8 Chapter 1: Introduction
Opto Aux I (2)
LVDS Aux In (2)
LVDS Aux Out (1)
TTL Aux I/Os (3)
Opto Aux I (2)
LVDS Aux In (2)
LVDS Aux Out (1)
TTL Aux I/Os (3)
Opto Aux I (2)
LVDS Aux In (2)
LVDS Aux Out (1)
TTL Aux I/Os (3)
Opto Aux I (2)
LVDS Aux In (2)
LVDS Aux Out (1)
TTL Aux I/Os (3)
* CXP-12 model / CXP-6 model
I/O data /

Matrox Rapixo CXP board

Matrox Rapixo CXP is a family of high-performance PCIe frame grabbers that
support image capture from high-resolution and high-speed video sources using
the CoaXPress (CXP) communication standard. There are two models of the
Matrox Rapixo CXP: Matrox Rapixo CXP base model, and Matrox Rapixo CXP
Pro. There are two versions of the base model: Quad CXP-6 and Quad CXP-12,
and one version of the Pro model: Pro Quad CXP-12. The Pro model of the board
also comes with FPGA-based processing-offload capabilities (a Processing FPGA).
Power-over
12 V
Coa XP ress
24V
24 V
12.5 / 6.25 Gbits/s*
41.66 / 20.83 Mbits/s*
n
Auxiliary I/O
interface
n
Auxiliary I/O
interface
n
Auxiliary I/O
interface
n
Auxiliary I/O
interface
Image data
Internal auxiliary 12 V
power connector
Coa XP ress
interface
Coa XP ress
interface
Coa XP ress
interface
Coa XP ress
interface
GPIO
controller
supplemental
Host x8 PCI
Matrox Rapixo CXP
Base Model
On-board memory
( DDR SDRAM 4
4 GB
LUTs
Memory
Controller
Host Interface
Color space
converter &
pixel formatter
Bayer decoder
DMA Write
MIL License
Fingerprint
and
MIL license
storage
e 3.1/2 1 bus .
)
19.2/14.9 GB /s *
8/4 GB /s *
8/4 GB /s *
full duplex
