: Etherbert
EtherBERT Allows Ethernet Layer 1 up to Layer 4 and Unframed Layer 1 traffic generation with specific test pattern for Bit Error Rate analysis. Typical EtherBERT test applications:  EXFO Module EXFO Module Network under test Testing Unit Loopback Unit...
Page 77 Test Setup - Test Applications EtherBERT EXFO Module EXFO Module Network under test Testing Unit Loopback Units Supported Interfaces/Rates: 10M to 400G. Dual Port topology is  available for either rates up to 10G WAN or for rates 40/100G. Power Blazer...
Page 78: Traffic Gen & Mon
Test Setup - Test Applications Traffic Gen & Mon Traffic Gen & Mon Allows Ethernet traffic generation and analysis of up to 16 streams. Typical Traffic Gen & Mon test applications:  EXFO Module EXFO Module Network under test Testing Unit Loopback Unit...
Page 79 Test Setup - Test Applications Traffic Gen & Mon EXFO Module EXFO Module Network under test Testing Unit Loopback Units Supported Interfaces/Rates: 10M to 100G. Dual Port topology is only  available for rates up to 10G WAN. Power Blazer...
Page 80: Smart Loopback
The Smart Loopback test can be created locally (refer to Ethernet Test Applications on page 87) or remotely using an EXFO unit (refer to Discover Remote Button on page 636) or a Third-Party device (see Third-Party Remote Loopback on page 69).
Page 81 This feature is used for unidirectional testing, where the test stream is transmitted from the third party device to a remote EXFO device. The looped back test stream is received and analyzed by the third-party device.
Page 82: Through Mode
Typical Through Mode test application:  EXFO Module Network Ethernet Testing Unit Network Ethernet in Through Mode Supported Interfaces/Rates: 10M to 10GE LAN, and 100GE;...
Page 83: Tcp Throughput
TCP Throughput and windows size statistics will be gathered throughout the test. Typical TCP Throughput test application:  EXFO Module EXFO Module Network under test Local Testing Unit Remote Unit Supported Interfaces/Rates: 10M to 1G.
Page 84: Carrier Ethernet Oam
(Y.1731/MEF). Connectivity Fault Management provides the capability for detecting,  verifying, and isolating connectivity failure (Y.1731/802.1ag/MEF). Typical Ethernet OAM and MPLS TP OAM test applications:  EXFO Module Peer MEP Local MEP EXFO Module EXFO Module Local MEP Smart Loopback with S-OAM Responder enabled.
Page 85 Link OAM The Link OAM test validates the Link OAM protocol capabilities and the Ethernet link connection of a remote equipment. Typical Link OAM test application:  EXFO Module NID/Switch Testing Equipment Supported Interfaces/Rates: 10M to 10G LAN/WAN.  Power Blazer...
Page 86: Cable Test
Category 5, Category 5e/Class D, and Category 6e/Class E. Note: Cable test result is reliable for cable length of 10 meters to 120 meters (32.81 feet to 393.7 feet). Typical Cable Test applications:  EXFO Module UTP cable Testing Unit Far end equipment EXFO Module...
Page 87 The 1588 PTP (Precision Time Protocol) test application handles the 1588 PTP communication with the Grand Master (GM) clock, collects statistics related to packets, and monitors the clock Quality Level. Typical 1588 PTP test application:  EXFO Module Grand Master Clock Source Network under test Testing Unit GM Clock Supported Interfaces/Rates: 10M to 10G LAN.
Page 88: Synce
SyncE The Synchronous Ethernet (SyncE) test application provides elementary test primitives to interactively validate the clock management functions of a SyncE capable network equipment. Typical SyncE test applications:  EXFO Module Network under test Testing Unit Network Equipment EXFO Module...
Page 89: Wander
Time Error is defined as the difference between the time reported by a clock signal under test and the time reported by a reference clock. Typical Wander test applications:  EXFO Module Network under test Testing Unit Supported Interfaces/Rates: 100/1000M Electrical, 10GE LAN, ...
Page 90 FC-2 layer allowing BER testing for link integrity measurements, latency, buffer-to-buffer credit measurements for optimization as well as login capabilities. Typical Fibre Channel BERT test applications:  EXFO Module Network under test Testing Unit DUT Loopback...
Page 91: Cpri/Obsai Bert
Test Setup - Test Applications CPRI/OBSAI BERT CPRI/OBSAI BERT The CPRI/OBSAI BERT test application offers the capability to test the fronthaul and dark fiber for Unframed rates and Framed L2 protocol, round trip delay, and Service Disruption Time measurements. The Common Public Radio Interface (CPRI) is an industry cooperation aimed at defining a publicly available specification for the key internal interface of radio base stations between the Radio Equipment Control (REC) and the Radio Equipment (RE).
Page 92 Test Setup - Test Applications CPRI/OBSAI BERT Typical CPRI/OBSAI BERT test applications:  EXFO Module EXFO Module Unframed, Network Framed L2 under test Testing Unit Testing Unit EXFO Module Unframed Network under test Testing Unit Physical Loopback RRH or EXFO Module...
Page 93: Selecting And Starting A Test
Selecting and Starting a Test A test can be created either by selecting the test from the Test Applications tab or by loading a previously saved configuration (refer to Save/Load Button on page 653 for more information). Intelligent Apps iOptics To select, configure, and start iOptics: 1.
Page 94 Selecting and Starting a Test Intelligent Apps 4. Ensure the laser is ON and tap the Start button from the right navigation bar to start the test (refer to Start/Stop|TX Button on page 657). The Summary result page will be automatically displayed when the test is started.
Page 95 Selecting and Starting a Test Intelligent Apps iSAM To select, configure, and start iSAM: 1. From the test menu, tap Setup. 2. From the Test Applications tab, under Intelligent Apps, tap the iSAM icon. 3. From the Test Configurator tab configure the interface structure and its parameters.
Page 96 Selecting and Starting a Test Intelligent Apps 3b. From the Network block, either select the basic test parameters or click on More for all settings (refer to Network Details (iSAM) on page 226). The total bandwidth and the estimated test duration are displayed.
Page 97: Transport Test Applications
Selecting and Starting a Test Transport Test Applications Transport Test Applications To select, configure, and start a Transport test: 1. From the test menu, tap Setup. 2. From the Test Applications tab, under Transport, tap a test icon. 3. From the Test Configurator tab configure the signal structure and its parameters.
Page 98 Selecting and Starting a Test Transport Test Applications 3e. Tap the test block to configure the specific test settings (refer to page 95). Not available with NI/CSU Emulation test application. 3f. Tap the clock block to configure the clock synchronization (refer to Clock on page 148).
Page 99: Ethernet Test Applications
Selecting and Starting a Test Ethernet Test Applications Ethernet Test Applications To select, configure, and start an Ethernet test: 1. From the test menu, tap Setup. 2. From the Test Applications tab, under Ethernet, tap a test icon. 3. From the Test Configurator tab configure the interface structure and its parameters.
Page 100 Selecting and Starting a Test Ethernet Test Applications 3d. Tap the protocol block to configure the frame structure and its parameters (refer to page 97). For RFC 2544, EtherBERT, and Traffic Gen & Mon in Dual Port topology, there is a protocol block for each port.
Page 101: Sync Test Applications
Selecting and Starting a Test Sync Test Applications Sync Test Applications To select, configure, and start a Sync test: 1. From the test menu, tap Setup. 2. From the Test Applications tab, under Sync, tap a test icon. 3. From the Test Configurator tab configure the interface structure and its parameters.
Page 102 Selecting and Starting a Test Sync Test Applications 4. Tap the Timer tab to automatically start and/or stop the test at a given time or for a specific duration (refer to Timer on page 330). Not supported with Wander test application. 5.
Page 103: Fibre Channel Test Application
Selecting and Starting a Test Fibre Channel Test Application Fibre Channel Test Application To select, configure, and start a Fibre Channel test: 1. From the test menu, tap Setup. 2. From the Test Applications tab, under Fibre Channel, tap the FC BERT test icon.
Page 104 Selecting and Starting a Test Fibre Channel Test Application 3d. Tap the test block to configure the specific test settings (refer to page 155). 3e. Tap the clock block to configure the clock synchronization (refer to Clock on page 148). 4.
Page 105: Wireless Test Application
Selecting and Starting a Test Wireless Test Application Wireless Test Application To select, configure, and start a Wireless test: 1. From the test menu, tap Setup. 2. From the Test Applications tab, under Wireless, tap the CPRI/OBSAI BERT test icon. 3.
Page 106 Selecting and Starting a Test Wireless Test Application 3c. Tap the test block to configure the specific test settings (refer to page 155). For Dual Port topology, there is a test block for each port. 3d. For Framed L2 in Base Station emulation mode, tap the clock block to configure the clock synchronization (refer to Clock on page 148).
Page 107: Test Setup - Test Configurator, Timer, And System
Test Setup - Test Configurator, Timer, and System The Setup menu offers the following structure: Test Configurator for Intelligent Apps test application.  Test Application Block Subtab or Pop Up Page iOptics Optical Device Under Test Optical Device Under Test Details Test Sequence iSAM...
Page 108 Test Setup - Test Configurator, Timer, and System Test Configurator for Transport test applications.  Available with SONET/ OTN- Subtab or Multi- SONET/ DSn/ SDH - Block Page SONET/ NI/CSU Pop Up Channel DSn/ BERT Emulation BERT BERT BERT BERT Button Modify Structure Signal Auto-Detect...
Page 109 Test Setup - Test Configurator, Timer, and System Test Configurator for Ethernet test applications.  Test Application Block Subtab or Pop Up Page Button Modify Structure Interface CFP4/CFP8/QSFP/SFP28/SFP/SFP+ Frequency Interface Network TA-SFP28 Protocol MAC/IP/UDP Services - Global Services - Profile Streams - Global Streams - Profile Test...
Page 110 Test Setup - Test Configurator, Timer, and System Test Configurator for Sync test applications.  Test Application Block Subtab or Pop Up Page 1588 PTP SyncE Wander Button Modify Structure Interface Interface Network SFP/SFP+ Test 1588 PTP SyncE Wander External External Reference Reference No configuration available.
Page 111 Test Setup - Test Configurator, Timer, and System Test Configurator for Wireless test application.  Test Application Block Subtab or Pop Up Page CPRI/OBSAI BERT Button Modify Structure Interface Interface SFP/SFP+ Test BERT and Unframed BERT Timer, see page 330. ...
Page 112: Test Configurator Overview
Test Setup - Test Configurator, Timer, and System Test Configurator Overview Test Configurator Overview The Test Configurator tab displays the interconnected blocks composing the test structure. Each block of the test structure gives an overview of its configuration/status. Availability of each block depends on the selected test application and its structure.
Page 113 Test Setup - Test Configurator, Timer, and System Test Configurator Overview iSAM: Network Block Remote Operation Mode Local Block Remote Block The block arrangement represents the network under test. From any block, either select the basic parameters or click on More for all settings.
Page 114 Test Setup - Test Configurator, Timer, and System Test Configurator Overview Transport Test Applications:  Modify Structure Test Application Topology Port Status Interface Block Protocol Block Test Block Physical Interface Port Arrows Clock Block Physical Clock Port Ethernet Test Applications: ...
Page 115 Test Setup - Test Configurator, Timer, and System Test Configurator Overview Sync Test Applications:  Modify Structure Test Application Interface Block Test Block Physical Interface Port Arrows Physical External External Reference Reference Port Block Fibre Channel Test Application:  Modify Structure Test Application Interface Block Protocol Block...
Page 116 Test Setup - Test Configurator, Timer, and System Test Configurator Overview Test Application indicates the selected test application.  Topology, for Transport Test Applications, indicates the selected  test topology. Modify Structure button, allows the configuration of the physical  port and the signal interface structure.
Page 117 Port A/B - The battery for the insertion counter is The battery is low and must be replaced by an low, please contact EXFO Support EXFO authorized service center. Port A/B - The battery for the insertion counter is...
Page 118 Test Setup - Test Configurator, Timer, and System Test Configurator Overview Arrows are used to indicate the interconnection between blocks as  well as the direction of the clock and data flow. A line with an arrow on both ends indicates a bidirectional communication (TX/RX).
Page 119 Test Setup - Test Configurator, Timer, and System Test Configurator Overview Clock Block displays an overview of the clock settings and status.  Tap on the clock area to change the settings and to see detailed status. For Dual Port topology, the clock block is not present but the clock is set to Internal.
Page 120: Modify Structure Button
Test Setup - Test Configurator, Timer, and System Modify Structure Button Modify Structure Button From the Test menu, tap Setup, Test Configurator, and the Modify Structure button. For Transport Test Applications TX/RX allows the configuration of the following parameters for either TX/RX, TX1/RX1 and RX2, TX, or RX depending on the selected topology.
Page 121 Test Setup - Test Configurator, Timer, and System Modify Structure Button Test Interface/Rate DS1 [1.544 Mbit/s] DS3 [44.736 Mbit/s] E1 [2.048 Mbit/s] E3 [34.368 Mbit/s] E4 [139.264 Mbit/s] NI/CSU Emulation Connector allows the selection of the module’s port.  Connector Interface/Rate 8870/8880 88200NGE...
Page 122 Test Setup - Test Configurator, Timer, and System Modify Structure Button Connector Interface/Rate 8870/8880 88200NGE DS1 [1.544 Mbit/s] Bantam RJ48C E1 [2.048 Mbit/s] Bantam RJ48C DS3 [44.736 Mbit/s] E3 [34.368 Mbit/s] E4 [139.264 Mbit/s] Availability of connectors depend on the model. This port accepts QSFP+ or QSFP28 transceivers.
Page 123 Test Setup - Test Configurator, Timer, and System Modify Structure Button Framing  Note: For OTN BERT, and SONET/SDH BERT test applications for rates up to 10G, the framing is set to Framed. For OTN BERT test application, parallel interfaces, allows the selection of the test framing type.
Page 124 Test Setup - Test Configurator, Timer, and System Modify Structure Button 4 Unframed Physical Lanes: Independent test pattern in each  physical lane. Available with: OTU3 (4 Lanes) [43.018 Gbit/s], OTU3e1 (4 Lanes) [44.571 Gbit/s], OTU3e2 (4 Lanes) [44.583 Gbit/s], and OTU4 (4 Lanes) [111.81 Gbit/s] 88000 Series...
Page 125 Test Setup - Test Configurator, Timer, and System Modify Structure Button OTN Multiplexing - Config Mux button allows the selection of the OTN  test mapping including the selection of the payload type (PT20 or PT21) when applicable. Refer to OTN BERT on page 45 and OTN-SONET/SDH BERT on page 47 for supported path/mapping.
Page 126 Test Setup - Test Configurator, Timer, and System Modify Structure Button Interface/Rate OTN Multiplexing OTU4 (4 Lanes) [111.81 Gbit/s] ODU4 (default) ODU4/ODU3 ODU4/ODU3/ODU2 ODU4/ODU3/ODU2/ODU1 ODU4/ODU3/ODU2/ODU1/ODU0 ODU4/ODU3/ODU1 ODU4/ODU3/ODU0 ODU4/ODU2 ODU4/ODU2/ODU1/ODU0 ODU4/ODU2/ODU1 ODU4/ODU2/ODU0 ODU4/ODU2/ODUflex ODU4/ODU1 ODU4/ODU1/ODU0 ODU4/ODU0 ODU4/ODU2e ODU4/ODU1e ODU4/ODUflex Only available on 88200NGE. 88000 Series...
Page 127 Test Setup - Test Configurator, Timer, and System Modify Structure Button Embedded SONET/SDH, only available with OTN-SONET/SDH BERT  test application, allows the selection of the embedded SONET/SDH signal. OTN Multiplexing Embedded SONET/SDH ODU4/ODU3 OC-768, STM-256 ODU3 ODU4/ODU3/ODU2 OC-192, STM-64 ODU4/ODU2 ODU3/ODU2 ODU2...
Page 128 Test Setup - Test Configurator, Timer, and System Modify Structure Button SONET/SDH Multiplexing - Config Mux button allows the selection of  SONET/SDH multiplexing. Available with OTN-SONET/SDH and SONET/SDH BERT test applications. Interface/Rate or Embedded SONET/SDH Multiplexing SONET/SDH OC-768 STS-768c, STS-192c, STS-48c, STS-12c, STS-3c, STS-1 STM-256 AU-4-256c, AU-4-64c, AU-4-16c, AU-4-4c, AU-4, AU-3 STS-192c, STS-48c, STS-12c, STS-3c, STS-1, STS-1/VT2,...
Page 129 Test Setup - Test Configurator, Timer, and System Modify Structure Button DSn/PDH Multiplexing, available with DSn/PDH test application,  allows the selection of the DSn/PDH multiplexing. Interface/Rate DSn/PDH Multiplexing None (default), DS1, E1 None None (default), E3, E3/E2/E1 None (default), E2/E1 None Client allows the selection of either Pattern (default) or an EoOTN ...
Page 130 Test Setup - Test Configurator, Timer, and System Modify Structure Button Topology allows the selection of the network test topology. Only  Coupled (TX=RX) is available with Multi-Channel OTN. Coupled (TX=RX) uses the same settings for both the TX and RX ...
Page 131 Test Setup - Test Configurator, Timer, and System Modify Structure Button Through Intrusive loops the RX signal to the TX port with TX  overwrite capabilities. Only available with OTN rates. Dual RX uses two DS1 or DS3 signals at the same time. Both RX ...
Page 132 Test Setup - Test Configurator, Timer, and System Modify Structure Button For Ethernet Test Applications Port 1 and Port 2 are only displayed when Dual Port topology is  selected and allows configuring each port individually. Interface/Rate choices depend on the selected test and the rates ...
Page 133 Test Setup - Test Configurator, Timer, and System Modify Structure Button PHY Type allows selecting the 100GE (4 Lanes) CFP4/QSFP transceiver  PHY type: LR4/ER4 (default), SR4, CWDM4, CLR4, or Other. The PHY type when set to any except LR4/ER4, allows enabling RS-FEC (see page 182);...
Page 134 Test Setup - Test Configurator, Timer, and System Modify Structure Button Framing, available for EtherBERT test application, allows the selection  of the test framing type; otherwise the framing is set to Framed Layer 2. See Network on page 220 for more information on frame format. The framing is not configurable and set to Framed Layer 2 for 40GE/100GE dual port topology and for 400GE test.
Page 135 Test Setup - Test Configurator, Timer, and System Modify Structure Button Unframed (Interop) is only available with optical interface up  to 25GE: For Seed A and Seed B, available with 10G LAN and 25G, the pattern is generated by the PCS scrambler from a specific seed. The pattern is not encoded.
Page 136 Test Setup - Test Configurator, Timer, and System Modify Structure Button 20 Unframed PCS: Independent infinite length test pattern in each  PCS lane (no blocks and no lane markers). Available with 100GE (4 Lanes). 4 Unframed XLAUI: Independent infinite length test pattern in ...
Page 137 Test Setup - Test Configurator, Timer, and System Modify Structure Button Loopback Mode  Note: Only available for Smart Loopback Ethernet test application. Transparent (Pseudo-Physical) check box when selected (cleared by default) determines that the Smart Loopback operates as a physical loopback by transmitting all received frames unaltered and without discrimination.
Page 138 Test Setup - Test Configurator, Timer, and System Modify Structure Button For Sync Test Applications Interface/Rate: Select the desired interface rate. Choices depend on  the selected test and the rates available on the module. Test Interface/Rate 1588 PTP 10GE LAN SyncE 1GE Optical 100M Optical...
Page 139 Test Setup - Test Configurator, Timer, and System Modify Structure Button Connector: Allows the selection of the module’s port available for the  selected interface/rate. Connector Interface/Rate 8870/8880 88200NGE 10GE LAN Port 1 - SFP+ Port 1 - SFP+ 1GE Optical Port 2 - SFP+ 100M Optical 10/100/1000M Electrical...
Page 140 Test Setup - Test Configurator, Timer, and System Modify Structure Button For Fibre Channel Test Application Interface/Rate choices depend on the rates available on the module.  Connector Interface/Rate 8870-8880 88200NGE Port 1 - SFP+ Port 1 - SFP+ Port 2 - SFP+ Availability of connectors depend on the model.
Page 141 Test Setup - Test Configurator, Timer, and System Modify Structure Button For Wireless Test Application Port 1 and Port 2 are only displayed when Dual Port topology is  selected and allows configuring each port individually. Interface/Rate allows the selection of the interface rate. ...
Page 142 Test Setup - Test Configurator, Timer, and System Modify Structure Button Emulation Mode is available with Framed L2  Base Station (default) is used to validate the connectivity with the  RRH. For CPRI, it initiates the start-up sequence and provides synchronization with the RRH.
Page 143: Signal Auto-Detect
Test Setup - Test Configurator, Timer, and System Signal Auto-Detect Signal Auto-Detect The Signal Auto-Detect allows the detection of the DS1/DS3 interface Line Coding (DS1), Framing, and Test Pattern. Signal Auto-Detect is only available: with DS1 and DS3 interfaces.  when the test is stopped.
Page 144 Test Setup - Test Configurator, Timer, and System 1588 PTP 1588 PTP From the Test menu, tap Setup, Test Configurator, and the 1588 PTP test block. Note: Refer to Status Bar on page 28 for PTP link status. Profile  ITU G.8265.1 (default), also called Telecom Profile, is for ...
Page 145 Test Setup - Test Configurator, Timer, and System 1588 PTP is the IP address of the Grand Master Clock used by GM IP Address  the 1588 PTP function to communicate with it. Quick Ping button allows testing if the Grand Master IP address can ...
Page 146 Test Setup - Test Configurator, Timer, and System 1588 PTP Message Rate  Announce determines the transmission interval of the Announce  messages: Configurable for G.8265.1: 1 msg/16s, 1 msg/8s, 1 msg/4s, 1 msg/2s (default), 1 msg/s, 2 msg/s, 4 msg/s, or 8 msg/s. For G.8275.1, indicates the announce rate log message interval.
Page 147 Test Setup - Test Configurator, Timer, and System 1588 PTP GM Info  Note: Only available when Grand Master clock information is available. The Grand Master Information window displays the decoded clock information. For G.8265.1 only: Identity reports the 8-byte identification code of the Grand Master ...
Page 148 Test Setup - Test Configurator, Timer, and System 1588 PTP For both G.8265.1 and G.8275.1: Clock Class reports the description and code of the Grand Master  Clock Class. Code Description 0-5, 8-12, 15-51, 53-57, 59-67, 123-132, 171-186, 188-192, 194-215, Reserved 233-247, 249-254 Sync to primary reference...
Page 149 Test Setup - Test Configurator, Timer, and System 1588 PTP Alarm Timeout/Threshold Note: The following parameters are also used to declare the Pass/Fail verdict. Receipt Timeout defines the threshold used to declare a Loss  Announce or Loss Sync message alarm: 2 to 255 messages (default is 3 messages).
Page 150 Test Setup - Test Configurator, Timer, and System 1588 PTP Pass/Fail Verdict Pass/Fail Verdict check box when selected (default) enables the use of the pass/fail verdict. The global pass/fail verdict is based on the following criteria: alarms (Link Down, Loss Sync, Loss Announce, Unusable (G.8265.1), and/or QL Mismatch (when QL Mismatch Monitoring is enabled)), or the test is automatically aborted (service request denied, session canceled, or no reply for G.8265.1;...
Page 151: Bert And Unframed Bert
Test Setup - Test Configurator, Timer, and System BERT and Unframed BERT BERT and Unframed BERT Note: Available with Pattern client. For EtherBERT unframed test up to 10GE, refer to EtherBERT, FC BERT, BERT (CPRI/OBSAI), and Unframed BERT on page 155. From the Test menu, tap Setup, Test Configurator, and tap on the BERT or Unframed BERT block.
Page 152 Test Setup - Test Configurator, Timer, and System BERT and Unframed BERT TX Pattern/RX Pattern sets respectively the TX and RX test pattern.  OTN, SONET/SDH, and EtherBERT 40GE/100GE Unframed: Test Pattern OTN BERT - framed PRBS9, PRBS15, PRBS20, PRBS23, PRBS31 (default), Null Client, and User Pattern. OTN BERT - unframed PRBS9, PRBS11 , PRBS15, PRBS20 , PRBS23, PRBS31 (default),...
Page 153 Test Setup - Test Configurator, Timer, and System BERT and Unframed BERT For Multi-Pattern, see Multi-Pattern Configuration on page 144. When User Pattern is selected, enter the payload pattern hexadecimal value. Invert check box, when selected (cleared by default), inverts the test ...
Page 154 Test Setup - Test Configurator, Timer, and System BERT and Unframed BERT Bit Error Pass/Fail Verdict allows enabling bit-error-rate pass/fail verdict by  selecting either Bit Error Count or Bit Error Rate. The default value is Disabled. BER Threshold allows entering the threshold Count or Rate value that ...
Page 155 Test Setup - Test Configurator, Timer, and System BERT and Unframed BERT Layer Defect STS/AU Path AIS-P/AU-AIS, LOP-P/AU-LOP, RDI-P/HP-RDI, REI-P/HP-REI, B3, UNEQ-P/HP-UNEQ, PDI-P (SONET) VT/TU Path AIS-V/TU-AIS, LOP-V/TU-LOP, UNEQ-V/LP-UNEQ, RDI-V/LP-RDI, REI-V/LP-REI, BIP-2 AIS, OOF, RAI, Framing Bit, CRC-6 AIS, OOF, Idle, RDI, F-Bit, C-Bit, P-Bit, FEBE AIS, CRC-4, E-Bit, LOMF, TS16 AIS, LOF, FAS, RAI, RAI MF E4, E3, E2 AIS, LOF, FAS, RAI...
Page 156 Test Setup - Test Configurator, Timer, and System BERT and Unframed BERT Note: Clearing the Disruption Monitoring check box will stop the measurement without clearing the results. The disruption monitoring is automatically stopped without clearing results when the test is stopped. However, starting the test again while the Disruption Monitoring check box is selected will reset the results before restarting.
Page 157: Cable Test
Test Setup - Test Configurator, Timer, and System Cable Test Cable Test From the Test menu, tap Setup, Test Configurator, and the test block. Global Options Wiring Standard is the pin-to-pair assignment corresponding to the  UTP cable used: T568A (default) or T568B. Length Unit is the unit used for cable length and distance to fault ...
Page 158 Test Setup - Test Configurator, Timer, and System Cable Test Power Class, available when PoE is enabled, selects the power class of  the simulated powered device: Power Class Power Device Class 0 (13.0W) - (default) Type 1 Class 1 (3.8W) Class 2 (6.5W) Class 3 (13.0W) Class 4 (25.5W)
Page 159: Cfp4/Cfp8/Qsfp/Sfp/Sfp+/Sfp28
Test Setup - Test Configurator, Timer, and System CFP4/CFP8/QSFP/SFP/SFP+/SFP28 CFP4/CFP8/QSFP/SFP/SFP+/SFP28 This tab gives hardware information related to the inserted transceiver module. From the Test menu, tap Setup, Test Configurator, tap on the interface block or on the Local block for iSAM, and on the CFP4/CFP8/QSFP/SFP/SFP+/SFP28 tab.
Page 160: Clock
Test Setup - Test Configurator, Timer, and System Clock Clock Allows the configuration of the clock synchronization. From the Test menu, tap Setup, Test Configurator, and tap on the clock block. Clock Synchronization Clock Mode allows selecting the source clock that will be used for transmission (TX).
Page 161 Test Setup - Test Configurator, Timer, and System Clock Ext Clock In Note: Available when the Clock Mode is set to External. Allows setting the external clock for test synchronization. Interface Type allows the selection of the clock interface:  DS1 (default), E1, 2MHz (default when DS1 is not supported), or 1PPS.
Page 162 Test Setup - Test Configurator, Timer, and System Clock For E1: TERM provides an input that terminates the E1 signal.  MON provides high-input impedance and compensation for  resistive loss. This setting is useful for monitoring E1 signals at monitor points, which are resistor-isolated.
Page 163 Test Setup - Test Configurator, Timer, and System Clock Ext Clock Out Note: Available when the Clock Mode is set to Internal, Recovered, or Backplane. Not available on 8870. Allows setting the clock that will be generated. Interface Type allows the selection of the clock interface: None ...
Page 164 Test Setup - Test Configurator, Timer, and System Clock REF OUT Source, available with CFP4 and QSFP28 transceivers, allows selecting the source clock that will be used for transmission (TX) on the REF OUT port: TX MCLK (default for CFP4), Internal 1/8, Internal 1/40, Internal 1/160 (default for QSFP28).
Page 165 Test Setup - Test Configurator, Timer, and System Clock Clock Out indicates the status of the clock generated on the REF OUT port as follows: Green: a valid clock is generated.  Red: the clock is either not available (--) then not generated, or not ...
Page 166 Test Setup - Test Configurator, Timer, and System Clock Tributary Synchronization Note: Only available with SONET/SDH - DSn/PDH and DSn/PDH test applications on 8870/8880 module. Not supported in Through topology. Clock Mode allows selecting the source clock that will be used for tributary transmission (TX);...
