ABS Warning Lamp

The lamp turns on when the key is in the
"ON" position.
If the lamp turns on during operation of
the vehicle, it means that there' s some
problem in the ABS system.
OM-B374
REFERENCE
Regular brakes function perfectly even when the warning
lamp is turned on during the operation of the vehicle.

ASR System Warning Lamp

The lamp turns on when the key is in the
"ON" position.
Applicable only to the vehicle equipped
with ASR system. The lamp turns on
upon activation of ASR.
OM-B419
The lamp turns on during the initial start of the engine, and
turns off upon application of the brake pedal.
REFERENCE
ASR makes it possible for the vehicle to escape from a
situation in which one wheel of the driving wheels has
slipped (on ice or sand) and the driver is having difficulties
in moving the vehicle due to the wheels skidding, by fixing
only one side of the wheels.

Engine Aftertreatment Warning Lamp (Red)

●
The indication is on when SCR
(Aftertreatment) malfunctions. The
indication is on when urea tank capacity
falls down to 10%.
OM-B344
Refill urea and if the indication is still on, visit the nearest
service center.
ISM Engine
●
The indication is on when there is a problem with the
engine system.
You must visit the nearest service center if the indication is
on.
WARNING
If you continue to drive with lower than 5% urea capacity, it
may result in reduced power and damaged aftertreatment
parts.

Tail Lamp Activation Indicator Lamp

The lamp turns on when the tail lamp is
activated.
OM-B352
3-33
DEVICE CONTROL TIPS
EURO IV Engine (DL06,DL08,DV11)
