- Page 1 Installation and Operating Manual ebios fire - Elipse & Quadra models incl. Mini series GB 1...
- Page 2 PREFACE / QUALITY PHILOSOPHY You have decided in favour of a Spartherm ebios-fire - thank you for your confidence in our company. In a world of excess and mass production, our company stands for the values expressed by our owner, Gerhard Manfred Rokossa: „High technical quality combined with contemporary design and service to the...
-
Page 3: Table Of Contents
CONTENTS 1. General information 5 Maintenance/troubleshooting 1.1 Scope of Delivery 5.1 Furniture and glass (depending on the design) becomes sooted heavily, rapidly and unevenly 2. Installation instructions 5.2 Fire is difficult to ignite 2.2 CERAMAT FN burner fleece 5.3 Unpleasant odours 2.3 Basic requirements for installation 5.4 Appearance of flames changes 2.4 Installation site... -
Page 4: General Information
IMPORTANT INFORMATION 1. GENERAL INFORMATION As per the German Equipment and Product Safety Act (GPSG) and our Small children, elderly or infirm persons: as is the case with all open flames, statutory duty to notify, we would like to inform you about heating with this it is expedient that you attach a protective fixture for these groups of persons product. -
Page 5: Scope Of Delivery
Only allow the device to be refilled by individuals who are familiar with the safety instructions and who you have trained on its operation. The ebios-fire is not a heater but a decorative fire. Bioethanol is a dangerous substance and must only be stored in the pre- scribed quantities as per the regulations: Storage in a cellar: max. - Page 6 2.1 TECHNICAL DATA An overview of the models: ebios-fire Model Elipse Base Elipse Wall Elipse Wall Mini Bioethanol Fuel type: (ethanol content 96%) Positioning Floor Wall Wall Filling quantity (depending on model): 1.2 - 2.6 l Number of burners Fuel consumption: 0.4- 0.5 l/hr Width in mm Burning duration (depending on the model):...
-
Page 7: Ceramat Fn Burner Fleece
2.2 CERAMAT FN BURNER FLEECE • Transport aids (if necessary), special hand trucks must only be loaded with the rear of the ebios-fire facing down. The CERAMAT FN burner fleece (black) included should only be touched • There must be no fuel in the tank during transportation. when wearing gloves as there is otherwise a risk of skin irritations. -
Page 8: Installation / Assembly
• In areas which are not protected against transverse ventilation • On tables, pieces of furniture, shelves etc. • In entrance areas of hotel lobbies, bars, restaurants etc. where higher air change rates can be expected. (draught) 2.5 INSTALLATION / ASSEMBLY The ebios-fire model, whether as a floor- or wall-mounted version, must be aligned horizontally and protected from tilting. -
Page 9: Installation And Assembly - Quadra And Elipse Models
2.5.1 INSTALLATION AND ASSEMBLY - 2.6 FIRE PROTECTION QUADRA AND ELIPSE MODELS In order to guarantee sufficient thermal insulation, there must be a mini- Close the furniture housing cover of the device. Please ensure correct posi- mum distance of 300 mm (see Fig. 4) to flammable components, furniture, tioning so that there is a uniform (depending on the model see Fig. -
Page 10: Operating Manual
3. OPERATING MANUAL • With all models (Elipse and Quadra), ensure that the housing covers are closed and that the protective panes are inserted. Read these installation and operating instructions carefully before installing • It is recommended to open a window during operation. and starting up your ebios-fire. -
Page 11: Fire Protection
3.3 FUEL • The handling of fuel in the vicinity of the hot or burning device is associ- ated with significant risks and is not permitted! • Only fill the burner via the filling opening and never via the burner chan- Bioethanol (chemical formula C O) with an ethanol content of 96.6% is nel! (see Fig. -
Page 12: Startup Of The Models Elipse And Quadra
3.4 STARTUP 3.4.1 STARTUP OF THE MODELS ELIPSE AND QUADRA The ebios-fire devices are supplied with empty burners to prevent any ethanol from flowing out or evaporating during transit. Ensure (particularly Proceed as follows: before being put into use) that there is no fuel in the safety container. 1. - Page 13 8. The fill level indicator shows the maximum permitted fill level. The maxi- 11. Close the housing cover on the device and ensure that the cover does mum fill level is achieved once the red fill level ball floats to the top. not extend into the flame area and instead maintains a uniform distance from the burner channel (depending on model, refer to Fig.
-
Page 14: Refilling The Burner
16. Ignite the fire on the side of the burner mat and step back from the Proceed as follows to refill: flames. It may take a few minutes until uniform flames appear. 1. Ensure that the air supply is sufficient. (see 2.7) 2. -
Page 15: Taking Out Of Operation Safely
4. CLEANING AND CARE 8. The fill level indicator shows the maximum permitted fill level.The maxi- mum fill level is reached when the bioethanol runs out of the slit (see arrow) into the reflector curve. The ebios-fire furniture may only be cleaned when cold. 4.1 CLEANING CLADDING PARTS •... -
Page 16: Maintenance/Troubleshooting
5 MAINTENANCE/TROUBLESHOOTING 5.3 UNPLEASANT ODOURS • The wick and burner fleece must be visually inspected at regular inter- • Fuel in a burner which is not in use? (see 3.1) vals. The material can be easily damaged. As such, the burner fleece •... -
Page 17: General Warranty Conditions
They are not congruent with the contractual and warranty claim. Spartherm Feuerungstechnik GmbH is not obliged to satisfy any claim terms which the dealer/distributor offers his customers in individual cases. -
Page 18: Elimination Of Defects / Repair
Damages and claims for compensation which are not the result of deliv- over the terms of this warranty, all necessary repair works resulting from ery of a defective appliance from Spartherm Feuerungstechnik GmbH are material or manufacturing defect shall be carried out free-of-charge in the excluded and are not part of this warranty promise. - Page 19 NOTES GB 19...
- Page 20 IT Il vostro rivenditore specializzato | E Sus comercios especializados NL Uw vakhandelaar | PL Państwa sprzedawca | РУС Ваш дилер SPARTHERM Feuerungstechnik GmbH · Maschweg 38 · D-49324 Melle Phone +49 (0) 5422 94 41-0 · Fax +49 (0) 5422 9441-14 · www.spartherm.com GB 20...