Page 167: Etherbert, Fc Bert, Bert (Cpri/Obsai), And Unframed Bert
Test Setup - Test Configurator, Timer, and System EtherBERT, FC BERT, BERT (CPRI/OBSAI), and Unframed BERT EtherBERT, FC BERT, BERT (CPRI/OBSAI), and Unframed BERT Note: For EtherBERT unframed test 40GE or 100GE, refer to BERT and Unframed BERT on page 139. From the Test menu, tap Setup, Test Configurator and tap on the EtherBERT, FC BERT, BERT, or Unframed BERT block.
Page 168 Test Setup - Test Configurator, Timer, and System EtherBERT, FC BERT, BERT (CPRI/OBSAI), and Unframed BERT No Pattern Analysis (Live) check box when cleared (default; selected  by default for framed CPRI), monitors the incoming traffic pattern and Round-Trip Latency. For live traffic, the No Pattern Analysis (Live) check box should be selected as the traffic is a live pattern and in this case no monitoring is required.
Page 169 Test Setup - Test Configurator, Timer, and System EtherBERT, FC BERT, BERT (CPRI/OBSAI), and Unframed BERT BER Threshold allows entering the threshold Count or Rate value that  will be used to declare the pass/fail verdict. For Count, enter the maximum bit/pattern error count allowed before declaring a fail verdict: 0 (default) to 999999.
Page 170 Test Setup - Test Configurator, Timer, and System EtherBERT, FC BERT, BERT (CPRI/OBSAI), and Unframed BERT Restore CPRI/OBSAI Defaults Note: Available with CPRI/OBSAI BERT test application. Reverts the current test application to its default factory settings. Service Disruption Note: Not available for FC BERT. No Traffic Time (ms) represents the time between two Ethernet ...
Page 171 Test Setup - Test Configurator, Timer, and System EtherBERT, FC BERT, BERT (CPRI/OBSAI), and Unframed BERT FC Frame Note: Only available with FC BERT. Frame Size (Bytes) allows entering the frame size (in step of 4 bytes) for FC BERT test application: 40 to 2148 bytes (default). However the minimum frame size is 64 bytes when the Latency Tag check box is selected.
Page 172 Test Setup - Test Configurator, Timer, and System EtherBERT, FC BERT, BERT (CPRI/OBSAI), and Unframed BERT Shaping TX Rate allows the selection of the transmission rate in percentage of  utilization (100 percent by default), Mbit/s, Gbit/s, Frame/s, or IFG for Ethernet;...
Page 173 Test Setup - Test Configurator, Timer, and System EtherBERT, FC BERT, BERT (CPRI/OBSAI), and Unframed BERT Ethernet Frame Frame Size (Bytes) allows entering the frame size for Ethernet test applications. The range is from 64 to 16000 The following table lists each component that may affect the minimum frame size values.
Page 174 Test Setup - Test Configurator, Timer, and System EtherBERT, FC BERT, BERT (CPRI/OBSAI), and Unframed BERT Note: The following frame parameters are only available for OTN BERT test application with Ethernet client (EoOTN). Source MAC Address is the module default and unique Source Media ...
Page 175: Ethersam - Burst
Test Setup - Test Configurator, Timer, and System EtherSAM - Burst EtherSAM - Burst Note: The Burst settings are only available for configuration when the Burst Test check box is selected (see page 165). From the Test menu, tap Setup, Test Configurator, tap on the test block, and on the Burst tab.
Page 176 Test Setup - Test Configurator, Timer, and System EtherSAM - Burst Parameters Number of Burst Sequence is the number of times, 1 to 100 (default  is 2), the burst sequence will be repeated for the CBS and EBS tests. Refill Delay Ratio (%) is the percentage of time required to refill the ...
Page 177: Ethersam - Global
Test Setup - Test Configurator, Timer, and System EtherSAM - Global EtherSAM - Global From the Test menu, tap Setup, Test Configurator, tap on the test block, and on the Global tab. Dual Test Set Dual Test Set (DTS) check box when selected (cleared by default) ...
Page 178 Test Setup - Test Configurator, Timer, and System EtherSAM - Global Subtests Service Configuration Test verifies if the network configuration is  correct for each service before starting a long term test (Service Configuration Test). To test the network configuration, a ramp test and/or a burst tests is/are generated for each configured service.
Page 179 Test Setup - Test Configurator, Timer, and System EtherSAM - Global Burst Test check box when selected (cleared by default) verifies  that the expected burst size can be transmitted at maximum burst rate with minimal loss. CBS (Committed Burst Size) check box when selected (see SLA Parameters on page 285), verifies the performance of a committed burst size at CIR’s average TX rate.
Page 180 Test Setup - Test Configurator, Timer, and System EtherSAM - Global Global Options Per Direction Configuration check box when selected (default)  specifies that the values can be configured independently for each direction (local to remote and remote to local) for Dual Test Set or for each port (P1 to P2 and P2 to P1) for Dual Port;...
Page 181: Ethersam - Ramp
Test Setup - Test Configurator, Timer, and System EtherSAM - Ramp EtherSAM - Ramp Note: The Ramp tab is only available for configuration when the Ramp Test check box is selected (see page 165). From the Test menu, tap Setup, Test Configurator, tap on the test block, and on the Ramp tab.
Page 182 Test Setup - Test Configurator, Timer, and System EtherSAM - Ramp Delete Step Allows deleting a step from the ramp. Select the step from the list and tap on Delete. Defaults Reverts the ramp configuration to its default factory settings. 88000 Series...
Page 183: External Reference
Test Setup - Test Configurator, Timer, and System External Reference External Reference Allows the configuration of the external reference signal. Available with Wander test application. From the Test menu, tap Setup, Test Configurator, and tap on the External Reference block. Reference Mode is set to External Reference.
Page 184: Fibre Channel Fc Bert X
Test Setup - Test Configurator, Timer, and System Fibre Channel Fibre Channel From the Test menu, tap Setup, Test Configurator, and the Fibre Channel block. World Wide Name (WWN) The following WWN settings are only available when the Login - Enable check box is selected (see page 173).
Page 185 Test Setup - Test Configurator, Timer, and System Fibre Channel Login After a link is established, it is possible to login to the Fibre Channel Network to send and receive data between a local and remote fibre channel port. Enable check box when selected (default) allows pressing the Login ...
Page 186 Test Setup - Test Configurator, Timer, and System Fibre Channel Fabric Status indicates the status of the Fabric switching network. The  status is not available when the discovered topology is Point-to-Point. Logged-in indicates that the login process has completed ...
Page 187: Frequency
Test Setup - Test Configurator, Timer, and System Frequency Frequency From the Test menu, tap Setup, Test Configurator, tap on the interface block, and on the Frequency tab. TX Frequency TX Frequency (GHz) indicates the frequency (actual frequency +  Frequency offset) used for transmission.
Page 188 Test Setup - Test Configurator, Timer, and System Frequency Note: The following frequency statistics are available for each lane. RX Frequency Frequency (GHz) indicates the frequency of the input signal.  Offset (ppm) indicates the frequency offset between the standard rate ...
Page 189: Ftfl/Pt And Pt
Test Setup - Test Configurator, Timer, and System FTFL/PT and PT FTFL/PT and PT For OTN BERT and OTN-SONET/SDH BERT: From the Test menu tap Setup, Test Configurator, tap on the interface block, and on the FTFL/PT tab. For Multi-Channel OTN: From the Test menu, tap Setup, Test Configurator, tap on either: the interface block, and on the PT tab to configure the higher ODU ...
Page 190 Test Setup - Test Configurator, Timer, and System FTFL/PT and PT FTFL Allows the configuration of the Forward and Backward ODU Fault Type Fault Location (FTFL) to be generated. Not available with Multi-Channel OTN. Overwrite check box when selected generates the defined FTFL. ...
Page 191 Test Setup - Test Configurator, Timer, and System FTFL/PT and PT PT / Global PT Note: Global PT, available with Muti-Channel OTN, indicates that the PT settings apply to all channels. Note: Changing the payload type (PT) does not alter the signal structure; it only modifies the OH value that is generated.
Page 192 Test Setup - Test Configurator, Timer, and System FTFL/PT and PT Payload type Hex Code 1234 5678 OC-12/STM-4 into ODU0 0000 1011 FC-100 into ODU0 0000 1100 FC-200 into ODU1 0000 1101 FC-400 into ODUflex 0000 1110 FC-800 into ODUflex 0000 1111 Bit Stream with Octet Timing mapping...
Page 193: Gfp-F/Gfp-T
Test Setup - Test Configurator, Timer, and System GFP-F/GFP-T GFP-F/GFP-T Note: Only available with Ethernet 1GbE, 10GbE, or Ethernet (flex/GFP-F) client. From the Test menu, tap Setup, Test Configurator, and tap on the GFP-F/GFP-T block. Note: Refer to Generic Framing Procedure (GFP) on page 727 for more information on Client Data and Client Management frames.
Page 194: Interface (Ethernet, Packet Sync, Fibre Channel, And Wireless)
Test Setup - Test Configurator, Timer, and System Interface (Ethernet, Packet Sync, Fibre Channel, and Wireless) Interface (Ethernet, Packet Sync, Fibre Channel, and Wireless) From the Test menu, tap Setup, Test Configurator, the interface block, and the Interface tab. LINK An arrow is used to indicate the port link status (at the PCS level for parallel interfaces): link up (green arrow), error or link down (red arrow), or awaiting incoming data to provide a status (gray arrow).
Page 195 Test Setup - Test Configurator, Timer, and System Interface (Ethernet, Packet Sync, Fibre Channel, and Wireless) For 400GE (8 Lanes) framed Ethernet interface: RS-FEC (RX Only) check box when selected (default) enables the use of the RS-FEC in RX; when cleared, ignores RS-FEC parity symbols, detection of FEC errors, and no correction of message symbols are performed.
Page 196 Test Setup - Test Configurator, Timer, and System Interface (Ethernet, Packet Sync, Fibre Channel, and Wireless) For EtherBERT test application: Remote Fault Emulation check box when selected, generates Remote  Fault ordered sets when a Link Fault is received. Only available with EtherBERT, 10GE (all framing at the exception of Seed A/B and PRBS31 Unscrambled), and 40GE/100GE (Framed Layer 2 and up).
Page 197 Test Setup - Test Configurator, Timer, and System Interface (Ethernet, Packet Sync, Fibre Channel, and Wireless) Speed, available with 10/100/1000M Electrical interface, allows the  selection of the interface rate: 10M, 100M, 1GE, or Auto . The negotiated speed will be displayed next to the Speed field selection. The 10M speed is not available with SyncE test application.
Page 198 Test Setup - Test Configurator, Timer, and System Interface (Ethernet, Packet Sync, Fibre Channel, and Wireless) For Fibre Channel test application: PSP (Link Protocol) (Primitive Sequence Protocol) check box when  selected (default) allows link management by activating the port. For CPRI Unframed test application: Scrambling check box when selected (default) enables the scrambler.
Page 199 Test Setup - Test Configurator, Timer, and System Interface (Ethernet, Packet Sync, Fibre Channel, and Wireless) C&M Channel defines the kind of channel that will be used by the  startup sequence for negotiation. Auto (default): Overhead byte #Z.66.0 can use any of the HDLC ...
Page 200 Test Setup - Test Configurator, Timer, and System Interface (Ethernet, Packet Sync, Fibre Channel, and Wireless) Rate (Mbit/s) is available with HDLC and Ethernet C&M Channel.  For HDLC: Allows the selection of the HDLC bit rate. Choices depend on the selected CPRI interface rate. HDLC Proprietary is used to exercise a case where the Base Station is aware in advance of the HDLC rate to use.
Page 201 Test Setup - Test Configurator, Timer, and System Interface (Ethernet, Packet Sync, Fibre Channel, and Wireless) For OBSAI Framed L2 test application: Sync indicates the RX State Machine status: green for FRAME_SYNC,  gray for pending, or red for other states. The TX and RX State Machines are also displayed.
Page 202 Test Setup - Test Configurator, Timer, and System Interface (Ethernet, Packet Sync, Fibre Channel, and Wireless) RP3 Address (OBSAI Framed L2) Source identifies the source node of RP3 messages: 0000 to 1FFF;  default is 1234. The RP3 address 1FFF corresponds to the empty message address that is dropped according to the standard.
Page 203  up to 15 bytes (a CRC-7 byte will be added in front for a total of 16 bytes). Default is EXFO 10GigE. Note: J0 and J1 values should be 7-bit T.50 suitable characters. The Padding drop list from the message keyboard allows selecting Null or Space to fill up the J0 Trace and J1 Trace up to15 byte value.
Page 204 Test Setup - Test Configurator, Timer, and System Interface (Ethernet, Packet Sync, Fibre Channel, and Wireless) Physical Interface For parallel interfaces, the following information is displayed for each optical lane. Optical Lane indicates the optical lane number.  Optical Interface Optical Lane Number 40GE (4 Lanes) [41.25 Gbit/s] 0 through 3...
Page 205 Test Setup - Test Configurator, Timer, and System Interface (Ethernet, Packet Sync, Fibre Channel, and Wireless) Laser ON/OFF button, available with parallel interfaces, is used to  activate the laser control per optical lane or for all lanes. Optical lane numbers are from 0 to 3 or 0 to 7 depending on the selected interface/rate.
Page 206 Test Setup - Test Configurator, Timer, and System Interface (Ethernet, Packet Sync, Fibre Channel, and Wireless) TX Frequency Note: The following TX Frequency information applies to serial interface only, refer to TX Frequency on page 175 for parallel interfaces. Not available when using an active copper SFP.
Page 207 Test Setup - Test Configurator, Timer, and System Interface (Ethernet, Packet Sync, Fibre Channel, and Wireless) RX Frequency Note: The following RX Frequency information applies to serial interface only, refer to RX Frequency on page 176 for parallel interfaces. Not available when using an active copper SFP.
Page 208: Labels
Test Setup - Test Configurator, Timer, and System Labels Labels For SONET/SDH BERT, from the Test menu, tap Setup, Test Configurator, the interface block, and on the Labels tab. For OTN-SONET/SDH BERT, from the Test menu, tap Setup, Test Configurator, the protocol block, and on the Labels tab. Note: Selecting a Label byte to be generated will automatically update the corresponding OH byte.
Page 209 Test Setup - Test Configurator, Timer, and System Labels PLM-V/UNEQ-V / LP-PLM/LP-UNEQ: Enables the Payload Mismatch  and VT/TU UNEQ monitoring. This setting is coupled with the configuration on the Labels on page 427. Expected: Select the expected V5 byte from the list. Refer to V5 on ...
Page 210: Link Oam
Test Setup - Test Configurator, Timer, and System Link OAM Link OAM From the test menu, tap Setup, Test Configurator, and the Link-OAM (802.3) test block. OAM Mode Allows the selection of the OAM mode: Active (default) initiates the OAM discovery and send OAMPDU ...
Page 211 Test Setup - Test Configurator, Timer, and System Link OAM OAM Discovery Status Local reports the local OAM discovery status as follows:  Status Description Evaluating OAM discovery is started. Stable OAM discovery is completed. Local OAM is satisfied with the remote OAM settings.
Page 212: Local Details (Isam)
Test Setup - Test Configurator, Timer, and System Local Details (iSAM) Local Details (iSAM) From the Test menu, tap Setup, Test Configurator, and the More button from the Local block. LINK An arrow is used to indicate the status of the test link (at the PCS level ...
Page 213 Test Setup - Test Configurator, Timer, and System Local Details (iSAM) RS-FEC check box when selected (default), enables the use of the  RS-FEC. The RS-FEC check box must be selected when using a 100GBASE-SR4 or 100GE-CWDM4 transceiver and may be selected for 100GE-CLR4;...
Page 214 Test Setup - Test Configurator, Timer, and System Local Details (iSAM) Speed, available with 10/100/1000M Electrical interface, allows the  selection of the interface rate: 10M, 100M, 1GE, or Auto; Auto is only available when the Auto-Negotiation check box is selected. The negotiated speed will be displayed next to the Speed field selection.
Page 215 Test Setup - Test Configurator, Timer, and System Local Details (iSAM) IP Version is set to IPv4.  Automatic IP (DHCP) check box, when selected (cleared by default),  allows obtaining dynamically an IP address from a DHCP (Dynamic Host Configuration Protocol) server. Note: IP Address, Subnet Mask, and Default Gateway are not available when the Automatic IP (DHCP) check box is selected.
Page 216: Mac/Ip/Udp
Test Setup - Test Configurator, Timer, and System MAC/IP/UDP MAC/IP/UDP Note: Only available with Framed Layer 2 (see Framing from the Modify Frame Structure). From the Test menu, tap Setup, Test Configurator, and... For RFC 2544 and EtherBERT, tap on the protocol block. ...
Page 217 Test Setup - Test Configurator, Timer, and System MAC/IP/UDP Modify Frame Structure Allows modifying the structure of the frame. Global Option  S-OAM check box when selected enables EtherSAM over service  OAM at Layer 2 on all services. The EtherSAM uses LBM and LBR messages of the S-OAM protocol to perform the test.
Page 218 Test Setup - Test Configurator, Timer, and System MAC/IP/UDP Framing  Note: The framing for EtherSAM in a NAT environment is limited to Ethernet II, IPv4, and UDP. Frame Format (layer 2) allows selecting Ethernet II (default) or  802.3 SNAP as the frame format. Network Layer (layer 3) sets the network traffic type: ...
Page 219 Test Setup - Test Configurator, Timer, and System MAC/IP/UDP EoE: The EoE VLAN check box, when selected (cleared by default),  enables the EoE VLAN tag. Available when EoE is selected as Provider Encapsulation. PBB-TE: The B-VLAN check box, when selected (cleared by default), ...
Page 220 Test Setup - Test Configurator, Timer, and System MAC/IP/UDP Type, VLAN Ethernet Type, choices are 0x8100, 0x88A8, 0x9100,  0xA100 (default), 0x9200, and 0x9300. Drop Eligible:, when set to Yes (DEI = 1), the transmitted frames  will be dropped first on receipt when congestion occurs under test. Drop Eligible is not available when VLAN type is 0x8100.
Page 221 Test Setup - Test Configurator, Timer, and System MAC/IP/UDP PBB-TE Note: Available when PBB-TE is selected as the Provider Encapsulation (see Modify Frame Structure on page 205). Source B-MAC Address indicates and allows changing (when the  Factory Default check box is cleared) the default source Backbone MAC address: 00:03:01:xx:xx:xx.
Page 222 Test Setup - Test Configurator, Timer, and System MAC/IP/UDP Source MAC Address indicates the default and unique Media Access  Control (MAC) address given to the Ethernet port; editable when using Provider Encapsulation. Destination MAC Address: Enter the destination MAC address for the ...
Page 223 Test Setup - Test Configurator, Timer, and System MAC/IP/UDP Note: Source/Destination Flooding and Flood Range are only available with Traffic Gen & Mon when the Network Layer is set to None (see page 206). Source Flooding and Destination Flooding check boxes when ...
Page 224 Test Setup - Test Configurator, Timer, and System MAC/IP/UDP MPLS Note: MPLS is only available when the MPLS Label is enabled; refer to Modify Frame Structure on page 205. Label allows the selection of the MPLS TX labels: 0 to 1048575 (default ...
Page 225 Test Setup - Test Configurator, Timer, and System MAC/IP/UDP For IPv4 the following configuration parameters are available. Automatic IP (DHCP) check box, when selected (cleared by default),  allows obtaining an IP address dynamically from a DHCP (Dynamic Host Configuration Protocol) server. Source IP Address allows entering the source IP address for the ...
Page 226 Test Setup - Test Configurator, Timer, and System MAC/IP/UDP Global IPv6 Address (GUA) is used to communicate with on-link  neighbors and for global communication with hosts outside the subnet. Mode  None disables the Global IPv6 Address and the Default Gateway Address.
Page 227 Test Setup - Test Configurator, Timer, and System MAC/IP/UDP Prefix Mask, available with Static mode, allows specifying a prefix  that defines the subnet. The accepted range is 0000:0000:0000:0000:0000:0000:0000:0000 to FFFF:FFFF:FFFF:FFFF:0000:0000:0000:0000. For example: Global Address: 2001:0DB8:0001:0002:02AA:00FF:FE11:1111 Prefix Mask: FFFF:FFFF:FFFF:0000:0000:0000:0000:0000 Corresponding Prefix: 2001:0DB8:0001. Default Gateway allows the configuration of the default gateway ...
Page 228 Test Setup - Test Configurator, Timer, and System MAC/IP/UDP The following configuration parameters are available for both IPv4 and IPv6 unless otherwise specified. Quick Ping button automatically starts the quick Ping utility for the  stream destination IP address and provides either a successful or failed result.
Page 229 Test Setup - Test Configurator, Timer, and System MAC/IP/UDP TTL (IPv4) or HOP Limit TTL (IPv6) sets the Time To Live value: 1 to  255 (default is 128). Flow Label (IPv6) is a number used to identify a series of related ...
Page 230 Test Setup - Test Configurator, Timer, and System MAC/IP/UDP Reliability allows the selection of the reliability level:  Normal (default) or High. Monetary Cost allows the selection of the monetary cost level:  Normal (default) or Low. Reserved Bit allows the selection of the reserved bit value: ...
Page 231 Test Setup - Test Configurator, Timer, and System MAC/IP/UDP Allows the selection of the source and destination UDP port number. Source Port is configurable from 0 to 65535; the default is 49184.  Destination Port is configurable from 0 to 65535; the default is ...
Page 232: Network
Test Setup - Test Configurator, Timer, and System Network Network From the test menu tap Setup, Test Configurator, the interface block, and the Network tab. Note: For Through Mode test application, the Network tab is only available for the Primary Port but the configured parameters apply to both ports. MAC Address indicates and allows changing, when the Factory ...
Page 233 Test Setup - Test Configurator, Timer, and System Network IP Version allows the selection of either IPv4 (default) or IPv6. Only IPv4 is supported for TCP Throughput and RFC 6349 test applications. For IPv4 the following configuration parameters are available. Automatic IP (DHCP) check box, when selected (cleared by default), ...
Page 234 Test Setup - Test Configurator, Timer, and System Network For IPv6 the following configuration parameters are displayed: Link-Local IPv6 Address, Global IPv6 Address, and Default Gateway. Tap on the Config button to access all settings. Link-Local IPv6 Address (LLA) is used for local communication ...
Page 235 Test Setup - Test Configurator, Timer, and System Network Global IPv6 Address (GUA) is used to communicate with on-link  neighbors and for global communication with hosts outside the subnet. Mode  None disables the Global IPv6 Address and the Default Gateway Address.
Page 236 Test Setup - Test Configurator, Timer, and System Network Prefix Mask, available with Static mode, allows specifying a prefix  that defines the subnet. The accepted range is 0000:0000:0000:0000:0000:0000:0000:0000 to FFFF:FFFF:FFFF:FFFF:0000:0000:0000:0000. For example: Global Address: 2001:0DB8:0001:0002:02AA:00FF:FE11:1111 Prefix Mask: FFFF:FFFF:FFFF:0000:0000:0000:0000:0000 Corresponding Prefix: 2001:0DB8:0001. Default Gateway allows the configuration of the default gateway ...
Page 237 Test Setup - Test Configurator, Timer, and System Network VLAN VLAN Tag check box, when selected (cleared by default), enables and allows setting up to 3 stacked VLANs. For each VLAN tag enabled, C-VLAN / S-VLAN / E-VLAN, the following parameters are configurable.
Page 238: Network Details (Isam)
Test Setup - Test Configurator, Timer, and System Network Details (iSAM) Network Details (iSAM) Either select the Layer parameter, the number of services, for each service the profile and CIR settings, or click on More for all settings. The total bandwidth (when the Performance Test is enabled) and the estimated test duration are also displayed.
Page 239 Test Setup - Test Configurator, Timer, and System Network Details (iSAM) Configuration Test check box when selected (default) verifies if the  network configuration is correct for each service before starting a long term test (Performance Test). Set the Configuration Test duration in seconds per step enabled (CIR and CIR+EIR): 5 seconds (default) to 60 seconds.
Page 240 Test Setup - Test Configurator, Timer, and System Network Details (iSAM) Services Allows the selection of the number of services: 1 (default) to 4. The following parameters are configurable individually for each service: Profile  Two profiles are defined by default as well as User Profile. Profiles are user definable and up to 25 profiles can be predefined (see Customizable Profiles on page 233).
Page 241 Test Setup - Test Configurator, Timer, and System Network Details (iSAM) Note: At least one check box (CIR or CIR+EIR) has to be selected. Thus, clearing the CIR check box while CIR+EIR check box is cleared, will automatically select the CIR+EIR check box and vice versa. Note: For Dual Test Set, the CIR and CIR+EIR values are the same (Symmetric) for both L->R and R->L directions.
Page 242 Test Setup - Test Configurator, Timer, and System Network Details (iSAM) Frame Size  Type Frame Size (bytes) Fixed (default) (default) to 16000 EMIX to 16000 The minimum value is adjusted according to the frame structure and components selected as shown in the following table. The maximum frame size is limited to 10000 for 10/100/1000Mbps electrical interface.
Page 243 Test Setup - Test Configurator, Timer, and System Network Details (iSAM) Classification  Allows the selection of the value for the selected classification: Classification Value VLAN ID 0 through 4095 (default is 2). Refer to VLAN ID and Priority on page 758. VLAN Priority 0 (default) to 7.
Page 244 Test Setup - Test Configurator, Timer, and System Network Details (iSAM) Performance Criteria  The following performance criteria are available by default: Name ≤ FD (ms) ≤ IFDV (ms) ≤ FLR (%) MEF Metro High 0.01 MEF Metro Med 0.01 MEF Metro Low Disabled MEF Regional High...
Page 245 (iSAMProfilesTemplate.ini) using a word processor like Notepad. The file is located under ProgramData\EXFO\ProtocolProducts\ or depending on Documents and Settings\All Users\Application Data\EXFO\ProtocolProducts\ the operating system. Example of profile’s text file: [Priority] Frame Type = EMIX...
Page 246 Test Setup - Test Configurator, Timer, and System Network Details (iSAM) Each profile entry has the following parameters. Profile Name: 1 to 16 characters. All ASCII characters from 32 to 126  decimal are supported. Frame Type: Enter Fixed or EMIX. When the frame type is missing ...
Page 247 (iSAMPerformanceCriteriaTemplate.ini) using a word processor application like Notepad. The file is located under ProgramData\EXFO\ProtocolProducts\ or depending on Documents and Settings\All Users\Application Data\EXFO\ProtocolProducts\ the operating system. Example of performance criteria’s text file: [MEF Metro High] FD = 10 IFDV = 3 FLR = 0.01...
Page 248 Test Setup - Test Configurator, Timer, and System Network Details (iSAM) If the threshold value for a parameter is not defined, it is considered as disabled (as in the example above for IFDV =). The value of a parameter is validated to ensure it is within the supported range;...
Page 249: Odu Channels - Global
Test Setup - Test Configurator, Timer, and System ODU Channels - Global ODU Channels - Global From the Test menu, tap Setup, Test Configurator, tap on the test block (ODU Channels), and on the Global tab. Note: The ODU channels global configuration applies to all channels. Pattern The test pattern icon next to the Pattern label indicates the status of the received pattern signal.
Page 250 Test Setup - Test Configurator, Timer, and System ODU Channels - Global Bit Error Pass/Fail Verdict allows enabling bit-error-rate pass/fail verdict by  selecting either Bit Error Count or Bit Error Rate. The default value is Disabled. BER Threshold allows entering the threshold Count or Rate value that ...
Page 251 Test Setup - Test Configurator, Timer, and System ODU Channels - Global Defect allows choosing on which layer and defect the service  disruption time test will be performed. Choices depend on the selected test path. Layer Defect ODUk LOFLOM, AIS, OCI, LCK, BDI, BIP-8, BEI OPUk AIS, CSF Note: The Service Disruption Time measurement supports a parent defect...
Page 252 Test Setup - Test Configurator, Timer, and System ODU Channels - Global Channel Summary Channel ID / Type table indicates each channel number with its ODU  mapping type. Payload Type indicates the mapped ODU payload type.  Quantity of Channels indicates the number of channels part of the ...
Page 253 Test Setup - Test Configurator, Timer, and System ODU Channels - Global The following table indicates the number of tributary slots per channel: For... Mapped into... Tributary slot per channel ODU3 OPU4 ODU2 OPU4 ODU1 OPU4 ODU0 OPU4 The table provides a status for each channel using visual indication as follows: Background Description...
Page 254 Test Setup - Test Configurator, Timer, and System ODU Channels - Global Background Description Color Configured structure is not matching the MSI received signal or could contain an unsupported mapping (for example Unallocated). Gray Impaired signal is preventing RX structure decoding (for example when a LOS alarm is detected).
Page 255 Test Setup - Test Configurator, Timer, and System ODU Channels - Global Del Ch button removes the selected channel.  Delete All button removes all channels.  Assign / Unassign / Mode  To assign or unassign tributary slots: 1. From the Channel Assignation Status table, select a channel. 2.
