- Page 1 Installation and Operation Manual Doorphone (réf. 34817) v1.1.2 160310...
- Page 2 INTRODUCTION Read carefully this instruction manual before using the device We would like to thank you for using this product. This kit contains an LCD monitor and an outdoor camera. Their installation and maintenance are simple. 1. inside unit 1.Antenna 9.Intercom LED 2.Screen 10.Unlock button...
-
Page 3: Installation
3. LED indicator Intercom LED: under the intercom status, the LED will light Monitor LED: under the monitor status, the LED will display red and yellow lights Charging the LED display red light, charged the LED display green lights INSTALLATION 1. -
Page 4: Wiring Diagram
Installation Exten sion cable DC Power (excluded) 2 wire Lock Outdoor-camera (excluded) Power When mounting the outdoor-camera, ensure that it is located in dry place. It is important that the camera or the electronics do not get wet. The outdoor-camera should ideally be mounted at a height of between 1.45-1.50 meters. -
Page 5: Match Code
Notice : When the outdoor unit is mounted on the thicker wall where effects the signal, please extend the build-in Antenna of outdoor unit with Extend antenna. Match code 1. Under the monitor status, Press button about 3 seconds then will pop up interface 2. -
Page 6: Specification
3. Press the button to adjust, 4. Press the button to confirm and exit, 7. Intercom: When a visitor presses the call button of outdoor-camera, the indoor-monitor will give a bell tone and activate the monitor screen. The indoor-monitor screen will display a picture of the visitor automatically. -
Page 7: Indoor- Monitor
Warranty A CHACON declara que o aparelho 34888 está em conformidade com as exigências essenciais e as outras disposições pertinentes da diretiva To activate your warranty, please fill in the online form at www.chacon.be/warranty EN61000-3-2:2006+A2:2009;...
