- Page 1 MSS Tilt & Recline Item # MS 3000N EU Authorized Representative Drive Medical LTD Ainley’s Industrial Estate Elland, West Yorkshire, United Kingdom HX5 9JP...
- Page 2 6. Insert footrest assembly (D) into bracket (F) under the seat of the chair assembly: and tighten knob (Y). 7. Mount footrests rods (E) onto vertical section of footrest assembly. 1. Remove all positioning components from box. Mount left side first. 2.
-
Page 3: Seat Width
SEAT TO BACK ANGLE AND SEAT DEPTH adjustments: Loosen bolts (A) and position back at desired depth. Place seat to back angle at desired setting. TILT POSITION Open knob (N) and pull back securing bracket (O). Press tilt actuator (P) and press down of both push handles (Q) to desired tilt angle. Return securing bracket (O) and tighten knob (N). -
Page 4: Back Height
BACK HEIGHT FOOTRESTS Back height can be adjusted by Height - Loosen knob (W) and raise or lower bracket. loosening knobs (U) and raising or Angle – Loosen knob (X). lowering back. Position • Lateral position of foot sandals on rod can be achieved by LATERALS loosening knob (X). Laterals can be adjusted in • Depth position of foot sandals on rod can be achieved by loosening height and width. - Page 5 ACCESSORIES If you have a question about your Drive device or this war- BASE ranty, please contact an authorized Drive dealer. MS 0014N - High base MS 0015N - Low base Mount chair onto either base.