Page 256 Test Setup - Test Configurator, Timer, and System ODU Channels - Global Copy RX MSI allows automatic configuration of the Channel to Trib  Slot that matches the system under test configuration. A warning message is displayed when the RX test structure is either: Unsupported: An unsupported ODU channel is received (for example Unallocated).
Page 257: Optical Device Under Test (Ioptics)
Test Setup - Test Configurator, Timer, and System Optical Device Under Test (iOptics) Optical Device Under Test (iOptics) From the Test menu, tap Setup, and Test Configurator. Transceiver selection: Tap on a transceiver icon to select the  interface/port. The selected transceiver is highlighted with an amber contour.
Page 258 Test Setup - Test Configurator, Timer, and System Optical Device Under Test (iOptics) Rate Transceiver Fibre Transport Ethernet Wireless Channel SFP+ OTU2 10GE WAN CPRI - 1.2G SFP/SFP+ OTU1e 10GE LAN CPRI - 2.4G OTU2e 1GE Optical CPRI - 3.1G (Port 1 only) OTU1f 100M Optical...
Page 259 Test Setup - Test Configurator, Timer, and System Optical Device Under Test (iOptics) More gives additional transceiver information and settings.  Parameters are retrieved from the transceiver:  Parameter CFP4 CFP8 QSFP SFP+ Module ID Vendor Name Part Number Serial Number Hardware Revision Firmware Version Adaptor Revision...
Page 260: Remote Details (Isam)
Test Setup - Test Configurator, Timer, and System Remote Details (iSAM) Remote Details (iSAM) The remote block automatically scans the remote modules for DTS and Remote Loopback modes and allows the selection of the remote module that is used to loop back the traffic via Smart Loopback or EtherSAM in Dual Test Set (DTS) mode for simultaneous bidirectional results.
Page 261 Test Setup - Test Configurator, Timer, and System Remote Details (iSAM) Preferred check box when selected indicates that this module is  part of the preferred module’s list. Preferred remote modules will be considered first during the automatic connection process as follows: Priority Preferred or not...
Page 262 Test Setup - Test Configurator, Timer, and System Remote Details (iSAM) For Remote Loopback Operation Mode Loop-Up button establishes the connection with the selected remote  module and sets the remote module into Smart Loopback test application. Following a successful loop-up, the IP address of the remote module will be used as the destination IP address for the test.
Page 263 Test Setup - Test Configurator, Timer, and System Remote Details (iSAM) For Manual Loopback Operation Mode MAC, available with layer L2, allows entering the destination MAC  address of the remote. IP , available with L3/L4, allows entering the destination IP address of ...
Page 264: Rfc 2544 - Global
Test Setup - Test Configurator, Timer, and System RFC 2544 - Global RFC 2544 - Global From the Test menu, tap Setup, Test Configurator, tap on the RFC 2544 block, and on the Global tab. Dual Test Set Dual Test Set (DTS) check box when selected (cleared by default) ...
Page 265 Test Setup - Test Configurator, Timer, and System RFC 2544 - Global Global Options Flow Direction allows the selection of the traffic direction as follows:  TX to RX for Single Port topology.  Port #1 to Port P2, Port #2 to Port #1, and Bidirectional for ...
Page 266 Test Setup - Test Configurator, Timer, and System RFC 2544 - Global Frame Size (Bytes): For RFC 2544 distribution, gives predefined frame  size distribution values. For User Defined distribution, enter up to seven frame size values. Distribution Frame Size RFC 2544 ,128, 256, 512, 1024, 1280, and 1518 User Defined...
Page 267: Rfc 2544 - Subtests
Test Setup - Test Configurator, Timer, and System RFC 2544 - Subtests RFC 2544 - Subtests From the Test menu, tap Setup, Test Configurator, tap on the RFC 2544 block. and on the Subtests tab. Allows the configuration of each enabled subtest. Throughput The objective of this test is to find the throughput of the device under test for which there is no frame loss.
Page 268 Test Setup - Test Configurator, Timer, and System RFC 2544 - Subtests Max. Rate is the maximum rate the test should begin with, in terms of  a percentage of the line rate (%), Mbit/s, or Gbit/s. For Dual Test Set Max.
Page 269 Test Setup - Test Configurator, Timer, and System RFC 2544 - Subtests Accuracy is the accuracy measurement in percentage of the line rate  (%), Mbit/s, or in Gbit/s. The accuracy is not based on the configured Maximum Rate but on the Ethernet line rate. The accepted values are as follows: Max.
Page 270 Test Setup - Test Configurator, Timer, and System RFC 2544 - Subtests Back-to-Back The objective of this test is to find the maximum number of frames that can be sent at maximum throughput without frame loss. A burst of frames (Burst Time) is sent with minimum inter-frame gaps to the device under test and the number of forwarded frames is counted.
Page 271 Test Setup - Test Configurator, Timer, and System RFC 2544 - Subtests Frame Loss Configuration The objective of this test is to find the percentage of frames that are lost due to lack of resources. Starting at the specified maximum rate (Max. Rate), the test is performed for a specific frame size and for the specified duration (Trial Duration).
Page 272 Test Setup - Test Configurator, Timer, and System RFC 2544 - Subtests Latency Configuration The objective of the test is to measure the time required for the frame to go through the device under test and return back to source. Starting by sending a stream of frames for the predefined duration (Trial Duration) and throughput (Max.
Page 273 Test Setup - Test Configurator, Timer, and System RFC 2544 - Subtests Measurement Mode, available with Dual Test Set for rates from 10M  to 10GE, allows the selection of the latency measurement mode: Round-Trip (default) or One-Way. Synchronization with an external 1PPS clock is required to perform One-Way Latency measurement.
Page 274 Test Setup - Test Configurator, Timer, and System RFC 2544 - Subtests Thresholds Button Note: For Dual Test Set, thresholds are configurable for Local to Remote and Remote to Local directions at the exception of Round-Trip Latency Threshold for which the value is unique. For Dual Port topology, thresholds are configurable for P1 to P2 (P1->P2) and P2 to P1 (P2->P1) directions.
Page 275 Test Setup - Test Configurator, Timer, and System RFC 2544 - Subtests Frame Loss Threshold (%) sets the threshold value of frame loss.  The range is from 0.000 to 100.000 (default is 0.100) and it applies to all frame sizes when applicable. Latency Threshold / Round-Trip Latency Threshold sets the ...
Page 276: Rfc 6349
From the Test menu, tap Setup, Test Configurator, and the RFC 6349 block. Connection Operation Mode allows the selection of the test operation mode: Dual  Test Set (DTS) or EXFO|Worx Interop. The connection is graphically displayed with its status as follows: Operation Status Description Mode Dual Test Set Disconnected No connection established with a remote module.
Page 277 Direction allows the selection of the traffic direction: Local to Remote,  Remote to Local, and Bidirectional (default). Remote IP Address, available with EXFO|Worx Interop, is either the  remote IP address of the verifier or the WAN IP address when the verifier is behind a NAT router.
Page 278 Test Setup - Test Configurator, Timer, and System RFC 6349 TOS/DS (IPv4) allows entering an hexadecimal value, 00 (default) to  FF. Changing the IP TOS/DS value will affect the TOS/DS Config settings and vice versa. Max MTU (bytes) determines the Maximum Transfer Unit (MTU) to ...
Page 279: S-Oam And Mpls-Tp Oam
Test Setup - Test Configurator, Timer, and System S-OAM and MPLS-TP OAM S-OAM and MPLS-TP OAM From the test menu, tap Setup, Test Configurator, and the S-OAM (Y.1731/802.1ag/MEF) or MPLS-TP OAM (G.8113.1) test block. OAM Mode Allows the selection of the OAM mode. OAM Type OAM Mode S-OAM...
Page 280 Test Setup - Test Configurator, Timer, and System S-OAM and MPLS-TP OAM S-OAM and MPLS-TP OAM Responder S-OAM Responder or MPLS-TP OAM Responder check box when selected (default) allows responding to LBM, LTM, DMM, LMM, and SLM valid messages (test running or not). LTM and SLM are only available with Ethernet OAM.
Page 281 Test Setup - Test Configurator, Timer, and System S-OAM and MPLS-TP OAM Pass/Fail Verdict Pass/Fail Verdict check box when selected (default) enables the use of the pass/fail verdict. A global fail verdict is declared when any of the following condition is met: Link Down alarm, Loss Continuity alarm, or any fail verdict for Frame Delay, Frame Loss, Synthetic Loss (Only applicable to Ethernet OAM), Frame Delay Failure, Frame Loss Failure, Synthetic Loss Failure (Only applicable to Ethernet OAM), Loopback Failure, or Test...
Page 282 MA Name (Short MA Name) is a Maintenance Association Name  text field set to EXFO MA Name by default. The length of the MA Name field is from 1 to either 44 bytes minus the Domain ID field length when Domain ID is present or 45 bytes when not present.
Page 283 Test Setup - Test Configurator, Timer, and System S-OAM and MPLS-TP OAM MEG Level (Y.1731, MEF, and G.8113.1) is the Maintenance Entity  Group Level configurable from 0 to 7 (default). MD Level (802.1ag) is the Maintenance Domain Level and is ...
Page 284 Test Setup - Test Configurator, Timer, and System S-OAM and MPLS-TP OAM Drop Eligible, available with S-OAM Mode or when VLAN is enabled  (see VLAN on page 225), is set to No (no frames will be dropped when congestion occurs) and is not configurable. Period determines the transmission period of the CCM frame: 3.33 ms, ...
Page 285 Test Setup - Test Configurator, Timer, and System S-OAM and MPLS-TP OAM Test Function Note: Test Function parameters are not configurable when the TX Enable check box is selected. Function allows the selection of the test function to be performed. ...
Page 286 Test Setup - Test Configurator, Timer, and System S-OAM and MPLS-TP OAM Requesting MEP ID TLV (G.8113.1) check box when selected (default)  determines if the Requesting MEP ID TLV is present in the LBM frame. The Requesting MEP ID TLV check box is cleared and not selectable when the Continuous check box is selected.
Page 287 Test Setup - Test Configurator, Timer, and System S-OAM and MPLS-TP OAM Frame Size allows entering the frame size. The frame size range for  Ethernet II frame format is as follows: S-OAM Mode: 64 to 1518 . The minimum frame size is adjusted ...
Page 288 Test Setup - Test Configurator, Timer, and System S-OAM and MPLS-TP OAM Parameter Number of bytes to be added Apply to Label 2 4 bytes G.8113.1 18 bytes for Data TLV Type Continuous 21 bytes for Test TLV Type Requesting MEP ID TLV 56 bytes Note: Sending traffic with frame size >1518 in switched network may result in losing all frames.
Page 289: Services - Global
Test Setup - Test Configurator, Timer, and System Services - Global Services - Global From the Test menu, tap Setup, Test Configurator, tap on the services block, the Global tab, and on the General button. General Button The following parameters are displayed and configurable per service. Check boxes: ...
Page 290 Test Setup - Test Configurator, Timer, and System Services - Global Frame Size indicates the frame size of each service. Tap on the Frame  Size button to modify the frame size of each service. Framing indicates the framing of each service. Tap on the Framing ...
Page 291 Test Setup - Test Configurator, Timer, and System Services - Global Total TX Rate Note: Only available when the Service Performance Test check box is selected (see EtherSAM - Global on page 165). For Dual Test Set, the total TX rates are displayed for both Local and Remote directions.
Page 292: Services - Profile
Test Setup - Test Configurator, Timer, and System Services - Profile Services - Profile The EtherSAM test application supports the configuration of up to 10 different services individually. All parameters are configurable per service. From the Test menu, tap Setup, Test Configurator, tap on the services block, and on the Profile tab.
Page 293 Test Setup - Test Configurator, Timer, and System Services - Profile Total TX Rate Note: Only available when the Service Performance Test check box is selected (see EtherSAM - Global on page 165). Indicates the total transmit rate of all services enabled for transmission. Unit selection is available from the SLA Parameters on page 285.
Page 294 Test Setup - Test Configurator, Timer, and System Services - Profile Note: The CIR value will be calculated on the basis of the selected service profile and the value entered in the Number of Calls or Number of Channels field. Frame Size (Bytes) indicates the frame size for Voice and Video ...
Page 295 Test Setup - Test Configurator, Timer, and System Services - Profile The following table lists each component that may affect the minimum frame size value. Component Description VLAN 4 bytes per VLAN (up to 2 VLAN) MPLS 4 bytes per label (up to two labels) 8 bytes 20 bytes Ethernet Header...
Page 296 Test Setup - Test Configurator, Timer, and System Services - Profile Test Parameters Note: Unit selection is available from the SLA Parameters on page 285. For Dual Test Set, parameters are configurable for both local to remote (L->R) and remote to local (R->L) directions. For Dual Port topology, parameters are configurable for both P1 to P2 (P1->P2) and P2 to P1 (P2->P1).
Page 297 Test Setup - Test Configurator, Timer, and System Services - Profile SLA Parameters The Service-Level Agreement (SLA) parameters allow enabling and defining the pass/fail verdict thresholds for the service. For Dual Test Set, parameters are configurable for both local to remote (L->R) and remote to local (R->L) directions at the exception of Max Round-Trip Latency for which the value is unique.
Page 298 Test Setup - Test Configurator, Timer, and System Services - Profile CBS check box when selected (default) sets the maximum committed  burst size to which services’ frames will be sent and be CIR-compliant (default is 12144 bytes). The CBS minimum and maximum values are affected by the CIR, Burst Max Rate, and Frame Size values.
Page 299: Signal (Transport)
Test Setup - Test Configurator, Timer, and System Signal (Transport) Signal (Transport) From the Test menu, tap Setup, Test Configurator, the interface block, and the Signal tab. Physical Interface - Optical Note: For electrical interface, see Physical Interface - Electrical on page 289. Optical Lane indicates the optical lane number for parallel interfaces.
Page 300 Test Setup - Test Configurator, Timer, and System Signal (Transport) indicates, when supported, the minimum Min RX Power (dBm)  received power level of the optical lane/laser in dBm. Max RX Power (dBm) indicates, when supported, the maximum  received power level of the optical lane/laser in dBm. Laser ON/OFF button is used for parallel interfaces to activate the laser ...
Page 301 Test Setup - Test Configurator, Timer, and System Signal (Transport) Physical Interface - Electrical Note: The following settings are available with electrical signal and their availability depend on the signal itself and its mapping. For optical interface, see Physical Interface - Optical on page 287. LBO (Line Build Out): The LBO allows meeting the interface ...
Page 302 Test Setup - Test Configurator, Timer, and System Signal (Transport) Line Coding  Signal Line Coding AMI and B8ZS B3ZS AMI and HDB3 HDB3 STS-1e/STM-0e B3ZS STS-3e/STM-1e Default value. RX Termination  Signal Termination DS1/E1 Term , Mon, and Bridge. DS3/E3/E4/STS-1e/STM-0e/STS-3e/STM-1e Term , and Mon...
Page 303 Test Setup - Test Configurator, Timer, and System Signal (Transport) TX Frequency Note: The following TX Frequency information applies to serial interface only, refer to TX Frequency on page 175 for parallel interfaces. TX Frequency (GHz) indicates the frequency (actual frequency + ...
Page 304 Test Setup - Test Configurator, Timer, and System Signal (Transport) Interface Frequency Offset Nominal Frequency OTU1e ± 120 ppm 11049107143 bit/s OTU2e 11095727848 bit/s OTU1f 11270089286 bit/s OTU2f 11317642405 bit/s The frequency offset range is guaranteed for a source signal at 0 ppm. In the event that the source signal already has an offset, then the output signal may exhibit an offset larger than the range specified.
Page 305 Test Setup - Test Configurator, Timer, and System Signal (Transport) Note: For both Frequency and Offset the following background colors are used: Background color Description Green The frequency is in range. The frequency is out-of-range or LOC Lane. LOC is also displayed.
Page 306: Signal - Signal Configuration (Dsn/Pdh)
Test Setup - Test Configurator, Timer, and System Signal - Signal Configuration (DSn/PDH) Signal - Signal Configuration (DSn/PDH) For SONET/SDH - DSn/PDH BERT, from the test menu, tap Setup, Test Configurator, and the protocol block. Only Framing setting and the Loopback button are available.
Page 307 Test Setup - Test Configurator, Timer, and System Signal - Signal Configuration (DSn/PDH) Background For multiplex test case, allows the selection of the default timeslot background traffic: AIS (default) or All Zeros. The diagram above shows a test case defined with DSn/PDH traffic where the background traffic is also inserted for the unused timeslots in a test case data path.
Page 308 Test Setup - Test Configurator, Timer, and System Signal - Signal Configuration (DSn/PDH) Modify DS0/E0 Modify DS0/E0 button is only available when the DS0/E0 check box is selected. Note: For DS0, the framing structure has 24 timeslots. For E0, the framing structures PCM-30 and PCM30 CRC-4 have 30 channel timeslots (1 to 15 and 17 to 31) while PCM-31 and PCM-31 CRC-4 have 31 channel timeslots (1 to 31).
Page 309 Test Setup - Test Configurator, Timer, and System Signal - Signal Configuration (DSn/PDH) Note: Bit 8 is the Least-Significant Bit (LSB) and bit 1 is the Most-Significant Bit (MSB). Payload Content and Set All  Payload Content allows the selection of the payload content that will be applied to all TX timeslots when tapping the Set All button: Pattern, Idle, or Tone.
Page 310 Test Setup - Test Configurator, Timer, and System Signal - Signal Configuration (DSn/PDH)  Apply Channel TX to RX, available for decoupled test, allows applying the RX payload content based on the TX settings. None will be used when TX is set to either Idle or Tone. For E0 the timeslots 0 and 16 (PCM30 and PCM30 CRC4) are not configurable.
Page 311 Test Setup - Test Configurator, Timer, and System Signal - Signal Configuration (DSn/PDH) Command Loopback Type Loop-Up Loop-Down NIU FAC2 (11000/11100) 11000 11100 NIU FAC3 (100000/100) 100000 Loop-Up injects the selected loop up code. The loop code will be  generated continuously for a maximum of 10 seconds or until the loopback is confirmed.
Page 312 Test Setup - Test Configurator, Timer, and System Signal - Signal Configuration (DSn/PDH) DS1 Loopback - for NI/CSU Emulation Test The Loopback feature generates a code that is interpreted by the DUT. The DUT interprets the command and implements the loopback. Mode selects the loopback control Mode;...
Page 313 Test Setup - Test Configurator, Timer, and System Signal - Signal Configuration (DSn/PDH) Out-of-Band loop code Loop-UP Code Loop-Down Code Line 00001110 11111111 00111000 11111111 Payload 00010100 11111111 00110010 11111111 Reserved For Network Use 00010010 11111111 00100100 11111111 ISDN Line (NT2) 00101110 11111111 00100100 11111111 CI/CSU Line(NT1)
Page 314: Signal - Signal Configuration (Otn)
Test Setup - Test Configurator, Timer, and System Signal - Signal Configuration (OTN) Signal - Signal Configuration (OTN) Note: The following signal configuration parameters are available from the interface block. From the Test menu, tap Setup, Test Configurator, the interface block, and on the Signal tab.
Page 315 Test Setup - Test Configurator, Timer, and System Signal - Signal Configuration (OTN) ODU4, ODU3, ODU3e1, ODU3e2, ODU2, ODU2f, ODU1f, ODU2e,  ODU1e,ODU1, ODU0, or ODUflex. Only the higher ODU layer is available with Multi-Channel OTN. OPU Tributary Port , available for each OPU level of a mapped ...
Page 316 Test Setup - Test Configurator, Timer, and System Signal - Signal Configuration (OTN) Background Traffic, available for a multiplex signal, is used to  generate traffic on the timeslots that are not part of the foreground test traffic. Choices are Unallocated (available with PT21 only), AIS, Null Client, and PRBS31 (default).
Page 317 Test Setup - Test Configurator, Timer, and System Signal - Signal Configuration (OTN) Modify Tributary Slots/Port  The payload type 20 or 21 is indicated for each mapped OPU level. For... Mapped into... Tributary slot selection ODU3 OPU4 ODU2e OPU4 ODU1e ODU2 OPU4...
Page 318 Test Setup - Test Configurator, Timer, and System Signal - Signal Configuration (OTN) Tributary Port, configurable when the Fixed Structure check box  is cleared, allows selecting the Tributary Port number that will be associated to the selected tributary slots. When the Fixed Structure check box is selected, the Tributary Port is automatically assigned to either the selected slot number or for OPU3 to the first slot number in the column.
Page 319: Signal - Signal Configuration (Sonet/Sdh)
Test Setup - Test Configurator, Timer, and System Signal - Signal Configuration (SONET/SDH) Signal - Signal Configuration (SONET/SDH) For OTN-SONET/SDH BERT, from the Test menu, tap Setup, Test Configurator, the protocol block, and the Signal tab. For SONET/SDH BERT, from the Test menu, tap Setup, Test Configurator, the interface block, and the Signal tab.
Page 320 Test Setup - Test Configurator, Timer, and System Signal - Signal Configuration (SONET/SDH) REI-L/MS-REI Computation Method (OC-192/STM-64 only): Allows  selecting the default method used to calculate the REI-L/MS-REI error for OC-192 and STM-64 signals. Choices are M1 Only and both M0 and M1.
Page 321 Test Setup - Test Configurator, Timer, and System Signal - Signal Configuration (SONET/SDH) STS/AU Path (SONET/SDH HOP): The following diagram shows a test case data path that is terminated right after SONET/SDH high order path. High order background traffic is automatically adapted to the rate (STS-1, AU-3, or AU-4) signal level for the paths that are not defined in the test case.
Page 322 Test Setup - Test Configurator, Timer, and System Signal - Signal Configuration (SONET/SDH) VT/TU Path (SONET/SDH LOP) The following diagram shows a test case data path that is terminated at the SONET/SDH low order path. The remaining STS-1 or AU-3 timeslot not involved in the test case are filled with background traffic of STS-1 or AU-3 level depending on the interface being SONET or SDH.
Page 323: Smart Loopback
Test Setup - Test Configurator, Timer, and System Smart Loopback Smart Loopback Note: The Smart Loopback block is only displayed when the Transparent (Pseudo-Physical) check box is cleared (see Loopback Mode on page 125). From the Test menu, tap Setup, Test Configurator, and the Smart Loopback block.
Page 324 Test Setup - Test Configurator, Timer, and System Smart Loopback S-OAM Responder The S-OAM Responder check box when selected (default) allows responding to LBM, LTM, DMM, LMM, and SLM valid messages (test running or not). Traffic statistics are also monitored (refer to Responder on page 535).
Page 325: Streams - Global
Test Setup - Test Configurator, Timer, and System Streams - Global Streams - Global From the Test menu, tap Setup, Test Configurator, the protocol block, and the Global tab. The following parameters are displayed and configurable per stream. Check boxes: ...
Page 326 Test Setup - Test Configurator, Timer, and System Streams - Global Addressing MAC/IP indicates the source and destination MAC/IP  addresses for each stream. Tap on the Addressing MAC/IP button to modify the customer addressing (see MAC and IP from the MAC/IP/UDP tab).
Page 327: Streams - Profile
Test Setup - Test Configurator, Timer, and System Streams - Profile Streams - Profile The Traffic Gen & Mon test application supports the configuration of up to 16 different streams individually. From the Test menu, tap Setup, Test Configurator, the protocol block, and the Profile tab.
Page 328 Test Setup - Test Configurator, Timer, and System Streams - Profile Profile Profile button allows the selection and configuration of either Voice,  Video, or Data (default) emulation profile. The selected profile icon and its Codec for Voice and Video are displayed next to the Profile button.
Page 329 Test Setup - Test Configurator, Timer, and System Streams - Profile Frame Size (Bytes) for Data profile is selectable: Fixed (default),  Random, or Sweep. The Frame Size is forced to Fixed for Voice and Video profiles. Only Fixed frame size is available when using Provider Encapsulation.
Page 330 Test Setup - Test Configurator, Timer, and System Streams - Profile For Sweep type, the first frame is generated starting with the  minimum number of bytes defined then each subsequent frame is incremented by 1 byte until the maximum number of bytes is reached and start over with minimum.
Page 331 Test Setup - Test Configurator, Timer, and System Streams - Profile Shaping TX Mode allows the selection of the transmission mode for the  selected stream when Data profile is selected. The TX Mode is forced to Continuous for Voice and Video profiles and when using Provider Encapsulation.
Page 332 Test Setup - Test Configurator, Timer, and System Streams - Profile Customer Frame TX Rate, available when using Provider  Encapsulation, indicates the customer frame TX rate based on the TX Rate defined. Frame Count is only available with n-Frame Transmit Mode. Enter the ...
Page 333 Test Setup - Test Configurator, Timer, and System Streams - Profile Total TX Rate indicates the percentage of the total line utilization  which is the sum of all TX rate enabled streams. Note: The Individual stream can be enabled/disabled even when the test is started and running.
Page 334 Test Setup - Test Configurator, Timer, and System Streams - Profile Customer Frame Throughput. available when using Provider  Encapsulation, displays the calculated customer frame throughput minimum and maximum thresholds based on the throughput values. Frame Loss Count/Rate check box when selected enables the Frame ...
Page 335: Synce
Test Setup - Test Configurator, Timer, and System SyncE SyncE From the Test menu, tap Setup, Test Configurator, and the SyncE test block. ESMC Monitoring ESMC (Ethernet Synchronization Message Channel) is a live value  monitored even when the test is not started. An arrow next to the ESMC label indicates that ESMC valid information frames are received or not.
Page 336 Test Setup - Test Configurator, Timer, and System SyncE Pass/Fail Verdict check box when selected (default) enables the use  of the pass/fail verdict. The global pass/fail verdict is based on the following criteria: ESMC Rate Threshold (when enabled), QL Mismatch Monitoring (when enabled), ESMC Loss, or Link Down.
Page 337: System
Test Setup - Test Configurator, Timer, and System System System From the Test menu, tap Setup, and System. Factory Default Restore Default button restores the factory default settings for all test  applications. Restore Default at Start-Up check box when cleared (default), ...
Page 338: Ta-Sfp28
Test Setup - Test Configurator, Timer, and System TA-SFP28 TA-SFP28 Gives the transceiver adapter insertion counter and information on the inserted transceiver module. Note: Only available with FTBx-88260 modules. From the Test menu, tap Setup, Test Configurator, tap on the interface block and on the transceiver adaptor (TA-...) tab.
Page 339: Tcp Throughput
Test Setup - Test Configurator, Timer, and System TCP Throughput TCP Throughput From the Test menu, tap Setup, Test Configurator, and tap on the test block. TCP Mode Since two units are required to perform a TCP Throughput test, one unit must be the source (Local) unit and the other one the destination (Remote).
Page 340 Test Setup - Test Configurator, Timer, and System TCP Throughput TCP Throughput Configuration Note: TCP Throughput Configuration is only available on the local unit. Initial Window Size is the window size that is used when the test is  started: 1024 Bytes to 65536 KBytes (default is 2 KBytes). The Initial Window Size value must be between the Minimum Window Size and the Maximum Window Size values.
Page 341: Test Sequence (Ioptics)
Test Setup - Test Configurator, Timer, and System Test Sequence (iOptics) Test Sequence (iOptics) From the Test menu, tap Setup, and Test Configurator. Power Threshold (W) indicates the power consumption threshold  based on the power level/class detected including uncertainty from the selected transceiver to declare the pass/fail verdict.
Page 342: Timer
Test Setup - Test Configurator, Timer, and System Timer Timer Allows starting and/or stopping automatically the test at a given time or for a specific duration. From the Test menu, tap Setup, and Timer. Timer Note: For RFC 2544 and RFC 6349, only Start Time and the ARM button are available.
Page 343 Test Setup - Test Configurator, Timer, and System Timer Stop Time selects the time the test will automatically stop. The Stop  Time check box has to be selected to be included in the test timer. Note: A valid stop time has to be subsequent to the current time or to the start time, when enabled.
Page 344: Traces (Otn)
Test Setup - Test Configurator, Timer, and System Traces (OTN) Traces (OTN) For OTN BERT and OTN-SONET/SDH BERT: From the Test menu tap Setup, Test Configurator, tap on the interface block, and on the Traces tab. For Multi-Channel OTN: From the Test menu, tap Setup, Test Configurator, tap on either: the interface block, and on the Traces tab to configure the higher ODU ...
Page 345 Multi-Channel OTN Traces OTN-SONET/SDH BERT (lower ODU layer) Multi-Channel OTN (higher ODU layer) EXFO OTU SAPI EXFO OTU SAPI EXFO ODU SAPI XFO ODU SAPI EXFO TCMi SAPI The default message contains a NULL (all 0’s) character preceding it. NULL (all 0’s) characters are automatically appended to the message for bytes that are not defined.
Page 346 TTI Traces Default Message OTN BERT Multi-Channel OTN OTN-SONET/SDH BERT EXFO OTU OPERATOR SPECIFIC EXFO OTU OPERATOR SPECIFIC EXFO ODU OPERATOR SPECIFIC XFO ODU OPERATOR SPECIFIC EXFO TCMi OPERATOR SPECIFIC NULL (all 0’s) characters are automatically appended to the message for bytes that are not defined.
