Yealink T58V Solution Manual

Smart media phone with algo video intercoms application note
Hide thumbs Also See for T58V:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Administrator's Manual, Configuration Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T58V and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Yealink T58V

Summary of Contents for Yealink T58V

  • Page 2: Table Of Contents

    Introduction ..............................3 Before You Begin ............................3 Get Help ................................ 3 Scenario................................. 4 Configuring Yealink T58V .......................... 4 Configuring Algo 8061 IP Relay Controller ....................5 Configuring Algo 8039 SIP Video Intercom ....................6 Configuring 8036 SIP Multimedia Intercom ....................8...

  • Page 3: Introduction

    Introduction This guide outlines the configuration required to set up a video call to/from Yealink T58V Smart Media phone to the Algo 8036 SIP Multimedia Intercom or 8039 SIP Video Intercom. Also covered are instructions to step up the optional Algo 8061 IP Relay Controller, where the telephone keypad can activate a relay for releasing a locked door/gate during an intercom call.

  • Page 4: Scenario

    Scenario This example shows how to configure the 8036 and/or 8039 for one-way video communication with Yealink T58V Smart Media Phone. Configuring the 8061 IP Relay Controller for door control is also covered. Configuring Yealink T58V 1) To view the phone's IP address, navigate to the Settings menu on the phone, under Status, click General 2) To access the configuration panel, open an empty web browser, enter the device’s IP...

  • Page 5: Configuring Algo 8061 Ip Relay Controller

    Configuring Algo 8061 IP Relay Controller 1) To configure the 8061, open an empty web browser, enter the device’s IP address in the address field, and press Enter 2) To find the device’s IP address, please refer to the user guide available at: http://www.algosolutions.com/8061/guide 3) In the web interface, enter the password to log in (default password is algo) 4) There is no need to do a separate SIP Server registration, in this scenario.

  • Page 6: Configuring Algo 8039 Sip Video Intercom

    6) It is recommended to have a Static IP Address assigned to this device, as it will need to be entered on the 8036 and/or 8039. Save the changes Configuring Algo 8039 SIP Video Intercom 1) To configure the 8039, open an empty web browser, enter the device’s IP address in the address field, and press Enter 2) To find the device’s IP address, please refer to the user guide available at: http://www.algosolutions.com/8039/guide...
  • Page 7 5) Navigate to Basic Settings tab, then Door Control tab. Enter the IP address ( Network Door ) and password ( ) assigned to the 8061 Controller Address Network Door Controller Password previously. Save the changes 2018-02-14...

  • Page 8: Configuring 8036 Sip Multimedia Intercom

    Configuring 8036 SIP Multimedia Intercom Note: Two-way video is not supported on the current firmware release. 1) To configure the 8036, open an empty web browser, enter the device’s IP address in the address field, and press Enter 2) To find the device’s IP address, please refer to the user guide available at: http://www.algosolutions.com/8036docs 3) In the web interface, enter the password to log in (default password is algo) 4) Click on Basic Settings tab and then SIP tab.
  • Page 9 6) To configure the user interface, buttons, and functions, please see the Quick Start guide available at: www.algosolutions.com/8036docs 2018-02-14...