Page 347 Test Setup - Test Configurator, Timer, and System Traces (OTN) SAPI OTU/ODU/TCM-TIM check box, when selected (cleared by  default), allows editing the expected Source Access Point Identifier (SAPI) and also enables OTU/ODU/TCM-TIM alarm monitoring. DAPI OTU/ODU/TCM-TIM check box, when selected (cleared by ...
Page 348: Traces (Sonet/Sdh)
J0/J1/J2 EXFO SONET/SDH J0/J1/J2 EXFO SONET/SDH Analyzer Section/RS trace test message EXFO SONET/SDH Analyzer high order path trace test message J1 (STS/AU) EXFO SONET/SDH Analyzer low order path trace test message J1 (TU-3)/J2 Hexadecimal value. Refer to OH - SONET/SDH on page 591 to change this value.
Page 349 Test Setup - Test Configurator, Timer, and System Traces (SONET/SDH) Note: 16-bytes selection allows typing up to 15 bytes (a CRC-7 byte will be added in front for a total of 16 bytes). 64-bytes selection allows typing up to 62-bytes (<C >...
Page 350: Wander
Test Setup - Test Configurator, Timer, and System Wander Wander From the Test menu, tap Setup, Test Configurator, and the Wander test block. Test Sampling Rate is the time error measurement sampling rate:  30 samples/s (default), 20 samples/s, 10 samples/s, 5 samples/s, and 1 sample/s.
Page 351 Test Setup - Test Configurator, Timer, and System Wander Mask MTIE TDEV G.8261- CES Case 2A - 2048 kbit/s (MRTIE) G.8261- EEC Option 1 - SyncE Interface G.8261- EEC Option 2 - SyncE Interface G.8261.1- PEC-Slave Frequency Case 3 G.8262- EEC Option 1- SyncE - Constant Temperature G.8262- EEC Option 1- SyncE - Variable Temperature G.8262- EEC Option 2- SyncE - Constant Temperature G.8263- PEC-Slave Frequency - Constant Temperature...
Page 352 Test Setup - Test Configurator, Timer, and System Wander Verdict The following pass/fail verdict are available and configurable when applicable. MAX Absolute TE (ns) check box when selected, allows selecting the  maximum absolute time error threshold value: 50 ns to 2000 ns (default is 1100 ns).
Page 353: Test Results
Test Results The Test Results menu offers the following structure: Intelligent Apps test applications Test Application Page iOptics iSAM Logger Summary <--- Transport test applications Available with Multi- OTN- Page SONET/SDH DSn/PDH NI/CSU Channel SONET/SDH BERT BERT BERT Emulation BERT Alarms/Errors FTFL/PT or PT GFP-F/GFP-T...
Page 354 Test Results Ethernet test applications Test Application Tab - Subtab Page Alarms/Errors Graph Link OAM Logger S-OAM / MPLS-TP OAM Service Configuration - Burst Service Configuration - Ramp Service Performance Streams - Customer Frame Throughput Streams - Frame Loss / Out-of-Sequence Streams - Jitter Streams - Latency Streams - MPLS...
Page 355 Test Results Sync test applications Test Application Page 1588 PTP SyncE Wander Alarms/Errors Analysis - MTIE/TDEV Analysis - Time Error Logger PTP Stats Quality Level (1588 PTP) Quality Level (SyncE) Summary <--- Traffic - Ethernet Fibre Channel test application Test Application Page Fibre Channel BERT Alarms/Errors...
Page 356: Alarms/Errors Overview
Test Results Alarms/Errors Overview Alarms/Errors Overview Current and history alarms/errors are displayed using different background colors as defined in the following table. Background Alarm/ Description color Error Gray Current No test result available. History Green Current No alarm/error has occurred in the last second. History No alarm/error has occurred during the test.
Page 357 Test Results Alarms/Errors Overview Pass/Fail Verdict Note: The verdict is not displayed when disabled or unavailable. The Pass/Fail verdict is represented by the following icons: Icon Verdict Description PASS Result value meet the configured threshold criterion. FAIL Result value does not meet the configured threshold criterion. Statistic Values Current indicates the average measurements in the last second.
Page 358 Test Results Alarms/Errors Overview Alarms/Errors From the Test menu, tap Results, and the Alarms/Errors tab. Depending on the test structure, the Alarms/Errors page may be split in different tabs such as OTN, GFP-T/GFP-F, and Ethernet; tap on the desired tab when required.
Page 359 Test Results Alarms/Errors Overview The following table lists the availability of alarms/errors per layer for TX and RX. Layer Alarms/Errors Page TX/RX RX only Pattern Loss No Traffic, Client Frequency Bit Error, Pattern Error Mismatch ‘0’, Mismatch ‘1’, Frame Loss, Out-of-Seq. CLOCK LOC, LOPPS-L, LOPPS-R CPRI...
Page 360 Test Results Alarms/Errors Overview Layer Alarms/Errors Page TX/RX RX only LFD, DCI, FDI, RDI, LOCS, LOCCS, EXM, UPM, Reserved CMF User-Defined CMF cHEC-CORR, cHEC-UNCORR, tHEC-CORR, tHEC-UNCORR, eHEC-CORR, eHEC-UNCORR, SB-CORR (Post), SB-CORR (Pre), SB-UNCORR, 10B_ERR, pFCS Cm-CRC-8, CnD-CRC-5 Interface LOC Lane, Frequency, LOC BPV, EXZ, CV, K30.7 IP/UDP/TCP IP Chksum, UDP Chksum,...
Page 361 Test Results Alarms/Errors Overview Layer Alarms/Errors Page TX/RX RX only S-OAM RDI, AIS, LCK, C-LOS, C-FDI, C-RDI, C-DCI Loss Continuity, Mismerge, Unexp MEG Lvl, Unexp MEP, Unexp Period Section/Line / LOF-S/RS-LOF, SEF/RS-OOF, AIS-L/MS-AIS, TIM-S/RS-TIM RS/MS RDI-L/MS-RDI FAS-S/RS-FAS, B1, B2, REI-L/MS-REI STS-x / AU-x AIS-P/AU-AIS, LOP-P/AU-LOP, TIM-P/HP-TIM, PLM-P/HP-PLM...
Page 362 Test Results Alarms/Errors Overview Alarms No Traffic (Available with EtherBERT or OTN BERT with EoOTN client)  Ethernet: No pattern traffic has been received in the last second. Fibre Channel: No traffic is being transmitted when Login Management fails; a pop up displays No Data is being transmitted on Port(s) <port number>.
Page 363 Test Results Alarms/Errors Overview Mismatch ‘0’ (Available with EtherBERT and OTN BERT with EoOTN  client; not available with 100GE - 4 Unframed CAUI-4 and OTU4 - 4 Unframed Physical Lanes on 88200NGE.) RX: There is a bit error on a binary ‘0’ (for example ones that should be zeros) found in the test pattern only.
Page 364 Test Results Alarms/Errors Overview CPRI Note: CPRI alarms/errors are only available for Framed L2. Alarms Link Down  RX: Indicates that the start-up sequence is not in F (Operation) or G (Passive) link state. LOF (Loss Of Frame)  RX: The hyperframe alignment cannot be achieved or is lost. R-LOS (Remote - Loss Of Signal) ...
Page 365 Test Results Alarms/Errors Overview Note: For Wander test application only AIS and OOF alarms are supported. Alarms AIS (Alarm Indication Signal)  RX: An unframed all-ones signal is received. OOF (Out-OF-Frame)  RX: Four consecutive frame bit errors are detected. RAI (Yellow) (Remote Alarm Indication) ...
Page 366 Test Results Alarms/Errors Overview Alarms AIS (Alarm Indication Signal)  RX: The M-frame contains zeros (0) for C-bits, ones (1) for X-bits, 1010... repeating sequence with a one (1) immediately following any of the control bit positions for the information bits. Idle (DS3 Idle) ...
Page 367 Test Results Alarms/Errors Overview Note: For Wander test application only AIS and LOF alarms are supported. Alarms Note: Only AIS is available when the framing is set to Unframed. AIS (Alarm Indication Signal)  RX: Two or less ZEROs are received in each of two consecutive double frame periods (512 bits).
Page 368 Test Results Alarms/Errors Overview Errors FAS (Frame Alignment Signal) is only available with PCM30 CRC-4 or  PCM31 CRC-4 framing. RX: Bits 2 to 8 of the frame containing the FAS differ from 0011011. CRC-4 (Cyclical Redundancy Check)  RX: One or more bit errors are detected in a block of data through cyclical redundancy check.
Page 369 Test Results Alarms/Errors Overview Alarms Note: Only AIS is available when the framing is set to Unframed. AIS (Alarm Indication Signal)  RX: An unframed all-ones signal is received. LOF (Loss Of Frame)  RX: Four consecutive incorrect frame alignment signals is received. RAI (Remote Alarm Indication) ...
Page 370 Test Results Alarms/Errors Overview Alarms Note: Only AIS is available when the framing is set to Unframed. AIS (Alarm Indication Signal)  RX: An unframed all-ones signal is received. LOF (Loss Of Frame)  RX: Four consecutive incorrect frame alignment signals is received. RAI (Remote Alarm Indication) ...
Page 371 Test Results Alarms/Errors Overview Ethernet Note: Available with EtherBERT, Wander, and OTN BERT with EoOTN client. For Wander test application only Link Down alarm is supported. Alarms Note: For LOA, Inv. Mapping, L Deg SER Det, L Deg SER Rcd, and R Deg SER alarms see Ethernet - PCS on page 362.
Page 372 Test Results Alarms/Errors Overview Client Frequency (available with EoOTN 1GbE client)  RX: The received client signal rate doesn’t meet the standard rate specification of 1250000000 ± 150000 bps (± 120 ppm). Errors Symbol  RX/TX: Invalid code-group is detected/generated in the code. Idle ...
Page 373 Test Results Alarms/Errors Overview Oversize (available when the Oversize Monitoring check box is  selected.) RX: Frames larger than 1518 bytes with a valid FCS; 1534 bytes EoE; 1536 bytes for PBB-TE. Runt  RX: Frames smaller than 64 bytes with an invalid FCS; 80 bytes for EoE; 82 bytes for PBB-TE.
Page 374 Test Results Alarms/Errors Overview Ethernet - PCS Note: Available with parallel interfaces only: 40/100/400G Gbit/s Ethernet and OTN with 40/100GbE Ethernet client. Available under the PCS sub tab for Through Mode test providing alarms/errors for both ports. Alarms LOA (Loss Of Alignment) ...
Page 375 Test Results Alarms/Errors Overview Errors The following errors are available with 400G: 66B Block (Available with 400G)  RX: Invalid 64b/66b block code are received. An invalid 64b/66b block is declared when the synchronization field has a value of 00 or 11. FEC-UNCOR-CW (Available with 400G when RS-FEC is enabled) ...
Page 376 Test Results Alarms/Errors Overview Ethernet - PCS Lanes Note: Available with parallel interfaces only: 40/100/400G Gbit/s Ethernet and OTN with 40/100 GbE Ethernet client. Available under the PCS sub tab for Through Mode test providing alarms/errors for both ports. Skew Alarm Threshold (bits), available with Ethernet test application, ...
Page 377 Test Results Alarms/Errors Overview Exc. Skew (Excessive Skew)  RX: The skew exceeds the defined threshold (see Skew Alarm Threshold (bits) on page 145). Errors Block is available with Ethernet test applications and 100 GbE over  OTU4. Injection is not available when RS-FEC is enabled. RX: Invalid 64b/66b block code are received.
Page 378 Test Results Alarms/Errors Overview Fibre Channel Alarms Link Down  RX: The Fibre Channel connection is down meaning that there is a local or a remote fault condition. Local Fault Detected (FC 10X)  RX: Indicates that at least one of the following events is detected: LOS, Loss of bit synchronization, Loss of Block synchronization, Link down, or High BER (High BER is true when the bit error ratio >...
Page 379 Test Results Alarms/Errors Overview Error Symbol (FC 1X/2X/4X/8X)  RX/TX: Invalid code-group is detected/generated in the code. Block (FC 10X/16X)  RX: The number of frames received with an errored block condition. FCS (Frame Check Sequence)  RX: Frames with an invalid FCS are received. Oversize ...
Page 380 Test Results Alarms/Errors Overview GFP (Generic Framing Procedure) Note: Available from the GFP-F/GFP-T sub-tab. Alarms GFP-LFD (GFP - Loss of Frame Delineation)  RX: Indicates that the GFP engine is out of synchronization. TX: Generates a sufficient number of cHEC uncorrectable errors to avoid synchronization.
Page 381 Test Results Alarms/Errors Overview GFP-FDI (GFP - Forward Defect Indication) is available with GFP-F.  RX: The FDI alarm is declared when CMF frame is received with an UPI set to “0000 0100”. TX: Generates a client FDI by setting the UPI field to “0000 0100”. Note that the configuration of the CMF pFCS check box (see GFP-F/GFP-T on page 181) is temporarily cleared and the UPI value changed when the GFP-FDI alarm is selected.
Page 382 Test Results Alarms/Errors Overview GFP-Reserved CMF (Client Management Frame) is available when the  Reserved CMF Monitoring check box is selected. RX: CMF alarms other than the ones described above. Reserved CMF Monitoring check box, when selected, allows monitoring the GFP-Reserved CMF alarms. GFP-UserDefined CMF ...
Page 383 Test Results Alarms/Errors Overview GFP-tHEC-UNCORR (GFP - type Header Error Check - Uncorrectable)  RX: Indicates that two or more bit errors have been detected in the Type header (tHEC, PTI, PFI, EXI, and UPI). TX (requires client data frame generation): Generates a “Walking 11” pattern to hit all consecutive 2 bits applicable to the bits covered by the tHEC, PTI, PFI, EXI and UPI.
Page 384 Test Results Alarms/Errors Overview GFP-SB-UNCORR (GFP - Superblock Uncorrectable) is available with  GFP-T. RX: Indicates that two or more bit errors have been detected in the CRC-16 word of the superblock. Note that if two errors are spaced by exactly 43 bits, they will not be reported as uncorrectable.
Page 385 Test Results Alarms/Errors Overview GMP and ODTU4.1 - GMP (Generic Mapping Procedure) Note: GMP is only available with EoOTN client (ODU0 with PT21). GMP is displayed under ODUx alarms/errors group. GMP is labelled as ODTU4.1 - GMP with Multi-Channel OTN. Alarms OOS (Generic Mapping Procedure - Out Of Synchronization).
Page 386 Test Results Alarms/Errors Overview Interface Alarms LOS (Loss Of Signal)  RX: Absence of an input signal or an all-zeros pattern is received. Available for each Optical Lane for parallel interfaces. For CPRI Framed L2: Absence of an input signal or at least 16 8B/10B code violations occur in one hyperframe.
Page 387 Test Results Alarms/Errors Overview For serial interfaces: Interface Standard Rate Specification 1544000 ±36.6 ppm 2048000 ±54.6 ppm 34368000 ±24.6 ppm 44736000 ±24.6 ppm STS-1e/STM-0e, OC-1/STM-0 51840000 ±20 ppm 139264000 ±19.6 ppm STS-3e/STM-1e, OC-3/STM-1 155520000 ±20 ppm OC-12/STM-4 622080000 ±20 ppm OC-48/STM-16 2488320000 ±20 ppm OTU1...
Page 388 Test Results Alarms/Errors Overview EXZ (Excessive Zeros)  For DS1 with AMI Line Coding, more than 15 consecutive bit periods with no pulses have been received. For DS1 with B8ZS Line Coding, more than 7 consecutive bit periods with no pulses have been received. For DS3, more than 2 consecutive bit periods with no pulses have been received.
Page 389 Test Results Alarms/Errors Overview OBSAI Note: OBSAI alarms/errors are only available for Framed L2. Alarms Link Down  RX: Indicates that the RX state machine is not FRAME_SYNC. LOF (Loss Of Frame)  RX: The RX state machine is in either WAIT_FOR_K28.7_IDLES or SCR_CAP state.
Page 390 Test Results Alarms/Errors Overview ODUx Note: For OPUx alarms see page 383. For GMP alarms/errors see page 373. Alarms AIS (Alarm Indication Signal)  RX: The STAT information in the PM byte 3, bits 6 to 8 is “111” for at least 3 consecutive frames.
Page 391 Test Results Alarms/Errors Overview FSF (Forward Signal Fail)  RX: The FTFL byte 0 is “00000001”. TX: Generates a “00000001” pattern in the FTFL Byte 0 continuously. LCK (Lock)  RX: STAT information in the PM byte 3, bits 6 to 8 is “101” for at least 3 consecutive frames.
Page 392 Test Results Alarms/Errors Overview Errors BIP-8 (Bit Interleave Parity-8)  RX: There is a PM BIP-8 mismatch between the received value and locally computed value (0 to 8). BEI (Backward Error Indication)  RX: Interleaved block in error detected by the corresponding ODU path monitoring sink using the BIP-8 code.
Page 393 Test Results Alarms/Errors Overview ODUx-TCM Alarms BDI (Backward Defect Indication)  RX: The BDI bit in the TCM overhead field Byte 3, bit 5 is “1” for at least 5 consecutive frames. TX: Generates a "1" in the BDI bit of the TCM overhead field (byte 3, bit 5) continuously.
Page 394 Test Results Alarms/Errors Overview Errors BIP-8 (Bit Interleave Parity-8)  RX: There is a TCM BIP-8 mismatch between the received value and locally computed value (0 to 8). BEI (Backward Error Indication)  RX: Interleaved block in error detected by the corresponding ODU tandem connection monitoring sink using the BIP-8 code.
Page 395 Test Results Alarms/Errors Overview OPUx Note: OPUx is displayed under ODUx alarms/errors group. Alarms AIS (Alarm Indication Signal) is only available on the OPU client signal  (designated as LO in the standard). RX: A PRBS11 pattern is received indicating a failure of the client signal.
Page 396 Test Results Alarms/Errors Overview OOMFI (Out of OPU Multi-Frame Identifier) is only available for OPU4  of a mapped signal. RX: OPU Multi-frame Identifier number are in error for at least 5 consecutive OTU frames. PLM (Payload Mismatch) is available when OPU-PLM check box is ...
Page 397 Test Results Alarms/Errors Overview Alarms LOL (Loss of Lane Alignment)  RX: Multilane alignment process is in the out-of-alignment (OLA) state for 3 ms. LOF (Loss of Frame)  RX: OOF is present for at least 3 ms. OOF (Out-Of-Frame) ...
Page 398 Test Results Alarms/Errors Overview OTUx Note: Available for OTU4, OTU3, OTU3e1, OTU3e2, OTU2, OTU2f, OTU1f, OTU2e, OTU1e, and OTU1. Alarms AIS (Alarm Indication Signal) available with serial interfaces only.  RX: Polynomial number 11 (PN-11) is over all OTU frame bits including FAS and MFAS for at least 3 consecutive 8192 bit-interval.
Page 399 Test Results Alarms/Errors Overview LOF (Loss of Frame)  RX: OOF is present for at least 3 ms. TX: Generates error in all FAS bits continuously. LOM (Loss Of Multiframe)  RX: OOM is present for at least 3 ms TX: Generates error in MFAS bits continuously.
Page 400 Test Results Alarms/Errors Overview Errors BEI (Backward Error Indication)  RX: SM BEI errors are received from the DUT (value 0 to 8). OTU BEI bits ODUk BEI bits BIP violations BIP violations (1234) (1234) 0000 0101 0001 0110 0010 0111 0011 1000...
Page 401 Test Results Alarms/Errors Overview FEC-UNCORR (FEC - Uncorrectable)  RX: Statistics on the detected codewords (CW) having uncorrectable errors. TX: FEC-UNCORR-CW (Forward Error Correction - Uncorrectable - Codeword) generates 16 symbol (bytes) containing 8 bits in error each, in each codeword. FEC-STRESS (Forward Error Correction - Stress) ...
Page 402 Test Results Alarms/Errors Overview Alarms Loss Sync  RX: The Slave Clock does not receive packet timing signal messages (Sync, Follow Up, Delay Resp) within their expected arrival time for a duration exceeding the configured Receipt Timeout (refer to Alarm Timeout/Threshold on page 137).
Page 403 Test Results Alarms/Errors Overview QoS Metrics Note: Only available with Traffic Gen & Mon test application. Errors Frame Loss  RX: A sequence number is missing in the received frames. Out-of-Seq. (Out-of-Sequence)  RX: The received frame sequence number is either smaller than the expected frame sequence number or is a duplicate number.
Page 404 Test Results Alarms/Errors Overview RS-FEC Alarms FEC-LOA (FEC-Loss Of Alignment)  RX: Deskew process is not complete meaning that not all lanes are synchronized (Alignment Marker locked) and aligned. FEC-LOAML (FEC-Loss Of Alignment Marker Lock)  RX: The location of the alignment marker payload sequence for a given lane on the PMA service interface is not detected.
Page 405 Test Results Alarms/Errors Overview S-OAM and MPLS-TP OAM Alarms Note: The following alarms are available when the CC Function check box is selected (refer to page 271). Loss Continuity  RX: No CCM frames with same or lower MEG/MD Level were received from the peer MEP within an interval equal to 3.5 times the configured CCM transmission period.
Page 406 Test Results Alarms/Errors Overview Unexp MEP (Unexpected MEP)  RX: A CCM frame was received from the peer MEP with same MEG/MD Level, correct MEG ID/MAID, and correct source MAC Address (corresponds to the peer MEP) but with unexpected MEP ID. The alarm is cleared when no CCM frames with same MEG/MD Level, correct MEG ID/MAID, correct source MAC Address (corresponds to the peer MEP) but with an unexpected MEP ID are received within an interval...
Page 407 Test Results Alarms/Errors Overview Note: The following alarms are available with G.8113.1, Y.1731 and MEF modes. AIS (Alarm Indication Signal)  RX: A valid AIS frame is received. A valid frame has its destination MAC address matching either the unit port Unicast MAC address or a Multicast class 1 address (refer to page 757), VLANs matching the unit port VLANs, and MEG level matching the local MEG level.
Page 408 Test Results Alarms/Errors Overview C-FDI (Client Signal Fail - Forward Defect Indication)  RX: A CSF frame is received with CSF type equal to 001.The alarm is cleared when no CSF (C-FDI) frames are received during an interval equal to 3.5 times the CSF transmission period indicated in the last received CSF (C-FDI) frame, or when a CSF frame is received with Client Defect Clear Indication (C-DCI) information (CSF Type 011).
Page 409 Test Results Alarms/Errors Overview Section/Line / RS/MS Alarms LOF-S (Loss Of Frame - Section) - SONET  RS-LOF (Regeneration Section - Loss Of Frame) - SDH RX: A SEF (SONET)/RS-OOF (SDH) defect on the incoming optical signal persists for at least 3 milliseconds. TX: Generates non-valid framing bytes (A1 and A2).
Page 410 Test Results Alarms/Errors Overview RDI-L (Remote Defect Indication - Line) - SONET  MS-RDI (Multiplex Section - Remote Defect Indication) - SDH RX: Bits 6, 7, and 8 of the K2 byte contain the “110” pattern in five consecutive frames. TX: Generates a “110”...
Page 411 Test Results Alarms/Errors Overview STS-x/AU-x Alarms AIS-P (Alarm Indication Signal - Path) - SONET  AU-AIS (Administrative Unit - Alarm Indication Signal) - SDH RX: The H1 and H2 bytes contain an all-ones pattern in three consecutive frames or more. TX: Generates an all-ones pattern over H1, H2, H3, and SPE.
Page 412 Test Results Alarms/Errors Overview PLM-P (Payload Label Mismatch - Path) - SONET  HP-PLM (HP - Payload Label Mismatch) - SDH RX: Five consecutive frames have mismatched STS/VC signal labels (C2 byte). Only available when PLM-P/UNEQ-P / HP-PLM/HP-UNEQ is enabled (refer to Labels on page 196). PDI-P (Payload Defect Indication - Path) - SONET ...
Page 413 Test Results Alarms/Errors Overview ERDI-PSD (Enhanced RDI - Path Server Defect) - SONET  ERDI-SD (Enhanced RDI - Server Defect) - SDH RX: Bits 5, 6 and 7 of the G1 byte contain the “101” pattern in five consecutive frames. TX: Generates a “101”...
Page 414 Test Results Alarms/Errors Overview TCM (SONET/SDH) Note: TCM is displayed for rates up to OC-192/STM-64 under the STS-x/AU-x or VT/TU alarms/errors group when TCM is enabled. Alarms TC-UNEQ-P / HPTC-UNEQ (Unequipped)  RX/TX: An all “0”s pattern is received/generated in the higher order path signal label byte (C2), the TCM byte (N1) and the path trace byte (J1), and a valid BIP-8 bytes (B3).
Page 415 Test Results Alarms/Errors Overview TC-TIM-P / TC-TIM-V / HPTC-TIM / LPTC-TIM (Trace Identifier  Mismatch) RX: The received message differs from the defined expected message. The TC-TIM is also declared when receiving invalid ASCII characters or when errors are detected with CRC-7. TC-RDI-P / TC-RDI-V / HPTC-RDI / LPTC-RDI (Remote Defect ...
Page 416 Test Results Alarms/Errors Overview TC-IEC-P / HPTC-IEC (Incoming Error Count)  RX: The TC-IEC indicates the number of B3 parity violations detected at the TC Source for STS-1 SPE/VC-3 and above (bits 1 to 4 of the N1 byte). Number of Number of BIP-8 violations BIP-8 violations...
Page 417 Test Results Alarms/Errors Overview Transcoding Note: Only available with OTU3 BERT test application with 40 GbE client. Alarms LOBL1027B (Loss of Block Lock 1027 Blocks)  RX: Sixteen 1027-bit blocks with invalid 3-bit patterns are received before sixty-four valid blocks. Hi-BER1027B (High-Bit Error Ratio 1027 Blocks) ...
Page 418 Test Results Alarms/Errors Overview VT/TU Alarms AIS-V (Alarm Indication Signal - VT) - SONET  TU-AIS (Tributary Unit - Alarm Indication Signal) - SDH RX: V1 and V2 bytes for the VT/TU path contain an all-ones pattern in three (SONET) / five (SDH) consecutive superframes. TX: Generates an all-ones pattern for the V1 and V2 bytes of the VT/TU path and payload.
Page 419 Test Results Alarms/Errors Overview TIM-V (Trace Identifier Mismatch - VT) - SONET  LP-TIM (LOP - Trace Identifier Mismatch) - SDH SONET: The J2 Trace doesn’t match the expected message value.  Only available when the TIM-V check box is selected (refer to page Traces (SONET/SDH) on page 336).
Page 420 Test Results Alarms/Errors Overview ERDI-VCD (Enhanced RDI - VT Connectivity Defect) - SONET  LP-ERDI-CD (LOP - Enhanced RDI - Connectivity Defect) - SDH RX: Bits 5, 6, and 7 of the Z7 (SONET) / K4 (SDH) byte contain the “110” pattern, and bit 8 of the V5 byte contain “1”, in five consecutive VT/LP superframes.
Page 421 Test Results Alarms/Errors Overview Note: Available under the WIS sub tab for 10G WAN interface only. Alarms WIS Link Down  RX: At least one of the following errors is present: AIS-P, LOF, PLM-P , SEF, LOP, or AIS-L. SEF (Severely Errored Framing) ...
Page 422 Test Results Alarms/Errors Overview RDI-P (Remote Defect Indication - Path)  RX: Bits 5, 6 and 7 of the G1 byte contain the “100" or “111" pattern in ten consecutive frames. TX: Generates a “100” pattern for bits 5, 6 and 7 of the G1 byte. LCD-P (Loss of Code-Group Delineation - Path) ...
Page 423 Test Results Alarms/Errors Overview ERDI-PCD (Enhanced RDI - Path Connectivity Defect)  RX: Bits 5, 6 and 7 of the G1 byte contain the “110” pattern in five to ten consecutive frames. TX: Generates a “110” pattern for bits 5, 6 and 7 of the G1 byte. ERDI-PPD (Enhanced RDI - Path Payload Defect) ...
Page 424 Test Results Alarms/Errors Overview REI-L (Remote Error Indicator - Line)  RX: Bits 5 through 8 of the M0 byte contain one pattern from the following binary range: “0001" through “1000" (1 to 8) (located in the first STS-1 of an STS-n signal). REI-P (Remote Error Indicator - Path) ...
Page 425 Test Results Alarms/Errors Overview Inject Button Open/Close pop-up button Selected Alarm/Error and status Layer: Allows selecting on which layer is the alarm/error to be  generated. Choices depend on the test application and its interface. For Multi-Channel OTN using mix-mapping, ODUk and OPUk represent ODU and OPU levels of the selected channel(s).
Page 426 Test Results Alarms/Errors Overview Manual allows entering the amount of error to be generated: 1  (default) through 50 or 100 (depends on the selected error). Rate allows the selection of the error injection rate. The rate must  be within the minimum and maximum values specified. Max Rate generates the error to its theoretical maximum rate.
Page 427 Test Results Alarms/Errors Overview The following settings are available with Carrier Ethernet OAM test application. Address Type defines the destination address type of the frame:  Unicast or Multicast (default). Priority allows selecting the VLAN user priority: 0 (default) to 7. ...
Page 428 Test Results Alarms/Errors Overview Inject button  For Manual mode: Manually generates the selected errors according to the defect and the amount selected. For Rate and Max Rate: Generates respectively the selected error at the rate specified or at its theoretical maximum rate. Note: The selected alarm/error as well as its injection mode and status are displayed next to the Inject button.
Page 429: Analysis - Mtie/Tdev
Test Results Analysis - MTIE/TDEV Analysis - MTIE/TDEV From the Test menu, tap Results, Analysis, and the MTIE/TDEV tab. Graph Graphically displays the MTIE/TDEV values in function of the observation interval. The MTIE and TDEV masks are also displayed when supported by the selected standard.
Page 430 Test Results Analysis - MTIE/TDEV Cursor The Cursor check box when selected (default), allows the selection of a specific observation interval value and returns the MTIE/TDEV values and the corresponding mask when enabled. Arrow buttons: Use the left and/or right arrow buttons to move the ...
Page 431: Analysis - Time Error / Time Interval Error
Test Results Analysis - Time Error / Time Interval Error Analysis - Time Error / Time Interval Error From the Test menu, tap Results, Analysis, and the Time Error tab. Graph Graphically displays the time error values as a function of time. Note: A refresh is required to update the graph (see Refresh below).
Page 432 Test Results Analysis - Time Error / Time Interval Error Save TE/TIE Data Saves the TE/TIE data into CSV file format. Folder Path allows the selection of the file destination drive and folder.  Use the Browse button to change the file location. The default file location is: Users\<User>\Documents\88000-PowerBlazer\Wander File Name allows the selection of the file name.
Page 433: Ftfl/Pt And Pt
Test Results FTFL/PT and PT FTFL/PT and PT For OTN BERT and OTN-SONET/SDH BERT: From the Test menu tap Results, and the FTFL/PT tab. For Multi-Channel OTN: From the Test menu, tap Results, and the PT tab. Channel Available with Multi-Channel OTN, allows the selection of the channel number.
Page 434 Test Results FTFL/PT and PT Operator Identifier displays the received operator identifier (bytes 1  to 9 for forward, byte 129 to 137 for backward). Operator Specific displays the received operator specific (bytes 10 to  127 for forward, byte 138 to 255 for backward). PT (Payload Type) Payload Type and Code ...
Page 435: Gfp-F/Gfp-T
Test Results GFP-F/GFP-T GFP-F/GFP-T Note: This tab is only available with OTN BERT test application with 1GbE, 10GbE, or Ethernet (flex/GFP-F) client. From the Test menu, tap Results, and the GFP-F/GFP-T tab. Transport Layer Bandwidth Usage (%) indicates the transmitted/received transport ...
Page 436 Test Results GFP-F/GFP-T Reserved PTI indicates the received client data and management  frames with a payload type identifier different of 000 and 100 without uncorrectable cHEC, tHEC, and eHEC, and pFCS errors. Possible rate units are Frames (default), or Bytes per second. Reserved PLI indicates the number of reserved control frames (PLI=1, ...
Page 437 Test Results GFP-F/GFP-T Superblock Note: Superblock is only available with GFP-T. Valid indicates the transmitted/received superblocks without any  uncorrectable error. Invalid indicates the transmitted/received superblocks with  uncorrectable error. Total indicates the total transmitted/received valid and invalid  superblocks. Power Blazer...
Page 438 Test Results Graph (RFC 2544) Graph (RFC 2544) Displays the graph showing the Throughput, Back-to-Back, Frame Loss, and Latency measurements. For Dual Test Set the graph shows results from Local to Remote and Remote to Local using distinctive colors. For Dual Port topology the graph shows results from P1 to P2 (P1->P2) and P2 to P1 (P2->P1) using distinctive colors.
Page 439: Labels
Test Results Labels Labels From the Test menu, tap Results, and Labels. Note: Selecting a Label byte to be generated will automatically update the corresponding OH byte. Refer to OH - SONET/SDH on page 591 for more information. Labels STS/AU Path (C2): The C2 byte is allocated to indicate the content of ...
Page 440: Link Oam
Test Results Link OAM Link OAM From the Test menu, tap Results, and the Link OAM tab. Remote MAC Address Indicates the remote OAM link partner MAC address. Remote OAM Information OAM Version indicates the protocol version supported by the DTE. ...
Page 441 Test Results Link OAM Vendor Specific Information reports the 32-bit Vendor Specific  Information field identifying the vendor’s product model and version. Unidirectional reports unidirectional support capability:  Supported indicates that the DTE is capable of sending OAMPDUs when the receive path is non-operational. Unsupported indicates that the DTE is not capable of sending OAMPDUs when the receive path is non-operational.
Page 442 Test Results Link OAM Remote Error Event Statistics Date Stamp indicates the date the last Event Notification OAMPDU  frame was received. Time Stamp indicates the time the last Event Notification OAMPDU  event was received by the test equipment. Window ...
Page 443 Test Results Link OAM Error Running Total  Symbol Period The number of symbol errors since the last reset Frame The number of frame event errors since the last reset Frame Period The number of frame period errors since the last reset Frame Seconds The number of frame seconds summary errors since the last reset Event Running Total...
Page 444: Logger
Test Results Logger Logger The Logger page displays color-coded events and pass/fail verdict. From the Test menu, tap Results, and the Logger tab. Sort By Select the sorting order of the event logger entries: ID/Time (default) displays the event logger entries in numeric ...
Page 445 Test Results Logger Details: Provides contextual information including the pass/fail verdict.  The following table displays the nature of information reported by type of event: Type of Event Nature of Information Test Started Start Date Test Stopped Pass/Fail Verdict Alarm Events Count value Error Events Current Count and Total Count...
Page 446: Messages
Test Results Messages Messages From the Test menu, tap Results, and the Messages tab. Message Type The count of each OBSAI message type is reported. Message Type TX Count RX Count Control Measurement WCDMA/FDD WCDMA/TDD GSM/EDGE TETRA CDMA2000 WLAN Loopback Frame Clock Burst X (BTS only) X (RRH only)
Page 447 Test Results Messages RX Frame Clock Burst Details When a valid Frame Clock Burst (FCB) message is received, its SFN and c1 values are reported. SFN (System Frame Number): The master frame number received with  an FCB message. c1: Arrival time of the FCB message Reference Point 1 (RP1) versus ...
Page 448: Mpls
Test Results MPLS MPLS For Traffic Gen and Mon, from the test menu, tap Results, Streams, and the MPLS tab. For Though Mode, from the test menu, tap Results, Traffic, and the MPLS tab. Note: For Dual Port topology, the P1 and P2 buttons allow respectively displaying results for port #1 (P1) or port #2 (P2).
Page 449: Otl-Sdt
Test Results OTL-SDT OTL-SDT Note: Only available for parallel interfaces when an OTL defect, at the exception of LOL, is selected for Service Disruption Time (refer to Service Disruption on page 142). From the Test menu, tap Results, and the OTL-SDT tab. Service Disruption Note: Service Disruption results are only available when Disruption Monitoring is enabled (refer to BERT and Unframed BERT on page 139).
Page 450 Test Results OTL-SDT Longest Disruption indicates the longest measured disruption time.  Lanes with Disruption indicates the number of lanes with service  disruption. Note: When a disruption event is equal or longer than the test period which is fixed to 5 minutes, then the measured disruption time is equal to the test period.
Page 451: Performance Monitoring
Test Results Performance Monitoring Performance Monitoring Note: This tab is only available with Transport test applications with Pattern client. The Performance Monitoring tab gives error performance events and parameters for the circuit under test. From the Test menu, tap Results, and the Performance Monitoring tab. Each button on top of the window represents a level of the analyzed signal for which the Performance Monitoring (PM) is available.
Page 452 Test Results Performance Monitoring Near-End EFS (Error Free Second) (G.821, G.826, G.828, and G.829): Gives the  number of seconds within which no error occurred. EC (Error Count) (G.821 only): Gives the number of bit errors.  EB (Errored Block) (G.826, G.828, and G.829): Gives the count of ...
Page 453 Test Results Performance Monitoring For M.2100 ISM: Gives the count of the seconds within which anomalies (frame bit errors, CRC block errors, etc.) are  Y or at least one defect occurred. Y depends on the type of DSn/PDH signal as described in the following table.
Page 454 Test Results Performance Monitoring UAS (Unavailable Second): Gives the count of the seconds  corresponding to the periods of unavailable time that begins at the onset of 10 consecutive SES events, including these 10 seconds. A period of available time shall begin at the onset of 10 consecutive non-SES events, including these 10 seconds.
Page 455 Test Results Performance Monitoring SEP (Severely Errored Period) (G.828 only): A sequence between  3 to 9 consecutive SES. The sequence is terminated by a second which is not a SES. SEPI (Severely Errored Period Intensity) (G.828 only): Gives the count ...
Page 456 Test Results Performance Monitoring For M.2100 ISM: Gives the count of the seconds within which anomalies (frame bit errors, CRC block errors, etc.) are  Y or at least one defect occurred. Y depends on the type of DSn/PDH signal as described in the following table.
Page 457 Test Results Performance Monitoring UAS (Unavailable Second): Gives the count of the seconds  corresponding to the period of unavailable time that begins at the onset of 10 consecutive SES events, including these 10 seconds. A period of available time shall begin at the onset of 10 consecutive non-SES events, including these 10 seconds.
Page 458: Ptp Stats
Test Results PTP Stats PTP Stats From the Test menu, tap Results, and the PTP Stats tab. TX/RX PTP Message Count/Rate Gives the transmitted/received count and average rate for each PTP message, and the total count for all messages. Signaling Announce Req Signaling Announce Grant Signaling Sync Req Signaling Sync Grant...
Page 459 Test Results PTP Stats IPDV Inter Packet Delay Variation (IPDV) is available for Sync and Delay Req messages and is measured for all valid in-sequence messages (see Delay Measurement on page 478). Current, Average, Minimum, Maximum, and Standard Deviation measurement values are displayed. The Standard Derivation is the measure of the dispersion of messages from its mean.
Page 460: Quality Level (1588 Ptp)
Test Results Quality Level (1588 PTP) Quality Level (1588 PTP) The quality level characterizes the clock quality in terms of network synchronization. From the Test menu, tap Results, and the Quality Level tab. Last QL Received indicates the last Quality Level value received. The ...
Page 461 Test Results Quality Level (1588 PTP) Profile Quality PTP Clock Description Level value Class G.8265.1 QL-PRS (default) 80 Primary Reference Source Traceable (G.811) QL-STU/UNK Synchronized - Traceability Unknown QL-PRC Primary Reference Clock Traceable (G.811) QL-ST2 Traceable to Stratum 2 (G.812 Type II) QL-INV3 Quality Level Invalid 3 QL-SSU-A/TNC...
Page 462: Quality Level (Synce)
Test Results Quality Level (SyncE) Quality Level (SyncE) The quality level characterizes the clock quality in terms of network synchronization. From the Test menu, tap Results, and the Quality Level tab. Generated QL indicates the Quality Level value that is generated. ...
Page 463 Test Results Quality Level (SyncE) Quality Level Description value QL-SSU-B Type VI slave clock (G.812) QL-INV9 Quality Level Invalid 9 QL-EEC2/ST3 Ethernet Equipment Clock Option 2 (default) Traceable to Stratum 3 (G.812 Type IV) QL-EEC1/SEC Ethernet Equipment Clock Option 1 Synchronous Equipment Clock (G.813 or G.8262, Option 1) QL-SMC Traceable to SONET Minimum Clock (G.813 or G.8262, Option 2)
Page 464: S-Oam And Mpls-Tp Oam
Test Results S-OAM and MPLS-TP OAM S-OAM and MPLS-TP OAM From the Test menu, tap Results, and the S-OAM or MPLS-TP OAM tab. Loopback Status displays the status of the test function (refer to page 511).  TX LBM indicates the count of transmitted LBM frames. ...
Page 465 Test Results S-OAM and MPLS-TP OAM Invalid Payload indicates the count of received LBR frames having  either a TLV type different than the one transmitted, Bit error or wrong data value detected in the data payload of a Data TLV, Bit error, Pattern Loss, or Pattern Type mismatch of a Test TLV.
Page 466 Test Results S-OAM and MPLS-TP OAM Frame Delay Status displays the status of the test function (refer to page 511).  TX DMM indicates the count of transmitted DMM frames.  RX DMR indicates the count of valid DMR frames received. A valid ...
Page 467 Test Results S-OAM and MPLS-TP OAM Frame Loss Status displays the status of the test function (refer to page 511).  TX LMM indicates the count of transmitted LMM frames.  RX LMR indicates the count of valid LMR frames received. A valid ...
Page 468 Test Results S-OAM and MPLS-TP OAM Synthetic Loss Note: Only available with Ethernet OAM. Status displays the status of the test function (refer to page 511).  TX SLM indicates the count of transmitted SLM frames.  RX SLR indicates the count of valid SLR frames received. A valid frame ...
Page 469: Sdt (Multi-Channel Otn)
Test Results SDT (Multi-Channel OTN) SDT (Multi-Channel OTN) From the Test menu, tap Results and the SDT tab. Note: The SDT tab is only available when Disruption Monitoring is enabled (refer to ODU Channels - Global on page 237). Service Disruption is the time during which there is a disruption of service due to the absence of traffic or to the detection of defects per channel.
Page 470 Test Results SDT (Multi-Channel OTN) Total (ms) indicates the total duration of all measured disruption  times. Count indicates the number of disruption events detected since the  beginning of the test. PASS FAIL, available when pass/fail verdict is enabled, indicates the ...
Page 471: Service Configuration - Burst
Test Results Service Configuration - Burst Service Configuration - Burst From the Test menu, tap Results, Service Configuration, and the Burst tab. Service Name and Selection Service Name indicates the name of the selected service. Select the service to be displayed by either using the left/right arrow or by tapping over the service numbers area then tapping on a specific service number.
Page 472: Service Configuration - Ramp
Test Results Service Configuration - Ramp Service Configuration - Ramp From the Test menu, tap Results, Service Configuration, and the Ramp tab. Service Name and Selection Service Name indicates the name of the selected service. Select the service to be displayed by either using the left/right arrow or by tapping over the service numbers area then tapping on a specific service number.
Page 473 Test Results Service Configuration - Ramp Informational parameters are for information purpose only, they are  not included in the test pass/fail verdict. See Summary (EtherSAM) on page 485 for more information on Frame Loss, Max Jitter, and Round-Trip Latency. Average RX Rate indicates the measured average utilization ...
Page 474: Service Performance
Test Results Service Performance Service Performance From the Test menu, tap Results, and the Service Performance tab. Service Name and Selection Service Name indicates the name of the selected service. Select the service to be displayed by either using the left/right arrow or by tapping over the service numbers area then tapping on a specific service number.
Page 475 Test Results Service Performance Note: For the Current value, 0 is displayed when no RX rate has been measured in the last second. Note: Delay variation measurements smaller than 15 μs will be discarded, not used for the sampling process, and < 0.015 is displayed as the minimum value.
Page 476: Streams - Frame Loss / Out-Of-Sequence
Test Results Streams - Frame Loss / Out-of-Sequence Streams - Frame Loss / Out-of-Sequence From the Test menu, tap Results, Streams, and the Frame Loss / Out-Of-Sequence tab. The P1 and P2 buttons, available with Dual Port topology, allow  respectively displaying results for port #1 (P1) or port #2 (P2).
Page 477: Streams - Latency
Test Results Streams - Latency Streams - Latency From the Test menu, tap Results, Streams, and the Latency tab. The P1 and P2 buttons, available with Dual Port topology, allow  respectively displaying results for port #1 (P1) or port #2 (P2). Stream: Indicates the stream identification number.
Page 478: Streams - Throughput / Customer Frame Throughput
Test Results Streams - Throughput / Customer Frame Throughput Streams - Throughput / Customer Frame Throughput From the Test menu, tap Results, Streams, and the Throughput or the Customer Frame Throughput tab. The P1 and P2 buttons, available with Dual Port topology, allow ...
Page 479: Summary
Test Results Summary Summary Note: Available with Transport, and Ethernet (EtherBERT, Through Mode, Smart Loopback), and Wireless test applications. For other test applications see the corresponding test summary page. From the Test menu, tap Results, and the Summary tab. Global (default), P1, and P2 buttons, available with Dual Port ...
Page 480 Test Results Summary Interface Note: Only available with CPRI/OBSAI Unframed test application. Alarms  LOS indicates that there is no input signal. Errors  CV (Code Violation) indicates that invalid 10B code word are received. BER and Multi-Pattern BER Note: See BER on page 350 for a description of each alarm/error. Note: For Multi-Pattern, alarms/errors are available for each pattern.
Page 481 Test Results Summary Bit/Pattern Error Rate/Count graphically displays a meter  representing either the bit/pattern error rate or the bit/pattern error count depending on the Pass/Fail Verdict selection When the verdict is enabled , the values under the threshold are presented in green while the values above are in red.
Page 482 Test Results Summary Service Disruption Note: Service Disruption results are only available with Transport, CPRI/OBSAI, and EtherBERT test applications when Disruption Monitoring is enabled (refer to BERT and Unframed BERT on page 139 or EtherBERT, FC BERT, BERT (CPRI/OBSAI), and Unframed BERT on page 155). When Service Disruption is disabled, the message Service disruption monitoring disabled is displayed.
Page 483 Test Results Summary Note: When a disruption event is equal to or longer than the test period which is fixed to 5 minutes, then the measured disruption time is equal to the test period. SDT Threshold (ms) allows entering the SDT threshold value that will ...
Page 484 Test Results Summary C&M indicates either the received (HDLC or Ethernet) or negotiated  (Auto) C&M for Ethernet subchannel and HDLC rates in Mbit/s. A red background indicates either a C&M type mismatch or HDLC Rate/Ethernet subchannel mismatch. An arrow is displayed indicating which C&M Channel, Ethernet or HDLC, is selected following the negotiation process.
Page 485 Test Results Summary RX Frequency Note: RX Frequency is available for Through Mode test application on both ports (Port 1 and Port 2) for rates up to 10G LAN. Not available for a port using an active copper SFP. Frequency (GHz) indicates the frequency of the input signal. ...
Page 486: Summary (1588 Ptp)
Test Results Summary (1588 PTP) Summary (1588 PTP) From the Test menu, tap Results, and the Summary tab. Test Status displays the current status of the 1588 PTP test. The global  test pass/fail verdict is displayed next to the Test Status field when enabled (see Pass/Fail Verdict on page 138).
Page 487 Test Results Summary (1588 PTP) Negotiation Status  The status of the PTP Negotiation is displayed while in Unicast negotiation (available with G.8265.1 profile). Negotiation Background Description Status Color Request Granted All the Signaling request types have been granted. Green [Message type] The Signaling grant message has not been granted.
Page 488 Test Results Summary (1588 PTP) GM Info  Note: Only available when Grand Master clock information is available. The Grand Master Information window displays the decoded clock information. For G.8265.1 only: Identity reports the 8-byte identification code of the Grand Master ...
Page 489 Test Results Summary (1588 PTP) For both G.8265.1 and G.8275.1: Clock Class reports the description and code of the Grand Master  Clock Class. Code Description 0-5, 8-12, 15-51, 53-57, 59-67, 123-132, 171-186, 188-192, 194-215, Reserved 233-247, 249-254 Sync to primary reference 7, 14 Holdover Sync to application-specific reference...
Page 490 Test Results Summary (1588 PTP) Delay Measurement Sync IPDV meter displays the average of the inter packet delay  variation of consecutive Sync messages in the last second. The value and the pass/fail verdict is also displayed when enabled. Delay Req IPDV meter displays the average of the inter packet delay ...
Page 491: Summary (Cable Test)
Test Results Summary (Cable Test) Summary (Cable Test) From the Test menu, tap Results, and the Summary tab. Test Status Test Status indicates the progress of the cable test as follows: Idle (test has not started)  In Progress  Completed ...
Page 492 Test Results Summary (Cable Test) Delay Skew (ns) indicates the delay skew value for the pair having the  worst delay skew. The Pass/Fail verdict is also displayed when enabled. The Delay Skew result is only available for 1000 Base-T interface when the link is up.
Page 493 Test Results Summary (Cable Test) Wire Map Test Result gives the wire map test result for each pair.  When the link is up: The wire map result for each pair is given as seen by the module to get a link up. This means that the wire map result may not correspond to the type of cable tested depending on the cable(s) used and/or the configuration of the cable mode (MDI, MDIX, or auto-detection) on both the module and the far end equipment.
Page 494 Test Results Summary (Cable Test) When the link is down: Short Short-circuit between Tip and Ring wires of a pair or Tip or ring wire of a pair is connected with an alien wire grounded. Open No cable plugged in, remote end open, or either one or two wires of a pair are not connected.
Page 495 Test Results Summary (Cable Test) Note: Only available on 8870/8880. Detection/Classification Power Presence indicates on which cable pairs (refer to Wiring  Standard on page 145) the power is received and the polarity of each pair. Result is presented as follows: Power Presence Description Pos: <pair>;...
Page 496 Test Results Summary (Cable Test) Operation Note: The following results are only reported when the classification succeeded. Unloaded Voltage (V) indicates the measured voltage when no load is  applied. A value less then 5 is reported as <5.0 and a value greater than 59 is reported as >59.0.
Page 497: Summary (Ethersam)
Test Results Summary (EtherSAM) Summary (EtherSAM) From the Test menu, tap Results, and the Summary tab. Note: For Dual Test Set, only Start Time is displayed on the remote module. Service Configuration/Performance Test Status indicates the actual  test status as follows: Test Status Description “--”...
Page 498 Test Results Summary (EtherSAM) Remote unit in Dual Test Set Mode indicates that this module is set as  remote but the DTS Connection is not established. Service Configuration/Performance Test: Tap Service Configuration  Test or Service Performance Test button to view the result summary of the corresponding test.
Page 499 Test Results Summary (EtherSAM) Committed Frame Loss Rate indicates the rate of frames that are lost. The  reported value is the maximum rate of Frame Loss from all burst sequences and ramp steps excluding the CIR+EIR, EBS, and Traffic Policing steps. Frame Loss is displayed as a percentage value when the remote module does not support exponential notation.
Page 500: Summary (Fc Bert)
Test Results Summary (FC BERT) Summary (FC BERT) From the Test menu, tap Results, and the Summary tab. Test Status indicates the actual test status as follows:  “--”: The test is not running or results are not available.  In Progress: The test is running.
Page 501 Test Results Summary (FC BERT) Note: See BER on page 350 for a description of each alarm/error. BER Threshold is available when Pass/Fail Verdict is enabled (refer to  page 156). Bit Error Rate/Count graphically displays a meter representing either ...
Page 502 Test Results Summary (FC BERT) Round-Trip Latency Round Trip Latency (ms) is measured for each local and remote port.  Current, Average, Minimum, and Maximum indicates respectively the current, average, minimum, and the maximum round trip latency from the local to the remote port in the last one second. The pass/fail verdict is also displayed for the maximum round trip latency.
Page 503: Summary (Ioptics)
Test Results Summary (iOptics) Summary (iOptics) From the Test menu, tap Results, and the Summary tab. Start Time indicates the date and time the test was started. The date and time reset every time the test is restarted. When necessary for power consumption monitoring the Calibrating progress message is displayed.
Page 504 Test Results Summary (iOptics) Optical TX Power Test (dBm) reports the minimum and maximum  optical TX power values; in-range values are displayed in green while out-of-range are in red. Optical RX Power Test (dBm) reports the minimum and maximum ...
Page 505: Summary (Isam)
Test Results Summary (iSAM) Summary (iSAM) From the Test menu, tap Results, and the Summary tab. Start Time indicates the date and time the test was started. The date  and time is reset every time the test is restarted. Configuration/Performance Results and RFC 6349 Results buttons ...
Page 506 Test Results Summary (iSAM) For Dual Test Set the following values are reported for both local to remote (L->R) and remote to local (R->L). Service indicates the service’s number and name.  The pass/fail verdict icon is displayed next to the service name indicating if the service complies to the configured SLA parameters.
Page 507 Test Results Summary (iSAM) RFC 6349 Test Test Status indicates the actual test status as follows:  Test Status Description “--” Test has not started. In Progress The test is running. Completed, <Verdict> Test has completed and the test pass/fail verdict is displayed when enabled.
Page 508 Test Results Summary (iSAM) Window indicates the total Max Window (1 KiB = 1024 bytes)  followed by the number of connections and KiB per connection in parenthesis as follows: (n conn.@ n KiB). Ideal L4 indicates the ideal TCP throughput metric. ...
Page 509: Summary (Link Oam)
Test Results Summary (Link OAM) Summary (Link OAM) From the Test menu, tap Results, and the Summary tab. Test Status displays the current status of the Link OAM test. The global  test pass/fail verdict is displayed next to the Test Status when enabled (see Pass/Fail Verdict on page 324).
Page 510 Test Results Summary (Link OAM) Dying Gasp: Indicates that the OAM link partner has sent an  unrecoverable local failure notification (bit 1 of the Flags field is set to 1). Link Fault: Indicates that the OAM link partner has sent a link fault ...
Page 511: Summary (Multi-Channel Otn)
Test Results Summary (Multi-Channel OTN) Summary (Multi-Channel OTN) From the Test menu, tap Results, and the Summary tab. Status indicates the actual test status as follows.  “--”: The test is not running or results are not available.  In Progress: The test is running. ...
Page 512 Test Results Summary (Multi-Channel OTN) Interface / OTL / OTU4, ODU4, and Channel Buttons Note: Refer to Alarms/Errors on page 346 for more information on alarms/errors and alarms/errors injection. Interface / OTL / OTU4 displays alarms/errors for Interface (see  page 374), Clock (see page 351), OTL (see page 385), and OTU4 (see page 386) as well as the received SM TTI Traces (see page 525).
Page 513: Summary (Ni/Csu Emulation)
Test Results Summary (NI/CSU Emulation) Summary (NI/CSU Emulation) From the Test menu, tap Results, and the Summary tab. Status Status indicates the progress of the test as follows: Idle (test has not started)  In Progress  Completed  The Pass/Fail verdict is displayed next to the Test Status field, when enabled, based on the following criteria: The worst pair’s Wire Map, Prop.
Page 514 Test Results Summary (RFC 2544) Summary (RFC 2544) From the Test menu, tap Results, and the Summary tab. Start Time indicates the date and time the test was started. The date  and time is reset every time the test is restarted or reset. For Dual Test Set, this is the only information available on the remote module.
Page 515 Test Results Summary (RFC 2544) Throughput, Back-to-Back, Frame Loss, and Latency Subtests Throughput, Back-to-Back, Frame Loss, and Latency  For each subtest, its status (-- (Idle), In Progress, Completed, or Aborted - (reason)) and duration are displayed. TX Frames and RX Frames display the transmitted and received ...
Page 516 Test Results Summary (RFC 2544) Unit: Select the subtest result unit:  For Throughput: Mbit/s, Gbit/s, frame/s, and %. For Back-to-Back: Mbit/s, Gbit/s, frame/burst, and %. Frame Loss: %. Latency: ms, and μs. Layer: For Throughput and Back-to-Back subtests, select the ...
Page 517 Test Results Summary (RFC 6349) Summary (RFC 6349) From the Test menu, tap Results, and the Summary tab. Status indicates the actual test status as follows:  Test Status Description “--” Test has not started. In Progress The test is running. Completed, <Verdict>...
Page 518 Test Results Summary (RFC 6349) , when displayed, indicates that the logger is full. Refer to Logger Full  Logger on page 432. Remote unit in use and locked for Dual Test Set indicates that this  module is used for Dual Test Set as the remote module. Remote unit in Dual Test Set Mode indicates that this module is set ...
Page 519 Test Results Summary (RFC 6349) Buffer Delay (%) indicates the Buffer Delay percentage metric which  represents the increase in RTT during a TCP Throughput test versus the Minimum RTT. TCP Throughput Threshold (% of ideal) allows entering the TCP ...
Page 520: Summary (S-Oam And Mpls-Tp Oam)
Test Results Summary (S-OAM and MPLS-TP OAM) Summary (S-OAM and MPLS-TP OAM) From the Test menu, tap Results, and the Summary tab. Test Status displays the current status of the S-OAM / MPLS-TP OAM  test. The global test pass/fail verdict is displayed next to the Test Status when enabled (see Pass/Fail Verdict on page 324).
Page 521 Test Results Summary (S-OAM and MPLS-TP OAM) Continuity Check (Peer MEP) Status displays the status of the continuity check with the peer MEP.  Status Description Loss Continuity Loss of Continuity alarm is active. Mismerge Mismerge alarm is active. Unexpected MEG Level Unexpected MEG Level alarm is active.
Page 522 Test Results Summary (S-OAM and MPLS-TP OAM) CCM indicates the content of the last received CCM frame including  MEG ID (Y.1731 and G.8113.1), Domain ID (802.1ag and MEF), MA Name (802.1ag and MEF), MEG Level (Y.1731, MEF, and G.8113.1), MD Level (802.1ag), MEP ID, and Period.
Page 523 Test Results Summary (S-OAM and MPLS-TP OAM) Loopback / Test / Frame Delay / Frame Loss / Synthetic Loss Note: Either Loopback, Test, Frame Delay, Frame Loss, or Synthetic Loss (available with Ethernet OAM) statistics are displayed according with the selected test function (refer to Test Function on page 273).
Page 524 Test Results Summary (S-OAM and MPLS-TP OAM) RX Line Utilization meter and value, available with Loopback  function, indicate the line rate utilization percentage (only LBR frames are considered) received in the last second. TST RX Rate meter and value, available with Test function, indicate the ...
Page 525: Summary (Synce)
Test Results Summary (SyncE) Summary (SyncE) From the Test menu, tap Results, and the Summary tab. Test Status displays the current status of the SyncE test. The global test  pass/fail verdict is displayed next to the Test Status when enabled (see Pass/Fail Verdict on page 324).
Page 526 Test Results Summary (SyncE) ESMC Indicates the current (meter and value), average, minimum, and maximum ESMC frame rate (including information and event frames) received in frame/s. A fail verdict is also displayed beside the minimum and/or maximum values when the ESMC frame rate is outside the range while the Pass/Fail Verdict is enabled.
Page 527 Test Results Summary (SyncE) Last QL Message indicates the last Quality Level value received. The  pass/fail verdict is also displayed when both QL Mismatch Monitoring and Pass/Fail Verdict check boxes are selected. Last Change indicates the date and time of the Last QL Message has changed.
Page 528: Summary (Tcp Throughput)
Test Results Summary (TCP Throughput) Summary (TCP Throughput) From the Test menu, tap Results, and the Summary tab. Test Status indicates the actual test status as follows:  Test Status Description “--” The test is not running or results are not available. In Progress The test is running.
Page 529 Test Results Summary (TCP Throughput) TCP Throughput TCP Connection Status indicates the actual TCP connection status.  Test Status Description “--” The test is not running or results are not available. In Progress The TCP initialization algorithm is in progress. Waiting Indicates on the remote unit that the test is started but the TCP initialization algorithm is not initiated by the local unit.
Page 530 Test Results Summary (TCP Throughput) TCP Throughput displays respectively the last, minimum, maximum,  and average TCP Throughput measurement. Window Size displays respectively the last, minimum, and maximum  TCP window size. Round Trip Latency (ms) displays respectively the last, minimum, ...
Page 531: Summary (Traffic Gen & Mon)
Test Results Summary (Traffic Gen & Mon) Summary (Traffic Gen & Mon) From the Test menu, tap Results, and the Summary tab. The P1 and P2 buttons, available with Dual Port topology, allow  respectively displaying the test summary for port #1 or port #2. Test Status indicates the actual test status as follows.
Page 532 Test Results Summary (Traffic Gen & Mon) Out-of-Sequence: See Streams - Frame Loss / Out-of-Sequence on  page 464. Stream indicates the stream number and provides stream detailed  statistics when tapping on its button. The following statistics are displayed for the selected stream. Stream Selection: Select a stream by either using the left/right ...
Page 533: Summary (Wander)
Test Results Summary (Wander) Summary (Wander) From the Test menu, tap Results, and the Summary tab. Test Status displays the current status of the Wander test. The global  test pass/fail verdict is displayed next to the Test Status when enabled (see Pass/Fail Verdict on page 324).
Page 534 Test Results Summary (Wander) Time Error Statistics Note: The following statistics are collected using 0.1 Hz Low-Pass filtering. The following statistics are available with 1PPS signal. TE (ns) indicates the last time error value collected in the last second.  Max TE (ns) indicates the maximum time error value collected since ...
Page 535 Test Results Summary (Wander) Note: The following statistics are collected without any filtering. cTE (ns) indicates the constant time error which is an average value of  time error over the defined period as follows (refer to cTE Averaging Period on page 339): since the beginning of the test when the cTE Average Period is set ...
Page 536 Test Results Summary (Wander) Graph Dynamically displays the graph of either TE or TIE values as a function of time. The dynamic view is a sliding window displaying the last 27000 samples collected. Zooming the graph: Using the touch screen: Tap two points on the graph and drag them to ...
Page 537: Traces - Otn
Test Results Traces - OTN Traces - OTN From the Test menu, tap Results, Traces, and the OTN sub-tab. Channel Available with Multi-Channel OTN, allows the selection of the channel number. OTUx, ODUx, ODUk, and TCM Buttons Tap on either OTUx, or an ODUx/ODUk button. For ODUx when TCM is enabled (see Modify TCM on page 306), tap on a TCMx button to select a TCM level.
Page 538 Test Results Traces - OTN DAPI allows editing the expected Destination Access point Identifier  (TTI bytes 16 to 31). Available when the DAPI OTU/ODU-TIM check box is selected. SAPI OTU/ODU-TIM check box , when selected (cleared by default),  allows editing the expected Source Access Point Identifier (SAPI) and also enables OTU/ODU-TIM alarm monitoring.
Page 539: Traces - Sonet/Sdh
Test Results Traces - SONET/SDH Traces - SONET/SDH From the Test menu, tap Results, Traces, and the SONET/SDH sub-tab. Note: Selecting a Trace byte to be generated will automatically update the corresponding OH byte. Refer to OH - SONET/SDH on page 591 for more information.
Page 540: Traffic - Ethernet
Test Results Traffic - Ethernet Traffic - Ethernet From the Test menu, tap Results, Traffic, and when applicable the Ethernet tab. Note: For Through Mode test application, the traffic statistics are displayed for both port directions (P1->P2 and P2->P1). P1 and P2 Buttons The P1 and P2 buttons, available with Dual Port topology, allow respectively displaying results for port #1 (P1) or port #2 (P2).
Page 541 Test Results Traffic - Ethernet Unicast indicates the number of unicast frames transmitted/received  without FCS errors. Non-Unicast indicates the number of multicast and broadcast frames  transmitted/received without FCS errors. Total indicates the total number of all frames transmitted/received ...
Page 542 Test Results Traffic - Ethernet 1024 - 1536: for PBB-TE, frames from 1024 to 1536; add 4 bytes to  1536 for each VLAN layer enabled in the encapsulated Ethernet payload and 4 bytes for B-VLAN when enabled. > 1518/1534/1536: ...
Page 543: Traffic - Flow Control
Test Results Traffic - Flow Control Traffic - Flow Control From the Test menu, tap Results, Traffic, and the Flow Control tab. P1 and P2 Buttons The P1 and P2 buttons, available with Dual Port topology, allow respectively displaying results for port #1 (P1) or port #2 (P2). Frame Count - RX Pause Frames indicates the number of received valid flow-control ...
Page 544 Test Results Traffic - Flow Control Pause Injection Note: Pause injection is only available for Traffic Gen & Mon test application. Packet Pause Time: Enter the pause time value to be transmitted in  Quanta or Microsecond (default is 100 Quanta). Range Interface Quanta...
Page 545: Traffic - Graph
Test Results Traffic - Graph Traffic - Graph From the Test menu, tap Results, Traffic, and the Graph tab. P1 and P2 Buttons The P1 and P2 buttons, available with Dual Port topology, allow respectively displaying results for port #1 (P1) or port #2 (P2). The graph displays the received line utilization.
Page 546: Traffic - Oam, S-Oam, And Mpls-Tp Oam
Test Results Traffic - OAM, S-OAM, and MPLS-TP OAM Traffic - OAM, S-OAM, and MPLS-TP OAM From the Test menu, tap Results, Traffic, and the OAM, S-OAM, or MPLS-TP OAM tab. Traffic Monitoring Note: Only available with Carrier Ethernet OAM test application. In TX, reports counts of CCM, LBM, LTM, DMM, LMM, SLM, TST, AIS, ...
Page 547 Test Results Traffic - OAM, S-OAM, and MPLS-TP OAM Responder Note: Available when the S-OAM Responder or MPLS-TP OAM Responder check box is selected (refer to S-OAM and MPLS-TP OAM Responder on page 268). For Carrier Ethernet OAM test application: In TX, reports counts of LBR, LTR, DMR, LMR, and SLR total frames ...
Page 548: Window Sweep - X
Test Results Window Sweep Window Sweep Displays the graph showing the Ideal L4 and Actual L TCP Throughput measured for each Window Sweep step. The number of connections and KiB per connection is also displayed in parenthesis as follows: (n conn.@ n KiB) From the Test menu, tap Results, and the Window Sweep tab.
Page 549 Test Results From the Test menu, tap Results, and the WIS tab. Traces/Label J0 Trace displays the J0 Trace value in 16-bytes format.  J1 Trace displays the J1 Trace value in 16-bytes format.  Path Signal Label (C2) displays the content of the STS SPE including ...
Page 551: Test Functions
10 Test Functions The Test Functions menu offers the following structure: Transport Test Applications Available with SONET/ OTN- Multi- SONET/ DSn/ SDH - Tab - Sub Tab Page SONET/ NI/CSU Channel DSn/ BERT Emulation BERT BERT BERT BERT 40/100G Advanced - CFP4/QSFP Control 40/100G Advanced - Lanes Mapping &...
Page 552: Etherbert
Test Functions Ethernet Test Applications Test Application Tab - Sub Tab Page 40/100G Advanced - CFP4/QSFP Control 40/100G Advanced - Lanes Mapping & Skew Filters Packet Capture Ping & Trace Route S-OAM Link Trace Traffic Scan EtherSAM RFC 6349 RFC 2544 EtherBERT Traffic Gen &...
Page 553 Test Functions Sync Test Applications Test Application Page 1588 PTP SyncE Filters Packet Capture Ping & Trace Route Wireless Test Application Test Application Framing Page CPRI/OBSAI BERT CPRI OBSAI Unframed Framed L2 Framed L2 Power Blazer...
Page 554: G/400G Advanced - Cfp4/Cfp8/Qsfp Control
Test Functions 40/100G/400G Advanced - CFP4/CFP8/QSFP Control 40/100G/400G Advanced - CFP4/CFP8/QSFP Control From the Test menu, tap Functions, 40/100G/400G Advanced, and the CFP4/CFP8/QSFP Control tab. CFP4/CFP8 Reference Clock (MHz) Allows selecting the reference clock that will be used by the transceiver. 1/160 Host Lane Rate Interface/Rate 1/40 Host Lane Rate...
Page 555 Test Functions 40/100G/400G Advanced - CFP4/CFP8/QSFP Control CFP4/CFP8/QSFP Control Pins Allows the following transceiver control pin settings. Refer to the CFP MSA standard for more information. Note: To apply any control, first select its check box then clear it; the control is applied only when the selected check box is cleared.
Page 556 Test Functions 40/100G/400G Advanced - CFP4/CFP8/QSFP Control CFP4/CFP8/QSFP MDIO/I2C Access Interface MDIO/I2C - Bulk Read  Page Select, available for QSFP I2C, allows selecting the I2C  address page: 0x00 (default) to 0xFF. MDIO/I2C Start Address allows selecting the MDIO/I2C start ...
Page 557: G/400G Advanced - Lanes Mapping & Skew
Test Functions 40/100G/400G Advanced - Lanes Mapping & Skew 40/100G/400G Advanced - Lanes Mapping & Skew Note: Only available with parallel interfaces. Not available when the RS-FEC check box is selected. From the Test menu, tap Functions, 40/100G/400G Advanced, and the Lanes Mapping &...
Page 558 Test Functions 40/100G/400G Advanced - Lanes Mapping & Skew PCS/Logical Lane Allows ordering the PCS/Logical Lane markers in either Ascending (1,2,3...) or Coupled to RX. Alarms For a description of each alarm, refer to OTL on page 385 for Transport and Ethernet - PCS Lanes on page 364 for Ethernet.
Page 559 Test Functions 40/100G/400G Advanced - Lanes Mapping & Skew Default/Random/Manual Mapping Allows changing the PCS/Logical lane mapping that will be used for the test. Not available with 100 GbE client in OTU4. Default Mapping sets the TX mapping to the default numerical order ...
Page 560 Test Functions 40/100G/400G Advanced - Lanes Mapping & Skew Reset/Manual Skew Allows the selection of a relative delay in bit time that will be introduced for each PCS/Logical lane. Not available with 100 GbE client in OTU4. Reset Skew sets all TX skew (bit time) values to 0. ...
Page 561 Test Functions 40/100G/400G Advanced - Lanes Mapping & Skew Laser ON/OFF Allows activating the laser control per optical lane or for all lanes. Optical lane numbers are from 0 to 3 or 0 to 7 depending on the selected interface/rate. All Lanes check box, when selected, applies the change(s) to all ...
Page 562 Test Functions From the Test menu, tap Functions, and the APS tab. TX/RX Switching Mode, available for both TX and RX, selects the switching  mode: Linear (default) or Ring.  Request: Bits 1 through 4 of the K1 byte. Request Bits 1 to 4...
Page 563 Test Functions Channel (Linear switching mode) or Destination Node ID (Ring switching mode): Bits 5 through 8 of the K1 byte. Bits Channel ID Destination Node ID Bits Channel ID Destination Node ID 5 to 8 (Linear mode) (Ring mode) 5 to 8 (Linear mode) (Ring mode)
Page 564 Test Functions Architecture (Linear switching mode) or Bridge Request (Ring switching mode): Bit 5 of the K2 byte. The default setting is 1+1 for Linear switching mode and Short Path Request for Ring switching mode. Architecture Bridge Request Bit 5 (Linear mode) (Ring mode) Short Path...
Page 565: Client Offset
Test Functions Client Offset Client Offset Note: Available with OTN BERT test application with 1GbE client and Pattern client with ODUflex multiplexing. From the Test menu, tap Functions, and the Client Offset tab. TX Frequency Note: TX Frequency is not available in Through / Through Intrusive topology. Frequency (GHz) indicates the frequency (nominal frequency + ...
Page 566 Test Functions Client Offset RX Frequency Frequency (GHz) indicates the frequency of the input signal.  Client Measurement range 1GbE 1250000000 ±120 ppm Pattern in ODUflex Expected Frequency ±120 ppm (see page 555) Offset (ppm) indicates the frequency offset between the standard rate ...
Page 567 Test Functions Client Offset Max. Positive Offset (ppm) indicates the maximum positive  frequency offset between the standard rate specification and the rate from the received signal. Note: The following parameters are only available with ODUflex mapped to pattern. Frequency Offset Analysis check box, when selected, enables the ...
Page 568: Fdl - Bit-Oriented Message
Test Functions FDL - Bit-Oriented Message FDL - Bit-Oriented Message Allows setting and configuring the Bit-Oriented Messages (BOM) of the Extended Super-Frame (ESF). Note: FDL is only available for DS1 interface with ESF framing. For Dual RX test, FDL is only available for the DS1 TX/RX port 1. From the Test menu, tap Functions, FDL, and the Bit-Oriented Message tab.
Page 569 Test Functions FDL - Bit-Oriented Message Codeword Command/Response Command/Response Pattern Pattern Codeword Codeword Line Loopback Activate 00001110 11111111 Protection Switch Line 22 01101100 11111111 Line Loopback Deactivate 00111000 11111111 Protection Switch Line 23 01101110 11111111 Payload Loopback Activate 00010100 11111111 Protection Switch Line 24 01110000 11111111 Payload Loopback Deactivate 00110010 11111111...
Page 570 Test Functions FDL - Bit-Oriented Message Receive Messages Link Activity indicates the activity of the following parameters during  the last second of measurement. Idle indicates that only idle codes have been detected in the last  second. Priority indicates that at least one valid priority message has been ...
Page 571 Test Functions FDL - Bit-Oriented Message Command/Response  Current indicates the command/response message detected in the last second. If no priority message has been detected, “--” is displayed. Previous indicates the last command/response message detected excluding the current message. If no command/response message has been detected since the beginning of the test, “--”...
Page 572: Fdl - Performance Report Message
Test Functions FDL - Performance Report Message FDL - Performance Report Message Note: FDL PRM is only available for DS1 interface with ESF framing. For Dual RX test, FDL is only available for the DS1 TX/RX port 1. For NI/CSU Emulation, only available in the RX direction.
Page 573 Test Functions FDL - Performance Report Message Received Messages Event Counts lists received PRM bit event counts.See PRM Bit Events  below. Report Content lists received performance information. See  Performance Information below. Circuit indicates the selected circuit type: CI to Network or ...
Page 574 Test Functions FDL - Performance Report Message Performance Information table, available when the Report Content  button is selected, reports the time t0, t0-1, t0-2, and t0-3 for each PRM. Time T0 represents the valid PRM message received in the last second of ...
Page 575: Feac
Test Functions FEAC FEAC The Far-End Alarm and Control signal (FEAC) provides Communication Channel capability over a DS3 in a network applications using C-bit Parity configuration (see page 294). From the test menu, tap Functions, and the FEAC tab. Generated Messages Allows configuring and sending alarms/status information and control signals (loopback commands) to other network elements.
Page 576 Test Functions FEAC Amount is the amount of codeword to be generated: 1 to15  (default is 10). Inject generates error(s) according to the Codeword and mode  selected. Loopback Commands  Control  Codeword is the loopack control codeword to be generated: Line Loopback Activate (00001110) - (Default) or Line Loopback Deactivate (00111000).
Page 577 Test Functions FEAC Received Messages Displays current and previous alarms/status and loopback commands as well as the link activity for the received DS3 signal. Link Activity  None (All 1’s): An all ones pattern (11111111 11111111) has been  detected in the last second. Alarm/Status: An Alarm/Status codeword has been detected in the ...
Page 578 Test Functions FEAC Loopback Commands  Current displays the valid message received in the last second of  measurement. A valid message is detected only when receiving 10 consecutive occurrences of a specific Loopback Command immediately followed by 10 occurrences of a specific Channel Codeword.
Page 579: Filters
Test Functions Filters Filters Allows gathering statistics according to the programmed filters. Filters provide the capability to analyze a specific stream’s behavior in order to monitor a single protocol’s behavior, perform SLA verification, or precisely troubleshoot unwanted behavior. Up to 10 filters having up to four operands each can be defined and enabled.
Page 580 Test Functions Filters Assign to Capture Note: Only available when the ETH-CAPTURE software option is enabled. Refer to Software Option on page 34 for more information. Assigns the selected filter for packet capture. See Packet Capture on page 571. Filter Configuration Note: Multiple filter criteria is only available when the ADV-FILTERS option is enabled;...
Page 581 Test Functions Filters Filter specifies the filter to be used (None by default).  Category Filter Ethernet MAC Destination Address, MAC Source Address, EtherType , C-VLAN ID, S-VLAN ID, E-VLAN ID, C-VLAN Priority, S-VLAN Priority, E-VLAN Priority IPv4 IPv4 Destination Address, IPv4 Source Address, IPv4 TOS, IPv4 Precedence, IPv4 Protocol, IPv4 DiffServ IPv6 IPv6 Destination Address, IPv6 Source Address,...
Page 582 Test Functions Filters Mask allows masking the defined filter value. A bit mask of 1  indicates that the corresponding bit in the value is compared for the match. A bit mask of 0 indicates that the corresponding bit in the value is ignored.
Page 583: Packet Capture
Test Functions Packet Capture Packet Capture Capture is used to analyze all or filtered data traffic and save complete or truncated frames into a buffer. It allows observing network truncated data precisely, or understanding errors and unwanted behavior. From the Test menu, tap Functions, and the Packet Capture tab. P1 and P2 Buttons The P1 and P2 buttons, available with Dual Port topology, allow respectively displaying results for port #1 (P1) or port #2 (P2).
Page 584 Test Functions Packet Capture Frame Length Specifies the length of the frame that will be saved in the capture buffer. Complete captures the entire frames.  Truncated captures only the first specified number of bytes per frame.  Use either the Bytes field to manually enter the number of bytes per frame or tap on the Truncation Calculator button for automatic bytes per frame calculation.
Page 585 Test Functions Packet Capture Trigger Trigger Type defines the trigger source criterion that will be used to  automatically start/stop the capture when a received frame matches the filter and the trigger criteria. Manual automatically starts the frame capture when the Capture ...
Page 586 Test Functions Packet Capture Trigger Position selects the triggered frame position within the buffer.  Post-Trigger for a trigger frame located at the beginning of the  buffer. The buffer will contain the triggered frame with the following frames. Mid-Trigger for a trigger frame located at the middle of the buffer. ...
Page 587 Test Functions Packet Capture Triggered Frame - Details gives details on the triggered frame.  The triggered frame corresponds to the first received frame that matches the filter and the trigger settings. Frame Number indicates the triggered frame position in the buffer. The framing MAC/IP/UDP/TCP source and destination addresses are displayed in a table.
Page 588 Test Functions Packet Capture View File After Generation: Allows displaying the report once it is  generated using the Wireshark application. The View File After Generation check box is not selected by default. Generate & Save  Allows generating and saving the capture data. The name of the captured file is automatically selected and contains the date and time of the capture.
Page 589: Gcc Bert
Test Functions GCC BERT GCC BERT Note: Only supported with Coupled topology. From the Test menu, tap Functions, and the GCC BERT tab. GCC Channels GCC0, GCC1, and GCC2 check boxes allow respectively enabling OTU GCC0, ODU GCC1, and ODU GCC2 generation and monitoring using a PRBS15 pattern.
Page 590 Test Functions GCC BERT Bit Error Allows selection of the GCC channel on which bit error will be injected. Only enabled GCC channels are listed; All selects all enabled GCC channels. Inject generates bit errors on the selected GCC channel(s). Reset Resets GCC BERT statistics: Pattern Loss and Bit Error.
Page 591 Test Functions Note: Available with Transport test applications with either payload type 21 (PT21) or one of the following clients: 1GbE, 40GbE, 100GbE, Ethernet (flex/GFP-F), or SONET/SDH (through ODU0). From the Test menu, tap Functions, and the GMP tab. Channel Available with Multi-Channel OTN, allows the selection of the channel number.
Page 592: Oh - Gfp-F/Gfp-T
Test Functions OH - GFP-F/GFP-T OH - GFP-F/GFP-T Note: Available with OTN BERT test application with 1GbE (GFP-T), 10GbE (GFP-F), or Ethernet (flex/GFP-F) client. From the Test menu, tap Functions, OH tab, and GFP-F/GFP-T sub tab. Core Header  PLI and cHEC are not configurable. Type Header ...
Page 593 Test Functions OH - GFP-F/GFP-T EXI (Extension Header Identifier) allows overwriting the Extension  Header Identifier. Description 0000 Null Extension Header 0001 Linear Frame 0010 Ring Frame 0011 to 1111 Reserved UPI (User Payload Identifier) allows overwriting the User Payload ...
Page 594 Test Functions OH - GFP-F/GFP-T Description for Description for PTI = 000 PTI = 100 0001 0010 Framed DVD-ASI 0001 0011 Framed 64B/66B Ethernet 0001 0100 Framed 64B/66B Ethernet Ordered Set 0001 0101 Reserved for future standardization through 1110 1111 1111 0000 Reserved for proprietary use through...
Page 595 Test Functions OH - GFP-F/GFP-T Note: The following Core Header, Type Header, and Extension Header parameters are available for Client Data, Client Management, and Reserved PTI frames. The details of the selected OH field is displayed in the OH Details section on the bottom-right of the screen. Core Header ...
Page 596 Test Functions OH - GFP-F/GFP-T Extension Header: CID, Spare, and eHEC are only available when EXI  is set to Linear (refer to EXI on page 181). CID (Channel IDentifier) indicates the communication channel  used by the signal. Possible values are 00000000 through 11111111 (0 to 255).
Page 597 Test Functions OH - OTN OH - OTN For OTN BERT, from the Test menu, tap Functions, and the OH tab. For OTN SONET/SDH BERT, from the Test menu, tap Functions, OH, and the OTN sub tab. Allows respectively modifying the overhead information to be transmitted or viewing the overhead information received.
Page 598 Test Functions OH - OTN The third SM byte (column 10) contains the following sub-fields. This byte is configurable from 00 (default) to FF. Bit 1-4 Bit 5 Bit 6 Bit 7-8 BEI/BIAE GCC0, columns 11-12, OTU OH: The two General Communication ...
Page 599 Test Functions OH - OTN Row 2 RES, columns 1-2, ODU OH: The two Reserved (RES) bytes are  configurable from 00 (default for each byte) to FF. PM & TCM, column 3, ODU OH: The Path Monitoring and Tandem ...
Page 600 Test Functions OH - OTN JC2 or JC  JC2, column 16, OPU OH: Controlled by GMP function. This byte is not configurable. JC, column 16, OPU OH: Bits 1-6, Reserved (RES), are configurable from binary 000000  (default) to 111111. Bits 7-8, Justification Control (JC), are configurable from binary ...
Page 601 Test Functions OH - OTN JC6 or RES  JC6, column 15, OPU OH: Bits 1-3 set to all-0s, and bits 4-8 are controlled by GMP function. This byte is not configurable. RES, column 15, ODU OH: The Reserved (RES) bytes are configurable from 00 (default) to FF.
Page 602 Test Functions OH - OTN RES, column 9-14, ODU OH: The six Reserved (RES) bytes are  configurable from 00 (default for each byte) to FF. PSI, column 15, OPU/ODU OH: Tap the PSI field to configure (TX) or  display (RX) the Payload Structure Identifier.
Page 603: Oh - Sonet/Sdh
Test Functions OH - SONET/SDH OH - SONET/SDH The SONET/SDH OH page allows modifying (TX) the overhead information to be transmitted and viewing (RX) the overhead information received. For SONET/SDH BERT, from the Test menu, tap Functions, and the OH tab.
Page 604 Test Functions OH - SONET/SDH Transport OH - Section/RS A1 and A2: Framing. The value should be hexadecimal F6 for A1 and  28 for A2. They must appear in every STS-1/STM-1 frame of a composite signal. SONET: Provide frame alignment of each STS-1 frame within a composite signal (STS-1 to STS-n).
Page 605 Test Functions OH - SONET/SDH F1: User/User Channel. This byte is reserved for user purposes. This  byte is only defined for the first STS-1/STM-1 frame of a composite signal. D1, D2, and D3: Data Communications Channel (DCC). Provides a ...
Page 606 Test Functions OH - SONET/SDH B2: BIP-8  SONET: The BIP-8 (Bit-Interleaved Parity) byte provides line error monitoring. This byte is only defined for the first STS-1/STM-1 frame of a composite signal. The byte is calculated by performing a routine even-parity check over all bits of the LOH and the STS-1 frame capacity of the previous frame of a composite signal (STS-1 to STS-n).
Page 607 Test Functions OH - SONET/SDH M0 or M1/Z2 (SONET)  M0: REI-L: The M1 byte is used for line Remote Error Indication (REI-L) For STS-1e and OC-1: The M0 byte located in the STS-1 indicates  BIP violations. M0, bits Indicates 234 5678 000 0000...
Page 608 Test Functions OH - SONET/SDH For OC-12: The M1 byte located in the STS-1 #7 indicates BIP  violations. M1, bits 234 5678 Indicates 000 0000 0 BIP violation 000 0001 1 BIP violation 110 0000 96 BIP violations 110 0001 to 0 BIP violation 1111 1111 For OC-48: The M1 byte located in the STS-1 #7 indicates BIP...
Page 609 Test Functions OH - SONET/SDH For M0 and M1 computation method: Indicates Located in STS-1 #4 Located in STS-1 #7 0000 0000 0000 0000 0 BIP violation 0000 0000 0000 0001 1 BIP violation 0000 0110 0000 0000 1536 BIP violations 0000 0110 to 0000 0001 to 0 BIP violation...
Page 610 Test Functions OH - SONET/SDH STS/AU/TU-3 J1: Trace. Available when the Trace format is set to 1 Byte (refer to  Traces (SONET/SDH) on page 336). SONET: The J1 Trace byte provides a 16 or 64 byte fixed string to verify connection between path transmitting equipment and path receiving equipment.
Page 611 Test Functions OH - SONET/SDH C2: Signal Label. Entering a C2 byte value will automatically update the  Path Signal Label (C2) selection and vice versa. Refer to STS/AU Path (C2) on page 196 for more information. Description (Hex.) SONET Unequipped UNEQ or supervisory-UNEQ Equipped - Non-Specific...
Page 612 Test Functions OH - SONET/SDH G1: Path Status. The G1 byte provides a method to communicate the  far-end path status back to the path originating equipment. REI: Bits 1 to 4 of G1 Description 0000 No error 0001 1 error 0010 2 errors 1000...
Page 613 Test Functions OH - SONET/SDH Z3 and Z4:  SONET only: Growth.  SDH only: User Channel. The Path User Channel provides a channel for communication purposes between path elements and is payload dependent.  SDH only: Automatic Protection Switching (APS). Bits 1 to 4 of the K3 byte are used for APS signaling.
Page 614 Test Functions OH - SONET/SDH VT/TU V5 VT/TU Path Overhead  The V5 byte is allocated to indicate the content of the VT/TU path, including the status of the mapped payloads. It provides the same functions for VT/VC paths that the B3, C2, and G1 bytes provide for STS/STM paths.
Page 615 Test Functions OH - SONET/SDH If the signal label in V5 (bits 5, 6, and 7) is 101 the contents of the extended signal label is valid and contains in a 32 bit multiframe as shown below. See Z7/K4 Structure shown below. Z7/K4 Structure J2 Trace.
Page 616 Test Functions OH - SONET/SDH Z7 /K4 : Extended signal label  Description Bits Z7 (SONET) K4 (SDH) Extended signal label. Bits 12 to 19 of the 32 bit frame multiframe (see Z7/K4 Structure on page 603) contain the extended signal label. Virtual concatenation.
Page 617: Ping & Trace Route
Test Functions Ping & Trace Route Ping & Trace Route From the Test menu, tap Functions, and the Ping & Trace Route tab. P1 and P2 Buttons The P1 and P2 buttons, available with Dual Port topology, allow respectively displaying the alarms/errors for port #1 (P1) or port #2 (P2). Source IP Address Displays the configured Source IP Address.
Page 618 Test Functions Ping & Trace Route Use Stream Use Stream, available with test application using stream/services, allows using the source and destination IP of the defined or selected stream/services. Ping Data Size (Bytes): Enter the data size that will be sent to the network ...
Page 619 Test Functions Ping & Trace Route Trace Route Max Hop Count: Enter the maximum network device the packet is  allowed to go through. Choices are 1 to 255; 128 by default. Timeout (ms): Enter the maximum time allowed between an ICMP ...
Page 620 Test Functions Ping & Trace Route Status: Indicates the status of the attempt as follows:  Status Description Successful Valid ICMP echo reply received. User Aborted When a user has manually stopped the ping/trace route function before the end of attempts.
Page 621 Test Functions Ping & Trace Route Replied Details  For ping, indicates the IP address of the replier, the buffer size of the ICMP echo response, the time of response in milliseconds, and the TTL of the ICMP echo response. For trace route, indicates the IP address of the replier, and the time of response in milliseconds.
Page 622: Pointer Adjustment
Test Functions Pointer Adjustment Pointer Adjustment From the Test menu, tap Functions, and the Pointer Adjustment tab. TX Pointer Adjustment Note: Only available in Coupled topology. The pointer adjustment supports two modes of operation: Manual and Sequence. Both modes offer the generation of pointer events even when the test is not started.
Page 623 Test Functions Pointer Adjustment Jump New Pointer allows selecting a new pointer value:  For STS/AU: 0 (default) to 782 For VT/TU: Path Range VT1.5 0 to 103 0 to 139 TU-3 0 to 764 TU-11 0 to 103 TU-12 0 to 139 Inject button sends the new pointer value.
Page 624 Test Functions Pointer Adjustment TX Pointer Adjustment - Sequence Button Note: The pointer sequence is only supported on one test layer; either on VT/TU layer or on STS/AU when the test doesn’t contain VT/TU mapping. The field next to the Sequence operation mode button indicates the path level used for the sequence pointer adjustment.
Page 625 Test Functions Pointer Adjustment Initialization / Cool Down / Sequence  The following time line examples show the initialization, cool down, and the pointer sequence according to the selected sequence and parameters. Example 1: Periodic 87-3 with Cancel Example 2: Regular pointers plus one double pointer Legend: Description When located at the end (right) of the sequence, indicates a continuous repetition of the pointer...
Page 626 Test Functions Pointer Adjustment T1 to T6 are configurable duration parameters. The range of the  duration parameters as well as their availability versus pointer sequence are described in the following table. Pointer Sequence Pattern Parameter Duration range Single pointers of opposite polarity 10 to 30 s (default 10 s) Regular pointers plus one double pointer AU/TU-3: 7.5 ms to 30 s (default 0.333 s)
Page 627 Test Functions Pointer Adjustment T1 (s) represents the interval between two pointer events.  Example of Single pointer of opposite polarity sequence. T2 (s) represents the interval between successions of pointer  events. Example of Regular pointers with one missing pointer sequence.
Page 628 Test Functions Pointer Adjustment T4 (ms) represents the interval between back to back pointer  events in periodic pointer sequence. Example of Burst pointer adjustment sequence. T5 (s) represents the interval between successions of pointer  events in a Periodic pointer sequence. Example of Periodic 87-3 with Cancel sequence.
Page 629 Test Functions Pointer Adjustment Increment/Decrement allows determining if the pointer sequence will  increment (positive) or decrement (negative) the pointer values. Periodic check box when selected, generates the pointer sequence  continuously. The pointer sequence is generated only once when the Periodic check box is cleared.
Page 630 Test Functions Pointer Adjustment Sequence button when enabled, generates pointer events on a regular  basis. The initialization and cool down sequence are described below for each pointer sequence pattern. Pointer Sequence Pattern Initialization Cool down Single pointers of opposite polarity Basic sequence Basic sequence ...
Page 631 Test Functions Pointer Adjustment RX Pointer Adjustment Pointer Value  For STS/AU: Displays the value for the pointer, H1 and H2, indicating the offset in bytes between the pointer and the first byte of the STS-n (SONET) or AU-n (SDH). For VT/TU: Displays the value of the pointer, V1 and V2, indicating the offset in bytes between the pointer and the first byte of the VTn (SONET) or TU-n (SDH) of the high order path.
Page 632 Test Functions Note: Available with Pattern client. Not available in Decoupled, Through, or Through Intrusive mode. Round Trip Delay (RTD) measurements are needed to quantify the time it takes for a signal to cross the network and come back. Usually, transport delay is due to two factors: long configured paths and transit times through the network elements along the path.
Page 633 Test Functions Measure Delay Button Allows enabling the round trip delay measurement. For Single mode, the test is performed once and stops (the Measure Delay button turns off by itself). The Measure Delay button is only available when the test is running. For Continuous mode, the test is performed continuously until the RTD test or the test case itself is stopped.
Page 634 Test Functions Disabled: Indicates that the RTD feature is disabled.  --: Indicates that the RTD measurement is not ready.  Reset Resets the RTD results and measurement counts. Delay Indicates the time required for a bit to travel from the transmitter back to its receiver after crossing a far-end loopback.
Page 635: Rtd/Rtt (Cpri/Obsai Framed L2)
Test Functions RTD/RTT (CPRI/OBSAI Framed L2) RTD/RTT (CPRI/OBSAI Framed L2) Note: Only available with CPRI/OBSAI Framed L2 in Base Station emulation mode. Round Trip Delay (RTD for CPRI) and Round Trip Time (RTT for OBSAI) measurements are needed to quantify the time it takes for a signal to cross the remote radio head and come back.
Page 636 Test Functions RTD/RTT (CPRI/OBSAI Framed L2) Round Trip Delay (CPRI) Indicates the time required for a bit to travel from one point to another. Delay T14 indicates the round trip delay measurement from the Base  Station going through the Remote Radio Head (including Toffset) and back to the Base Station.
Page 637 Test Functions RTD/RTT (CPRI/OBSAI Framed L2) Round Trip Time (OBSAI) Indicates the time required for a bit to travel from one point to another. RTT indicates the round trip time measurement from the Base Station  going through the Remote Radio Head (including Delay 1,2) and back to the Base Station.
Page 638: S-Oam Link Trace
Test Functions S-OAM Link Trace S-OAM Link Trace From the Test menu, tap Functions, and the S-OAM Link Trace tab. Link Trace Priority allows selecting the VLAN user priority: 0 (default) to 7. Refer  to VLAN ID and Priority on page 758 for more information. is set to No (no frames will be dropped when Drop Eligible ...
Page 639 Test Functions S-OAM Link Trace RX LTR indicates the count of received LTR frames having their  destination MAC address matching the unit port MAC address, and VLANs matching the unit port VLANs. LTR Timeout indicates the count of LTR Timeout event which occurs if ...
Page 640: Signaling Bits
Test Functions Signaling Bits Signaling Bits Allows generation and monitoring of the signaling bits. Only available for DSn/PDH BERT framed test with DS0/E0 enabled. From the Test menu, tap Functions and the Signaling Bits tab. Note: Two signaling bits (AB) are available for SF or SLC-96 framing while four signaling bits (ABCD) are available for ESF.
Page 641 Test Functions Signaling Bits RX Signaling Channel/AB/ABCD table: The monitoring of signaling bits of either the 24 - DS0 channels or 30 - E0 channels is performed when the test is running. Power Blazer...
Page 642: Spare Bits
Test Functions Spare Bits Spare Bits Note: Spare Bits are not available when the framing is set to Unframed. From the Test menu, tap Functions, tap the Spare Bits tab. Tap a spare bits field to set its value. Note: All spare bits are reserved for national use and should be set to 1 when not used.
Page 643 Test Functions Spare Bits  G.751 Bit 14, 15, 16 are reserved for national use.  G.751 Bit 12 is reserved for national use.  G.742 Bit 12 represents Bit 12 from Timeslot 1, 2, 3, and 4 respectively.  is located in the bit 1 of the frame containing the frame ...
Page 644: Traffic Scan
Test Functions Traffic Scan Traffic Scan The traffic scan tool provides the capability to discover and monitor VLAN traffic flows on the network. Note: Not available with dual port test and when Provider Encapsulation is used. From the Test menu, tap Functions, and the Traffic Scan tab. Level Allows the selection of the criteria that will be used to filter the incoming VLAN traffic flows.
Page 645 Test Functions Traffic Scan Rate Layer Allows the selection of the rate unit used for Link Rate and Rate statistics. Line Utilization is used to express the real line rate including the  Preamble, SFD, and IFG. Ethernet BW (Bandwidth) is used to express the Ethernet bandwidth ...
Page 646 Test Functions Traffic Scan Monitored Frames Table Statistics are gathered for each different traffic flow matching the scan criteria. Each different monitored traffic flow creates a separate entry in the scan table. When the limit is reached, new traffic flows are not considered in the table but the existing traffic flows are still monitored.
Page 647: Test Control
11 Test Control This chapter describes the test control buttons available on the right navigation bar of the application. Button For more information, see: Discover Remote Discover Remote Button on page 636 Inject Inject Button on page 639 Laser Laser Button on page 639 Lpbk Tool Lpbk Tool Button (Loopback Tool) on page 640 Report...
Page 648: Discover Remote Button
The Discover Remote function allows performing Ethernet tests in conjunction with a second test set (module) by scanning and connecting to any available EXFO Datacom remote module. The remote module is used to loop back the traffic via Smart Loopback or Dual Test Set (DTS) for simultaneous bidirectional RFC 2544, RFC 6349, or EtherSAM results.
Page 649 Test Control Discover Remote Button Status indicates the status of the remote module.  Status Description Idle-<test application> The specified test application is selected but not running. Busy-<test application> The specified test application is running. Not Responding No response from the specified IP address (only possible when Target is set to Specific IP).
Page 650 Test Control Discover Remote Button Connect and Disconnect buttons are only available with RFC 2544,  RFC 6349, and EtherSAM test applications. Connect establishes the connection with the selected remote  module and sets the remote module into either DTS RFC 2544, DTS RFC 6349, or DTS EtherSAM test application, depending on the active test on the local module.
Page 651: Inject Button
Test Control Inject Button Inject Button Injects alarms/errors based on settings from the Inject Button on page 413. Laser Button The Laser button enables or disables the laser for optical interfaces. For Dual Port topology, enables or disables the laser for both optical interfaces (ports).
Page 652: Lpbk Tool Button (Loopback Tool)
Test Control Lpbk Tool Button (Loopback Tool) Lpbk Tool Button (Loopback Tool) The Loopback Tool provides the capability of looping back the Ethernet frames/packets that are received on the loopback tool port. Pressing the Lpbk Tool button opens the Loopback Tool pop-up and powers up the port unused by the main test application (it does not start looping back the frames yet).
Page 653 Test Control Lpbk Tool Button (Loopback Tool) Loopback Tool tab The Loopback Tool tab allows the configuration of the loopback parameters and displays the traffic statistics as well as the S-OAM Responder statistics. Press the Lpbk Tool button and select the Loopback Tool tab. Status: The status field displays the current status of the Loopback test.
Page 654 Test Control Lpbk Tool Button (Loopback Tool) Loopback Mode determines at which layer the address/port swapping  is limited. Ethernet swaps the MAC addresses of received packets having  their Destination MAC address matching the MAC address of the loopback port. Ethernet (All Unicast) swaps the MAC addresses of received ...
Page 655 Test Control Lpbk Tool Button (Loopback Tool) S-OAM Responder check box when selected (default) allows  responding to LBM, LTM, DMM, LMM, and SLM valid messages (Lpbk Tool must be started, see Loopback button below). Traffic statistics are also monitored (refer to Responder on page 535). Responds to...
Page 656 Test Control Lpbk Tool Button (Loopback Tool) Interface Tab Physical Interface  Interface/Rate allows the selection of the loopback tool interface  rate: 10/100/1000M Electrical (default), 100M Optical, 1GE Optical, or 10GE LAN. 10GE LAN is only available when the loopback tool runs on Port #1.
Page 657 Test Control Lpbk Tool Button (Loopback Tool) Power Range (dBm) indicates, when supported, the received  power level range of the optical laser in dBm. RX Frequency (MHz/GHz) indicates the frequency of the input  signal. When no frequency reading is possible, “--” is displayed. Not available when using an active copper SFP.
Page 658 Test Control Lpbk Tool Button (Loopback Tool) Cable Mode is available with 10/100/1000M Electrical interface.  Manual mode is selected when the Auto-Negotiation check box is cleared and allows selecting the type of cable: MDI (default) for straight through cable or MDIX for crossover cable. Automatic mode is selected when the Auto-Negotiation check box is selected and allows detecting automatically the MDI or MDIX cable type.
Page 659: Report Button
Test Control Report Button Report Button The report contains all information about the current test including its setup and results. Note: Nothing prevents the configuration and alarm/error injection setup while the test has been stopped; thus, the report should be saved/printed before changing any test parameters to avoid printing discrepancy between the configuration and results.
Page 660 ID, and Comment. Up to 30 characters are allowed for each parameter at the exception of Comment for which 256 characters are allowed. Note: When the EXFO Connect Server check box is selected in EXFO Connect Client, the Opeator Name is not editable but can be selected from the EXFO Connect operator list using the Change button.
Page 661 Test Control Report Button Save Report  Auto-Generate File Name check box, when selected (default),  automatically generates the report file name which contains the name of the test, the date (YY.MM.DD), and time (HH.MM.SS). Clear the Auto-Generate File Name check box to enter a specific file name.
Page 662 Test Control Report Button Open Tab Report files can be opened from this page. Tap the Report button and the Open tab. To open a saved report: 1. Select the file location (see File Location on page 647). 2. Select the report file from the list. 3.
Page 663 Test Control Report Button Import/Export Tab Allows transferring and deleting report files from an external USB media. Also allows importing images that can used as the Logo for reports. Tap the Report button and select the Import/Export tab. To import/export a report or image: 1.
Page 664: Reset Button
Test Control Reset Button Reset Button Tap the Reset button to clear results, statistics, and logger content. The Reset button is only available when the test is running. Note: The Reset button is not available for EtherSAM, RFC 2544, RFC 6349, Cable Test, and Smart Loopback test applications.
Page 665: Save/Load Button
Test Control Save/Load Button Save/Load Button The Save/Load button allows saving, loading, importing, exporting, and deleting configuration file(s). Note: Save/Load is only possible when the test is stopped. File location My Documents offers two file locations: use Favorites for most ...
Page 666 Test Control Save/Load Button Save/Load Tab Tap the Save/Load button and the Save/Load tab. The save function stores the configuration of the module including all test settings to a file. To save a configuration: 1. Select the file location (see File location on page 653). 2.
Page 667 Test Control Save/Load Button To rename a configuration file: 1. Select the file location (see File location on page 653). 2. Select the file from the list. 3. Tap the Rename button. 4. Change the name of the configuration file. 5.
Page 668 Test Control Save/Load Button Import/Export Tab Configuration files can be transferred to and from an external USB media as well as deleted. Tap the Save/Load button and the Import/Export tab. To import/export a test configuration: 1. Select the source file location (see File location on page 653). 2.
Page 669: Start/Stop|Tx Button
Test Control Start/Stop|TX Button Start/Stop|TX Button The Start/Stop|TX button allows starting or stopping manually any test as well as enabling traffic generation (Traffic Gen & Mon). To start the test: Tap the Start button to start the test. Start is available when the test is not running.
Page 671: Power Failure Recovery
12 Power Failure Recovery The automatic power failure recovery is used to select, configure, and restart the test that was running before the power failure; a test that was not running will be selected and configured but not started. To provide this level of protection, the configuration of the current test is automatically saved;...
Page 672: Enabling Power Failure Recovery
Power Failure Recovery Enabling Power Failure Recovery Enabling Power Failure Recovery To enable the automatic power failure recovery: 1. Enable launching the application when starting the platform (refer to the platform user guide for more information): From ToolBox X, tap on the System Settings button, the Startup Applications button, and select the corresponding module’s check box.
Page 673: When Using The Test Timer
Power Failure Recovery When Using the Test Timer When Using the Test Timer Refer to Timer on page 330 for more information on test timer. The test that was running will be re-created and started after a power failure if conditions described above are met in addition with the following test time conditions: The start time has not expired during the power failure.
Page 675: Maintenance
13 Maintenance To help ensure long, trouble-free operation: Always inspect fiber-optic connectors before using them and clean  them if necessary. Keep the unit free of dust.  Clean the unit casing and front panel with a cloth slightly dampened ...
Page 676: Cleaning Lc/Sc/Mpo-24 Connectors
Battery Safety Information The TA-... modules contain a battery for the insertion counter. If the battery status is low, contact your nearest authorized EXFO service center for its replacement. ARNING Do not throw batteries into fire or water and do not short-circuit the batteries’...
Page 677: Recalibrating The Unit
EXFO unit. Under normal use, the recommended interval for your module is: 2 years. For newly delivered units, EXFO has determined that the storage of this product for up to six months between calibration and shipment does not affect its performance (EXFO Policy PL-03).
Page 678: Recycling And Disposal
(2 years) To ensure that your unit conforms to the published specifications, calibration may be carried out at an EXFO service center or, depending on the product, at one of EXFO’s certified service centers. Calibrations at EXFO are performed using standards traceable to national metrology institutes.
Page 679: Troubleshooting
14 Troubleshooting Solving Common Problems Before calling EXFO’s technical support, please read the following common problems that can occur and their respective solution. Problem Possible Cause Solution Optical Laser LED is off and the The Laser On option is disabled.
Page 680: Contacting The Technical Support Group
Contacting the Technical Support Group To obtain after-sales service or technical support for this product, contact EXFO at one of the following numbers. The Technical Support Group is available to take your calls from Monday to Friday, 8:00 a.m. to 7:00 p.m.
Page 681: Warranty
15 Warranty General Information EXFO Inc. (EXFO) warrants this equipment against defects in material and workmanship for a period of one year from the date of original shipment. EXFO also warrants that this equipment will meet applicable specifications under normal use.
Page 682: Liability
Liability Liability EXFO shall not be liable for damages resulting from the use of the product, nor shall be responsible for any failure in the performance of other items to which the product is connected or the operation of any system of which the product may be a part.
Page 683: Exclusions
Warranty Exclusions Exclusions EXFO reserves the right to make changes in the design or construction of any of its products at any time without incurring obligation to make any changes whatsoever on units purchased. Accessories, including but not limited to fuses, pilot lamps, batteries and universal interfaces (EUI) used with EXFO products are not covered by this warranty.
Page 684: Service And Repairs
5. Return the equipment, prepaid, to the address given to you by support personnel. Be sure to write the RMA number on the shipping slip. EXFO will refuse and return any package that does not bear an RMA number.
Page 685: Exfo Service Centers Worldwide
Fax: +86 (755) 2955 3101 Xintian Avenue, support.asia@exfo.com Fuyong, Bao’An District, Shenzhen, China, 518103 To view EXFO's network of partner-operated Certified Service Centers nearest you, please consult EXFO's corporate website for the complete list of service partners: http://www.exfo.com/support/services/instrument-services/ exfo-service-centers. Power Blazer...
Page 687: A Specifications
The following general specifications can change without notice. The information presented in this section is provided as a reference only. To obtain this product’s most recent technical specifications, visit the EXFO Web site at www.exfo.com. AUTION The operation and storage temperatures, as well as the altitude, humidity and IP rating of some modules may differ from those specified for your platform.
Page 688 Specifications General Specifications 8870/8880/ Specification 88260 88400NGE 88200NGE Size 118 x 25 x 160 mm 118 x 25 x 159 mm 118 x 100 x 160 mm (H x W x D) (4 5/8 x 1 x 6 3/8 in) (4 5/8 x 1 x 6 3/8 in) (4 5/8 x 4 x 6 3/8 in) Weight (without transceiver) 8870: 0.35 kg (0.75 lb)
Page 689: B Glossary
Glossary Acronym List 10B_ERR 10B_Error 400GAUI-16 400 Gbit/s Attachment Unit Interface - 16 physical lanes Help Alternating Current Associated Channel Header Activity Alarm Indication Signal Alternate Mark Inversion Automatic Protection Switching Asynchronous Transfer Mode AU-n Administrative Unit-n Attachment Unit Interface B-VLAN Backbone Virtual Local Area Network B8ZS...
Page 690 Glossary Acronym List BERT Bit Error Rate Test BIAE Backward Incoming Alignment Error Bit-Interleaved Parity bit/s Bit per second Backward Signal Degrade Backward Signal Fail Current C-DCI Client - Defect Clear Indication C-FDI Client - Forward Defect Indication C-LOS Client - Loss Of Signal C-RDI Client - Remote Defect Indication C-VLAN...
Page 691 Glossary Acronym List Client Management Frames CORR Correctable Class Of Service CPRI Common Public Radio Interface Cyclic Redundancy Check CRC-4 Cyclic Redundancy Check on 4 bits CRITIC Critical Client Signal Fail Comma Separated Value constant Time Error Code Violation Code Word Destination MAC Address DAPI Destination Access Point Identifier...
Page 692 Glossary Acronym List dynamic Time Error High Don’t Use for Synchronization Device Under Test E-VLAN Extended Virtual Local Area Network European standard for digital transmission-level 0 (64 Kbit/s). European standard for digital transmission-level 1 (2.048 Mbit/s). European standard for digital transmission-level 2 (8.448 Mbit/s). European standard for digital transmission-level 3 (34.368 Mbit/s).
Page 693 Glossary Acronym List EXFO Universal Interfaces Extension Header Identifier Extension Header Mismatch EXT CLK External Clock Frame Alignment Signal Fibre Channel Federal Communications Commission Frame Clock Burst Frame Check Sequence Frame Delay Forward Defect Indication Forward Error Correction FEC-UNCOR- FEC Uncorrectable Codeword...
Page 694 Glossary Acronym List Generic Associated Channel Label Gigabit Ethernet Gbit/s Gigabit per second General Communication Channel Generic Framing Procedure GFP-F GFP - Framed GFP-T GFP - Transparent Giga Hertz Grand Master Generic Mapping Procedure GMP OOS GMP Out of Synchronization Global IPv6 Address Graphical User Interface History...
Page 695 Glossary Acronym List Incoming Alignment Error IAIS Incoming Alarm Indication Signal Identification International Electrotechnical Commission Incoming Error Count IEEE Institute of Electrical & Electronics Engineers IFDV Inter-Frame Delay Variation Input Internet Protocol IPDV Inter Packet Delay Variation IPTV Internet Protocol Television Interframe Gap IPv4 Internet Protocol version 4...
Page 696 Glossary Acronym List Loss of Code-Group Delineation Locked Light-Emitting Diode Label Edge Router Pound Line Build Out Loss of Frame Delineation Link-Local IPv6 Address Logical Link Control Logical Lane Marker Loss Measurement Message Loss Measurement Reply Loss Of Alignment LOAML Loss of Alignment Marker Lock LOAML1027B Loss of Alignment Marker Lock 1027 Blocks...
Page 697 Glossary Acronym List Loss Of Pointer Loss Of Recovery Loss Of Signal Least-Significant Bit Label Switch Path Label Switching Router Loss of Sequence Synchronization Loss of Tandem Connection Link Trace Message Link Trace Reply Minute Meter Maintenance Association Media Access Control MAID Maintenance Association Identification Mbit/s...
Page 698 Glossary Acronym List MEG Intermediate Point Mean Path Delay MPLS Multiprotocol Label Switching Multiplex Section Multisource Agreement Most-Significant Bit MSEQV Marker Sequence Violation msg/s Message per second MSIM Multiplex Structure Identifier Mismatch MTIE Maximum Time Interval Error Maximum Transfer Unit Network Address Translation NATO North Atlantic Treaty Organization...
Page 699 Glossary Acronym List Outgoing Defect Indication Optical Data Unit Outgoing Error Indication Overhead Out-of-Lane-Alignment OMFI OPU Multi-Frame Identifier OOMFI Out of OPU Multi-Frame Identifier Out-Of-Frame Out-Of-Multiframe Out-Of-Recovery Generic Mapping Procedure Out Of Synchronization Out-Of-Sequence OOSM Out-Of-Service Monitoring Optical Payload Unit Optical channel Transport Lane Optical Transport Network Optical Transport Unit...
Page 700 Glossary Acronym List Payload Defect Indication Protocol Data Unit Provider Edge pFCS payload Frame Check Sequence Payload Frame Check Sequence Identifier Physical Layer Device Payload Length Indicator Payload Label Mismatch PLOGI Port Login Performance Monitoring Provisionable by the Network Operator Position Field POSV Position Field Violation...
Page 701 Glossary Acronym List Quality Level Quality of Service QSFP Quad Small Form Factor Pluggable R Deg SER Remote Degraded SER Reverse Defect Indication Remote Defect Indication Remote Error Indicator Reserved Remote Failure Indication Return Merchandise Authorization Reference Point n Regenerator Section Round Trip Delay Round Trip Time Receive...
Page 702 Glossary Acronym List Server Defect Synchronous Digital Hierarchy Service Disruption Time SDTV Standard Digital Television Severely Errored Framing Severely Errored Period SEQV Sequence Violation Severely Errored Second SESR Severely Errored Second Ratio Superframe System Frame Number Small Form Factor Pluggable International System Service Instance Identifier Service-Level Agreement...
Page 703 Glossary Acronym List Stratum 1 Traceable Stratum 2 Traceable Stratum 3 Traceable ST3E Stratum 3E Traceable Synchronous Transport Module Synchronous Transport Signal Synchronized - Traceability Unknown SYMB Symbol Software Transceiver Adaptor Traffic Class Tandem Connection Monitoring Transport Control Protocol TDEV Time Deviation Time Error tHEC...
Page 704 Glossary Acronym List Tributary Unit Group Transmit Unavailable Second User Data Protocol UNCORR Uncorrectable UNEQ Unequipped User Payload Identifier User Payload Mismatch μs microsecond United States of America Unshielded Twisted Pairs Virtual Container VIOL Violation VLAN Virtual Local Area Network VoIP Voice over Internet Protocol Virtual Tributary...
Page 705 Glossary Acronym List Wide Area Network WAN Interface Sublayer World Wide Name XLAUI 40 Gbit/s Attachment Unit Interface Power Blazer...
Page 706: G Ethernet Client
Glossary 10G Ethernet Client 10G Ethernet Client The OTN Overclocked technology provides the capability to transparently transport 10G base-R Ethernet signals into OPU2 as specified in ITU-T. Two optical rates are provided: 11.0957 Gbits/s, +/- 100 ppm, designated OTU2e  11.0491 Gbits/s, +/- 100 ppm, designated OTU1e ...
Page 707 Glossary 10G Ethernet Client The following figure presents a typical network application. Power Blazer...
Page 708 The following figure presents a typical test application. The Ethernet layer provides the equivalent functionality of the BERT Framed Layer 2 Test application supported on EXFO’s Datacom product family with the particularity that there is no Ethernet Physical port as such.
Page 709 Glossary 1588 PTP 1588 PTP The goal of the IEEE 1588 Precision Time Protocol (PTP) is to provide Network Synchronization using a packet based distribution mechanism. Depending on the system application the Network Synchronization may require phase and frequency synchronization. 1588 PTP has the capability to deliver both by allowing a Client clock to track a Master clock in phase (time of day) and in frequency.
Page 710 Glossary 1588 PTP Peer Delay mechanism uses message Pdelay Request, Pdelay  Response, and if required Pdelay Response Follow Up. This mechanism is restricted to topologies where each peer-to-peer port communicates PTP messages with, at most, one other such port. Peer Delay is not supported by the Telecom Profile.
Page 711 Glossary 1588 PTP The 1588 PTP supports the following Master/Client communication; however Unicast is used for the Telocom Profile. Multicast: A Master clock sends its Sync/Follow Up and Delay  Response in a multicast mode. A Client can collect information from many Master clocks and select the Master clock that is best suited for its application.
Page 712 Glossary 1588 PTP Telecom Profile G.8265.1 The Telecom Profile G.8265.1 is designed for frequency synchronization in Telecom network applications. The main attributes of this profile are: Unicast communication with the Grand Master  UDP/IPv4 network layer  With the Telecom Profile, the Client Clock initiates the communication to the Master Clock by making a request for service that consists of sending Signaling messages containing a REQUEST UNICAST TRANSMISSION TLV to the IP address of the Master Clock.
Page 713 Glossary 1588 PTP The following diagram shows the sequence of message exchange between a Client Clock and a Master Clock. First, the Client request Unicast Announce message service. When this is granted and the first Announce message is received, the Client can check the QL value conveyed in the clockClass field of the message.
Page 714 Glossary 1588 PTP Telecom Profile G.8275.1 The Telecom Profile G.8275.1 is designed for time/phase synchronization in telecom network applications. The main attribute of this profile are: Full timing support from the network, i.e. all network nodes are  boundary clocks Slave clocks synchronize with its respective upstream Boundary Clock ...
Page 715: Cpri
Glossary CPRI CPRI Overview Traditional mobile installations are bulky (use thick coaxial cables) and require a lot of power to operate (there is a huge power loss in the coaxial cabling which often requires the use of Tower Mounted Amplifiers) as outlined in the following figure.
Page 716 Glossary CPRI This protocol called Common Public Radio Interface (CPRI) separates a traditional radio base station configuration into two separate elements: Radio Equipment Control (REC) and the Radio Equipment (RE). The REC processes the baseband radio digital information and performs the control of the Radio Equipment.
Page 717 Glossary CPRI Functional Description As mentioned earlier, CPRI remotely locates the RE from the REC. This means that the RE must be controlled, managed and synchronized from the REC in addition to transporting the User information (Voice and user application data) and all that on the same digital link. As such, CPRI is composed of 3 communication flows multiplexed into a single serial signal transmitted in the same optical fiber as illustrated in the following figure.
Page 718 Glossary CPRI CPRI Model The CPRI Model revolves around the 3 communication flows described above. CPRI defines only the Layer 1 and Layer 2 associated to these communication flows as outlined in the following figure. The User Data Plane contains mostly voice/data traffic in the form of IQ Data samples.
Page 719 Glossary CPRI Physical Interface CPRI offers 8 options in terms of interface rates. Rates below 10G uses 8B/10B line coding as per CPRI V6.0 while rates above 10G use 64B/66B coding. Depending on the rates used, scrambling is optional. Depending on the CPRI signal structure (Framed or Unframed) the scrambling is either manually configured or negotiated.
Page 720: Ethernet Cables
Glossary Ethernet Cables Ethernet Cables Minimum Category 3 cable is required for 10Base-T connection while Category 5 cable is required for 100Base-TX and 1000Base-T connections. Maximum cable length (between two nodes) for 10Base-T, 100Base-TX, or 1000Base-T connection is 328 feet (100 meters). Straight Through Cable (10/100 Mbit/s) ...
Page 721 Glossary Ethernet Cables Straight Through Cable (1000 Mbit/s)  Crossover Cable (1000 Mbit/s)  Power Blazer...
Page 722: G.709 Optical Transport Network (Otn)
Glossary G.709 Optical Transport Network (OTN) G.709 Optical Transport Network (OTN) Overview The optical transport network (OTN) combines the benefits of SONET/SDH technology with the bandwidth expansion capabilities offered by dense wavelength-division multiplexing (DWDM) technology. The OTN consists of the following layers: Optical Transport Section (OTS) ...
Page 723 Glossary G.709 Optical Transport Network (OTN) Each of these layers and their functions are distributed along the network and activated when they reach their termination points, which are illustrated in the following figure. OTN Layer Termination Points The termination of the OTS, OMS and OCh layers is performed at the optical level of the OTN.
Page 724 Glossary G.709 Optical Transport Network (OTN) The OTU, ODU (including the ODU tandem connection) and OPU layers can all be analyzed and monitored. As per ITU G.709, current test solutions offer these possibilities using the following line rates: OTU1 (255/238 x 2.488 320 Gbit/s ≈ 2.666057143 Gbit/s) also referred to ...
Page 725 Glossary G.709 Optical Transport Network (OTN) In order to map client signals via ITU G.709, they are encapsulated using the structure illustrated in the following figure. Basic OTN Transport Structure Power Blazer...
Page 726 Glossary G.709 Optical Transport Network (OTN) As depicted above, to create an OTU frame, a client signal rate is first adapted at the OPU layer. The adaptation consists of adjusting the client signal rate to the OPU rate. Its overhead contains information to support the adaptation of the client signal.
Page 727 Glossary G.709 Optical Transport Network (OTN) OTU Frame Structure and Overhead As shown in the figure below, the OTU frame is broken down into the following components: Framing  OTL, OTU, ODU, OPU overhead  OTU FEC  OTU Frame Description Power Blazer...
Page 728 Glossary G.709 Optical Transport Network (OTN) Framing  The OTU framing is divided into two portions: FAS and MFAS. The frame alignment signal (FAS) uses the first six bytes and, similarly to SONET/SDH, it is used to provide framing for the entire signal. In order to provide enough 1/0 transitions for synchronization, scrambling is used over the entire OTU frame, except for the FAS bytes.
Page 729 Glossary G.709 Optical Transport Network (OTN) Optical Transport Unit (OTU)  The OTU overhead is comprised of the SM, GCC0 and RES bytes. The section monitoring (SM) bytes are used for the trail trace identifier (TTI), parity (BIP-8) and the backward error indicator (BEI), or backward incoming alignment error (BIAE), backward defect indicator (BDI), and incoming alignment error (IAE).
Page 730 Glossary G.709 Optical Transport Network (OTN) Optical Data Unit (ODU)  The ODU overhead is broken into several fields: RES, PM, TCMi, TCM ACT, FTFL, EXP , GCC1/GCC2 and APS/PCC. The reserved (RES) bytes are undefined and are set aside for future applications.
Page 731 Glossary G.709 Optical Transport Network (OTN) Optical Payload Unit (OPU)  The primary overhead field associated to the OPU is the Payload Structure Identifier (PSI). This is a 256 bytes multi-frame where its first byte is defined as the Payload Type (PT). The remaining 255 bytes are currently reserved.
Page 732 Glossary G.709 Optical Transport Network (OTN) Tandem Connection Monitoring (TCM) TCM enables the user and its signal carriers to monitor the quality of the traffic that is transported between segments or connections in the network. SONET/SDH allowed a single level of TCM to be configured, while ITU G.709 allows six levels of tandem connection monitoring to be configured.
Page 733 Glossary G.709 Optical Transport Network (OTN) Each of the six TCMi fields in the ODU overhead is assigned to a monitored connection. There can be from zero to six connections that can be configured for each connection. In the figure Tandem Connection Monitoring on page 720, there are three different connections that are actually monitored.
Page 734 Glossary G.709 Optical Transport Network (OTN) The FEC uses a Reed-Solomon RS (255/239) coding technique. This means that 239 bytes are required to compute a 16-byte parity check. The FEC can correct up to eight (bytes) errors per sub-row (codeword) or detect up to 16 byte errors without correcting any.
Page 735 Glossary G.709 Optical Transport Network (OTN) ODU Multiplexing The ODU multiplexer is a function that allows the multiplexing of ODU tributary signals into higher OTN signal rates. The G.709 standard supports 2 types of ODU multiplexer which can be classified as follows: Legacy architecture is based on multi-stage architecture to bring an ...
Page 736 Glossary G.709 Optical Transport Network (OTN) The main attributes of the ODU multiplexer functionality are as follows: The Asynchronous Mapping Procedure (AMP) is used for multiplexing  the tributary signals; this method uses a modified Justification Control mechanism which has 2 positive Justification Control bytes and one negative Justification Control byte.
Page 737 Glossary G.709 Optical Transport Network (OTN) ODUflex ODUflex provides the capability to carry client payload of variable size with a container size of 1.244 Gbit/s granularity. An ODUflex (L) signal can be transported once multiplexed in an ODUk (H) signal, the multiplexer in this case handles tributary slots of 1.244 Gbit/s and has a Payload Type 21.
Page 738 Glossary G.709 Optical Transport Network (OTN) OTN Signal Rates Rate Signal 2.666057143 Gbit/s OTU1 10.709225316 Gbit/s OTU2 11.0491 Gbit/s OTU1e 11.0957 Gbit/s OTU2e 11.2701 Gbit/s OTU1f 11.3176 Gbit/s OTU2f 43.018413559 Gbit/s OTU3 44.571 Gbit/s OTU3e1 44.583 Gbit/s OTU3e2 111.81 OTU4 88000 Series...
Page 739: Generic Framing Procedure (Gfp)
Glossary Generic Framing Procedure (GFP) Generic Framing Procedure (GFP) Generic framing procedure (GFP), defined in ITU recommendation G.7041/Y.1303, is a framing mechanism to transport packet-based client signals, such as Ethernet, Fibre Channel, ESCON, FICON, over fixed-data-rate optical channels. As such, GFP provides a single, flexible mechanism to map these client signals into SONET/SDH and OTN networks, as shown in figure below.
Page 740 Glossary Generic Framing Procedure (GFP) Other methods have focused on using point-to-point protocol (PPP). The IP traffic coming to an Ethernet port is encapsulated over a PPP link and multiple ports can be encapsulated over multilink PPP (ML-PPP) links. By using an HDLC framing, the PPP traffic is transported over the SONET/SDH payload.
Page 741 Glossary Generic Framing Procedure (GFP) GFP Mapping Two types of mapping are currently available for GFP: framed-mapped (GFP-F) and transparent-mapped (GFP-T), whose mappings keep the same basic frame structure, as will be shown in the next sections. The decision on which mode to use is dependent on the underlying service to be transported.
Page 742 Glossary Generic Framing Procedure (GFP) The figure GFP-T vs GFP-F Features below provides a functional comparison between GFP-F and GFP-T, while figure GFP-T vs. GFP-F Frames below provides a comparison of the GFP frames for both modes. GFP-T vs GFP-F Features GFP-T vs.
Page 743 Glossary Generic Framing Procedure (GFP) Functionally, GFP consists of both common and client-specific aspects. Common GFP aspects apply to all GFP-adapted traffic (i.e., both GFP-F and GFP-T) and cover functions such as packet data unit (PDU) delineation, data link synchronization and scrambling, client PDU multiplexing, and client-independent performance monitoring.
Page 744 Glossary Generic Framing Procedure (GFP) The GFP generic frame structure is presented in figure below. GFP Generic Frame Structure Each GFP frame type consists of three main components: the core header, the payload header, and the payload information field. The core and payload headers form the GFP header, whereas the payload information field represents the customer traffic carrying the data services.
Page 745 Glossary Generic Framing Procedure (GFP) Core Header  The GFP core header consists of a two-octet length field, specifying the length of the GFP frame's payload area in octets, and a two-octet field containing a CRC-16 error-check code. Payload Length Indicator (PLI): The PLI is a two-byte field ...
Page 746 Glossary Generic Framing Procedure (GFP) Payload FCS Indicator (PFI): A one-bit subfield indicating the  presence (1) or absence (0) of the payload FCS field. The following table lists the currently defined PFI values. Description FCS Absent FCS Present Extension Header Identifier (EXI): A four-bit subfield identifying ...
Page 747 Glossary Generic Framing Procedure (GFP) Client Data Client Management 0000 0010 Mapped PPP Frame Client Signal Fail (Loss of Character Synchronization) 0000 0011 Transparent Fibre Channel Client Defect Clear Indication (DCI) 0000 0100 Transparent FICON Client Forward Defect Indication (FDI) 0000 0101 Transparent ESCON Client Reverse Defect Indication (RDI)
Page 748 Glossary Generic Framing Procedure (GFP) Type HEC (tHEC) Field: A two-octet field that contains a CRC-16  sequence to protect the integrity of the type field. The tHEC sequence is computed over the core header bytes using standard CRC-16. As with the cHEC, CRC-16 enables both single-bit error correction and multibit error detection.
Page 749 Glossary Generic Framing Procedure (GFP) Payload Information Field  The payload area (also referred to as payload information field) contains the framed client signal. This variable-length field may include from 0 to 65,535 – X octets, where X is the size of the payload header (including the extension header, if present) and the payload FCS field (if present).
Page 750 Glossary Generic Framing Procedure (GFP) GFP Summary GFP has been standardized to better optimize the transport of Ethernet and other data services over SONET, taking into account both the pros and cons of ATM and PPP/HDLC framing mechanisms. As described in this section, GFP represents a robust mapping mechanism that allows for the mapping of multiple client-data types into SONET/SDH payload (SPEs).
Page 751: Mpls Labels
Glossary MPLS Labels MPLS Labels The MPLS labels are listed in the following table. Label Description IPv4 explicit null Router alert IPv6 explicit null Implicit null OAM alert 4 to 13, and 15 Unassigned 16 to 1048575 Label ID Power Blazer...
Page 752: Obsai
Glossary OBSAI OBSAI Overview Traditional mobile installations are bulky (use thick coaxial cables) and require a lot of power to operate (there is a huge power loss in the coaxial cabling which often requires the use of Tower Mounted Amplifiers) as outlined in the following figure.
Page 753 Glossary OBSAI This protocol called Open Base Station Architecture Initiative (OBSAI) separates a traditional radio base station configuration into two separate elements: Base Transceiver Station (BTS) and Remote Radio Head (RRH). The BTS processes the digital baseband radio information and performs the control of the RRH.
Page 754 Glossary OBSAI OBSAI RP3-01 System Architecture OBSAI remotely locates the RRH from the BTS. This means that the RRH must be controlled, managed and synchronized from the BTS in addition to transporting the User information (Voice and user application data) and all that on the same digital link, the RP3-01.
Page 755 Glossary OBSAI OBSAI Protocol Stack The OBSAI RP3 Protocol Stack revolves around the 4 layers: Physical Layer, Data Link Layer, Transport Layer and Application Layer as outlined in the following diagram. Power Blazer...
Page 756 Glossary OBSAI Application Layer: Provides message sampling and mapping based on  payload type (ex: WCDMA/FDD, LTE, GSM/EDGE and 802.16 also known as Wi-Max). Transport Layer: End-to-End delivery message including routing based  on RP3 Address defined in the messages. Data Link Layer: ...
Page 757: Sonet/Dsn/Sdh/Pdh
Glossary SONET/DSn/SDH/PDH SONET/DSn/SDH/PDH SONET/DSn/SDH/PDH Nomenclature The GUI will used the International or European nomenclature based on the SONET and SDH software options installed on the module. Software option Nomenclature SONET only International SDH only European SONET and SDH International Signal Rates SDH/PDH Rate SONET/DSn...
Page 758 Glossary SONET/DSn/SDH/PDH SONET/SDH High and Low Order Path Nomenclature Path Type SONET High Order AU-3 STS-1 AU-4 STS-3c AU-4-4c STS-12c AU-4-16c STS-48c AU-4-64c STS-192c AU-4-256c STS-768c Low Order TUG-3 TUG-2 TU-11 VT1.5 TU-12 TU-3 88000 Series...
Page 759 Glossary SONET/DSn/SDH/PDH SONET/SDH Alarms and Errors Nomenclature Layer SONET Physical BPV/CV Section / Regenerator Section LOF-S RS-LOF RS-OOF TIM-S RS-TIM FAS-S RS-FAS Line / Multiplex Section AIS-L MS-AIS RDI-L MS-RDI REI-L MS-REI High Order Path AIS-P AU-AIS LOP-P AU-LOP H4-LOM H4-LOM PDI-P RDI-P...
Page 760 Glossary SONET/DSn/SDH/PDH Layer SONET Low Order Path AIS-V TU-AIS LOP-V TU-LOP RDI-V LP-RDI ERDI-VCD ERDI-CD ERDI-VPD ERDI-PD ERDI-VSD ERDI-SD RFI-V LP-RFI UNEQ-V LP-UNEQ TIM-V LP-TIM PLM-V LP-PLM BIP-2 BIP-2 REI-V LP-REI 88000 Series...
Page 761 Glossary SONET/DSn/SDH/PDH SONET Numbering Convention The module supports the Timeslot (default) and hierarchical two-level numbering conventions as per GR-253. Hierarchical Notation: The module supports numbering SONET high order path STS-1s and STS-3c using the two-level “STS-3#,STS-1#”convention in an OC-N. For example: STS-1 [2,3].
Page 762 Glossary SONET/DSn/SDH/PDH The module supports numbering SONET low order path using the two-level “VTGroup#,VT#” convention for numbering VTs within an STS-1. For example: VT1.5 [1,3], VT2 [3,2], VT6 [6,1]. The module supports numbering SONET high order path STS-nc within an OC-N using the two-level “STS-3#,STS-1#”.
Page 763 Glossary SONET/DSn/SDH/PDH Naming is as follows for each of the following rates: [E,D,C,B,A] for STM-256  [D,C,B,A] for STM-64  [C,B,A] for STM-16  [B,A] for STM-4  [0] for AU-4 in STM-1  [A] for AU-3 in STM-1  Power Blazer...
Page 764 Glossary SONET/DSn/SDH/PDH The low order paths are defined using a 2 or 3 level convention K,L,M depending on the rate of the AU-4 or AU-3 used to multiplex the low order signals. K: the TUG-3 are numbered 1 to 3 ...
Page 765 Glossary SONET/DSn/SDH/PDH The GUI Grid indicates the TUG-2 [x] and TUG-3 [x] values. Power Blazer...
Page 766 Glossary SONET/DSn/SDH/PDH DSn/PDH Numbering Convention The DS1 numbering in DS3 shall be numbered with respect to the DS2 muxing [DS2,DS1]. For example a DS3 has 7 DS2 and a DS2 has 4 DS1, so an example would be for a DS1 number [3,2]. The DS3 shall have a single number to represent its position.
Page 767: Synce
Glossary SyncE SyncE Synchronous Ethernet or SyncE enables a traceable network timing reference frequency to be distributed node-by-node across a chain of Ethernet devices (SyncE compliant devices only). The network timing reference is typically hierarchically traceable to a Primary Reference Source/Clock (PRS/PRC) in a unidirectional flow.
Page 768 Glossary SyncE In order for an Ethernet interface to be considered Synchronous Ethernet compliant it needs to be upgraded as shown in the following diagram. In addition to supporting the ESMC channel, this upgrade consists in allowing the recovered clock from the CDR to be propagated to a function called the Ethernet Equipment Clock (EEC).
Page 769: Unicast/Multicast Addresses For Ethernet Oam
Glossary Unicast/Multicast Addresses for Ethernet OAM Unicast/Multicast Addresses for Ethernet OAM Unicast or multicast address can be used for most of S-OAM functions. Unicast addresses a unique destination address of the MEP.  Multicast Class 1 addresses all MEPs in the MEG. The address value is ...
Page 770: Vlan Id And Priority
Glossary VLAN ID and Priority VLAN ID and Priority Special VID values (IEEE Std 802.1Q-1998) Description The null VLAN ID. Indicates that the tag header contains only user priority information; no VLAN identifier is present in the frame. This VID value must not be configured as a PVID, configured in any Filtering Database entry, or used in any Management operation.
Page 771: C Remote Toolbox
Remote ToolBox Overview The Remote ToolBox application allows remotely controlling a module installed on a platform using a remote PC. Remote users are connected to the platform using an Ethernet connection. Note: The remote control feature has to be enabled for the module on its specific slot on the platform.
Page 772 Remote ToolBox Overview A remote module application offers the same level of control as if the module is locally controlled with the following behaviors. Multi-user behaviors:  Up to five connections including the local and/or remote sessions are allowed per module. Beyond five connections, the performance to service the connections may decrease.
Page 773: Remote Toolbox Installation
Installation Download the Remote ToolBox application from EXFO STORE at www.exfo.com. Run the Setup.exe application and follow the on-screen instructions to complete the installation. A shortcut of the EXFO Remote ToolBox will be created on the PC desktop. Power Blazer...
Page 774: Starting And Using The Remote Toolbox Application
Starting and Using the Remote ToolBox Application Starting and Using the Remote ToolBox Application Start the Remote ToolBox application, either by using the desktop EXFO Remote ToolBox shortcut, or by clicking on the EXFO Remote ToolBox application from All Programs - EXFO.
Page 775 Remote ToolBox Starting and Using the Remote ToolBox Application Modules Once connected to the platform, lists the modules installed on the platform regardless of the remote control feature being enabled or not. The following information is displayed for each module. Type displays the module’s icon.
Page 776: Applications For
Remote ToolBox Applications for... Applications for... Note: The application icon is only available if the selected module has its Remote Control enabled and is only displayed if the module is supported by the Remote ToolBox application. Click on the icon to start the application. The application is automatically started when the same version of the application is installed on the local PC.
Page 777: Index
Index Index AIS-V ............406 Alarm Timeout/Threshold ......137 10B_ERR ............ 372 Alarm/Status..........565 1588 PTP ........75, 132, 338 Alarms ............546 20 Unframed Logical Lanes ....... 111 Alarms background color ....344, 500 20 Unframed PCS ........124 Alarms/Status and Unassigned ....
Page 778 Index Available BB_Credit ........172 Bit Error Count .......... 469 Average............. 345 Bit Error Rate ..........469 Average RX Rate........459 Bit Error Test..........492 Average TX Rate ........461 Bit-Oriented Message ........ 556 Avg RX Rate ..........487 Block..........360, 365 Avg.
Page 779 Index Cable Test..........74, 145 cHEC-UNCORR ........... 370 Calibration Failed ........621 CID ........181, 424, 582, 584 Cancelled........... 621 CIR........229, 265, 281, 285 Capture button ......... 575 CIR or CIR+EIR Frames....... 163 Capture Source.......... 571 CIR+EIR ..........229, 285 Capture Status ..........
Page 780 Index Connection..........264 Connector ... 109, 121, 127, 128, 129, 149, D1 ............. 593 171, 201, 644 D2 ............. 593 Continuity Check ........271 D3 ............. 593 Continuity Check (Peer MEP) ..... 509 D4 through D12 ........594 Continuous........ 273, 319, 620 DAPI ..........
Page 781 Index Destination Node ID ........551 Dying Gasp ..........498 Destination Port ........219 Dynamic Ramp .......... 169 Details ............433 Detection/Classification ......483 Differentiated Services....... 218 E0 check box ..........295 Direction .. 164, 265, 277, 459, 460, 486, 495, E1 ............
Page 782 FEBE ............354 Excess Steps ..........460 FEC ............ 302, 721 Excessive Skew Test ........492 FEC (RX Only)..........183 EXFO|Worx Interop ........264 FEC-COR-CW..........363 EXI........181, 424, 581, 583 FEC-CORR ..........388 Exit button ..........34 88000 Series...
Page 783 Index FEC-CORR-BIT ..........388 Frame Loss..232, 273, 321, 322, 391, 455, FEC-CORR-CW ........388, 392 463, 464, 487, 494, 503 FEC-CORR-SYMB ........388 Frame Loss / Out-of-Sequence FEC-LOA ............ 392 Stream ..........464 FEC-LOAML ..........392 Frame Loss button ........426 FEC-STRESS-CW .........
Page 784 Index G.8113.1 ........... 267 Global G1 ............. 600 EtherSAM..........165 GAL ............272 RFC 2544 ........252, 253 GCC BERT ..........577 Services ..........277 GCC0............586 Streams..........313 GCC1............589 Global alarm..........32 GCC2............589 Global Copy RX........422, 526 Generate &...
Page 785 Index HP-RDI ............400 Injects ............556 HP-REI ............401 inserting a module ........11 HPTC-IAIS ..........402 Inserting and Removing Transceiver Adaptor HPTC-IEC ........... 404 (TA)..........12 HPTC-LTC........... 402 Interface ..182, 200, 245, 329, 374, 501, 571 HPTC-ODI ..........402 Interface block...........
Page 786 Index I-TAG ............209 Lane............414 ITU G.8275.1 ..........132 Lanes Mapping & Skew ......545 Lanes with Disruption......438, 457 LASER ............25 Laser..........192, 287 J0 .............. 592 Laser OFF at Start-Up..193, 202, 247, 288 J0 Trace ..........191, 537 Laser On ............
Page 787 Index Link Capacity ..........314 Longest Disruption ......438, 457 Link Down ......352, 359, 366, 377 LOOMFI ............. 383 Link Events ..........429 Loop Down..........637 Link Fault........... 498 Loop UP............. 637 Link OAM .......... 198, 497 Loopback... 273, 298, 311, 452, 565, 643 Link Trace ..........
Page 788 Index Maximum ..........345 Maximum OAMPDU Size ......428 M0 ............ 595, 597 Maximum test duration......338 M1 ............ 595, 597 Maximum Window Size......328 MA Name ..........270 MD Level............ 271 MAC ............251 MDIO - Bulk Read ........544 MAC Address......
Page 789 Index Transport Test Applications ....108 Near-End ........... 440 Wireless Test Applications....129 Negative ............ 195 Modify Structure button ......108 Negotiation Status......133, 475 Modify Trib Slots/Channels ......240 Network ............ 220 Modify Trib Slots/Port........ 305 Network block ........... 101 module Network Details .........
Page 790 Index ODU Channels ........... 237 OTU ............717 ODU Multiplexing........723 OTU frame structure ........715 ODU Type ..........242 OTU overhead..........715 ODU0 ............303 OTU1 ............302 ODUflex............. 725 OTU1e ............302 ODUx............378 OTU1f ............302 ODUx-TCM ..........381 OTU2 ............
Page 791 Index Path/Mapping Physical clock port ........106 DSn/PDH BERT........54 Physical Interface OTN BERT......... 44, 45 Electrical ..........289 OTN-SONET/SDH BERT ......48 Optical ..........287 SONET/SDH - DSn/PDH BERT ....56 Physical interface port ....... 105 SONET/SDH BERT ........51 Ping &...
Page 792 Index Power Threshold ........329 QoS Metrics ........321, 391 PRBS15 Invert Pattern........ 577 QoS Metrics Tags Insertion ......314 Preamble/SFD ..........207 QSFP ........17, 18, 20, 147 Precedence ..........217 QSFP Control ..........542 Prefix Mask........215, 224 QSFP Control Pins ........
Page 793 Index REF OUT ........17, 18, 20, 22 Reserved PTI..........424 Reference ..........171 Reset............622 Reference Signal........391 Reset button..........652 REF-FAULT ..........391 Reset Skew ..........548 Refill ............163 Resolve MAC..........270 Refill Delay ..........163 Resolve MAC Address ....210, 216, 251 Refill Delay Ratio ........
Page 794 Index RS.............. 397 RS (J0) ............527 S. & F............504 RS-FAS............398 S1 ............307, 594 RS-FEC ........182, 201, 392 Sa4 ............ 630, 631 RS-FEC (RX Only) ........183 Sa5 ............ 630, 631 RS-LOF............397 Sa6 ............ 630, 631 RS-OOF............
Page 795 Shaping............. 319 Source IP Address ......213, 605 Shaping button ......... 320 Source IP Multiplicator ......216 shipping to EXFO ........672 Source MAC Address ......162, 210 Si0 ............. 630, 631 Source Node ID.......... 551 Si1 ............. 630, 631 Source Port ..........
Page 796 Index Start button ..........657 STS Path (N1)........337, 527 Start Time..330, 467, 474, 477, 479, 485, STS-1 Timeslot ........... 591 488, 491, 493, 497, 499, 501, 502, STS-x............399 505, 508, 513, 516, 519, 521, 641 Subchannel..........187 Stateless Auto ....
Page 797 Index TC-TIM ............337 TC-TIM-P ..........403, 527 T0.............. 562 TC-TIM-V..........403, 527 T0-1............562 TC-UNEQ-P......... 308, 402 T0-2............562 TC-UNEQ-V ........308, 402 T0-3............562 TC-VIOL-P ..........403 Target............636 TC-VIOL-V ..........403 Target RP3 Address ........190 TDEV............418 TC..............
Page 798 Index tHEC ............583 Total Number of Bytes ....... 572 tHEC-CORR ..........370 Total PTP Messages........478 tHEC-UNCORR ........... 371 Total TX Rate ..... 279, 281, 314, 321 Threshold .......... 328, 430 Total TX/RX MPLS ........436 Threshold (% of ideal) ....... 227, 266 Trace Route ..........
Page 799 Index TTI Traces TX Signaling ........295, 628 DAPI ODU-TIM ........335 TX SLM ............456 DAPI OTU-TIM........335 TX to RX ............ 253 DAPI TCM-TIM ........335 TX TST............453 PM ............332 Type....162, 190, 208, 211, 225, 413 SAPI ODU-TIM........
Page 800 Index Wavelength ........192, 287 Window............. 430 V5 ............. 602 Window (KiB) ........496, 506 Val............. 503 Window Size..........518 Valid............425 Window Size Target per Connection..265 Valid Event Count........561 Window Sweep ......... 506, 536 Validations ..........257 Windows Size Unit ........
Page 803 Tel.: 1 978 367-5600 · Fax: 1 978 367-5700 EXFO FINLAND Elektroniikkatie 2 FI-90590 Oulu, FINLAND Tel.: +358 (0) 403 010 300 · Fax: +358 (0) 8 564 5203 TOLL-FREE (USA and Canada) 1 800 663-3936 © 2018 EXFO Inc. All rights reserved. Printed in Canada (2018-05) ...

This manual is also suitable for:

Power blazer 88200nge Power blazer 8880 Power blazer 8870 Power blazer 88400nge Power blazer 88260
